Stanley Ds12 User manual

DS12

HYDRAULIC

UTILITY SAW

SAFETY, OPERATION AND MAINTENANCE

USER’S MANUAL

71069 11/2009 Ver 2

Read the Manual Wear your PPE

TABLE OF CONTENTS

Safety Symbols and Precautions .......................................................................................................4

Tool Stickers and Tags........................................................................................................................7

Hydraulic Hose Requirements............................................................................................................8

HTMARequirements........................................................................................................................10

Operation .........................................................................................................................................11

Tool Equipment and Care.................................................................................................................15

Troubleshooting................................................................................................................................16

Speciﬁcations...................................................................................................................................18

Accessories......................................................................................................................................18

Parts Illustration................................................................................................................................19

Parts List .........................................................................................................................................20

Utility Saw Clamp Instruction Sheet.................................................................................................21

Warranty...........................................................................................................................................22

For the nearest authorized and certiﬁed dealer, call Stanley Hydraulic Tools at the number listed on the

back of this manual and ask for a Customer Service Representative.

SERVICING THE STANLEY UTILITY CHAINSAW: This manual contains safety, operation, and routine

maintenance instructions. Stanley Hydraulic Tools recommends that servicing of hydraulic tools, other

than routine maintenance, must be performed by an authorized and certiﬁed dealer. Please read the fol-

lowing warning.

SERIOUS INJURY OR DEATH COULD RESULT FROM THE IM-

PROPER REPAIR OR SERVICE OF THIS TOOL.

REPAIRS AND / OR SERVICE TO THIS TOOL MUST ONLY BE

DONE BY AN AUTHORIZED AND CERTIFIED DEALER.

CERTIFICATE OF CONFORMITY

ÜBEREINSTIMMUNGS-ZERTIFIKAT

CERTIFICAT DE CONFORMITE CEE

CERTIFICADO DE CONFORMIDAD

CERTIFICATO DI CONFORMITA

Hydraulic Tools

______________________________________________________________________

I, the undersigned:

Ich, der Unterzeichnende:

Je soussigné:

El abajo firmante:

lo sottoscritto:

Piert, Charlie

Surname and First names/Familiennname und Vornamen/Nom et prénom/Nombre y apellido/Cognome e nome

hereby certify that the construction plant or equipment specified hereunder:

bestätige hiermit, daß das im folgenden genannten Werk oder Gerät:

certifies par ceci que l’ usine ou l’ équipement de construction indiqué cidessous:

por el presente certifico que la fabrica o el equipo especificado a continuacion:

certifico che l’impianto o l’attrezzatura sotto specificata:

1. Category: Utility Chain Saw

Kategorie:

Catégorie:

Categoria:

2. Make/Ausführung/Marque/Marca/Marca

Stanley

3. Type/Typ/Type/Tipo/Tipo: DS1231801

4. Serial number of equipment:

Seriennummer des Geräts:

Numéro de série de l’équipement:

Numero de serie del equipo:

Matricola dell´attrezzatura: All

5. Year of manufacture/Baujahr/année de fabrication/Año de fabricacion/Anno di fabbricazione Beginning 2009

Has been manufactured in conformity with - EEC Type examination as shown.

Wurde hergestellt in Übereinstimmung mit - EEC Typ-Prüfung nach.

Est fabriqué conformément - au(x) type(s) examiné(s) comme indiqué dans le tableau ci-après.

Ha sido fabricado de acuerdo con - tipo examen EEC como dice.

E’ stata costruita in conformitá con - le norme CEE come illustrato.

Examen CEE de type

Directive

Richtlinie

Directives particulières

Directriz

Direttiva

No.

Numéro

Date

Datum

Date

Fecha

Data

Approved body

Prüfung durch

Organisme agréé

Aprobado

Collaudato

Date of expiry

Ablaufdatum

Date d´expiration

Fecha de caducidad

Data di scadenza

Machinery Directive

ISO

98/37/EC

ISO 12100-1

ISO 12100-2

8662-1

3744

10726

1998

2007

2006

1988

1994

1992

Self

6. Special Provisions: None

Spezielle Bestimmungen:

Dispositions particulières:

Provisiones especiales:

Disposizioni speciali:

7. Representative in the Union: Stanley Dubuis 17-19, rue Jules Berthonneau-BP 3406 41034 Blois Cedex, France.

Done at/Ort/Fait à/Dado en/Fatto a Stanley Hydraulic Tools, Milwaukie, Oregon USA Date/Datum/le/Fecha/Data 10/22/2009

Signature/Unterschrift/Signature/Firma/Firma____________________________________________________________________________

Position/Position/Fonction/Puesto/Posizione Quality Assurance Manager rev01 11/09

CERTIFICATE OF CONFORMITY

Safety symbols and signal words, as shown below, are used to emphasize all operator, maintenance and repair actions

which, if not strictly followed, could result in a life-threatening situation, bodily injury or damage to equipment.

This safety alert and signal word indicate an imminently hazardous situa-

tion which, if not avoided, will result in death or serious injury.

Always observe safety symbols. They are included for your safety and for the protection of the tool.

LOCAL SAFETY REGULATIONS

Enter any local safety regulations here. Keep these instructions in an area accessible to the operator and mainte-

nance personnel.

CAUTION

WARNING

DANGER

NOTICE

CAUTION

This is the safety alert symbol. It is used to alert you to potential personal

injury hazards. Obey all safety messages that follow this symbol to avoid

possible injury or death.

This safety alert and signal word indicate a potentially hazardous situation

which, if not avoided, could result in death or serious injury.

This safety alert and signal word indicate a potentially hazardous situation

which, if not avoided, may result in minor or moderate injury.

This signal word indicates a potentially hazardous situation which, if not

avoided, may result in property damage.

This signal word indicates a situation which, if not avoided, will result in

damage to the equipment.

This signal word indicates a situation which, if not avoided, may result in

damage to the equipment.

IMPORTANT

SAFETY SYMBOLS

Tool operators and maintenance personnel must always comply with the safety precautions given in this

manual and on the stickers and tags attached to the tool and hose.

These safety precautions are given for your safety. Review them carefully before operating the tool and

before performing general maintenance or repairs.

Supervising personnel should develop additional precautions relating to the speciﬁc work area and local

safety regulations. If so, place the added precautions in the space provided on page 4.

This tool will provide safe and dependable service if operated in accordance with the instructions given in this

manual. Read and understand this manual and any stickers and tags attached to the tool and hoses before

operation. Failure to do so could result in personal injury or equipment damage.

• Establish a training program for all operators to ensure safe operation.

• The operator must be familiar with all prohibited work areas such as excessive slopes and dangerous terrain conditions.

• Do not operate the chain saw unless thoroughly trained or under the supervision of an instructor.

• Always wear safety equipment such as goggles, ear protection, breathing protection, head protection, leg protection, gloves, snug ﬁtting clothing

(do not operate the saw when wearing loose clothing) and safety shoes at all times when operating the chain saw.

• Do not overreach or cut above shoulder height. Maintain proper footing and balance at all times.

• Do not inspect or clean the chain saw while the hydraulic power source is connected.Accidental engagement of the chain saw can cause serious

injury.

• Always connect hoses to the chain saw hose couplers before energizing the hydraulic power source. Make sure all hose connections are tight.

• Do not operate the chain saw at ﬂuid temperatures above 140°F/60°C. Operation at higher temperatures can cause higher than normal tempera-

tures at the chain saw which can result in operator discomfort.

• Do not rely exclusively upon the safety devices built into the chain saw.As a chain saw user, several steps must be taken to keep your cutting

jobs free from accident or injury:

1. With a basic understanding of kickbacks, you can reduce or eliminate the element of surprise. Sudden surprise contributes to accidents.

2. Keep a good ﬁrm grip on the chain saw with both hands, the right hand on the rear handle and the left hand on the front handle when

operating the chain saw. Use a ﬁrm grip with thumbs and ﬁngers encircling the chain saw handles.A ﬁrm grip helps reduce kickbacks and

maintains control of the chain saw. Do not let go.

3. Make sure the area in which you are cutting is free of obstructions.

4. Cut at rated operating speeds (gpm).

5. Do not overreach or cut above shoulder height.

6. Only use replacement bars and chains speciﬁed by Stanley or the equivalent.

• Make sure the chain guard is in place before operating the chain saw.

• Remove or control the water slurry to prevent yourself or others from slipping while cutting.

• Provide adequate ventilation in closed areas when operating a gas or diesel hydraulic power source.

To avoid serious injury or death

SAFETY PRECAUTIONS

• Always be well rested and mentally alert before operating the chain saw.

• Do not allow bystanders near the chain saw when starting or cutting.

• Do not start cutting until you have a clear work area and secure footing.

• Keep all parts of the body away from the chain saw during operation.

• Carry the chain saw with the tool de energized and the bar and chain to the rear of your body.

• Do not operate a chain saw that is damaged, improperly adjusted, or not completely and securely assembled. Make sure the chain stops moving

when the control trigger is released.

• Keep the handle dry, clean and free of hydraulic ﬂuid.

• Do not use the chain saw near energized transmission lines.

• Turn off the power source or move the hydraulic control valve to neutral before setting the chain saw down.

• Use a guide bar scabbard when transporting the chain saw.

• Know the location of buried or covered electrical services before starting work.

• To avoid personal injury or equipment damage, all chain saw repair, maintenance and service must only be performed by authorized and prop-

erly trained personnel.

• Make sure the chain breaker and rivet spinner are securely mounted on ﬂat, clean work surfaces. Check the mounting screws/bolts often.

• Check all chain breaker and rivet spinner components regularly for wear and general condition.

• Provide adequate lighting when operating the saw in a darkened area or at night.

• Always keep critical tool markings, such as labels and warning stickers legible.Always replace stickers or decals that have become worn or dam-

aged.

• Be observant of hydraulic and water hoses that lay about the work area, especially in trenches where they can be hidden from view due to liquids

that have accumulated within the space.

• Keep all parts of the body away from the cleats that are attached to the saw, as these are sharp and can be a puncture hazard.

• Improper handling, use, or maintenance can result in an oil leak or burst. Do not contact an oil leak as high pressure oil can cause injection into

the body.

• Never stand in the path of the discharge, ejection of material from the work piece can cause personal injury.

• Never use the saw in a potentially explosive atmosphere.

SAFETY PRECAUTIONS

WARNING

Exposure to crystalline Silica (sometimes called “silica dust”) as a result of

cutting, breaking, drilling, or hammering of rock, concrete, asphalt or other

materials may cause Silicosis (a serious lung disease), silicosis-related ill-

nesses, cancer, or death.

Respiratory protection is highly recommended when working with materials

containing Silica Dust.

Always wear a respirator approved for protection against crystalline silica.

The safety tag (p/n 15875) at

right is attached to the tool

when shipped from the factory.

Read and understand the safety

instructions listed on this tag

before removal. We suggest

you retain this tag and attach it

to the tool when not in use.

12412

Warning Decal

IMPORTANT

READ OPERATION MANUAL AND

SAFETY INSTRUCTIONS FOR THIS

TOOL BEFORE USING IT.

USE ONLY PARTS AND REPAIR

PROCEDURES APPROVED BY

STANLEY AND DESCRIBED IN THE OPERA-

TION MANUAL.

TAG TO BE REMOVED ONLY BY

TOOL OPERATOR.

SEE OTHER SIDE

1. FAILURE TO USE HYDRAULIC HOSE LABELED AND CERTIFIED AS

NON-CONDUCTIVE WHEN USING HYDRAULIC TOOLS ON OR NEAR

ELECTRICAL LINES MAY RESULT IN DEATH OR SERIOUS INJURY.

BEFORE USING HOSE LABELED AND CERTIFIED AS NON-

CONDUCTIVE ON OR NEAR ELECTRIC LINES BE SURE THE HOSE

IS MAINTAINED AS NON-CONDUCTIVE. THE HOSE SHOULD BE

REGULARLYTESTEDFORELECTRICCURRENTLEAKAGEINACCORDANCE

WITH YOUR SAFETY DEPARTMENT INSTRUCTIONS.

2. A HYDRAULIC LEAK OR BURST MAY CAUSE OIL INJECTION INTO THE

BODY OR CAUSE OTHER SEVERE PERSONAL INJURY.

A DO NOT EXCEED SPECIFIED FLOW AND PRESSURE FOR

THIS TOOL. EXCESS FLOW OR PRESSURE MAY CAUSEA

LEAK OR BURST.

B DO NOT EXCEED RATED WORKING PRESSURE OF HYDRAU

LIC HOSE USED WITH THIS TOOL. EXCESS PRESSURE MAY

CAUSE ALEAK OR BURST.

C CHECKTOOL HOSE COUPLERSAND CONNECTORS DAILY

FOR LEAKS. DO NOT FEEL FOR LEAKS WITH YOUR HANDS.

CONTACT WITHA LEAK MAYRESULT IN SEVERE PERSONAL

INJURY.

IMPORTANT

READ OPERATION MANUAL AND

SAFETY INSTRUCTIONS FOR THIS

TOOL BEFORE USING IT.

USE ONLY PARTS AND REPAIR

PROCEDURES APPROVED BY

STANLEY AND DESCRIBED IN THE OPERA-

TION MANUAL.

TAG TO BE REMOVED ONLY BY

TOOL OPERATOR.

SEE OTHER SIDE

D DONOT LIFT OR CARRYTOOL BY THE HOSES. DO NOTABUSE HOSE.

DO NOT USE KINKED, TORN OR DAMAGED HOSE.

3. MAKE SURE HYDRAULIC HOSES ARE PROPERLY CONNECTED TO THE

TOOLBEFOREPRESSURINGSYSTEM. SYSTEM PRESSUREHOSEMUST

ALWAYS BE CONNECTED TO TOOL “IN” PORT. SYSTEM RETURN HOSE

MUSTALWAYS BE CONNECTEDTOTOOL“OUT”PORT. REVERSING CON-

NECTIONSMAYCAUSEREVERSETOOLOPERATIONWHICH CAN RESULT

IN SEVERE PERSONAL INJURY.

4. DONOTCONNECTOPEN-CENTERTOOLSTOCLOSED-CENTER HYDRAULIC

SYSTEMS. THISMAYRESULTINLOSSOFOTHERHYDRAULICFUNCTIONS

5. BYSTANDERSMAYBE INJURED INYOURWORKAREA. KEEPBYSTANDERS

CLEAR OF YOUR WORK AREA.

6. WEAR HEARING, EYE, FOOT, HANDAND HEAD PROTECTION.

7. TO AVOID PERSONAL INJURY OR EQUIPMENTDAMAGE,ALL TOOL REPAIR

MAINTENANCE AND SERVICE MUST ONLY BE PERFORMED BY AUTHO-

RIZED AND PROPERLY TRAINED PERSONNEL.

(shown smaller then actual size)

SAFETY TAG P/N 15875

71071

Name Tag Decal

28409

Composit Decal

Failure to use hydraulic hose labeled and certifiedFailure to use hydraulic hose labeled and certified

as non-conductive when using hydraulic tools onas non-conductive when using hydraulic tools on

or near electric lines may result in death oror near electric lines may result in death or

For proper and safe operation read owners manualFor proper and safe operation read owners manual

and mwke sure that you have been properlyand mwke sure that you have been properly

trained in correct procedures required for worktrained in correct procedures required for work

serious injury.serious injury.

on or around electric lines.on or around electric lines.

ELECTROCUTION

HAZARD

DANGER

12412

28409

71071 Name Tag

To avoid serious injury or death

TOOL STICKERS & TAGS

Always keep critical tool markings, such as labels and

warning stickers legible.Always replace stickers or decals

that have become worn or damaged.

71073 CE Tool Plate

11207

LWA

11212

HOSE TYPES

The rated working pressure of the hydraulic hose must be equal to or higher than the relief valve setting on the

hydraulic system. There are three types of hydraulic hose that meet this requirement and are authorized for use

with Stanley Hydraulic Tools. They are:

Certiﬁed non-conductive - constructed of thermoplastic or synthetic rubber inner tube, synthetic ﬁber

braid reinforcement, and weather resistant thermoplastic or synthetic rubber cover. Hose labeled certiﬁed non-

conductive is the only hose authorized for use near electrical conductors.

Wire-braided (conductive) - constructed of synthetic rubber inner tube, single or double wire braid rein-

forcement, and weather resistant synthetic rubber cover. This hose is conductive and must never be used near

electrical conductors.

Fabric-braided (not certiﬁed or labeled non-conductive) - constructed of thermoplastic or synthetic rubber

inner tube, synthetic ﬁber braid reinforcement, and weather resistant thermoplastic or synthetic rubber cover. This

hose is not certiﬁed non-conductive and must never be used near electrical conductors.

HOSE SAFETY TAGS

To help ensure your safety, the following DANGER tags are attached to all hose purchased from Stanley Hydrau-

lic Tools. DO NOT REMOVE THESE TAGS.

If the information on a tag is illegible because of wear or damage, replace the tag immediately. A new tag may be

obtained from your Stanley Distributor.

THE TAG SHOWN BELOW IS ATTACHED TO “CERTIFIED NON-CONDUCTIVE” HOSE

THE TAG SHOWN BELOW IS ATTACHED TO “CONDUCTIVE” HOSE.

SIDE 1 SIDE 2

D A N G E R

DO NOT REMOVE THIS TAG

D A N G E R

1 FAILURE TO USE HYDRAULIC HOSE LABELEDAND CERTIFIED AS NON-CONDUCTIVE

WHEN USING HYDRAULIC TOOLS ON OR NEAR ELECTRIC LINES MAY RESULT IN DEATH

OR SERIOUS INJURY.

FOR PROPER AND SAFE OPERATION MAKE SURE THAT YOU HAVE BEEN PROPERLY

TRAINED IN CORRECT PROCEDURES REQUIRED FOR WORK ON ORAROUND

ELECTRIC LINES.

2. BEFORE USING HYDRAULIC HOSE LABELED AND CERTIFIED AS NON-CONDUCTIVE ON

OR NEAR ELECTRIC LINES. WIPE THE ENTIRE LENGTH OF THE HOSEAND FITTING

WITH ACLEAN DRYABSORBENT CLOTH TO REMOVE DIRTAND MOSISTUREAND TEST

HOSE FOR MAXIMUM ALLOWABLE CURRENT LEAKAGE IN ACCORDANCE WITH SAFETY

DEPARTMENT INSTRUCTIONS.

DO NOT REMOVE THIS TAG

3. DO NOT EXCEED HOSE WORKING PRESSURE OR ABUSE HOSE. IMPROPER USE OR

HANDLING OF HOSE COULD RESULT IN BURST OR OTHER HOSE FAILURE. KEEP

HOSE AS FAR AWAY AS POSSIBLE FROM BODYAND DO NOT PERMIT DIRECT CONTACT

DURING USE. CONTACT AT THE BURST CAN CAUSE BODILY INJECTION AND SEVERE

PERSONAL INJURY.

4. HANDLE AND ROUTE HOSE CAREFULLY TOAVOID KINKING, ABRASION, CUTTING, OR

CONTACT WITH HIGH TEMPERATURE SURFACES. DO NOT USE IF KINKED. DO NOT USE

HOSE TO PULLOR LIFT TOOLS, POWER UNITS, ETC.

5. CHECK ENTIRE HOSE FOR CUTS CRACKS LEAKS ABRASIONS, BULGES, OR DAMAGETO

COUPLINGS IF ANYOF THESE CONDITIONS EXIST, REPLACE THE HOSE IMMEDIATELY.

NEVER USE TAPE OR ANY DEVICE TO ATTEMPT TO MEND THE HOSE.

6. AFTER EACH USE STORE IN ACLEAN DRYAREA.

3(shown smaller than actual size)

(shown smaller than actual size)

D A N G E R

DO NOT REMOVE THIS TAG

D A N G E R

1 DO NOT USETHIS HYDRAULIC HOSE ON OR NEAR ELECTRIC LINES. THIS HOSE IS

NOT LABELED OR CERTIFIEDAS NON-CONDUCTIVE. USING THIS HOSE ON OR NEAR

ELECTRICAL LINES MAY RESULT IN DEATH OR SERIOUS INJURY.

2. FOR PROPERAND SAFE OPERATION MAKE SURE THATYOU HAVE BEEN PROPERLY

TRAINED IN CORRECT PROCEDURES REQUIRED FOR WORK ON ORAROUND

ELECTRIC LINES.

3. DO NOT EXCEED HOSE WORKING PRESSURE OR ABUSE HOSE. IMPROPER USE OR

HANDLING OF HOSE COULD RESULT IN BURST OR OTHER HOSE FAILURE. KEEP

HOSE AS FAR AWAY AS POSSIBLE FROM BODYAND DO NOT PERMIT DIRECT CONTACT

DURING USE. CONTACT AT THE BURST CAN CAUSE BODILY INJECTION AND SEVERE

PERSONAL INJURY.

4. HANDLE AND ROUTE HOSE CAREFULLY TOAVOID KINKING, CUTTING, OR CONTACT

WITH HIGH TEMPERATURE SURFACES. DO NOT USE IF KINKED. DO NOT USE HOSE TO

PULL OR LIFTTOOLS, POWER UNITS, ETC.

DO NOT REMOVE THIS TAG

5. CHECK ENTIRE HOSE FOR CUTS CRACKS LEAKS ABRASIONS, BULGES, OR DAMAGETO

COUPLINGS IF ANYOF THESE CONDITIONS EXIST, REPLACE THE HOSE IMMEDIATELY.

NEVER USE TAPE ORANY DEVICE TO ATTEMPT TO MEND THE HOSE.

6. AFTER EACH USE STORE IN ACLEAN DRYAREA.

SEE OTHER SIDE

SIDE 1 SIDE 2

TOOL HOSE INFORMATION

Oil Flow Hose Lengths Inside Diameter USE

(Press/Return)

Min. Working Pressure

GPM LPM FEET METERS INCH MM PSI BAR

Certiﬁed Non-Conductive Hose - Fiber Braid - for Utility Bucket Trucks

4-9 15-34 up to 10 up to 3 3/8 10 Both 2250 155

Conductive Hose - Wire Braid or Fiber Braid -DO NOT USE NEAR ELECTRICAL CONDUCTORS

4-6 15-23 up to 25 up to 7.5 3/8 10 Both 2500 175

4-6 15-23 26-100 7.5-30 1/2 13 Both 2500 175

5-10.5 19-40 up to 50 up to 15 1/2 13 Both 2500 175

5-10.5 19-40 51-100 15-30 5/8 16 Both 2500 175

5-10.5 19-40 100-300 30-90 5/8 16 Pressure 2500 175

3/4 19 Return 2500 175

10-13 38-49 up to 50 up to 15 5/8 16 Both 2500 175

10-13 38-49 51-100 15-30 5/8 16 Pressure 2500 175

3/4 19 Return 2500 175

10-13 38-49 100-200 30-60 3/4 19 Pressure 2500 175

1 25.4 Return 2500 175

13-16 49-60 up to 25 up to 8 5/8 16 Pressure 2500 175

3/4 19 Return 2500 175

13-16 49-60 26-100 8-30 3/4 19 Pressure 2500 175

1 25.4 Return 2500 175

Typical Hose Connections

Tool to Hydraulic Circuit Hose Recom-

mendations

The chart to the right shows recommended mini-

mum hose diameters for various hose lengths

based on gallons per minute (gpm)/liters per min-

ute (lpm). These recommendations are intended

to keep return line pressure (back pressure) to a

minimum acceptable level to ensure maximum tool

performance.

This chart is intended to be used for hydraulic tool

applications only based on Stanley Hydraulic Tools

tool operating requirements and should not be used

for any other applications.

All hydraulic hose must have at least a rated

minimum working pressure equal to the maximum

hydraulic system relief valve setting.

All hydraulic hose must meet or exceed speciﬁ-

cations as set forth by SAE J517.

PRESSURE

RETURN

<<< FLOW

FLOW >>>

HTMA REQUIREMENTS

FLOW RATE

TOOL OPERATING PRESSURE

(at the power supply outlet)

SYSTEM RELIEF VALVE SETTING

(at the power supply outlet)

MAXIMUM BACK PRESSURE

(at tool end of the return hose)

Measured at a max. ﬂuid viscosity of:

(at min. operating temperature)

TEMPERATURE

Sufﬁcient heat rejection capacity

to limit max. ﬂuid temperature to:

(at max. expected ambient temperature)

Min. cooling capacity

at a temperature difference of

between ambient and ﬂuid temps

NOTE:

Do not operate the tool at oil temperatures above 140° F (60° C). Operation at higher temperatures can cause operator

discomfort at the tool.

FILTER

Min. full-ﬂow ﬁltration

Sized for ﬂow of at least:

(For cold temp. startup and max. dirt-holding capacity)

HYDRAULIC FLUID

Petroleum based

(premium grade, anti-wear, non-conductive)

VISCOSITY

(at min. and max. operating temps)

NOTE:

When choosing hydraulic ﬂuid, the expected oil temperature extremes that will be experienced in service determine the

most suitable temperature viscosity characteristics. Hydraulic ﬂuids with a viscosity index over 140 will meet the require-

ments over a wide range of operating temperatures.

*SSU = Saybolt Seconds Universal

4-6 gpm 7-9 gpm 11-13 gpm 9-10.5 gpm

(15-23 lpm) (26-34 lpm) (42-49 lpm) (34-40 lpm)

2000 psi 2000 psi 2000 psi 2000 psi

(138 bar) (138 bar) (138 bar) (138 bar)

2100-2250 psi 2100-2250 psi 2100-2250 psi 2200-2300 psi

(145-155 bar) (145-155 bar) (145-155 bar) (152-159 bar)

250 psi 250 psi 250 psi 250 psi

(17 bar) (17 bar) (17 bar) (17 bar)

400 ssu* 400 ssu* 400 ssu* 400 ssu*

(82 centistokes)(82 centistokes)(82 centistokes)(82 centistokes)

140° F 140° F 140° F 140° F

(60° C) (60° C) (60° C) (60° C)

3 hp 5 hp 7 hp 6 hp

(2.24 kW) (3.73 kW) (4.47 kW) (5.22 kW)

40° F 40° F 40° F 40° F

(22° C) (22° C) (22° C) (22° C)

25 microns 25 microns 25 microns 25 microns

30 gpm 30 gpm 30 gpm 30 gpm

(114 lpm) (114 lpm) (114 lpm) (114 lpm)

100-400 ssu* 100-400 ssu* 100-400 ssu* 100-400 ssu*

(20-82 centistokes)

TOOL CATEGORY

HYDRAULIC SYSTEM

REQUIREMENTS TYPE 1 TYPE II TYPE III TYPE RR

NOTE:

These are general hydraulic system requirements. See tool Speciﬁcation page for tool speciﬁc requirements.

PREOPERATION PROCEDURES

CHECK THE POWER SOURCE

1. Using a calibrated ﬂow meter and pressure gauge, make sure the

hydraulic power source develops a ﬂow of 7-9 gpm/26-34 lpm at 2000

psi/140 bar.

2. Make certain that the power source is equipped with a relief valve set

to open at 2100-2250 psi/145-155 bar.

3. Make certain that the power source return pressure does not exceed

250 psi/17 bar.

CONNECT HYDRAULIC HOSES

1. Wipe all hose couplers with a clean lint-free cloth before making con-

nections. If necessary, use a light-weight penetrating oil in a spray can to

clean the hose couplers before each connection.

2. Connect the hoses from the hydraulic power source to the chain saw

ﬁttings or quick disconnects. It is a good practice to connect return hoes

ﬁrst and disconnect them last to minimize or avoid trapped pressure

within the chain saw.

3. Observe the arrow on the couplers to ensure that the ﬂow is in the

proper direction. The female coupler on the chain saw is the inlet (pres-

sure) coupler.

4. Move the hydraulic circuit control valve to the “ON” position to operate

the chain saw.

NOTE:

If uncoupled hoses are left in the sun, pressure in-

crease inside the hoses might make them difﬁcult to

connect. Whenever possible, connect the free ends of

the hoses together.

CONNECTING TO A WATER SUPPLY

1. Using a standard garden hose, connect the DS12 to a city or auxiliary

water supply.

2. If you plan on operating the chain saw in freezing weather, make sure

you purge all the water from the system after each use.

CHAIN TENSIONING AND BAR ADJUSTMENT

Aproperly tensioned chain will optimize cutting performance. The tension-

ing rule of thumb for the utility cutting chain saw is that a properly ten-

sioned chain must not be bowstring tight and can be pulled freely around

the guide bar by hand easily without binding. Caution should be used

when adjusting these chains as the bar rail can become very sharp. Lift

the chain away from the bar rail when rotating and use extreme caution.

Note: The chain on the utility saw is non-directional and may be in-

stalled to travel either direction.

PROPER CHAIN TENSION

Check the chain tension often during operation, especially during the ﬁrst

1/2 hour when using a new chain.Adjust the chain accordingly when it

becomes loose.

If the chain is too loose, it could come off the bar, or it will allow the drive

sprocket to spin without turning the chain, which can chew up the chain

drive links. If the chain is too tight, a lot of the saw’s power goes into turn-

ing the chain rather than into the cut. In extreme over-tightened cases,

the saw may not be able to turn the chain at all. In addition, damage can

occur to the bar nose and premature stretch may occur.

HOW TO CHECK

Before cutting, check for proper tension by pulling the chain around the

bar by hand. If you cannot easily pull by hand, the chain is too tight and

needs to be loosened.

OPERATION

WHEN TO TENSION

All chains have a tendency to stretch when used. Diamond chains

stretch more than wood cutting chains because of the abrasive materials

they are cutting. When a chain stretches to a point where the drive links

are hanging approximately 1/2 in-3/4 in (12-18 mm) below the bar, it’s

time to tension the chain.

HOW TO TENSION

To tension the chain, ﬁrst loosen the side cover nuts, then while holding

the nose of the bar up, use a screw driver to turn the tensioning screw

clockwise until the chain drive links hanging below the bar are just begin-

ning to enter the bar groove. Continue to hold up on the nose of the bar

and ﬁrmly tighten the side cover nuts, (20 ft-lbs, 27 Nm).And remember,

it’s the side cover nuts that hold the bar in position.

NOTE: MAKE SURE THE BARATTACHING NUTSARE FULLY

TIGHTENEDAND THE CHAIN GUARD IS IN PLACE.

HOW TO PREVENT CHAIN TENSIONER

BREAKAGE

Do not attempt to adjust the tensioner without ﬁrst loosening the side

cover nuts. Do not use the saw without making sure the side cover nuts

are tight. If the side cover nuts are not tight, the bar can slip backwards

during cutting and break the tensioner pin.

ADDITIONAL INFORMATION

Utility chainsaws operate with looser chain tension than wood chain-

saws. It is common, on the utility chainsaw to have the drive links hang

completely out of the bar. Wood cutting chainsaws use oil to lubricate

the chain. The oil makes the chain very slippery and allows the drive

links to fully nest between the teeth of the drive sprocket. The utility

cutting chainsaws require water for cooling and ﬂushing the cut. Water is

not as good as oil as a lubricant.Also, there are cutting particles mixed

in with the water.As a result, sometimes the drive links do not nest

properly on the drive sprocket. When this happens, the chain acts like it

got tighter. There seems to be “tight” spots and “loose” spots as you pull

the chain around the bar. If you tension when the chain is in one of the

loose spots, it will be too tight at some point in it’s rotation around the

bar. Rotating the chain completely around the bar by hand will let you

know you have the chain properly tensioned.

ADDITIONAL TENSIONING TIPS

1. To reduce chain stretch and tensioning downtime, use 20 PSI (1.5

bar) or greater water pressure.

2. Oil the chain at the end of the day to prevent rust but be careful not to

over tension in this condition.

3. When pulling the chain around the bar by hand, be careful not to

touch the bar with thumb or foreﬁnger. The bar rails can be very

sharp. Using leather gloves grab only the diamond segments to pull

the chain.

4. Always turn the hydraulic power source off before tensioning the

chain.

OPERATION

CHECK THE WATER SUPPLY

1.Always have water running before starting the chain saw.

2. Recommended water ﬂow 4 gpm/15 lpm at 50 psi/3.5 bar (2-gp/7.5

lpm at 20-psi/1.3 bar minimum).

PRE-CUT CHECKLIST

• If using the clamp make sure it is securely fastened before attaching

the saw, tighten clamp nut with wrench.

• Proper Chain tension: Bottom tip of drive link hangs even with bottom

of bar.

• Ensure proper water ﬂow and hydraulic supply to power unit.

• Ensure cut can be made clear of dirt contact.

• Protective clothing/protection in place.

• Mark cut on pipe.

• Block pipe from shifting, support weight of pipe.

OPERATING PROCEDURES

NEW SAW CHAIN BREAK-IN

1.Always make sure the bar and sprocket are in good condition.

2. Turn on the water supply.

3. Operate the chain saw for two minutes (away from the intended cut)

and then check the chain tension.

4.Adjust accordingly using the procedures contained in Chain Tension-

ing and BarAdjustments section of this manual.

OPERATION

Chain and bar damage will occur if the chain saw

operates without the proper water supply.

CUTTING TIPS

If using pipe clamp (Applicable for 4”-12”, recommended for 8”-12”).

• Place clamp around top of pipe, hand tighten adjustment nut.

• Position saw on pipe for top down or bottom up (recommended) cut and

slide saw clamp mount through receiver hole at top of clamp, secure with

snap pin.

• Slide clamp/saw assembly around pipe to optimum cutting position and

tighten clamp nut with wrench.

• Ensure saw is positioned to allow handle to pivot during cut unobstruct-

ed, and ensure saw tip doesn’t contact dirt.

CUTTING FREE-HAND OR WITH PIPE CLAMP

• Position saw to avoid pinching the bar or chain as pipe is cut, support

pipe from top and side to prevent cut pipe from injuring operator.

• Hold saw so chain isn’t in contact with pipe, start water and activate saw

to recommended ﬂow rate, press chain against pipe slowly, apply pres-

sure to cut through pipe.

• Pressure can be applied to cut until saw starts to lug, if need be back off

on the cutting pressure to maintain a good cutting speed.

• If cut in a 12” pipe exceeds 5 minutes, cut pulls to one side, or diamond

coating is gone, chain may need replacement.

When the saw cut is complete be watchful of

sharp edges around the material that has been cut.

Before cutting make sure the material being cut

is properly supported from falling or shifting.

When exiting the cut, avoid applying high feed

loads as unexpected movement of the saw may

result. Using both hands, maintain ﬁrm control

of the tool throughout the entire cut.

TYPES OF CUTS

The DS12 can be operated not only using the pipe clamp but also make

free-hand cuts, any size pipe can be cut free hand.

Utility Chain Saw Cuts

• Ductile Iron Pipe • Rooﬁng Shingles

• Insituform Pipe Lining • CMU Concrete Block

• PVC Pipe • Non Reinforced Concrete

• Copper Pipe • Rooﬁng Tile

• Steel Rooﬁng Material • Lumber

• HDPE Pipe • Masonry

1. When using the pipe clamp with a 15-inch bar the cut capacity is 4” to

10”.

2. When using the pipe clamp with a 18-inch bar the cut capacity is 4” to

12”.

3. Do not use a cutting force in excess of 45 lbs/20 kg. Excessive force

causes the chain to slow down or stall and causes premature wear of the

saw bar and chain.

4.Always maintain a high chain speed. High chain speeds produce the

best results.

5.Avoid aggressive/heavy forces.Aggressive force can causes premature

bar and chain wear.

COLD WEATHER OPERATION

If the saw is to be used during cold weather, preheat the hydraulic ﬂuid at

low power source speed. When using the normally recommended ﬂuids,

ﬂuid should be at or above 50°F/10°C (400 ssu/82 centistokes) before

use.

Damage to the hydraulic system or chain saw can result from use with

ﬂuid that is too viscous or thick.

OPERATION

Top down Cut

Bottom up Cut

PLAN THE CUT

1. Plan your cuts to prevent injury to yourself and to keep from pinch-

ing the saw bar and chain as a result of falling pieces of iron pipe.

2. Outline the material being cut with a permanent marker for a visual

guide (especially when cutting free hand).

3. Know what kind of material you are cutting.

TOOL EQUIPMENT & CARE

• Make sure all couplers are wiped clean before connection.

• The hydraulic circuit control valve must be in the “OFF” position when coupling or uncoupling

hydraulic tools. Failure to do so may result in damage to the quick couplers and cause overheating

of the hydraulic system.

• Always store the tool in a clean dry space, safe from damage or pilferage.

• Make sure the circuit PRESSURE hose (with male quick disconnect) is connected to the “IN” port.

The circuit RETURN hose (with female quick disconnect) is connected to the opposite port. Do not

reverse circuit ﬂow. This can cause damage to internal seals.

• Always replace hoses, couplings and other parts with replacement parts recommended by Stanley

Hydraulic Tools. Supply hoses must have a minimum working pressure rating of 2500 psi/172 bar.

• Do not exceed the rated ﬂow (see Speciﬁcations) page in this manual for correct ﬂow rate and

model number. Rapid failure of the internal seals may result.

• Always keep critical tool markings, such as warning stickers and tags legible.

• Tool repair should be performed by experienced personnel only.

• Make certain that the recommended relief valves are installed in the pressure side of the system.

• Do not use the tool for applications for which it was not intended.

• Oil the chain at the end of the day to prevent rust but be careful not to over tension in this condition..

In addition to the Safety

Precautions on page in this

manual, observe the following for

equipment protection and care.

NOTICE

CHAIN SAW TROUBLESHOOTING

Excessive vibration and cuts rough. Loose chain tension. Retension the chain.

Excessive feed force. Reduce feed force.

Chain saw will not cut straight. Operator feed force not applied move left hand closer to centerline

directly over centerline of saw. of saw bar.

Accumulated saw bar wear and Turn the saw bar over and dress rails

uneven chain segment proﬁle wear. square. Replace the saw bar and

chain.

Loss of power. Drive sprocket slipping on Adjust and tighten Trantorque®

Trantorque® adapter. adapter, (30 ft. lbs/40.6 Nm).

Chain saw does not run. Power source not functioning. Check power source for proper ﬂow

and pressure (7-9 gpm/26-34 lpm @

2000 psi/140 bar).

Coupler or hoses are blocked. Remove obstruction.

Mechanical failure. Disassemble the chain saw and

inspect for damage.

Chain saw runs backwards. Pressure and return hoses Connect for proper ﬂow direction.

reversed. Motor shaft must rotate clockwise.

Trigger is hard to press. Pressure and return hoses Connect to proper ﬂow direction.

reversed. Motor shaft must rotate clockwise.

Back pressure too high. Should not exceed 250 psi/17 bar @

9 gpm/34 lpm measured at the end

of the chain saw’s operating hoses.

Fluid leakage around drive Motor shaft seal failure. Replace as required.

sprocket.

Fluid leakage between the rear Motor face seal failure. Replace as required.

gear housing and the chain saw

adaptor.

Fluid leakage between the valve Oil tube seal failure. Replace as required.

handle and the extension housing.

Fluid leakage between the ext- Oil tube seal failure. Replace as required.

ension housing assembly and

the chain saw adaptor.

Chain saw cuts slow. Insufﬁcient hydraulic ﬂuid ﬂow or Adjust proper hydraulic ﬂuid ﬂow to

low relief valve setting. proper gpm. For optimum perf-

ormance, adjust relief valve to 2100-

2250 psi/145-155 bar.

TROUBLESHOOTING

CHAIN SAW TROUBLESHOOTING CONTINUED

Chain saw cuts slow. Back pressure too high. Should not exceed 250 psi/17 bar @

9 gpm/34 lpm measured at the end

of the chain saw’s operating hoses.

Loss of diamond segment side Replace the chain.

clearance.

Hydraulic ﬂuid mixed in water supply. Check motor for leaks.

Wrong chain for application. Scale down to a lower numbered

chain.

Wire edged bar rails. Dress rails square.

Excessive vibration and cuts rough. Segment(s) broken or missing Remove and repair broken segment

from chain. or replace chain.

TROUBLESHOOTING

SPECIFICATIONS

Input Flow Range.............................................................................................................................................................................7-9 gpm / 26-34 lpm

Input Pressure......................................................................................................................................................................................2000 psi / 140 bar

Chain Type ................................................................................................................................................................................Force 4 (.444) inch Pitch

Weight (with bar)......................................................................................................................................................................................26 lbs / 11.8 kg

Length.................................................................................................................................................................................35 or 38 inches / 89 or 97 cm

Width......................................................................................................................................................................................................9 inches / 23 cm

Lubrication / Cooling........................................................................................................................................................ Internal Water Channels in Bar

Porting.......................................................................................................................................................................................................-8 SAE O-Ring

Connection.............................................................................................................................................3/8 inch Flush-Face Quick Disconnect Coupler

Hose Whips.................................................................................................................................................................................................................Yes

Sound Power Level.............................................................................................................................................................................................109 dBA

Vibration Level................................................................................................................................................................................Main Handle 4.9 m/s²

........................................................................................................................................................................................................Assist Handle 5.2 m/s²

ACCESSORIES

Water Pump, 12 VDC, DC Plug, Marine Type.................................................................................................................................................DCP30100

Water Pump, 12 VDC, Battery Clips................................................................................................................................................................DCP30101

3/8 inch Flush-Face Coupler Set............................................................................................................................................................................03971

25 feet, 1/2 inch Dual Hose with Flush-Face Couplers..........................................................................................................................................31972

50 feet, 1/2 inch Dual Hose with Flush-Face Couplers..........................................................................................................................................31848

Chain 15-inch ........................................................................................................................................................................................................ 71050

Bar 15-inch ............................................................................................................................................................................................................ 71049

Chain 18-inch ........................................................................................................................................................................................................ 71048

Bar 18-inch ............................................................................................................................................................................................................ 71047

Pipe ClampAssembly.............................................................................................................................................................................................71055

Drive Sprocket........................................................................................................................................................................................................71046

Water Flow Meter, 0-7 GPM................................................................................................................................................................................... 60859

Pipe Clamp Assembly 71055
