PARTS MANUAL
SRA60
COMPACTION
RAMMER
SRA 60

2 ► SRA 60 Parts Manual
MACHINE INFORMATION ........................................................................................................................................3
ADHESIVES..............................................................................................................................................................4
UPPER HANDLE.......................................................................................................................................................5
FUEL TANK ...............................................................................................................................................................6
ENGINE.....................................................................................................................................................................7
ENGINE GUARDING ................................................................................................................................................8
THROTTLE................................................................................................................................................................9
FILTER ....................................................................................................................................................................10
GEAR BOX.............................................................................................................................................................. 11
CLUTCH..................................................................................................................................................................12
PINION ....................................................................................................................................................................13
GUIDE TUBE...........................................................................................................................................................14
PISTON / SPRINGS................................................................................................................................................15
BELLOW..................................................................................................................................................................16
BASE PLATE...........................................................................................................................................................17
DECAL INFORMATION...........................................................................................................................................18
WORK PLATE 165MM ............................................................................................................................................19
WORK PLATE 200MM ............................................................................................................................................20
WORK PLATE 230MM ............................................................................................................................................21
WORK PLATE 330MM ............................................................................................................................................22
WORK PLATE 400MM ............................................................................................................................................23
WORK PLATE 340MM ASYMMETR .......................................................................................................................24
INTERMEDIATE PIECE, SHORT............................................................................................................................25
FOOT EXTENSION.................................................................................................................................................26
TRAILER ASSY.......................................................................................................................................................27
MAINTENANCE KIT................................................................................................................................................28
BASE PLATE KIT ....................................................................................................................................................29
REPAIR KIT (COUPLING).......................................................................................................................................30
REPAIR KIT (CARRY ROLLER)..............................................................................................................................31
REPAIR KIT (CARBURATOR).................................................................................................................................32
REPAIR KIT (BELLOW) ..........................................................................................................................................33
REPAIR KIT (SPRING LEG) ...................................................................................................................................34
SERVICING: This manual contains spare parts. Stanley Hydraulic Tools recommends that servicing this machine,
other than routine maintenance, must be performed by an authorized and certied dealer. Please read the following
warning.
For the nearest authorized and certied dealer, call Stanley Hydraulic Tools at the number listed on the back of this
manual and ask for a Customer Service Representative.
WARNING
SERIOUS INJURY OR DEATH COULD RESULT FROM THE IMPROPER REPAIR OR
SERVICE OF THIS TOOL.
REPAIRS AND / OR SERVICE TO THIS TOOL MUST ONLY BE DONE BY AN
AUTHORIZED AND CERTIFIED DEALER.
TABLE OF CONTENTS
IMPORTANT
To ll out a Product Warranty Validation form, and for information on your warranty,
visit Stanleyhydraulics.com and select the Company tab, Warranty.
(NOTE: The warranty Validation record must be submitted to validate the warranty).

SRA 60 Parts Manual ◄ 3
Important!
In order to enable spare parts orders to be processed quickly and correctly, we require the
following data:
1. Machine number:________________________________________
2. Machine type:___________________________________________
3. Motor type:_____________________________________________
(enter here for your own use; the data is shown on the type plate of the machine)
4. Item description, part number and quantity.
Only original spare parts ensure a perfect condition tested by us; no warranty can be given if
original spare parts are not used.
In case of warranty claims, make sure a Product Warranty Validation form has been lled out on our
website at “stanleyhydraulics.com” (Note: the warranty validation form must be submitted to validate the
warranty).
In case of warranty claims for combustion engines, please contact the engine manufacturer or one of
his authorised repair workshops to repair the damage or process the warranty claim.
Because of the steady development of our products, the shown illustrations are non-committal.
To order spare parts, please contact your local dealer or write to:
Stanley Hydraulic Tools
3810 SE Naef Road
Milwaukie, OR 97267
Ph: 503-659-5660
Fax: [phone]
MACHINE INFORMATION

4 ► SRA 60 Parts Manual
Sealing- and bonding adhesives
as specied in the individual
exploded views
ADHESIVES
Nm In. lb. Ft. lb.
5 44.2 3.6
10 88.5 7.3
15 132 11.0
20 177 14.7
25 221.2 18.4
30 265.5 22.1
35 309.7 25.8
40 354 29.5
45 398.2 33.1
50 442 36.8
55 486.7 40.5
60 531 44.2
Convertion: Newtom-Meters to in. lb. and ft. lb.

SRA 60 Parts Manual ◄ 5
SRA 60 UPPER HANDLE PARTS
Item No. Part No. Qty Description
1 75471 2 Spring Element
2 75682 4 Socket Head Cap Screw
6 75531 4 Conical Spring Washer
7 75727 4 Hexagonal Head Cap Screw
8 75380 1 Holding Bow
9 75319 1 Retaining Pin
10 75371 2 Carrying Roller
11 75676 4 Socket Head Cap Screw
12 75752 4 Hexagon Nut

6 ► SRA 60 Parts Manual
Item No. Part No. Qty Description
1 75382 1 Fuel Tank Assy.
2 75568 1 Tank Cap
3 75564 1 Filter
4 75565 1 Fuel Tap
5 75759 4 Hexagon Nut
6 75545 1 Hose Clamp
7 75566 1 Hose
8 75554 4 Hose Clamp
9 75451 1 O-Ring
10 75567 1 Hose
11 75563 1 Fuel Filter
12 76498 1 Tube Clamp (For fuel line)
SRA 60 FUEL TANK PARTS
12

SRA 60 Parts Manual ◄ 7
Item No. Part No. Qty Description
1 75633 1 Petrol Engine
2 75866 1 Gasket
3 75873 2 Flange Nut
4 75870 2 Stud Bolt
5 75321 1 Suction Elbow Part
6 75455 2 Joint Washer
7 75559 1 Straight Coupling
8 75320 1 Hose
9 75335 1 Formed Hose
10 75548 2 Hose Clamp
11 75345 1 Cable
12 75087 1 Fan-Shaped Washer
13 75722 1 Hexagonal Head Cap Screw
14 75751 1 Hexagon Nut
15 75365 1 Engine Protection Panel, Back
16 75862 1 Air Relief Tube
SRA 60 ENGINE PARTS

8 ► SRA 60 Parts Manual
SRA 60 ENGINE GUARDING PARTS
Item No. Part No. Qty Description
1 75330 1 Thermic Protection
2 75779 2 Button Socket Head Screw
3 75774 1 Thread Rolling Screw
4 75354 1 Engine Protection, Right
5 75355 1 Engine Protection, Left
6 75776 2 Button Socket Head Screw
7 75333 1 Console, Right
8 75334 1 Console, Left
9 75379 1 Engine Protection Panel, Top
10 75338 1 Engine Protection Panel
11 75773 6 Fastener
12 75780 7 Button Socket Head Screw
13 75365 1 Engine Protection Panel, Back
14 75509 2 Washer
15 75680 4 Socket Head Cap Screw
16 75512 4 Washer
18 75357 1 Rubber Plate
19 75361 1 Fastener

SRA 60 Parts Manual ◄ 9
SRA 60 THROTTLE PARTS
Item No. Part No. Qty Description
1 75644 1 Throttle Cable
2 75761 2 Countersunk Screw
3 75769 2 Cap Nut
5 75476 1 Rubber Buffer

10 ► SRA 60 Parts Manual
SRA 60 FILTER PARTS
Item No. Part No. Qty Description
1 75571 1 Cyclone
2 75703 1 Threaded Pin
3 75572 1 Service Indicator
4 75356 1 Nipple
5 75326 1 Panel
6 75723 2 Hexagonal Head Cap Screw
7 75328 1 Cover
8 75542 1 Wing Screw
9 75511 1 Washer
10 75420 1 O-Ring
11 75516 1 Support Washer
12 75419 1 O-Ring
13 75570 1 Filter Cartridge
14 75327 1 Threaded Plate
15 75762 2 Countersunk Screw
16 75533 2 Conical Spring Washer
17 75513 1 Lock Washer
18 76479 1 Foam Air Filter
Item 18 (Foam Air Filter)

SRA 60 Parts Manual ◄ 11
SRA 60 GEAR BOX PARTS
Item No. Part No. Qty Description
1 75377 1 Gearbox
2 75670 1 Screw Plug
3 75452 1 Joint Washer
4 75378 1 Cover
5 75426 1 O-Ring
6 75781 6 Button Socket Head Screw
7 75706 4 Stud Bolt
8 75539 2 Cylindrical Pin
9 75759 4 Hexagon Nut

12 ► SRA 60 Parts Manual
SRA 60 CLUTCH PARTS
Item No. Part No. Qty Description
1 75318 1 Clutch Socket
2 75416 1 Shaft Sealing Ring
3 75399 2 Groove Ball Bearing
4 75317 1 Distance Ring
5 75489 1 Retaining Ring
6 75499 1 Retaining Ring
7 75579 1 Centrifugal Clutch
8 75729 1 Hexagonal Head Cap Screw
9 75531 1 Conical Spring Washer
10 75600 1 Set Of Lining Strap

SRA 60 Parts Manual ◄ 13
SRA 60 PINION PARTS
Item No. Part No. Qty Description
1 75325 1 Connecting Rod
2 75400 1 Groove Ball Bearing
3 75483 1 Retaining Ring
4 75315 1 Bush
5 75494 1 Retaining Ring
6 75360 1 Pinion
7 75400 1 Groove Ball Bearing
8 75401 1 Groove Ball Bearing
9 75485 1 Retaining Ring
10 75495 1 Retaining Ring

14 ► SRA 60 Parts Manual
SRA 60 GUIDE TUBE PARTS
Item No. Part No. Qty Description
1See Note Above 1Guide Tube, Assy.
2See Note Above 1 Buffer
3See Note Above 1 Cover
4See Note Above 1 Retaining Ring
5 75344 1 Guide Tube
6 75436 1 O-Ring
8 75744 4 Hexagonal Head Cap Screw
DANGER
NOTE:
Non serviceable item. Never attempt to
remove item #4 Retaining Ring, com-
ponents held by item 4 Retaining Ring
are assembled under high spring com-
pression. Removal of the Retainer ring
may cause serious injury or death when
energy is released.
Items 1 thru 4 must be purchased as part
of an assembly (see item # 2 P/N-75341
Spring guide assy on page 33).

SRA 60 Parts Manual ◄ 15
Item No. Part No. Qty Description
1 75362 1 Intermediate Piece
2 75694 6 Socket Head Cap Screw
3 75569 1 Oil Level Indicator
4 75381 1 Bellow
5 75551 1 Clamping Piece
6 75552 1 Clamping Piece
7 76404 1 Guide Tube, Assy.
SRA 60 BELLOW PARTS

16 ► SRA 60 Parts Manual
Item No. Part No. Qty Description
1 75323 1 Base Plate
2 75324 1 Floor Plate
3 75789 2 Countersunk Screw
4 75787 3 Countersunk Screw
5 75316 5 Washer
6 75753 5 Hexagon Nut
7 75786 2 Countersunk Screw
8 75788 2 Countersunk Screw
11 75760 4 Hexagon Nut
12 75393 1 Grip
13 75366 1 Work Plate, Assy.
SRA 60 BASE PLATE PARTS

SRA 60 Parts Manual ◄ 17
SRA 60 DECAL INFORMATION
Item No. Part No. Qty Description
1 75099 1 Decal Information
2 75103 1 Decal Information
3 75102 1 Decal Information
4 75101 1 Decal Information
5 75093 1 Decal Information
6 75097 1 Decal Information
7 75096 1 Sign, Operation
8 75777 4 Tapping Screw
9 74911 2 Stanley Logo
10 74900 2 Decal SRA 60
9
10

18 ► SRA 60 Parts Manual
SRA FOOT SIZE OPTIONS (WIDTH 165MM)
Item No. Part No. Qty Description
1 75336 1 Base Plate
2 75337 1 Floor Plate
3 75787 3 Countersunk Screw
4 75316 1 Washer
5 75753 5 Hexagon Nut
6 75786 2 Countersunk Screw
7 75788 2 Countersunk Screw
10 75760 4 Hexagon Nut
11 75348 1 Work Plate, Assy.
165 mm / 6-1/2 in. Work Plate

SRA 60 Parts Manual ◄ 19
SRA FOOT SIZE OPTIONS (WIDTH 200MM)
Item No. Part No. Qty Description
1 75349 1 Base Plate
2 75350 1 Floor Plate
3 75789 2 Countersunk Screw
4 75787 3 Countersunk Screw
5 75316 5 Washer
6 75753 5 Hexagon Nut
7 75786 2 Countersunk Screw
8 75788 2 Countersunk Screw
11 75760 4 Hexagon Nut
12 75347 1 Work Plate, Assy.
200 mm / 7-7/8 in. Work Plate

20 ► SRA 60 Parts Manual
SRA FOOT SIZE OPTIONS (WIDTH 230MM)
Item No. Part No. Qty Description
1 75342 1 Base Plate
2 75343 1 Floor Plate
3 75789 2 Countersunk Screw
4 75787 3 Countersunk Screw
5 75316 5 Washer
6 75753 5 Hexagon Nut
7 75786 2 Countersunk Screw
8 75788 2 Countersunk Screw
11 75760 4 Hexagon Nut
12 75346 1 Work Plate, Assy.
230 mm / 9 in. Work Plate
