Model GR14SPTA
S258/0068
Features/Benefits:
★Expand your menu with Star’s Pro-Max speciality two sided
grill. Prepare burritos, quesadillas, sandwiches and many other
menu items quickly and easily while maximizing space.
★Split top design cooks a variety of products at the same time
while allowing maximum control of different temperatures.
★Electronic programmable timer with two controls to set different
time and temperatures. The timer counts down and is equipped
with an audible alarm to signal when timer reaches zero.
★Heavy-duty aluminum platens provide superior performance and
long life.
★Acounter balance hinge system provides safe and effortless
operation of both top platens. Spacious grilling height
accommodates product up to three inches.
★Easy to read digital thermostat is rated from 250°F(79°C) to
550°F (302°C).
★Front grease trough and drawer for easy cleaning.
★Stainless steel burn guard protects from accidental contact.
Applications:
Star’s two-sided grill can prepare sandwiches, burritos, quesadillas
and many other menu items quickly and easily. Split-top design pro-
vides maximum menu flexibility and cooking production.
Quality Construction:
The rugged body is constructed of 18 gauge stainless steel. The
grill is supplied with grease trough and stainless steel grease drawer.
The counter balance mechanism is constructed from hardened
aluminum. The 6 foot lead-in cord has a special covering that is
resistant to water and oil and the wires are protected by metallic
braiding. Cord comes complete with plug (see typical specifications).
Warranty:
Two-sided grill is covered by Star’s one year parts and labor
warranty.
PRO-MAX SMOOTH
SPECIALTY TWO-SIDED GRILL
Model GR14SPTA
®
S t a r M a n u f a c t u r i n g I n t e r n a t i o n a l , I n c .

Phone: [phone] - FAX: [phone] - www.star-mfg.com
Star Manufacturing International Inc. - 10 Sunnen Drive - P.O. Box 430129 - St. Louis, MO 63143-3800
Two-sided grill is constructed with a stainless steel body and aluminum smooth or grooved platens. Designed with electric controls
for precise temperature control and digital timer for select menu items. Acounter balance hinge mechanism provides easy opera-
tion of both top platens. Grilling height between platens is up to 3" with counter balance system providing 3-4 pounds of pressure
to the cooking product placed on bottom platen. Metal sheathed tubular elements and adjustable non-skid feet are standard. Unit
has pilot light, six foot power cord with NEMA plug. 230V has a detachable power cord with a CEE-7V11 plug. Units approved with
UL, UL Sanitation or UL Canada Standards. Printed in the U.S.A.
Height Height Approximate Weight
(A) (B) (C) (D)
Model Grid Width Depth Closed Open Voltage Wattage Amps NEMA Shipping Installed
No. Surface Inches Inches Inches Inches Plug Ibs. Ibs.
(cm) (cm) (cm) (cm) (kg) (kg)
GR14SPTA Alum. 16 23-1/8 14-1/4 31-5/8 120 2300 19.2 5-20P* 81 68
120 2300 19.2 5-30P**
(40.6) (58.7) (36.3) (80.3) 208/240 1725/2300 8.3/9.6 6-15P (37.8) (30.9)
230 2,100 9.2 CE E - 7 / V 11
Typical Specifications
PRO-MAX SMOOTH
SPECIALTY TWO-SIDED GRILL
Model GR14SPTA
®
Due to periodic changes in designs, methods, procedures, policies and regulations, the specifications contained in this sheet are subject to change without notice. While Star
Manufacturing exercises good faith efforts to provide information that is accurate, we are not responsible for errors or omissions in information provided or conclusions reached as
a result of using the specifications. By using the information provided, the user assumes all risks in connection with such use.
**Canadian Requirements
Model and Specifications
*Not CUL approved. For use on individual branch circuit only.
