stefani Whole Of House User manual

Installation and
Operation Manual

Congratulations on purchasing your Stefani Whole House Filtration
System. Please read carefully the installation and operation manual
before installing the unit.
IMPORTANT: Installation must comply with existing State or Local Plumbing codes. Some Plumbing
Codes require installation of this filter system to be carried out by a Licensed Plumber.
.
In some areas, the water pressure may exceed the system’smaximum pressure allowance.If this is
the case, apressure limiting valve will be required.Please check with your Licensed Plumber during
installation.Install in accordance with AS/NZS 3500.1
Please note to avoid void of warranty the installation shall be in accordance with the Plumbing Code
of Australia. A WaterMark certified backflow prevention device complying with AS/NZS 2845.1 shall
be installed at a first point of entry of a system.
RECOMMENDATION:If Whole House System has not been used to 2 or more days, you will need
to flush for 5 minutes (to be consistent with the instructions on changing the cartridge before using
the water. If the unit is to be left unused for more than 2 days, the water supply valve must be
turned off.
Slower Flow Rate gives longer contact times for better contaminant reduction
To Maintain a high level of performance and protection provided by the STEFANI water filtration
system, use on STEFANI replacement filter cartridges
HELPFULHINT: The life and performance of the filter cartridge may vary, depending on the volume
and quality of the water being filtered. An indication that your filter cartridges may need replacing is
the reduced volume of flow from the faucet, or return of offensive taste and/odour to the filtered water.
We recommend you continue to check for leaks for aday after installation.
INSTALLATION ADVICE: A water filter system/tap, like any product, has a limited life and may
eventually fail. Also sometimes failure happens early due to unforeseen circumstances. To avoid
possible property damage, this product should be regularly examined for leakage and/or deterioration
and replaced when necessary. A drain pan, plumbed to an appropriate drain or outfitted with a leak
detector, should be used in those applications where any leakage could cause property damage,
and/or the water supply should be turned off if no one is home/present.
1
CAUTION:The Whole House Water filtration System should only be used on water that is
microbiologically safe -that is, water that has been adequately chlorinated or disinfected. Additional
sterilising equipment will be required for unsafe water.
The Whole House Water Filtration System is designed to operate at a maximum pressure of Max
Pressure: 1205kpa/175psi -minimum pressure of 69kPa (10psi) and at a maximum Temperature of
40 degree Celsius. Stefani Warrants this filter to be free of defects in material and workmanship for
aperiod of one year * from the date of purchase (* Warranty period excludes filter cartridges which
are consumable items).

LIST OF PARTS
INSTALLATION INSTRUCTIONS
IMPORTANT NOTE
The Whole House Filtration system must be installed by alicensed plumber according to plumbing
codes in your state, and if it has not been installed in accordance with the installation instructions by a
licensed plumber it will void the warranty on this product.
2
Water Flow Direction
1345
2
76
Re Description Qty Product No.
1Filter Housing 10 inch 1HOUSING
2Bracket 1BRACKET
3Hex Head Screw for Manifold Bracket 8pcs/bag 4SCREW-8
4Wrench 1WRENCH
5Brass Nipples 3/4" BSP Threads 2NIPPLES
65 Micron PP Sediment Filter 1WHF-2C
75 Micron Carbon Block Filter 1WHF-3C
The Stefani Whole House Water Filtration Housing component identification &content check list

8. Connect water inlet and outlet to the appropriate brass nipples
9. Turn on mains water and check for leaks. Flush the system for 5 minutes at the nearest
garden tap to activate the filter
Notice: The Filter Housing comes with 2x 1” brass threaded male inlet/outlet and will require
additional fittings to adapt to your plumbing. A shut off valve is recommended prior to Whole
House Filter System
.
This filter housing must be mounted vertically. Make sure it fits comfortably into the location you have
selected for it to be installed and check that there is asuitable connection to cold water supply. The
connection of the filter housing head is 1’ BSP threads
When affixing the mounting bracket to the filter housing head, use only screws provided to avoid
damaging the filter housing head.
Mount the housing with the mounting screws provided. Allow approximately 50mm clearance under the
filter housing for removal of the filter housing to change cartridge
Do not over tighten the filter housing sump to the housing head. Do not use heat torch near the
plastic housing.
1. Shut off the water.
2. Attach the Mounting Bracket to the wall using the supplied Hex Head
Screws and Washers.
3. Attach the Filter System to the Mounting Bracket using the supplied Bolt Head Screws.
4. Lube the O-Ring with clean silicone grease before attaching the cover onto the housing.
Ensure packaging is removed from the filter cartridge.
5. Tighten the Filter Housing using the supplied Filter Wrench (counter clockwise). DO NOT
OVERTIGHTEN OR THE O RING WILL UNSEAT
6. Determine the size of your inlet water supply line. Brass Reducers may be needed to fit
the 1” Filter System
7. Wrap Teflon Tape around the 1” Brass nipples and screw firmly into the filter head.
3

Filter Cartridge Replacement Instructions
NOTE: Before changing cartridge, turn off water supply. Place a bucket under the filter to catch the
small amount of water that will run out after the housing removal.
1. Turn the mains water off and close the shutoff valve at filter head if installed.
2. Relieve pressure in housing by pushing red vent button.
3. Unscrew housing and remove old cartridge. Wash housing thoroughly with mild soap and water
and rinse thoroughly.
4. Remove packaging from new cartridge and insert new cartridge and re-install housing. Be sure
cartridge is seated in the housing before tightening onto head.
5. Use filter wrench to fully seat the cartridge. Tighten to make a water tight seal.
DO NOT OVERTIGHTEN OR THE O-RING MAY UNSEAT
6. Turn on mains water and open shutoff valve at filter head. If any leaks appear tighten housing as
needed
7. Flush system for five (5) minutes at nearest garden tap to activate the filter.
4

CAUTION
WARRANTY
STEFANI WAT E R FILTER CARTRIDGES
If this water filter housing is being installed in-line in metal water pipes, which are being used to earth or
ground the electrical or phone installation, contact your electrical contractor to install an approved
earth bypass.Do not cut the metal pipe until the bypass has been installed, as there may be risk of
electric shock.
This warranty is expressly limited to repair or replacement at our premises of any parts proving
defective providing purifier has been installed in accordance with our installation instructions, and
pressure and temperature do not exceed limits stated herein.This warranty does not extend to
mechanical damage.Save insofar as they may be excluded by law, this warranty is given in lieu of all
other expressed or implied warranties or conditions and STEFANI shall in no event be held liable for
damages or delays caused by defects and assume no responsibility for unauthorised repairs.
This warranty becomes void if the system has not been installed by alicensed plumber according to
plumbing codes in your state, and if it has not been installed in accordance with installation instruction.
The code for the replacement Filter Cartridges are WHF2C and WHF-3C
Stefani Australasia PTY LTD
55 Banksia Road, Welshpool
Western Australia 6106
Tel: [phone]
Email: [e-mail]
www.stefani.com.au/
REV D / 1920
WMTS-103
WM-022200
Stefani Australasia Pty Ltd
