STEINWAY LYNGDORF CDP-1 User manual

OWNER´S MANUAL
CDP-1

TABLE OF CONTENTS
TABLE OF CONTENTS .......................................................................................................................................................... 2
STANDARD REMOTE CONTROL.......................................................................................................................................... 3
SYSTEM REMOTE CONTROL................................................................................................................................................ 4
FRONT PANEL ...................................................................................................................................................................... 5
MENU SYSTEM ..................................................................................................................................................................... 6
MAINTENANCE .................................................................................................................................................................... 7
COMPLIANCE....................................................................................................................................................................... 8
2

Toggles through RoomPerfect™ options.
Skips forwards/backwards through CD tracks.
Press to play/pause the CD.
Adjusts the volume.
Switches the system on and off.
Mutes and restores the sound.
Accesses the SP-1 menu system.
Toggles between audio sources.
When the CDP-1 is selected as the SP-1´s input device, the Standard Remote Control will work like this:
STANDARD REMOTE CONTROL
OK
MENU
SRC+ / SRC-
3
/
/
/

Switches the system on and off.
Turn the outer wheel to adjust the volume.
Press to play/pause the CD.
Press and hold and tap to toggle through
RoomPerfect™ options.
Press and hold and tap to toggle
through inputs.
Skip forwards/backwards through CD tracks.
Toggles through voicing options.
Mutes and restores the sound.
When the CDP-1 is selected as the SP-1´s input device, the System Remote Control will work like this:
SYSTEM REMOTE CONTROL
VOLUME
/
4

Switches the system on and off.
Rotate left and right to toggle between CD
tracks and browse while in the menu.
Press and hold to access the menu, press to
select a menu item, press and hold to cancel.
Press to open/close the CD tray.
This describes the day-to-day operation of your system using the controls on the SP-1 Stereo Processor front panel.
FRONT PANEL
RIGHT BUTTON
5
POWER
LEFT KNOB

The timeout can be set to on or off.
On is a 10 second display timeout.
Auto off will automatically turn off the CDP-1 after
it has been idle for 5 minutes.
• Software Info
Displays the firmware version.
• Factory Reset
Resets the CDP-1 to the factory default settings.
• Software Update
How to update the CDP-1 with new firmware:
1. Download the new firmware
2. Upload it to the root of a FAT32 formatted USB stick.
3. Go to Software Update in the menu and click Yes.
The display should show “Updating: Name of
firmware file.” When fully updated, the CDP-1
will go to standby mode.
Exits the menu.
• Normal Play
• Repeat Entire Disc
• Repeat One Track
• Random Play
Shows additional CD information (e.g. album
name, song name, and artist) if available.
When turned on, track information will be
reduced in height.
Show Remaining Time:
• Yes
• No
Enable Link Control with the SP-1:
• Yes
• No
Chooses the sample rate of the digital outputs.
• 48 kHz / 24 bit
• 96 kHz / 24 bit (default)
• 192 kHz / 24 bit
The functionality of the menu items are:
MENU SYSTEM
Display Timeout
Auto Off
Advanced
Exit Menu
Time Display
CD Play Mode
CD-Text Display
6
Link Control
Dig. Out
Sample Rate

Surfaces
Do not use ordinary furniture polish or cleaning agents, as these
usually contain wax or silicone that may cause damage to your
system. Use a micro fiber polishing cloth, dry or slightly dampened
with de-mineralised water to polish the surfaces instead. This
especially applies to products with a high gloss lacquer finish.
Do not attempt to polish out scratches; instead contact your
certified Steinway Lyngdorf dealer.
Changing the remote control batteries
If the SP-1 Stereo Processor does not respond to remote control
commands, it may be because the batteries need to be replaced.
Use a cross-tip (PH1) screwdriver to remove the locking screw
from the battery compartment. The locking screw is at the base of
the remote control. When you have removed the locking screw,
the battery compartment is automatically ejected from the bottom
of the remote control. Remove the used batteries and replace
them with two AAA-size alkaline batteries. Insert the battery
compartment and tighten the locking screw.
Service
Do not attempt to open the product or perform service on the
system yourself. This may cause damage to the system. Contact
your certified Steinway Lyngdorf dealer instead.
MAINTENANCE
7

FCC
This device complies with part 15 and 68 of the FCC rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that
may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment. Equipment marketed to a consumer must
be capable of complying with the necessary regulations in the
configuration in which the equipment is marketed.
CE marking
This product is in conformity with the provisions of the Directives
1999/5/EC and 2006/95/EC.
Waste Electrical and Electronic Equipment (WEEE)
The European Parliament and the Council of the European Union
have issued the Waste Electrical and Electronic Equipment
Directive. The purpose of the Directive is the prevention of waste
of electrical and electronic equipment, and to promote the reuse
and recycling and other forms of recovery of such waste. As such
the Directive concerns producers, distributors, and consumers.
The WEEE directive requires that both manufacturers and end-
consumers dispose of electrical and electronic equipment and
parts in an environmentally safe manner, and that equipment
and waste are reused or recovered for their materials or energy.
Electrical and electronic equipment and parts must not be
disposed of with ordinary household refuse; all electrical and
electronic equipment and parts must be collected and disposed
of separately.
Products and equipment which must be collected for reuse,
recycling, and other forms of recovery are marked with the
pictogram shown.
COMPLIANCE
