Stellar Hearth viewpoint VP-48TP User manual

Direct Vent Gas Fireplace
Installation and Operating Manual
Viewpoint Series
MODEL: VP-48TP Campre Style Log Set
DO NOT DISCARD
These products have been tested and listed for use in
the USA and Canada by:
Underwriters Laboratories,
Northbrook, IL
File #MH48906
Installer: Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
This appliance may be installed in an aftermarket
permanently located, manufactured (mobile)
home, where not prohibited by local codes. A
manufactured home (USA only) or mobile home OEM
installation must conform with the Manufactured
Home Construction and Safety Standard, Title 24
CFR, Part 3280, or when such a standard is not
applicable, the Standard for Manufactured Home
Installations, ANSI/NCSBCS A225.1, or Standard
for Gas Equipped Recreational Vehicles and Mobile
Housing, CSA Z240.4
IMPORTANT: This appliance is only for use with
the type(s) of gas indicated on the rating plate.
An LP conversion kit is available when using Liquid
Propane gas; order separately. — Do not store or use gasoline or other
ammable vapors and liquids in the vicinity
of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier from
a neighbor’s phone. Follow the gas
supplier’s instructions.
• If you cannot reach your gas supplier,
call the re department.
— Installation and service must be performed
by a qualied installer, service agency or
the gas supplier.
WARNING: If the information in these instructions
are not followed exactly, a re or explosion may
result causing property damage, personal injury
or loss of life.
Page 1

INS_VP-48TP_Rev E
Page 2
Listing Label Information & Homeowner Reference
This manual should be read thoroughly before installing or operating the replace.
Installers, please leave manual for the homeowner to use for future reference.
Please have the replace model information available when contacting a dealer or Stellar Hearth for additional
information and service work. The model information regarding your replace can be found on the rating plate located in
the valve control area underneath the burner assembly of the replace.
Once you have located the rating plate, record the following information and keep with your records:
Date Installed:_________________________________
Model Name:__________________________________ Type of Gas:___________________________________
MFG Date:____________________________________
Serial Number:_________________________________ Dealer Purchased From: _________________________
VP-48T
VP-48TP
Note: Your particular rating plate may look di󰀨erent than the plate shown in this example.

Page 3
INS _VP-48TP_Rev E
TABLE OF CONTENTS
Listing Label Information & Homeowner Reference 2
1Safety Information 5
2Commonwealth of Massachusetts Requirements 6
3Specications 7-10
A. Fireplace Dimensions 7
B. Clearances 8
C. Installation Overview 9
D. Placement Clearance Requirements 9
E. Clean Trim Front and Hearth 10
4Prepare The Fireplace 11
A. Stand-O󰀨 Assembly and Installation
5Framing 12-15
A. Wall Enclosure Rough Opening 12
B. Minimum Finished Opening Dimensions 12
C. Horizontal Termination 13
D. Vertical Termination 14
E. Corner Installation 14
F. Nailing Flange Assembly and Installation 15
6Mantel Requirements 16
A. Non-combustible Zone
7Glass Frame Assembly 16-17
A. Remove Glass Frame Assembly 17
B. Install Glass Frame Assembly 17
8STL-FK160 Optional Fan Kit Installation 18
9Thermostat Remote Control Installation 19
10 Gas Line Connection 19
A. Gas Conversion
11 Gas Line Specications 20
A. Specications
12 Venting 21-28
A. Approved Venting 21
5" x 8" M&G Dura-Vent DVA and Metal-Fab Direct Vent System
B. Horizontal Vent System Clearances 21
C. Horizontal Termination 24" Section
Requirement
21
D. Restrictor 21
E. Elbows - Horizontal 21
F. Wall Pass-Through 22
G. Horizontal Terminations 23
H. Corner Terminations 23
J. Vertical Terminations 24
K. Elbows - Vertical 24
L. Horizontal & Vertical Combo Terminations 25
M. Horizontal Cap Location & Clearances 26-27
N. Vertical Cap Location & Clearances 28
13 Finishing 29
14 Optional Liner Kit and Log Set Installation 30-42
A. Optional Liner Kit Installation 30
A.1 Reective Glass Liner 30
A.2 Brick or Ledgestone Liner 30
B. VP-48TP Campre Log Set Installation 31-42
B.1 VP-48TP Campre Log Set Identication 31
B.2 VP-48TP Campre Log Set Installation 32-42
Step 1 - Log 1 32
Step 2 - Log 2 33
Step 3 - Log 3 34
Step 4 - Log 4 35
Step 5 - Log 5 36
Step 6 - Log 6 37
Step 7 - Log 7 38
Step 8 - Log 8 39
Step 9 - Log 9 40
Step 10 - Log 10 41
Step 11 - Clinkers 42

INS_VP-48TP_Rev E
Page 4
TABLE OF CONTENTS
17 Remote Control Operating Instructions 45-50
A. Remote Control Icon Identication 45
B. Remote Control Information 45
C. Continuous Pilot - Cold Conditions 46
D. Operation Using Battery Power 46
E. Matching Security Codes 46
F. Initial Set-Up 47
G. Gas Type Conversion 47
H. Celsius/Fahrenheit Conversion 47
I. Important Safety Feature 47
J. Continuous Pilot Feature 47
K. Childproof Feature 47
L. Manual Mode 48
M. Fan Mode 48
N. Lighting Mode 48
O. Flame Mode 49
P. Thermostat Mode 49
Q. Set The Day And Time Display 50
R. System Operation Without Handheld Remote 50
18 Lighting & Shutdown 51-52
A. Lighting 52
B. Turning O󰀨 Gas To Fireplace 52
19 Pressure Testing 53
20 Error Codes 54
A. Ignition Safety 54
B. Sensor Safety 54
C. Thermal Safety 54
D. Communication Safety 54
21 Finalizing The Installation 55-56
A. Flame Appearance 55
B. Factory Set Venturi Settings 55
C. Burner Tube Venturi
Adjustment Guidelines 55
D. To Adjust Burner Venturi 55
E. Restrictor Usage 56
F. Restrictor Troubleshooting 56
G. Restrictor Installation/Modication 56
22 Maintenance 57
MA. IP Board System 57
B. Fan 57
C. Vent System 57
D. Glass Cleaning & Replacement 57
23 Troubleshooting 58-59
A. Main Control Module Will Not Work 58
B. Pilot Will Not Light/Stay Lit 58
C. Pilot Flame Always On/Will Not
Extinguish 58
D. Pilot Burner But Ignitor Continues
To Spark
58
E. Main Flame Will Not Light 59
F. Flame Height Adjustments Not Working 59
G. Room Temp Display On
Remote Not Correct 59
H. Fireplace Will Not Respond In
"Thermo" Mode 59
24 LPCK-VP48TP Conversion Kit Instructions 60-62
A. Prepare The Fireplace 60
B. Convert Pilot Assembly 60
C. Replace Burner Orice 60
D. Gas Type Conversion 61
E. Convert Gas Control Valve 61
F. Complete The Conversion 61
G. Testing For Leaks 62
H. Inlet Pressure Test 62
25 Replacement Parts 63
Replacement Parts List 63
Lifetime Limited Warranty 64
15 Valve & Pilot Assembly Components 43-44
A. Valve Wiring Schematic 43
B. IPI Pilot Assembly 44
C. IPI Gas Valve 44
16 Control Module Components 44
A. Main Control Module 44
B. Extension Module, Battery Back-up
& AC Adaptor 44

Page 5
INS _VP-48TP_Rev E
1 - SAFETY INFORMATION
This replace has been tested to and complies with ANSI Z21.50a-2014·CSA 2.33a-2014
“VENTED GAS FIREPLACE” by Underwriters Laboratories, Northbrook, IL.
Installation must conform with local building codes or in the absence of local building codes,
with the National Fuel Gas Code, ANSIZ223.1/NFPA 54 - Current Edition, or
the Natural or Propane Installation Code, CSAB149.1
• Installation and repair should be done only by a qualied service person. The appliance should be inspected by a
qualied service person before use. Annual inspection by a qualied service person is required to maintain warranty. More
frequent cleaning may be required due to excessive lint from carpeting, bedding materials, etc. It is imperative that control
compartments, burners and circulation air passageways of the appliance be kept clean.
• If this appliance is installed directly on carpeting, tile or other combustible material other than wood ooring, the appliance
shall be installed on a metal or wood panel extending the full width and depth of the appliance.
• Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or
clothing ignition.
• Young children should be carefully supervised when they are in the same room as the appliance. Toddlers, young children
and others may be susceptible to accidental contact burns. A physical barrier is recommended if there are at risk individuals
in the house. To restrict access to a replace or stove, install an adjustable safety gate to keep toddlers, young children and
other at risk individuals out of the room and away from hot surfaces.
• Clothing or other ammable material should not be place on or near the appliance.
• Adequate accessibility clearances for servicing and proper operation must be maintained.
• This appliance must not share or be connected to a chimney ue serving any other appliance.
• Keep area around the appliance clear of combustible materials, gasoline and other ammable vapor and liquids.
• The ow of combustion and ventilation air must not be obstructed.
• Due to high temperatures the appliance should be located out of tra󰀩c and away from furniture and draperies.
• The glass front or any part removed for servicing the appliance must be replaced prior to operating the appliance. Work
should be done by a qualied service technician.
• Clean glass only when cool and only with non-abrasive cleansers.
• Do not operate this appliance with the glass/frame assembly removed, cracked or broken. The glass assembly, part #
STL-011-044 shall only be replaced as a complete unit, as supplied by Stellar Hearth Products. Replacement of the glass
assembly must only be performed by a licensed or qualied service person. DO NOT SUBSTITUTE MATERIALS.
• Do not strike or slam glass assembly.
• A barrier designed to reduce the risk of burns from the hot viewing glass is provided with this appliance and shall be installed
for the protection of children and other at-risk individuals.
• If the barrier becomes damaged, the barrier shall be replaced only with the manufacturer's barrier for this appliance.
• Any barrier removed for servicing the appliance must be replaced prior to operating the appliance.
• Under no circumstances should any solid fuel (wood, coal, paper or cardboard etc.) be used in this appliance.
• Keep burner and control compartment clean.
• Do not use this replace if any part has been under water. Immediately call a qualied service technician to inspect this
appliance and to replace any part of the control system and any gas control which has been under water.
