stellar labs 33-11625 User manual

A/V MediaConverter
VGA+L/RAnalogAudio
toHDMI
Model#33-11625
TableofContents
1.0Introduction……………………………………………….....2
2.0Specifications…………………………………………..……2
3.0PackageContents…………………………………………...3
4.0Panel Descriptions…………………………………….........4
5.0Connection andOperation…………………….…....…….4
DistributedExclusivelyby
MCMElectronics
www.mcmelectronics.com

VGA+L/R Audioto HDMIConverter
Model #33-11625
2
VGA+L/RAudiotoHDMI Converter
Dearcustomer
Thankyoufor purchasingthis product.For optimumperformanceandsafety,
pleasereadtheseinstructionscarefullybefore connecting,operatingor
adjustingthis product. Pleasekeepthis manual for future reference.
1.0INTRODUCTION
This deviceconvertsVGAinputintoHDMIandallowsPCuserstoenjoytheir
largerimageonTV.Additionally,L/R analog audiois added totheHDMI
stream. It is ideal for userswithaneedtoconnect laptops orPC’s tonewer HD
monitorsandprojectors.
1.1FEATURES
This HDMIconverter hasmanyfeaturesthatenableittoperforminasuperior
manner. Theseinclude:
lInstalls inseconds, nosetuprequired.
lConvertPC’sVGAvideoandR/LaudiointocompleteHDMIsignal.
lSupportshighestvideoresolution1280x1024.
lSupports165MHz/1.65Gbps per channel(6.75Gbps all channel)
bandwidth.
lSupports8bit perchannel(24bitall channel)deepcolor.
2.0SPECIFICATIONS
Signal Inputs/Output
InputVideoSignal 0.5-1.0volts p-p
InputDDC Signal 5volts p-p (TTL)
Output Video HDMI 1.2a
VGAResolution 640x48060Hz75Hz
800x60060Hz75Hz
1024x76860Hz75Hz
1280x72060Hz75Hz
1280x76860Hz75Hz
1280x96060Hz75Hz
1280x102460Hz75Hz
OperatingFrequency
Vertical FrequencyRange 50/60Hz
VideoAmplifier Bandwidth 1.65Gpbs/165MHz
Mechanical
Size(mm) 88 (W)x 25.5(H)x 68 (D)
Weight(Net) 0.68kgs

VGA+L/R Audioto HDMIConverter
Model #33-11625
3
Warranty
Limited Warranty 1YearParts andLabor
Environmental
Operating Temperature 0 to+70
Operating Humidity 10%to85%RH (nocondensation)
StorageTemperature -10 to+80
StorageHumidity 5%to95%RH(no condensation)
PowerRequirement
External PowerSupply 5VDC@2A
Power consumption(Max) 5W
RegulatoryApprovals
Converter Unit FCC,CE,
Power Supply CE,FCC
Accessories
AC Power Adapter USstandard
UserManual
Note:Specificationsaresubjecttochangewithout notice.
3.0PACKAGECONTENTS
Beforeattempting tousethis unit,pleasecheck thepackagingand makesure
the followingitems arecontainedintheshippingcarton:
lMainunit.
l5VDC PowerSupply
lUser's Manual

VGA+L/R Audioto HDMIConverter
Model #33-11625
4
4.0PANELDESCRIPTIONS
Pleasestudythe paneldrawings belowandbecomefamiliar withthesignal
input(s),output(s)andpowerrequirements.
INPUT
R/L
VGA
OUTPUT
DC/5V HDMI
5.0CONNECTION AND OPERATION
Beforeinstallation,pleasemakesureall devicesyouwishtoconnecthave
been turned off.
1)Connectthe VGAvideoand R/Laudiofromcomputer tothisproduct.
(Inputcablesareoptional)
2)Connectthe HDMIoutputfromthis product totheTVwhichhas HDMI
input.
3)Connectthe VGAandR/Laudiooutput of this producttothe
computer’smonitor and speaker if necessary.
4)Insertthe DCsideof5vpower supply intothis product andthenconnectthe
AC sideof thepowersupplyintothe wall outlet.
5)Power on the computerandTV,choosetheinputofTVtoits HDMI
channel.
6)The image doesnot needtobeadjusted. ThisConverter will
position it automatically.
Attention:Insert/ Extractcablesgently.

VGA+L/R Audioto HDMIConverter
Model #33-11625
5
5.1CONNECTION DIAGRAM
P/N1002
