stellar labs DI-50 User manual

1
Active DI Box
Model: DI-50
www.mcmelectronics.com
MCM Item#555-11012

2
Safety Information
The lightningboltwithina
triangleis intended toalertthe
user tothe presenceof
dangerous voltage levelswithin
the product’senclosure.
Thisvoltage maybe ofsufficient
magnitude toconstitutean
electricshock risk.
Toreducethe riskofelectricshock,do
not removecover ofthis device. There
are no user serviceablepartsinside.
Refer servicing onlytoqualified service
personnel.
The exclamation point withinatriangleisintended toalertthe
user toimportant operatingand maintenance(servicing)
instructions intheliterature accompanying the appliance.
SafetyPrecautions
•Read and retaintheseinstructions
•Followall instructions and heed warnings
•Do not usethisdevicenear water
•Ifthe surfacebecomes dirty,cleanonlywithdrycloth, donotusesolvents orthinners
•Install inaccordancewiththemanufacturer’s instructions
•Do not install near heat sources suchasradiators, heat registers,stoves,or other devicesthat produceheat
•Onlyuseaccessories specified bythe manufacturer
•Refer all servicingtoqualifiedpersonnel
•Thisdevicemust not beexposedtowater inanyway. No objectfilled withliquidsshouldbe placed onapparatus
Stellar Labs ActiveDIBox
Designed foruseon stage orin thestudio theStellarLabs DI-50 has been designed forlow noisesignalconversion.
Features
•9V Battery or18-48V phantompoweroperation
•On/Offswitch
•-20dB padforsignalattenuation
•6.35mm (¼”)&unbalancedXLRinput’swith parallel 6.35mm (¼”)outputunbalanced output
•Balanced XLRoutput
•Rugged metalchassiscompletewith rubbercorners

3
Operation:
1) PowerIndicator
Thepower indicatorwillilluminatewhen theDIbox is switched on andoperationalfrom a18-48Vphantom power
source. When used with a9VPP3 battery thepower indicatorwill flash.
2) PowerSwitch
On/Off control. Movetheswitch do theON position to switch on theunit. Switch off after useto preservebattery life.
3) GroundLift
Thegroundlift switch can beused to prevent earth loops within thesystem. Hums caused by groundloops often
occuraround50Hz. Movetheswitch to theUP(LIFT)position.
4) BalancedXLR Output
Standard 3-pin XLRbalancedoutput. Pin 1 GND, pin 2 +vesignal(Hot), pin 3 –vesignal(Cold). Connect theoutput
of theDIbox to yourmixingconsole’s balanced XLRmicinput takingcare to usegoodquality 2-core screened cable
with all pins wired. To prevent any noise, clicks orpops themixingconsole’s input channel shouldbe muted before
theconnection is made.

4
5) 9VBatteryCover
Unscrew thethumbscrew in an anti-clockwisedirection. Usegoodquality Alkaline9VPP3 cell batteries forlong
operationallife. If usingtheDIbox with phantom power thebattery circuit will automatically switch off.
6) PAD(Attenuation)
When usingtheDIbox with linelevel sources it may often be necessary to reducetheinput gain – theswitchable
PADprovides 20dBof attenuation. Movetheswitch tothedown position to activatethePAD. ThePADshouldonly be
used when theDI-50 distorts internally, if thedistortion is generated within themixingconsole theinput gain on the
console shouldbe adjusted.
7) Signal Input
Unbalanced 6.35mm (¼”)mono jack socket suitable forusewith instruments, keyboards orlinelevelsources.
Connections shouldbe wiredTIP= PositiveandRING = NEGATIVE
8) Signal Input
Unbalanced XLRsocket suitable forusewith instruments, keyboards orlinelevelsources. This input is wiredin
parallel with the6.35mm (¼”).
9) LinkOutput
Unbalanced 6.35mm (¼”)mono jack socket forlink output to aguitaramplifier etc. This input is wiredin parallel
with the6.35mm (¼”).
Technical Specification
•FrequencyResponse:10Hz~40kHz
•Noise:105dB
•THD+N@1kHz:<0.005%
•Input Impedance:>250k
•LoadImpedance:>600
•BatteryType:9V (alkalinerecommended)
•Dimensions:5.91”x2.16”x4.53”
•Weight:1.3lbs.
Compliance
Whenthisproductreachestheendof itslife,donotdisposewith householdwaste.Dispose ofStellarLabsproductsinan
environmentally soundfashion, contactMCMElectronicsfor moredetailsat www.mcmelectronics.com.
Warranty
StellarLabsproductsarewarranted,by MCM Electronics,againstmanufacturerdefectsfor aperiod ofoneyearfromtheoriginal date
of purchase.Thiswarrantyislimitedtomanufacturerdefects,in eithermaterialsorworkmanship.MCMElectronics nor anyother
worldwidedivisionsofPremierFarnell PLC,isnotresponsiblefor anyconsequentialor inconsequential damagetoanyother
component, structureorthecostof installationorremovalof saiditems.Defectiveitemsshouldbereturnedtotheretailerfrom
whomtheywereoriginally purchased.
Thiswarrantywill notcoverdamageduetoimproperuse suchas(andnotlimitedto)damagedcones,mountingframes,voice coils
oritemsdamagedbyweatherincluding exposuretomoisture.
Forquestionsorspecificinformationregardingwarrantyreplacement orrepair,contact: STELLARLABS
www.mcmelectronics.com
