Stiga Collector 53 S Combi
23-5281-22
COLLECTOR 53 S COMBI
• Multiclip or collect in the same machine without changing the
blade.
• 4 hp LS 45 engine from Briggs & Stratton.
• Multiclip by insert.
• Collect by bag.
• Instruction video comes with every machine.
• Conforms with the Californian emission levels 2002.
• Available push, self-propelled S and self-propelled with electric
start SE.
• Noise effect 97 dB(A) measured average. New European noise
regulations is below 100 valid from July 2001

Collector 53 S Combi (23-5281-22)
MOTOR
Brand B& S LS 45 CARB 2002
Power 4,0 hp, 3 kW
Number of revolutions 3000 rpm
WHEELS
Type of wheels Non PVC wheels with double ball bearings
Wheel size Front 175, rear 190 mm
Driving Rear self-propelled
CUTTING SYSTEM
Type of cutting system Collecting. High impact PP bag 65 l. Mulching by plug.
Cutting heights 5 heights from 27,36,45,56,67 mm
Cutting width 51cm
Cutting height adjustment Central springloaded
VIBRATIONS & NOISE LEVEL
Noise effect 97dB(A)
CONTROLS
Handlebar Ergo handle adjustable up and down 2 positions
COLOUR & MATERIAL
Colour of chassis Yellow UV-stabilized polyester powder coating
Material of chassis Steel, new reinforced
MEASURES & WEIGHT
Gross weight 38 kg
Package size W*H*L 815x560x495 mm
Units on pallet 8
OTHER FACTS
Owner's Manual 1136-1303-01
EAN bar code 731 332 230 002 8
Other Combi; mulching, collecting or free discharge
