Stirling STR-SSDW14 User manual

AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Model Number STR-SSDW14
Stainless Steel Dishwasher
INSTRUCTION MANUAL

2AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Welcome
Congratulations on choosing to buy a STIRLING®product.
All products brought to you by STIRLING®are manufactured to the highest
standards of performance and safety and, as part of our philosophy of customer
service and satisfaction, are backed by our comprehensive 3 Year In Home
Warranty. We hope you will enjoy using your purchase for many years to
come.

3
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Contents
02 Welcome
04 Warranty Details
05 General Safety Instructions
08 Product Overview
11 Installation
15 Getting Started
16 Features
18 Instructions
28 FAQs and Troubleshooting Guide
32 Other Useful Information
39 Repair and Refurbished Goods or Parts Notice

4AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Stainless Steel Dishwasher
Warranty Details
The product is guaranteed to be free from defects in workmanship and
parts for a period of 36 months from the date of purchase. Defects that
occur within this warranty period, under normal use and care, will be
repaired, replaced or refunded at our discretion. The benefits conferred by
this warranty are in addition to all rights and remedies in respect of the
product that the consumer has under the Competition and Consumer Act
2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and to compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION

5
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
General Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before first use, even if you are familiar with this type
of product. The safety precautions enclosed herein reduce the risk of fire, electric
shock and injury when correctly adhered to. Keep the manual in a safe place for future
reference, along with the completed warranty card and purchase receipt. If applicable,
pass these instructions on to the next owner of the appliance.
Always follow basic safety precautions and accident prevention measures when
using an electrical appliance, including the following:
Pay particular attention to safety messages that follow the words:
DANGER, WARNING and CAUTION.
These words are used to alert you to a potential hazard that can seriously
injure you and others. The instructions will tell you how to reduce the chance
of injury and let you know what can happen if the instructions are not followed.
DANGER means that failure to read this safety statement may result in severe
personal injury.
WARNING means that failure to read this safety statement may result in
extensive product damage or serious personal injury.
CAUTION means that failure to read this safety statement may result in
minor or moderate personal injury, property or equipment damage.
Electrical safety and cord handling
• Voltage: Before connecting and turning on the appliance, ensure the electrical voltage
and circuit frequency correspond to those indicated on the appliance rating label.
• WARNING! Ensure the outlet is properly earthed to the ground. If unsure, consult
a qualified electrician or a service representative. Improper connection of the
equipment grounding conductor can result in the risk of an electric shock if the
appliance malfunctions.
• WARNING! Do not modify the cord and plug provided with the appliance; if it does
not fit the outlet, have a proper outlet installed by a qualified electrician.
• WARNING! If the supply cord is damaged, do not use the appliance. A damaged
cord must be replaced by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard. Contact our after sales support centre.
• Connection: Do not use an adaptor; do not use an extension cord. We recommend
you connect the appliance to a separate circuit serving only this appliance.
• Power cord: Do not kink or damage the power cord. Position it out of the way so
no one steps on or places anything on the cord or against it.

6AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
General Safety Instructions (Cont.)
• Inserting/removing the plug: Before you insert or remove the plug, make sure
the appliance is switched off and the power is switched off at the electrical outlet.
Remove by grasping the plug, do not pull on the cord.
• CAUTION! To reduce the risk of electric shock, do not immerse the unit, cord or
plug in water or other liquid. Do not expose it to rain or moisture.
• Auto switch off: To save energy, in standby mode the appliance will switch off
automatically when there is no operation in 30 minutes.
• RCD: Unless your home is already fitted with a residual current device (safety
switch), we recommend installing an RCD with a rated residual operating current
not exceeding 30mA to provide additional safety protection when using electrical
appliances. See your electrician for professional advice.
Installation
• WARNING! Do not install the dishwasher yourself. Have it installed by an
appropriately qualified, licensed plumber or dishwasher installer only.
• WARNING! Any electrical work required for the installation of this dishwasher
should be carried out by a qualified, licensed electrician.
• Power supply cord: During installation, the power supply cord must not be
excessively or dangerously bent or flattened. Do not tamper with the controls.
• Safe disposal: When removing an old dishwasher from service or discarding it,
remove the door to the washing compartment.
• Hose sets: Only use new hose sets when connecting this dishwasher to the water
supply; do not reuse old hoses.
• Water pressure: The maximum permissible inlet water pressure is 1MPa. The
minimum permissible inlet water pressure is 0.04MPa.
• Flammable objects: Do not install the appliance on or near any flammable or hot
objects.
• Ventilation: If there are any ventilation openings in the base, make sure they are not
obstructed by carpet.
• Proper installation: Install the dishwasher on an even, flat and stable ground. Do
not operate your dishwasher unless all enclosure panels are properly in place.
Usage conditions and restrictions
• Domestic use only: This appliance is intended for indoor household use only. It is
not suitable for industrial, commercial or trade use. Do not use it for anything other
than its intended purpose, and only use it as described in this manual.
• Usage restriction: The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.

7
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
General Safety Instructions (Cont.)
• Children should be supervised to ensure they do not play with the appliance. Close
supervision is necessary when any appliance is used by or near children.
• WARNING! Never leave the appliance unattended while in use.
• Dishwasher door: Do not abuse, sit on or stand on the door or dish rack of the
dishwasher, or use it for anything other than its intended purpose. Do not place
any heavy objects on the dishwasher door when it is open. The appliance could tip
forward.
Open the door very carefully if the dishwasher is operating as there is a risk of
water squirting out.
The door should not be left wide open as this could increase the risk of someone
tripping over the door.
• Safe loading: Do not overload this dishwasher, it has a maximum capacity of 14
place settings. To ensure safe operation, follow a few simple rules when loading the
dishwasher:
—Place sharp items so they are not likely to damage the door seal.
—Place long bladed knives and other utensils with sharp points with their points
down in the basket or in a horizontal position to avoid potential hazards.
—Only wash plastic items that are marked dishwasher safe or the equivalent. For
plastic items not marked, check the manufacturer’s recommendations.
• Dishwasher detergent: Use only detergent and rinse additives designed for an
automatic dishwasher and keep them out of reach of children. Never use liquid
detergent (for manual washing up), soap or laundry detergent in your dishwasher.
DANGER! Some dishwasher detergents are strongly alkaline and can be extremely
dangerous if swallowed. Avoid contact with the skin and eyes.
DANGER! When the door of the dishwasher is open, make sure to keep children
away from the dishwasher. Even after a wash there could still be detergent left
inside. Make sure that the detergent compartment is empty after completion of the
wash cycle.
• Cleaning: Unplug before cleaning and performing maintenance on the appliance.
Use a soft cloth moistened with mild detergent for cleaning the appliance, and then
use a dry cloth to wipe it again.
• Do not modify or not attempt to alter this appliance or its controls in any way.
• Repair: Do not attempt to take the unit apart. Apart from regular maintenance as
described in this manual, this appliance is not designed to be dismantled by the
user. In case of damage or malfunction, have the unit repaired by trained personnel
only, or contact the after sales support line for advice.
• Misuse: Inappropriate use can result in property damage, injury or death. We
assume no liability for misuse of the appliance or noncompliance with these
instructions.

8AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Product Overview
Scope of delivery
Dishwasher: front view, open
1 Cutlery rack
2 Upper basket
3 Upper spray arm
4 Inner pipe
1
2
1
3
4
5
6
7
8
9
5 Lower basket
6 Detergent dispenser
7 Rinse aid dispenser
8 Cutlery basket
9 Cup rack (foldable)

9
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
NOTE: Due to continued product improvement, images and illustrations in this manual
may vary slightly from the product purchased. All images in this manual are for reference
purposes only. Parts are not necessarily pictured to scale.
Product Overview (Cont.)
Documentation (not pictured)
Instruction manual
Quick start guide
Warranty card
Dishwasher: rear view
10
12
11
10 Drain hose
11 Water supply hose
12 Power cord and plug

10 AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Control panel
K
AJD
BCH
E
FG
Product Overview (Cont.)
Operation buttons
A POWER Press this button to enter or exit the ready-to-use state, the
screen will light up.
B PROGRAM Press this button to select the appropriate washing program,
the selected program indicator will light up.
CEXTRA
DRYING
Press this button to have dishes dried more thoroughly. (It
can only be used with the Intensive, Heavy, Eco, Glass and
90 mins programs.)
D HALF LOAD
Choose this function when you only have a small load (about
6 place settings or less) to wash, to save energy and water. (It
can only be used with the Intensive, Heavy, Eco, Glass and
90 mins programs.)
E CHILD LOCK
This option allows you to lock the buttons on the control panel
so children cannot accidently start the dishwasher. Only the
POWER button remains active.
To lock or unlock the control panel buttons, press and hold the
HALF LOAD + DELAY buttons for 3 seconds simultaneously.
F DELAY TIMER Press this button to set the delayed hours for washing. You can
delay the start of washing up to 3/6/9 hours.
GSTART/PAUSE Press this button to start the selected washing program or
pause it when the dishwasher is working.
Display indicators
HIntensive, Heavy, Eco, Glass, 90 mins, Rapid wash program indicators
IHalf load and Extra Drying indicators
J
Child lock indicator: illuminates when the child lock is set
Rinse aid indicator: illuminates when a rinse aid refill is required
Progress indicator: illuminates when the program has finished
KDelay time indicator: shows the delay time (3h/6h/9h)
I

11
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Installation
DANGER! Make sure your electrical power is disconnected before installing the
dishwasher. Failure to do so can result in death or electric shock.
IMPORTANT! All relevant pipes and electrical equipment should be installed by
licensed plumbers, electricians or dishwasher installers. Make sure
to use new water supply and drain hoses; do not use old hoses.
IMPORTANT! Read this manual to familiarise yourself with all parts and operating
principles. Pay particular attention to the safety instructions.
Unpacking the appliance
• This product has been packaged to protect it against transportation damage.
Unpack the appliance but keep all packaging materials until you have made sure
your new dishwasher is undamaged and in good working order.
• The packaging carton is recyclable. Whenever possible, reuse the carton and
recycle it when disposing of the packaging materials.
• Plastic wrapping can be a suffocation hazard for babies and young children, so
ensure all packaging materials are out of their reach, and dispose of them safely.
• The baskets inside the dishwasher are taped to secure them during transport.
Remove any tape, ties and foam padding from inside the dishwasher.
• IMPORTANT! Using the loading instructions on pages 18–21 for guidance, make
sure all parts in the upper and lower baskets are properly installed inside the
dishwasher – you may need to relocate the cup/cutlery rack for appropriate usage.
• Unwind the cord to its full length and inspect it for damage. Do not use if damaged.
In case of damage, contact our after sales support centre for advice.
Positioning the appliance
• This dishwasher is freestanding. It can also be recessed under a single benchtop.
• Position the dishwasher close to an existing water inlet and drain connection and
make sure there is a power point nearby, or in an adjoining cabinet.
• The back should rest against the wall behind it and the sides along any adjacent
cabinets or walls.
• The dishwasher’s water supply and drain hoses can be positioned either to the
right or left sides to facilitate proper installation.
• Make sure the appliance does not stand on any water hoses or the power cable.

12 AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Levelling the appliance
• Position the dishwasher on a level and sturdy floor.
• If the floor is uneven, adjust the adjustable feet until
it reaches a horizontal position; just screw the feet
in or out a little (Fig. 1).
• The appliance should not be inclined more than 2°.
• Correctly levelled, the appliance will be more stable
and much less likely to move or cause vibrations
and noise during operation.
Freestanding installation
Between existing cabinets
• The height of the dishwasher, 845mm, has been
designed in order to allow the machine to be fitted
between existing cabinets of the same height in
modern fitted kitchens (Fig. 2). The feet can be
adjusted so that the correct height is reached.
• The laminated top of the machine does not require
any particular care.
Underneath an existing worktop
• In most modern fitted kitchens there is only
one single worktop under which cabinets and
electrical appliances are fitted. If you want to fit
this dishwasher under an existing worktop, you
need to remove the worktop of the dishwasher by
unscrewing the screws under the rear edge of the
top (Fig. 3: a).
IMPORTANT! Keep the screws! After removing the
worktop you will have to screw them back under
the rear edge of the top (Fig. 3: b).
• The height of the dishwasher will then be reduced
to 815mm (as per ISO regulations), which means it
should fit perfectly under your kitchen worktop.
Installation (Cont.)
Fig. 1
Fig. 2
Fig. 3

13
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Installation (Cont.)
Cold water connection
• Connect the cold water supply hose to a threaded 3/4”
connector. During use, the dishwasher will heat up the
water to the required temperature. Make sure the hose is
not kinked or squashed and is fastened tightly in place
(Fig. 4).
• If the water pipes are new or have not been used for
an extended period of time, let the water run to make sure it is clear and free of
impurities. This step is necessary to avoid the risk of the water inlet being blocked
and damaging the appliance.
• WARNING! Always close the water tap after using the dishwasher.
Drain hose connection
• The drain hose must be connected to the drain hose connector at the back of the
dishwasher. Insert the drain hose into a drain pipe with a minimum diameter of
40mm, or let it run into the sink, making sure to avoid bending, crimping or squashing
it. The height of drain pipe must be less than 1000mm from the floor. The free end of
the hose must not be immersed in water to avoid the backflow of water.
• Follow the illustration below (Fig. 5) when installing the drain hose connection
according to option Aor B.
• The drain hose must be correctly fitted in order to prevent water leaks. It should be
connected at a height of no more than 1m (maximum) and secured with a hose clip.
• If you need to drain any excess water from hoses and the sink is higher than 1m
from the floor, you will need to drain the excess water into a bowl or container held
underneath the pipe and lower than the sink.
• If you need a drain hose extension, make sure to use a similar hose that is no longer
than 4 metres, otherwise the cleaning effect of the dishwasher could be reduced.
Fig. 4
Fig. 5
Benchtop
Drain hose
Water inlet
Drain pipe
Mains cable
Back of dishwasher
max. 1000mm
∅ 40mm

14 AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Electrical connection
Make sure that the electrical voltage and circuit frequency in your home correspond to
those indicated on the appliance rating label and that the electrical system is sized for
the maximum voltage on the rating plate. This appliance requires a 10A fused, copper-
wired electrical supply. A time delay fuse or circuit breaker is recommended, as well
as provision of a separate circuit serving only this appliance. A suitable power outlet
should be located in an adjacent cabinet.
To connect the dishwasher, insert the plug into a properly earthed, easily accessible
electrical socket. If the socket is not appropriate for the plug, replace the socket rather
than use an adaptor or the like as such devices could cause overheating and burns.
Installation (Cont.)
WARNING!
• Do not use an extension cord or an adaptor with this appliance.
• Do not bend the power cord. Do not place the appliance on top of the cord.
• Do not modify the plug provided with this appliance. If it does not fit into your
power point, have a suitable outlet installed by a qualified electrician.
Earthing
This appliance must be earthed. In the event of a malfunction or breakdown, earthing
will reduce the risk of an electric shock by providing a path of least resistance for the
electric current. This appliance is equipped with a cord having an equipment-earthing
conductor and an earthing plug. The plug must be plugged into an appropriate outlet
that is installed and earthed in accordance with all local standards and requirements.
WARNING!
• Ensure the outlet is properly earthed to the ground. If unsure, consult a qualified
electrician or a service representative. Improper connection of the equipment
grounding conductor can result in the risk of an electric shock if the appliance
malfunctions.
• Do not, under any circumstances, cut or remove the third grounding prong from the
power plug.
Before first use
After your new dishwasher has been installed, and before using it for the first time,
make sure to check the following points to ensure safe and efficient operation:
• Is the dishwasher level and properly installed?
• Is the water tap open?
• Are the hose connections secured tightly and there is no leakage at either end?
• Are all electrical cords tightly connected?
• Is the power switched on at the power point?
• Are the inlet and drain hoses free of knots and kinks?
• Has all packing material been removed from the dishwasher?
• Is all product documentation stored safely for easy access?

15
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Quick operation guide
For detailed operating instructions, please read the corresponding content in this manual.
Getting Started
Install the dishwasher
Please refer to the “Installation” section on pages 11–14 in this manual. Make sure the water
tap is open.
Load the baskets
Load the baskets following the dishwasher
loading instructions on pages 18–21.
Prepare the dishes
Scrape off leftover food and soften burnt
food residues with water.
Fill/check the dispensers
Fill dishwasher detergent into the dispenser
compartment and ensure there is liquid
rinse aid in the dispenser (this is not neces-
sary if you use a detergent with rinse aid).
Select a program and run the dishwasher
Close the door and press the PROGRAM
button, then press START/PAUSE to start
the program. At the end of the program, wait
about 15 minutes before unloading.

16 AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Features
Wash programs and cycles
* This program was used for testing the appliance to the Australian standard AS/NZS
2007.1 (tested with 14 place settings, rinse aid setting on 6, upper basket with the
upper set of wheels on the rail support, and the door slightly opened (about 5cm) at
the end of the program to assist with drying of the dishes).
Program Suitability Cycles Detergent (pre/main) Running Time (min.) Energy (kWh) Water (L)
Intensive For the most heavily soiled loads,
such as pots, pans, casserole
dishes and dishes that have been
sitting with dried food on them
for a while.
Prewash (50ºC)
Wash (60ºC)
Rinse
Rinse
Rinse (65ºC)
Drying
5 / 27.5g
(or all-in-1) 170 1.6 18.5
Heavy
For heavily soiled loads, such
as pots, plates, cups, bowls and
serving dishes.
Prewash (45ºC)
Wash (55ºC)
Rinse
Rinse (65ºC)
Drying
5 / 27.5g
(or all-in-1) 160 1.4 15
ECO *
For normally soiled loads, such
as plates, glasses, bowls and
lightly soiled pots and pans: the
recommended daily wash program.
Prewash
Wash (45ºC)
Rinse (50ºC)
Drying
5 / 27.5g
(or all-in-1) 175 0.87 12.7
Glass
For lightly soiled loads, such as
glasses and fine china.
Prewash
Wash (42ºC)
Rinse
Rinse (60ºC)
Drying
5 / 27.5g
(or all-in-1) 125 0.9 14.5
90 mins
For lightly soiled loads that need
a quick wash.
Wash (65ºC)
Rinse
Rinse (65ºC)
Drying
25g
(or all-in-1) 90 1.2 11.5
Rapid
A shorter wash for lightly soiled
loads that do not need drying.
Wash (40ºC)
Rinse
Rinse (45ºC)
25g 30 0.6 11.5

17
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Program Suitability Cycles Detergent (pre/main) Running Time (min.) Energy (kWh) Water (L)
Intensive For the most heavily soiled loads,
such as pots, pans, casserole
dishes and dishes that have been
sitting with dried food on them
for a while.
Prewash (50ºC)
Wash (60ºC)
Rinse
Rinse
Rinse (65ºC)
Drying
5 / 27.5g
(or all-in-1) 170 1.6 18.5
Heavy
For heavily soiled loads, such
as pots, plates, cups, bowls and
serving dishes.
Prewash (45ºC)
Wash (55ºC)
Rinse
Rinse (65ºC)
Drying
5 / 27.5g
(or all-in-1) 160 1.4 15
ECO *
For normally soiled loads, such
as plates, glasses, bowls and
lightly soiled pots and pans: the
recommended daily wash program.
Prewash
Wash (45ºC)
Rinse (50ºC)
Drying
5 / 27.5g
(or all-in-1) 175 0.87 12.7
Glass
For lightly soiled loads, such as
glasses and fine china.
Prewash
Wash (42ºC)
Rinse
Rinse (60ºC)
Drying
5 / 27.5g
(or all-in-1) 125 0.9 14.5
90 mins
For lightly soiled loads that need
a quick wash.
Wash (65ºC)
Rinse
Rinse (65ºC)
Drying
25g
(or all-in-1) 90 1.2 11.5
Rapid
A shorter wash for lightly soiled
loads that do not need drying.
Wash (40ºC)
Rinse
Rinse (45ºC)
25g 30 0.6 11.5
Features (Cont.)

18 AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Loading the dishwasher
For best performance of your dishwasher, follow the loading guidelines in this manual.
ATTENTION: Before loading the dishwasher baskets:
It is not necessary to rinse the dishes under running water before you put them into
the dishwasher. However, we recommend you scrape off any large amounts of leftover
food and soften remnants of burnt food in pots and pans.
Place objects in the dishwasher in the following way:
• Hollow items such as cups, glasses, pots, pans, etc. should be placed upside
down so water cannot collect in the container or in a deep base.
• Curved items, or items with recesses, should be loaded at a slant so water can run off.
• All utensils should be stacked securely so they cannot tip over.
• All dishes and utensils should be placed in a way so the spray arms can rotate
freely during washing.
• Very small items should not be washed in the dishwasher as they could easily fall
out of the baskets and obstruct moving parts.
• Dishes and items of cutlery should not lie inside one another, or cover each other.
• To avoid damage to glasses, they must not touch.
• WARNING! Long bladed knives stored upright are a potential hazard! Always position
these and other sharp cutlery items horizontally on the cup/cutlery racks.
• Do not overload your dishwasher; it will hold a maximum of 14 standard place settings.
This is important for better washing results and lowers energy consumption.
• WARNING! Do not pull out the upper and lower basket at the same time, which
can lead to the appliance tipping forward.
Protecting your glass and tableware
Much of today’s tableware is dishwasher safe. However, not everything can be
washed safely in a dishwasher. The chemical composition of your dishwasher deter-
gent or the water temperature and duration of the wash program may adversely affect
some materials. To protect your special cutlery, glass and tableware from damage,
select a wash program with as low a temperature as possible (see pages 16–17 for
program details).
We recommend you do not wash in a dishwasher the items listed below, and take
special care with items deemed of limited suitability. And when buying new dishes,
glassware, porcelain or cutlery, look for products labelled dishwasher safe.
Not suitable for the dishwasher: cutlery with wooden, china or mother-of-pearl
handles; plastic items that are not heat resistant; older cutlery with glued parts that
are not temperature resistant; bonded cutlery items or dishes; pewter or copper items;
lead crystal glass; steel items subject to corrosion (rusting); wooden platters.
Of limited suitability: some types of glasses can become dull with frequent machine
washing; items made of silver and aluminium tend to discolour from machine washing;
glazed patterns may fade with frequent machine washing.
Instructions

19
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Instructions (Cont.)
Loading the upper basket
The upper basket is designed to hold
more delicate and lighter tableware
such as glasses, cups, small plates,
bowls and shallow pans (as long as
they are not too dirty).
Position these items securely so they
do not get moved by the spray of
water (Fig. 6).
The cup/cutlery trays
Fig. 8: Lower position Upper position
Wheels
Place long items, serving cutlery, salad servers,
knives and similar lightweight items (max. 1.5kg)
on one of the cup/cutlery racks (Fig. 7: A+B) in
the upper basket, so that they do not obstruct the
rotation of the spray arms. The extra rack (A) can
be removed when not required for use. It can hold
a maximum of 1.5kg. Rack (B) can be folded down
for convenience.
Adjusting the upper basket height
The height of the upper
basket can easily be
adjusted in order to create
more space for large utensils
in the upper or lower basket.
To adjust the height of the
upper basket, pull the basket
out and remove it from the
dishwasher cabinet, then
reinstall it with either the upper
or lower wheels on the rails
(Fig. 8).
Fig. 7
A
B
1
3
2
4
2 1
1
3 3
Fig. 6:
Upper basket, loaded to fit 14 place settings
1: Cups 2: Saucers 3: Glasses
4: Dessert dishes 5: Forks 6: Knives
5
6

20 AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: STR-SSDW14 PRODUCT CODE: 10933 09/2019
Loading the lower basket
The lower basket is designed to hold dinner plates, larger items and the cutlery basket
(Fig. 9).
Instructions (Cont.)
Fig. 10: Pots and pans in the lower basket
A
A
B
Fig. 11
Folding down the spike rows
If you need more space for pots and pans in the lower
basket, you can fold down the spike rows at the back (Fig. 11: A), so that larger or
more pots and pans can be loaded. Each row can be folded separately, or both
together to obtain a larger area. To fold down the spike rows, release them from the
frame using the blue clips at the side (Fig. 11: B).
Pots, pans, serving dishes
and bowls are often the
most difficult to clean and fit
best into the lower basket.
Always place pots, pans
and bowls upside down
into the basket or at a slant
so the water can flow out
(Fig. 10).
Load large serving dishes
and lids on the side of the
baskets so they do not block
the rotation of the top spray
arm. To ensure the detergent
dispenser lid can open freely,
the maximum diameter for
plates in front of the deter-
gent dispenser is 19cm.
4: Dessert dishes - 7: Dinner plates - 8: Soup plates - 9: Cutlery basket
Fig. 9: Lower basket, loaded to fit 14 place settings
7
4
8
4
7
4
9
