Stirling STR-DWSS12 User manual

Installing the dishwasher
Let’s get your new stainless steel
dishwasher ready to use!
Quick Start Guide
Model: STR-DWSS12
Customising your
dishwasher B
CAUTION! This dishwasher is heavy – ensure you have a helper to move it.
This dishwasher should be professionally installed by a licensed plumber or dishwasher
installer. Do not install it yourself.
WHERE TO INSTALL? This dishwasher is designed for freestanding use, but it can also be recessed
under a single benchtop. The back should rest against the wall behind it and the sides along any
adjacent cabinets or walls. Position the dishwasher on a level and sturdy floor. If the floor is uneven,
adjust the feet until it reaches a horizontal position.
WATER AND POWER CONNECTIONS Have the appliance installed close to an existing water
inlet and drain connection and make sure there is power point nearby, or in an adjoining cabinet.
The dishwasher’s water supply and drain hoses can be positioned either to the right or left sides to
facilitate proper installation. Only use the supplied new hoses when connecting this dishwasher to the
water supply.
Please refer to pages 12–15 in the manual for comprehensive installation instructions.
A
The height of the upper basket can easily be
adjusted in the upper or lower position in order
to accommodate taller dishes.
If you need more space for pots and pans in the
lower basket, you can fold down the spike rows
at the back so that larger or more pots and
pans can be loaded.
The cup rack is designed to hold smaller cups or
similar lightweight items. To make room for taller
items in the upper basket, you can raise it upwards,
or remove it when it is not required for use.
Cutlery should be washed in the cutlery basket
(in the lower basket).
Upper position ... ... lower position
1
1
2
3
Raise spike rows upwards ... ... or fold down
Cup rack folded out ... ... or raised upwards
2
3
Turn over, there’s a bit
more information...

Give us a call
What? You mean this Quick Start Guide didn’t have ALL the answers? The manual has more
comprehensive instructions, or speak to us. Call our After Sales Support on 1300 886 649.
Well done, you made it! Now sit back and relax ... your new stainless steel
dishwasher is automatically covered by a 3 year warranty. V1.0
6
7
5
Control panel
D
Open the door and draw out the lower basket. Load
your dishes and push the basket back into place.
Load the upper basket the same way.
Add dishwasher detergent and rinse aid (if
applicable) according to the instructions.
Close the dishwasher door properly.
Press the POWER button on the control panel.
Select the desired wash program using the
PROGRAM button, then press START/PAUSE.
At the end of the program, the machine will enter
standby state and switch off automatically after 30
minutes if there is no other operation.
Using your dishwasher C
Please refer to the instruction manual, pages 10–11, for comprehensive descriptions of all buttons
and indicators.
4
67
Press the POWER
button to enter or exit
the ready-to-use state.
Press the PROGRAM
button to select the
appropriate washing
program.
Press the START/PAUSE
button to start the
selected washing program
or pause it when the
dishwasher is working.
Press the DELAY
button to set the delay
start time to 3, 6 or
9 hours.
Press this button to select the
EXTRA DRYING function and have
dishes dried more thoroughly. It can
only be used with the Intensive, Eco
and 90 mins programs.
