Stirling SU105UE User manual

Operating Manual
02.06.19
SU105UE -86˚C
Ultra-Low Storage
6000 Poston Rd Athens, Ohio 45701, USA t: 740.274.7900 / 855.274.7900 f: 740.274.7901 www.stirlingultracold.com

2 of 40 Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19
THIS PAGE INTENTIONALLY LEFT BLANK

3 of 40
Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19 www.stirlingultracold.com
SU105UE Quick Guide
Initial Setup
1. Unpack freezer unit and included components, ensure all packaging material has been
removed from around the fan inlet and outlet holes.
2. Plug AC power cord into the main power socket at the back of the unit and then into
an electrical outlet.
3. Turn the AC power switch to the“On” position.
4. Notice: Ensure the access port stopper or sealant is in place. Remove factory tape at the port
stopper prior to initial use.
5. Turn on battery power. Battery switch is located in main power housing on the rear
of the freezer.
6. Ensure setpoint is within desired range (default is -86˚C) or change setpoint to user-preferred
temperature according to the control functions outlined below.
Guide to Basic GUI Functions
ON / OFF Switch the main power on, located at the back of the unit above the AC cord.
Battery Power Switch on the battery power located on the left of the Recessed Electrical
Panel. This is essential if monitoring is required in the event of a power failure.
Change Setpoint Tap Home > Setup > Setup > Enter PIN > Enter > Change > Setpoint > +/- > Save
Silence Alarm Tap Home > Setup > Silence
Event Log Tap Home > Setup > Event Log > Prev. Page, Next Page
Chart History Tap Home > Setup > Chart History
Guide to Advanced GUI Functions
Alarm Setup Tap Home > Setup > Setup > Enter PIN > Enter > Alarms > xxx Delay > +/- > Save
Date and Time Tap Home > Setup > PIN > Date & Time > +/- > Save
Change PIN Tap Home > Setup > Setup > Enter PIN > Enter > PIN > Enter New PIN > Enter >
Re-enter New PIN > Enter
Calibrate RTDs Tap Home > Setup > About > Service > RTD Calibr. > RTD Select > +/- > Calib.
Notice:
Before engaging door latch, ensure handle is fully rotated
down to the stop point in order to reset latching mecha-
nism. To engage door latch when closing, push outer
door IN before rotating door handle to UP position.

4 of 40 Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19
THIS PAGE INTENTIONALLY LEFT BLANK

5 of 40
Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19 www.stirlingultracold.com
The model SU105UE incorporates next generation free-piston Stirling engine technology.
Free-piston Stirling engine technology differs from conventional compressor-based refrigera-
tion by providing high efficiency, deep-temperature cooling in a lightweight package.
SU105UE
-86˚CUltra-Low Storage
EU Authorized
Representative:
Global Cooling, BV
Lage Dijk 22,
Helmond, 5705 BZ
The Netherlands
Table of Contents:
1. INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
1.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
1.2 Intended Uses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
1.3 Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
1.3.1 Operating Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
1.4 Organization of this Operating Manual. . . . . . . . . . . . . . . . .7
2. FEATURES OF THE SU105UE FREEZER. . . . . . . . 8-11
2.1 Free-Piston Stirling Engine. . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2.2 Cabinet Design Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2.3 Temperature Monitoring Features . . . . . . . . . . . . . . . . . . . . .8
2.4 Graphical User Interface (GUI). . . . . . . . . . . . . . . . . . . . . . . . . .9
2.5 Pictorial Tour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.6 Included Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.7 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.7.1 Adapter Installation Procedure. . . . . . . . . . . . . . . . . . . . . . .11
2.7.2 Power Cord Change. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
3. SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . 12-13
4. UNPACKING AND INSTALLATION. . . . . . . . . . . . 14-15
4.1 Freezer Site Qualification . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
4.2 Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
5. OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-31
5.1 Operation of the SU105UE Freezer . . . . . . . . . . . . . . . . 16-29
5.1.1 Graphical User Interface (GUI) & PIN . . . . . . . . . . . . . . . . . .17
5.1.2 GUI Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
5.1.3
Basic GUI Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
5.1.4 GUI Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-29
5.2 Managing Freezer Contents . . . . . . . . . . . . . . . . . . . . . . . . . .30
5.3 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
5.4 Calibration of the RTDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
6. TRANSPORTING, MOVING AND STORAGE . . . . . . 31
7. SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . 32-34
7.1 Freezer Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-33
7.2 Materials Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
8. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . .35
9. WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36-37
10. CE DOCUMENTATION. . . . . . . . . . . . . . . . . . . . . . . . 38

6 of 40 Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19
1. Introduction
1.1 – Description
The Stirling Ultracold SU105UE free-piston Stirling engine Ultra-Low Temperature
(-86°C) Freezer uses proven M150A free-piston Stirling engine technology to provide
high efficiency, deep-temperature cooling.
1.2 – Intended Uses
The SU105UE freezer provides ultra-low temperature storage for general (non-
flammable) research laboratory materials requiring a stable, computer-controlled,
deeply-frozen environment. The storage of blood or blood products intended for
medical purposes is prohibited.
1.3 – Documentation
1.3.1 – Operating Manual
• This operating manual describes all aspects of receiving, installing, use, moving and
storage of the Stirling Ultracold SU105UE Freezer. More detail on specific aspects of
operation of the freezer is available via online supplementary documentation.
• Performance of the freezer is controlled by electronic logic that is programmed
through a touch screen Graphical User Interface (GUI). This operating manual
describes use of the GUI in section 5.
User Advisory:
Deep temperatures are dangerous, use proper precautions when operating ultra-
low temperature freezers. This ultra-low temperature freezer is intended for storage
of frozen sample product or vials at deep temperatures. Stirling Ultracold, Division
of Global Cooling, Inc. cannot be held responsible for damages or loss of stored
product attributed to unintended use. In no case will Stirling Ultracold, Division
of Global Cooling, Inc. be held liable for loss of stored product resulting from
electrical, mechanical or structural failure. As with any ultra-low temperature freezer,
appropriate back-up and redundancy considerations are the responsibility of the
user.

7 of 40
Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19 www.stirlingultracold.com
Two Model SU105UE cabinets stacked.
Shown with optional stacking adapter.
1.4 – Organization of this Operating Manual
This manual is organized as follows:
• Unpacking and installation
• Set-up
• Operation
• Transporting and moving
Please note that precautions and safety instructions are part of each section of the
manual, and must be observed to avoid damage to the freezer or harm to its users.
Flammable Refrigerant Use:
SU105UE uses 30-33 grams of R-170 (Ethane) in hermetically sealed thermosiphon
tubing. It requires caution in use/repair.
A.Danger – Risk of Fire or Explosion. Flammable Refrigerant Used. Do Not Drill or
Puncture Inner Liner.
B. Danger – Risk of Fire or Explosion. Flammable Refrigerant Used. To be Repaired
Only by Trained Service Personnel. Component Parts Shall Be Replaced With Like
Components. Do Not Puncture Refrigerant Tubing.
C. Caution – Risk of Fire or Explosion.
Flammable Refrigerant Used. Consult
Repair Manual/Owner’s Guide Before
Attempting to Service this Product.
All Safety Precautions Must be Followed.
D.Caution – Risk of Fire or Explosion.
Dispose of Properly in Accordance
with Federal or Local Regulations.
Flammable Refrigerant Used.
E. Caution – Risk of Fire or Explosion
Due to Puncture of Refrigerant Tubing;
Follow Handling Instructions
Carefully. Flammable Refrigerant Used.
1. Introduction

8 of 40 Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19
2. Features of the SU105UE freezer
2.1 – Free-Piston Stirling Engine
The SU105UE Ultra-Low Temperature Freezer uses the state of the art Stirling
Ultracold Model M150A free-piston Stirling engine to provide high efficiency,
deep-temperature cooling. No HCFC or CFC refrigerants are used in the M150A and
SU105UE. The M150A Stirling cycle engine uses approximately 2 grams of helium
gas as a working fluid. 30-33 grams of R-170 are used in the thermosiphon which
removes energy from the freezer.
2.2 – Cabinet Design Features
The cabinet is VIP insulated with polyurethane foam support providing an internal
volume of cabinet approximately 105 liters. The environmentally friendly, SNAP-
compliant blowing agent is Ecomate®. A locking cam door latch ensures door
gasket compression when closed. Door sealing consists of three gaskets and is
factory replaceable. A door defrost minimizes water or ice deposition on the gasket
interface.
2.3 – Temperature Monitoring Features
Two resistance temperature detectors (RTDs) measure the internal cabinet
temperature of the SU105UE. One provides input to the free-piston Stirling engine
controller and the other provides input for the Graphical User Interface (GUI) display
and for reporting and logging. The display RTD may be user calibrated through the
GUI. The GUI provides a door open timeout alarm and monitors the temperature
reporting RTD for excursions beyond high and low limits that are set automatically
or manually. Alarms are reported through an audible alarm in the freezer enclosure
and through a contact closure that may be connected to an external alarm. The GUI
provides options to temporarily suppress alarms and set a delay time before the
alarm is reported via the contact closure. A one-time temperature alarm suppression
provided by the software allows for the initial cooling of the freezer after start-up.

9 of 40
Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19 www.stirlingultracold.com
2.4 – Graphical User Interface (GUI)
The GUI is implemented on a touch screen control panel on the front of the cabinet.
Its capabilities are described in detail later. General features of the control panel are:
• Set freezer control, alarm and communications parameters
• Provide password protected access to parameter changes
• Display freezer status
• Display temperature graph and event log
• Display diagnostic and service information
• Display freezer identification information
Values for the following SU105UE parameters are viewed and modified through
the touch screen.
Modiable Values Accessible Values
Temperature setpoint Current freezer interior temperature
Under temperature limit Temperature history chart
Over temperature limit Interior vs. free-piston Stirling engine temperatures
Over temperature delay after door opening Alarm status
Audible alarm silence interval GUI firmware event log
External contact delay upon alarm “About” screen (general information)
Door open alarm delay Service contact information
Door defroster status Diagnostics screen
Door auto-defrost status
Manual defrost time
Password Identication Number (PIN) status
Current date
Current time
RTD calibration adjustments
2. Features

10 of 40 Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19
2.5 – Pictorial Tour
1. Control Panel
2. Locking Latch
3. Door Gasket
4. Fixed Stainless Steel Shelf
5. Air Inlet
6. Access Port
— For thermocouple wires, purge gas, etc.
— 0.5" (12.7 mm) with plug
7. Air Outlet
8. Recessed Electrical Panel
A. AC Power Connector
B. AC Power Switch
C. External Alarm Terminal Strip,
Dry Contacts (NC, NO, C)
D. Battery Power Switch
2.6 – Included Items
• Packing List
• Operating Manual - (this document, including Warranty Card). 1 pc
• Port Sealant
• 1 Port Plug
• 2 Keys
• 1 Wrench
1
6
7
4
2
5
3
8
A
B
C
D
Model SU105UE. Shown with optional
stainless steel inventory racks.

11 of 40
Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19 www.stirlingultracold.com
2.7 – Options
• Stacking Adapter
When stacking two Stirling Ultracold SU105UE free-piston Stirling engine Ultra-
Low Temperature (-86°C) Freezers, a stacking adapter is required. The Stacking
Adapter consists of two (2) plates and twelve (12) screws.
2.7.1 – Adapter Installation Procedure
1. Remove rear casters
from both freezers.
Install adjustable
leveling feet.
2. Move 2nd unit over
the top of 1st unit
sitting on floor.
Note the net
weight is about
220 lbs. Three
person job.
3. Adjust height
if necessary.
4. Level top freezer.
5. Attach stacking plate and tighten six screws (torque 8 to 10 lb-in) at both sides.
Note that the stacking plate should not hold the weight of upper unit.
The upper unit should sit on the leveling feet.
• Power Cords
A simple line cord change can allow for multiple power and receptacle types.
2.7.2 – Power Cord Change
To change the line cord, unplug the old line cord from the AC Power Connector
found on the rear of the unit and plug the new line cord in its place. Make sure
to use the cord and plug appropriate for your location.
The options below are available:
1. Line Cords for North America. 120V, AC, 60Hz. NEMA 5-15P plug.
Requires standard NEMA 5-15R receptacle.
2. Line Cords for Europe/International. 240V, AC, 50Hz. Standard two-pin
plug requires two-pin receptacle.
3 holes on upper unit and 3
holes on lower unit need to
be lined up.
Clearance between bottom
of upper unit and top of
lower unit is 1.5 inches.
2. Features

12 of 40 Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19
3. Safety Precautions
Potential hazards associated with use of the SU105UE freezer may impact the safety
of persons in the workplace in which the freezer is installed. This includes persons
who operate the freezer, and other personnel in its vicinity. The freezer itself may
also be damaged or its warranty voided by improper operation or usage. It is very
important that all personnel that install, operate, transport or place the freezer into
storage read this entire manual to understand those hazards. Likewise, it is imperative
to place this manual for ready reference adjacent to the freezer at all times.
Specific appropriate precautions are included in each section of this operating
manual. However, several important general precautions must be observed and
are described below.
• Do not disassemble, modify or repair. There are no user serviceable parts inside the
freezer unit.*
• Do not operate freezer with the top cover removed as this will affect freezer
performance. To avoid risk of electrical shock and injury disconnect power before
removing top cover.
• Do not immerse in water, pour water on the unit, or operate where water may drip
or fall on the unit. Operation under extreme environmental conditions, e.g., in very
high humidity environments (RH 85% or more) also may lead to condensation or
water intrusion.*
• Warning: Unauthorized modification to the cabinet, controls or free-piston Stirling
engine will void all warranty provisions.
• Do not cut, change or modify the power cable.*
• Do not store flammable items such as gasoline, thinner or solvents in the freezer.
• The freezer is NOT rated as an explosion-proof freezer.
• Do not use hard and/or sharp objects, such as knives, screwdrivers, etc. to remove
any frost or ice that has accumulated on the inside of the freezer. The inside panels
are heat exchangers and can be damaged. Defrosting the cabinet is described later
in this operating manual.
*Doing so will void the warranty.

13 of 40
Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19 www.stirlingultracold.com
• Do not use solvents to clean the panel or the outside or inside of the freezer.
• When removing the power cable, hold onto the plug and not the cable.
• Do not block the air intake or air discharge vents used by the free-piston Stirling
engine (See pictorial on Page 10 for locations.)
• Ultra-low temperature freezers are different from home freezers in that at -86°C
frostbite can occur instantly.
• For the personal safety of freezer users, safe operating procedures are essential.
— Never handle samples or freezer accessories with bare hands. Be especially
careful not to spill ultra-low temperature materials onto skin or clothing.
— Do not use gloves that become brittle at ultra-low temperatures.
— Nitrile and latex gloves are inadequate.
• Permeable gloves are dangerous because frozen materials can contact skin
and cause damage.
— Be especially careful that materials at low temperatures are not spilled onto
skin or clothing.
• Ultra-low temperatures may adversely impact freezer contents:
— Do not put ice or liquid water directly in the freezer box; always use
suitable containers.
— Use only sample containers that have been approved or tested for ultra-low
temperature use.
— Do not use glass containers when the contents might freeze and expand.
— Some plastics shatter at ultra-low temperatures. Avoid splinter hazards.
— Biological and chemical hazards are still hazardous at ultra-low temperatures.
Always wear proper protective equipment and follow appropriate isolation
protocols.
— Many types of labels will fall off and/or break at ultra-low temperatures. Some
types of ink which stick to glass and/or plastic at room temperature lose adhesion
at ultra-low temperature.
• In addition to the ULT hazards above, there are also physical hazards to consider:
— Be cautious when closing the door to avoid a pinching hazard.
— Be careful when loading the cabinet with heavy items.
3. Safety Precautions

14 of 40 Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19
4. Unpacking and Installation
Verify the SU105UE freezer shipment by uncrating the freezer and included items,
inspecting them for damage during shipping, and compare the items to the
packing list for completeness.
4.1 – Qualify the installation site for the freezer before
placing it into service.
1. Note the shipping packaging dimensions (H x D x W) of 1041.4 x 787.4 x 787.4
mm | (41 x 31 x 31 in) and shipping weight of 121 kg | (266 lbs.), crated ocean
weight of 180 kg | (396 lbs.).
2. When moving the shipment from the point of receipt to the place where it
will be uncrated. The installation site must accommodate the freezer exterior
dimensions of (H x D x W) 864 x 711 x 686 mm | (34 x 28 x 27 in) and weight
of 100 kg | (220 lbs.).
3. There are no specific required clearances for the top, back and sides of the
freezer; however allowances must be made for electrical connections to the
panel on the back of the freezer.
4. Ingress to the access port (see Page 10) is required during normal operation.
5. The freezer must be installed on a nominally level surface and leveling feet will
accommodate small variations from level. SU105UE freezers are stackable up
to two high. Requires optional stacking adapter.
6. The aisle way into which the freezer door opens must be wide enough to
allow access to the contents of the freezer and not present a hazard to those
using the aisle way.
7. The facility/room lighting must not obscure the readability of the touch
screen display and must provide good visibility for working with the contents
of the freezer.
8. After the freezer is placed into its installation location, any blockages to the
air inlet and outlet must be removed. (See Page 10 for locations.)
9. Care must be taken while unpacking and installing the freezer not to injure
personnel or damage the freezer by loss of control of its motion during the
processes. Be mindful of its size and weight. Dropping the freezer is likely to
damage it.

15 of 40
Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19 www.stirlingultracold.com
4.2 – Set-up
1. Before switching on electrical power to the freezer, make all desired external
connections:
A. AC power connection
B. External alarm
2. Turn on the AC switch. If the DC power option has been provided please
see the supplemental instructions.
3. Notice: Ensure the access port stopper or sealant is in place. Remove factory
tape at the port stopper prior to initial use.
4. After the freezer reaches its operating temperature and its door is opened
and closed, the partial vacuum created when warm air is admitted, then
cooled, will prevent reopening of the door until the pressure is equalized.
A vacuum relief port is provided to accelerate this process.
5. Be mindful of any electrical shock hazards associated with making electrical
connections to the freezer, especially the external alarm connection.
6. Notice: To activate the battery for the alarm system, please place the
battery switch to the “on”position. Battery switch is located in the main power
housing on the rear of the freezer.
4. Unpacking and Installation

16 of 40 Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19
5. Operation
5.1 – Operation of the SU105UE freezer comprises four stages:
1. Monitoring temperature performance using the Graphical User Interface (GUI)
touch screen control panel.
2. Managing the freezer contents.
3. Cleaning and defrosting the freezer.
4. Calibrating the freezer's display RTD.
Specification of responsibilities for each of the above components of freezer
operation should be part of the procedures and policy documents and guidelines
for the clinical, laboratory, or other activity for which the freezer is used. Safety
requirements are integral to these responsibilities.

17 of 40
Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19 www.stirlingultracold.com
5.1.1 – Graphical User Interface (GUI) & PIN
A Password Identification Number (PIN) may be set, but is not displayed. The default
PIN is 1234 and may be changed by the user to any four-digit numeric. Use the PIN to
control access to parameter change screens.
The GUI is preprogrammed with generic default values for most parameters listed
on page nine, so entering the date, time and temperature setpoint are the most
essential actions. Unless temperature limits are set manually, the software calculates
default values appropriate for the temperature setpoint.
The GUI uses a menu system to display and modify system values. Generally, each
screen displays certain values and contains “soft” buttons that are pressed to access
other screens (according to the menu structure), and each screen has a soft button to
return to the Home screen and a“Back” soft button to return to the next higher level
of the menu (from which it was called).
5. Operation

18 of 40 Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19
5.1.2 – GUI Menu
The GUI menu tree below starts with the Home screen. (How to get there
is described later.) Soft buttons provide navigation to the screens on the next level
of the menu tree.
Home – display current freezer temperature.
• Setup – display Password Identification Number (PIN) status, door defrost status,
temperature setpoint, system date and time and alarm status.
• Setup – display temperature setpoint.
Change Setpoint – display and change the temperature setpoint and high
and low temperature limits.
Alarm Setup – display and change the Temp. Delay (to delay an over
temperature alarm after a door opening), Audible Delay (time interval to
silence the audible alarm upon request), Ext. Delay (to delay remote alarm
contact closure after alarm condition is detected) and Door Delay (period that
the door may remain open without alarm).
Date & Time Setup – display and change system date and time.
Door Defrost – enable/disable automatic door defrosting and/or set a manual
defrost time and initiate manual defrost.
PIN Setup – disable/enable the system PIN and change the PIN.
• Silence Alarm – temporarily silence audible alarm.
• Event Log – tracks the last approximately 200 alarm conditions such as door
openings, temperature setpoint changes, over temperature condition, and power
outages.
• Chart History – display the cabinet interior air temperature over the last 24 or 48
hours, or 7 days.
• About – display freezer model number, serial number, firmware version, engine
number, run hours, temperature setpoint, and install date.
–Service – display cabinet, control and cold-head RTD temperatures, warm-head
thermistor temperature and engine voltage, current and power.
Diagnostics – display temperature setpoint, engine running power as a
percentage of maximum running power, and freezer condition status.
Service Contact – provides phone, email, and web address for manufacturer.
RTD Calibration – display RTD readings and calibration offsets to apply to
reading (used to compensate for discrepancies between Display RTD and
user-supplied temperature standards).
• Firmware Upgrade – display screen for firmware check and upgrade options.
• Alarm Test – Tests alarm.

19 of 40
Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19 www.stirlingultracold.com
5.1.3 – Basic GUI Controls
• Generally, to change a value on a screen, Tap the appropriate soft button
to highlight the parameter.
• Use the +/- buttons to enter the desired value and then use the “Save”soft button
to complete the change.
• PINs are entered through a numeric keypad screen with an“Enter” soft button
to complete the entry and an “Exit” soft button to terminate it.
• PINs may be disabled on the PIN Setup screen by leaving the new PIN value blank.
When the PIN is disabled, any person can perform all actions available via the GUI,
including silencing alarms and calibrating the RTDs.
• The following examples of GUI usage describe sequential button taps, e.g., 1 > 2
means: tap button labeled“1” then tap button labeled “2”. GUI display screens are
named and those names are shown in bold. Access to certain screens requires
entry of the system PIN via a numeric keypad screen; this entry is shown
as the PIN button tap.
Guide to Basic GUI Functions
ON / OFF Switch the main power on, located at the back of the unit
above the AC cord.
Battery Power Switch on the battery power located on the left of the
Recessed Electrical Panel. This is essential if monitoring is
required in the event of a power failure.
Change Setpoint Tap Home > Setup > Setup > Enter PIN > Enter > Change >
Setpoint > +/- > Save
Silence Alarm Tap Home > Setup > Silence
Event Log Tap Home > Setup > Event Log > Prev. Page, Next Page
Chart History Tap Home > Setup > Chart History
Guide to Advanced GUI Functions
Alarm Setup Tap Home > Setup > Setup > Enter PIN > Enter > Alarms >
xxx Delay > +/- > Save
Date and Time Tap Home > Setup > PIN > Date & Time > +/- > Save
Change PIN Tap Home > Setup > Setup > Enter PIN > Enter > PIN > Enter
New PIN > Enter > Re-enter New PIN > Enter
Calibrate RTDs Tap Home > Setup > About > Service > RTD Calibr. > RTD
Select > +/- > Calib.
5. Operation

20 of 40 Operating Manual: SU105UE SU105U-MAN10-C | 02.06.19
5.1.4 – GUI Instructions
1. Start Screen:
Turn On Freezer and Battery Power
• Stirling Ultracold splash screen will appear for 3 seconds
2. Home Screen:
The Home screen will be displayed next
• Tap the Setup button to proceed to system settings
