STO N SHO SNS 354a Reference guide

Installation Procedures
2024 BMW X5 M-Sport
With ACC
3M Tape Only
SNS 354a
WARNING! READ BEFORE INSTALLATION!
3M tape is designed to adhere to the vehicle’s clear coat. A clear bra or vehicle wrap will
impair the 3M tape’s ability to bond with the surface. This bracket is not recommended for
use with either the clear bra or vehicle wrap.

Notice: Parking stops, high curbs, speed bumps, potholes, steep driveways, and
other road abnormalities can cause damage to your STO N SHO and vehicle. STO
N SHO LLC is not responsible for any damages that may occur to the STO N SHO
bracket or vehicle itself due to improper installation, road conditions, driving, or
care. Warranty only covers manufacture defects and STO N SHO LLC is not
responsible for damages as a result of driving your vehicle.
Warning: Please read directions completely before starting. If you have any
questions, please contact STO N SHO, LLC before beginning your installation.
Parts Included: License Plate mounting bracket Assembly. Includes Base Plate and
License Plate Holder
License Plate mounting Screws: (4) plastic ¼-20 X 5/8 (slot head) and ¼”
nuts (7/16 wrench size)
Base plate mounting screws: 3M tape, alcohol pad
Tools Needed: Blade Screwdriver and 7/16” wrench
Step 1: Ensure all parts listed above are accounted for. Note: If at any time during the
installation process you need assistance please call [phone].
Step 2: Separate the license plate holder from the base by simply pulling the pull pin ring
outward and sliding apart.
Step 3: Mount base plate bracket as shown in figure 1. The bracket will be mounted either right
or left of center to avoid ACC sensor with the back of the front plate sitting approximately ¼”
from the bumper as shown in figure 2 and 2a. Note: The white double-sided tape will help hold
the bracket in place while aligning. Slide the front bracket into the tubes to verify alignment.
Remove when alignment is complete and continue to step 4.
Step 4: Once base plate is correctly positioned be sure to mark the alignment using masking
tape or any other method that will ensure proper alignment. Thoroughly clean area where 3M
tape will be applied with alcohol pad. See figure 3.
Step 5: Remove the protective film from the base plate and carefully adhere to the bumper
using alignment marks/tape. The ideal application temperature range is 70°F to 100°F
(minimum temperature is 50°F). Caution: 3M tape is a one-shot application, meaning once
applied removal will result in the tape being damaged and losing its ability to stick. If this
occurs, please contact STO N SHO for assistance. Note: Bond strength. At room temperature

approximately 50% of ultimate bond strength will be achieved after 20 minutes, 90% after 24
hours and 100% after 72 hours.
Step 6: Secure the license plate and frame (optional) to the license plate bracket using the
screws provided. Note: If a frame is used it must be of a lightweight material. Requires the
blade screwdriver and 7/16 wrench (Not included).
Step 7: Slide the license plate rods into the two tubes located on the base plate. Slide the rods
into the tubes until the rods hit the pull pin. Simply pull the ring on the pull pin and advance the
rods. Release ring and continue to advance rods until the pull pin locks into place. NOTE: The
rods and spring-loaded pull pin are required to be sprayed periodically with WD-40 or any
other silicone type spray lube. Failure to do so could result in either the failure of the pull pin
or the rods becoming difficult to remove or reinsert. Note: In harsh environments, such as
areas where roads are either salted or sanded in the winter, spraying of the rods and pull pin
should be performed on a regular basis. Failure to provide this maintenance may void your
warranty. See figure 4. On some occasions the license plate may require a little adjustment to
level. Simply grab frame at arrows (See figure 5) and rotate. If the plate is high on left or right
side, rotate high side down slightly and release. Repeat as necessary. Once leveled plate will
remain level.
Congratulations! You have just installed the STO N SHOTM (Patented) front license plate
mounting system. Thank You for your purchase.
Caution: Bracket lowers ground clearance by approx. 1/2 inch
Remove prior to entering automated car wash
Exercise care when entering or exiting steep driveways or damage will occur
Parking Stops or high curbs, stop well before or damage will occur
Remove prior to running on track or racing
Medium skill level required. If unsure, have bracket installed by your local Dealer or Body shop.
Warranty only covers manufacture defects and STO N SHO LLC is not responsible for damages
as a result of driving your vehicle. Exercise caution and avoid roadways that will cause
damage to your vehicle.
Limited Lifetime Warranty (Excluding Pull-pin). Pull pin will be warrantied for a period of 1 year
(12 months) from the date of purchase.

STO N SHO, LLC warrants to the original purchaser only that this product will be free of
manufacturing defects in material and workmanship for the life of the product (Excluding pull-
pin, see above) provided all maintenance is performed as required to the limitations and
exclusions set forth below:
Return product to any authorized dealer. Contact STO N SHO, LLC for the dealer nearest you.
Upon examination, STO N SHO, LLC or its representative will, at its sole option and expense,
repair or replace any product found to be defective. If product to be replaced via mail, STO N
SHO, LLC will return the repaired or replaced unit to you via its usual shipping method from the
factory to your address in the United States of America or Canada only. Any shipping costs for
addresses outside of the United States or Canada shall be the responsibility of the purchaser.
This warranty is not transferable.
REMEDIES FOR BREACH OF WARRANTY.
This Warranty does not include repair for damage caused by improper use or handling,
including but not limited to damage caused by accident, mishandling, improper installation,
abuse, negligence, or any defect caused by repair to the product by anyone other than STO N
SHO, LLC.
This warranty does not cover reimbursement for your costs of removing and transporting the
product for warranty service evaluation, or installation of any replacement product provided
under this warranty.
This Warranty will be void if the product was not purchased from an authorized dealer or
reseller.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESSED AND
IMPLIED WARRANTIES. ALL SUCH OTHER WARRANTIES, INCLUDING BUT NOT LIMITED TO
IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NON-
INFRINGEMENT, WITH RESPECT TO THE PRODUCT. TO THE MAXIMUM EXTENT PERMITTED BY
LAW, STO N SHO, LLC SHALL NOT BE RESPONSIBLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES EXCEPT TO THE EXTENT PROVIDED (OR PROHIBITED) BY APPLICABLE LAW, EVEN IF
STO N SHO, LLC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Notwithstanding the above, if you qualify as a “consumer” under the Magnuson-Moss
Warranty Act, or applicable state laws, then you may be entitled to any implied warranties
allowed by law for the Warranty Period. Further, some states do not allow limitations on how
long an implied warranty lasts or allow the exclusion or limitation of consequential damages, so

such limitations may not apply to you. This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
For the name of your nearest authorized STO N SHO dealer, contact: STO N SHO, LLC at (408)
776-4080 or go to www.stonsho.com.
Fig 1.
Base plate will be either left or right, top to bottom. Be sure to
clean area where 3M tape will be applied with alcohol pad.
Note: Bracket will be left or right of center to avoid ACC sensor.

Fig 2
Fig 2a
Centered on bumper with the
back of the front plate ¼”
from bumper

Fig3
Fig 4
Use masking tape or any other marking
device to ensure proper alignment
when affixing to the vehicle.

Fig 5
