OPERATOR MANUAL
MODELS: CS1, CS2, CSP3

- 3 -
Table of Contents
TABLE OF CONTENTS ................................................................................................... 3-4
USER INFORMATION ..................................................................................................... 5-6
Foreword ................................................................................................................................ 5
Service Infor ation ................................................................................................................ 6
HEALTH & SAFETY ........................................................................................................ 7-9
Safety Training ....................................................................................................................... 7
Safety Precautions ..............................................................................................................8-9
TECHNICAL DATA ...................................................................................................... 10-15
Specifications ....................................................................................................................... 10
Machine Sound and Vibration Measure ents ..................................................................... 11
Service Check List ............................................................................................................... 12
Hardware Identification ....................................................................................................... 13
Torque Chart - I perial ........................................................................................................ 14
Torque Chart - Metric ...........................................................................................................15
OPERATIONS................................................................................................................ 16-20
Introduction .......................................................................................................................... 16
Deter ining the Right Machine ........................................................................................... 16
Operating Principle .............................................................................................................. 17
Delivery Checks ................................................................................................................... 17
Installing Blade .................................................................................................................... 17
Types of Cutting ................................................................................................................... 17
Before Starting ..................................................................................................................... 18
Cold Start.............................................................................................................................. 18
Hot Start ............................................................................................................................... 18
To Start Sawing .................................................................................................................... 18
Cutting .................................................................................................................................. 19
Belts & Pulleys ..................................................................................................................... 19
Dry Cutting ........................................................................................................................... 20
Concrete Saws

- 4 -
Table of Contents Concrete Saws
MAINTENANCE ........................................................................................................... 21-26
I portant .............................................................................................................................. 21
Electrical Power Supply Connection ................................................................................... 22
CS2 Electrical Syste .......................................................................................................... 23
CSP3 Electrical Syste ........................................................................................................ 24
Troubleshooting ............................................................................................................. 25-26
LUBRICATION ............................................................................................................. 27-28
Lubrication and Service ....................................................................................................... 27
Service Record Chart ........................................................................................................... 28
CALIFORNIA PROPOSITION 65 ................................................................................... IBC

- 5 -
User Information
These instructions include:
Safety regulations
Operating instructions
Maintenance instructions
These instructions have been prepared for
operation on the construction site and for
the maintenance engineer.
These instructions are intended to simplify
operation of the machine and to avoid
malfunctions through improper operation.
Observing the maintenance instructions will
increase the reliability and service life of the
machine when used on the construction
site and reduce repair costs and
downtimes.
Always keep these instructions at the place
of use of the machine.
Only operate the machine as instructed.
Observe the safety regulations as well as
the guidelines of the civil engineering trade
association. Observe the safety rules for the
operation and the pertinent regulations for
the prevention of accidents.
Stone Construction Equipment, Inc. is not
liable for the function of the machine when
used in an improper manner or for other
than the intended purpose.
Operating errors, improper maintenance
and the use of incorrect operating
materials are not covered by the warranty.
The above information does not extend the
warranty and liability conditions of business
of Stone Construction Equipment, Inc.
Stone Construction Equipment, Inc.
P. . Box 150, Honeoye, New York 14471
Phone: [phone]
Fax: [phone]
Foreword
1. Machine Type: ______________________________
Machine S/N: _______________________________
2. Engine Type: _______________________________
Engine S/N: ________________________________
3. VIN: ______________________________________
4. Purchase Date: ______________________________
. Dealer/Distributor Information:
Name: _____________________________________
Address: ___________________________________
__________________________________________
Phone #: ___________________________________
Fax #: _____________________________________
6. Battery
Manufacturer: ______________________________
Battery Type: _______________________________
Battery S/N: ________________________________
Location of above information:
1. Information on S/N tag.
2. Information on engine tag.
3. Information on S/N tag - if applicable.
4. Date you purchased machine.
. Dealer machine was purchased from.
6. Information on battery and battery warranty
card.

L i m i t e d W a r r a n t y
The Manufacturer warrants that products manufactured shall be free from defects in material and
workmanship that develop under normal use for a period of 90 days for concrete vibrators and electric
pumps, one year for Rhino®, Bulldog®, Wolfpac Rollers, trowels, Stompers®, saws, forward plates,
engine powered pumps, and 6 months for all other products from the date of shipment. The foregoing
shall be the exclusive remedy of the buyer and the exclusive liability of the Manufacturer. Our warranty
excludes normal replaceable wear items, i.e. gaskets, wear plates, seals, O-rings, V-belts, drive chains,
clutches, etc. Any equipment, part or product which is furnished by the Manufacturer but manufactured by
another,bearsonlythewarranty givenbysuch other manufacturer. (TheManufacturerextendsthe warranty
period to “Lifetime” for the drum bearings and seals for the mortar mixers, and agrees to furnish, free of
charge, the bearings and seals only upon receipt of the defective parts. The warranty is two years for
eccentric bearings on the forward plate compactors, mortar and plaster mixer drums, trowel gearboxes
andfiveyearsontheBulldog trench rollereccentricbearings.) A WarrantyEvaluationForm must accompany
all defective parts. Warranty is voided by product abuse, alterations, and use of equipment in applications
for which it was not intended, use of non-manufacturer parts, or failure to follow documented service
instructions. Theforegoing warranty isexclusive of allother warrantieswhether written ororal, expressed
or implied. No warranty of merchantability or fitness for a particular purpose shall apply. The agents,
dealerandemployees ofManufacturerare not authorizedtomake modificationtothis warranty, oradditional
warranties binding on Manufacturer. Therefore, additional statements, whether oral or written, do not
constitute warranty and should not be relied upon.
TheManufacturer’ssole responsibilityforany breachof the foregoingprovision ofthiscontract, withrespect
toany product or part notconforming to the Warranty orthe description hereincontained, isat its option(a)
to repair, replace or refund such product or parts upon the prepaid return thereof to location designated
specifically by the Manufacturer. Product returns not shipped prepaid or on an economical transportation
basis will be refused (b) as an alternative to the foregoing modes of settlement - the Manufacturer’s dealer
to repair defective units with reimbursement for expenses, except labor, and be reviewed with the
Manufacturer prior to repair. A Warranty Evaluation Form must accompany all warranty claims.
Except as set forth hereinabove and without limitation of the above, there are no warranties or other
affirmations which extends beyond the description of the products and the fact hereof, or as to operational
efficiency, product reliability or maintainability or compatibility with products furnished by others. In no
event whether as a result of breach of contract or warranty or alleged negligence, shall the Manufacturer
beliable for specialor consequentialdamages including butnot limited to:Loss ofprofits or revenues,loss
of use of the product or any associated product, cost of capital, cost of substitute products, facilities or
services or claims of customers.
Noclaim willbe allowed for products lostor damagedin transit. Suchclaims should befiled withthe carrier
within fifteen days.
EffectiveApril 1, 1998.
4/98 P/N 51018
Stone Construction Equipment, Inc.
32 East Main Street, P. O. Box 1 0
Honeoye, NY 14471-01 0
Bred Tough, Born To Work. The
Way It Ought To Be.
Phone: [phone]  1-716-229-5141
Fax: [phone]
www.stone-equip.com  e-mail: [email protected]

- 7 -
Health and Safety
SAFETY
These machines are designed to carry out the func-
tion of flat sawing material of the non-cohesive, bitu-
minous and granular varieties.
If used correctly they will provide an effective and
safe means of flat sawing and meet the appropriate
performance standards.
It is essential that the operator/driver of the machine
is adequately trained in its safe operation, be autho-
rized to operate it, and have sufficient knowledge of
the machine to ensure that it is in full working order,
before being put to use.
Safety Training

- 8 -
Health and Safety
Ear protection required when operating this equipment.
This notation appears before warnings in the text. It means that the
step which follows must be carried out to avoid the possibility of
personal injury or death. These warnings are intended to help the
technician avoid any potential hazards encountered in the normal
service procedures. We strongly recommend that the reader takes
advantage of the information provided to prevent personal injury or
injury to others.
USE COMMON SENSE WHEN HANDLING FUELS
Transport and handle fuel only when contained in approved safety
container.
Do not smoke when refueling or during any other fuel handling opera-
tion.
Do not refuel while the engine is running or while it is still hot.
If fuel is spilled during refueling, wipe it off from the engine immediately
and discard the rag in a safe place.
Do not operate the equipment if fuel or oil leaks exist - repair immedi-
ately.
Never operate this equipment in an explosive atmosphere.
Before using this equipment, study this entire
manualto becomefamiliar withitsoperation. Do
not allow untrained or unauthorized personnel,
especially children, to operate this equipment.
Use only factory authorized parts for service.
When warning decals are destroyed or missing,
contact the Manufacturer immediately at 1-800-
888-9926for replacement. Forthesafety of your-
self and others, it is imperative that the following
rulesareobserved. Failure to do so may resultin
serious injury or death.
Safety Precautions

- 9 -
Health and Safety
Never operate this equipment without all guards in place.
Head protection required when operating this equipment.
Eye protection required when operating this equipment.
Never operate unit in a poorly ventilated or enclosed area.
Avoid prolonged breathing of exhaust gases.
Avoid contact with hot exhaust systems and engines.
Allow engine to cool before performing any repairs.
Safety Precautions

- 10 -
Technical Data
CS1
175 lbs (80)
36.5" x 26.6" x 34.5" (92,7 x 67,6 x 87,6)
12", 14" (30,5 / 35,6)
3 5/8" w/ 12" blade (9,2)
4 5/8" w/ 14" blade (11,7)
9 hp Robin (6,7)
8 hp onda (5,9)
11 hp onda (8,2)
 recommended for 12" blade only
Dry Element
3200 rpm (53)
1.6 gal. (6,0)
Push
Corrosion Resistant, Dual Spray
Push
5/8" (15,9)
8" R / 4" F (20,3 R/10,2 F)
Greasable pillow block
sealed 1" (25,4)
1" R/L (25,4)
Front cutting guide
14" blade guard
5 or 8 gal. polyethylene water tanks
CSP3
475 lbs (216)
54" x 26.75" x 37" (137,2 x 68 x 94)
12," 14", 16", 18", 20" (30,5 / 35,6 / 40,6
/ 45,7 / 50,8)
3 5/8" w/ 12" blade (9,2)
4 5/8" w/ 14" blade (11,7)
5 5/8" w/ 16" blade (14,3)
6 5/8" w/ 18" blade (16,8)
7 5/8" w/ 20" blade (19,4)
13 hp onda (9,7)
*16 hp Briggs & Stratton (11,9)
Vanguard
*18 onda Twin (13,4)
*20 onda Twin (14,9)
* electric start
 not recommended for
18" blade
Cyclone Air Cleaner (13 onda)
Remote Cyclone (20 & 18 onda)
3200 rpm (53)
2 gals (7,6)
ydrostatic
Corrosion Resistant, Dual Spray
90 ft/min (27,7 m/min)
3/4" (19,1)
8" R / 4" F (20,3 R / 10,2 F)
Greasable pillow block
sealed 1 1/4" (31,8)
1" R/L (25,4)
Lift eye, 4" wheeled front cutting guide,
rear cutting guide, adjustable handles,
depth gauge, Triple V-belt,
14",16" or 18" blade guard
Pressurized Water pump (except on 13
onda) 3-5 gal/min. (11-19 l/min)
-
CS2
310 lbs (141)
47.3" x 26.6" x 36.75" (120,1 x 67,6 x 93,3)
12", 14", 16", 18" (30,5 / 35,6 / 40,6 /45,7)
3 5/8" w/ 12" blade (9,2)
4 5/8" w/ 14" blade (11,7)
5 5/8" w/ 16" blade (14,3)
6 5/8" w/ 18" blade (16,8)
9 hp Briggs & Stratton Vang. (6,7)
11 hp onda (8,2)
13 hp onda (9,7)
*16 hp Briggs & Stratton Vang. (11,9)
5 hp Electric (3,7)
* electric start
Dry Element
Cyclone Air Cleaner (11-13 onda)
3200 rpm (53)
1.7 gal. (6,4)
Push
Corrosion Resistant, Dual Spray
Push
3/4" (19,1)
8" R / 4" F (20,3 R / 10,2 F)
Greasable pillow block
sealed 1 1/4" (31,8)
1" R/L (25,4)
Lift eye, 4" wheeled front cutting guide, rear
cutting guide, adjustable handles, depth gauge,
14" or 16" blade guard
5 or 8 gal. polyethelene water tanks
Model
Dimensions
Weight lb (kg)
Dimensions (LxWx)  in (cm)
Blade Capacity in (cm)
Cut Depth in(cm)
Operating System
Engineshp/(kW)
Air ilter
EngineRPM (z)
uel Capacitygal (L)
Drive
Water System
Performnce
Speed ft/ min (m/min)
Axle (mm)
Wheel (R/)(cm)
Blade Shaft Bearings 
size in (mm)
Blade
Arborin (mm)
(size & R/L)
Standard eatures
Options
† Pointer in up position, Handles in mid-position
‡ Use Imperial measured components only (avilable from manufacturer)
Member Masonry and Concrete Saw Manufacturers Institute and the Concrete Sawing and Drilling Association.
Specifications Concrete/
Pavement Saws

- 11 -
Technical Data Machine Sound and Vibration
Measurements
Sound Pressure Values as measured are per the following:
Model/Configuration
CS1
8 HP Honda
w/14 in blade
CS2
11 HP Honda
w/14 in blade
CSP3
18 HP Honda
w/20 in blade
at operator’s ear 88dBA 93dBA 91dBA
RMS acceleration on the handle were measured per the following:
meter/sec213.16 23.4 18.0
Sound and vibration values have been taken in accordance to the EEC machine
regulation (edition 93/68/EEC)
Sound Pressure measurements were taken with Simpson model 886-2 type 2 meter,
calibrated 2/21/97
Acceleration measurements were taken with Quest Tech model VI-100 meter, calibrated
4/17/96
Sound and vibration measurements were obtained with machine operating at maximum
engine speed of 3200 RPM.
Units had blades mounted and measurements were taken out of cuts.
document in cs_rev e_2000.p65

- 12 -
Technical Data
ALL SAWS
All saws set RPM at 3200 +/- 50 (no load).
Check blade clamp hub face run-out with
indicator and magnetic chuck. Run-out not
to exceed .015.
Check belt tension.
Belt deflection = .19 inches at 4.2 lbs. for
used belt and 6.2 lbs for new belt.
Grease all pillow blocks.
Apply never-seize to acme screws.
CS2
Make sure kill switch is functional while
running.
CS2 / CSP3
Check depth gauge making sure knob turns
when lift crank is run up and down.
Check choke and throttle action.
CSP3
Run transmission with shifter making sure
neutral correlates with neutral at shifter.
(Adjust at clevis and/or at cable bracket
on transmission mount).
Set drive axle load springs at 2.38 +/- .06
inches when axle is in run position.
While engine is running, check wet/dry
switch for function. (Dry should run—wet
should kill engine).
Check water pump switch for function.
Check engage/disengage lever. Drive
axle to have .13 minimum clearance to
wheel when disengaged.
For longest service life, use any SAE 20W20
in transmission.
Service Check List

- 13 -
Technical Data Hardware Identification
ZN = ZINC PLATED
BLK = BLACK OXIDE FINISH
VR005A

- 14 -
Technical Data Torque Chart - Imperial
SAE GRADE 5
Coarse Thread, Zinc-Plated SAE GRADE 8 Coarse Thread, Zinc-Plated
SIZE TORQUE SIZE TORQUE
ft. lbs. Nm ft. lbs. Nm
1/4 - 20 (.250) 681/4 - 20 (.250) 912
5/16 - 18 (.3125) 13 18 5/16 - 18 (.3125) 18 24
3/8 - 16 (.375) 23 31 3/8 - 16 (.375) 33 45
7/16 - 14 (.4375) 37 50 7/16 - 14 (.4375) 52 70
1/2 - 13 (.500) 57 77 1/2 - 13 (.500) 80 108
9/16 - 12 (.5625) 82 111 9/16 - 12 (.5625) 115 156
5/8 - 11 (.625) 112 152 5/8 - 11 (.625) 159 215
3/4 - 10 (.750) 200 271 3/4 - 10 (.750) 282 382
7/8 - 9 (.875) 322 436.5 7/8 - 9 (.875) 454 615
1 - 8 (1.000) 483 655 1 - 8 (1.000) 682 925
SAE GRADE 5
Fine Thread, Zinc-Plated SAE GRADE 8 Fine Thread, Zinc-Plated
SIZE TORQUE SIZE TORQUE
ft. lbs. Nm ft. lbs. Nm
1/4 - 28 (.250) 7101/4 - 28 (.250) 10 14
5/16 - 24 (.3125) 14 19 5/16 - 24 (.3125) 20 27
3/8 - 24 (.375) 26 35 3/8 - 24 (.375) 37 50
7/16 - 20 (.4375) 41 56 7/16 - 20 (.4375) 58 79
1/2 - 20 (.500) 64 87 1/2 - 20 (.500) 90 122
9/16 - 18 (.5625) 91 123 9/16 - 18 (.5625) 129 175
5/8 - 18 (.625) 128 173 5/8 - 18 (.625) 180 244
3/4 - 16 (.750) 223 302 3/4 - 16 (.750) 315 427
7/8 - 14 (.875) 355 481 7/8 - 9 (.875) 501 679
1 - 12 (1.000) 529 717 1 - 12 (1.000) 746 1011
1 -14 (1.000) 541 733 1 -14 (1.000) 764 1036
t-chrt_i.doc

- 15 -
Technical Data Torque Chart - Metric
Monthly, inspect all hardware on this equipment and engine/motor. Loose hardware can contribute to early
component failure and poor performance. Use the torque chart below as a general guideline and keep all hardware
tight.
Note: ome hardware is used to retain parts that have to move freely for correct operation of this unit. The
hardware for these items should be snug enough to prevent excessive play, yet loose enough to allow the parts to
pivot freely.
Property Class 8.8
ZINC-PLATED Coarse Thread Fine Thread
SIZE Nm ft. lbs. Nm ft. lbs.
M6 9.9 7 10 7
M8 24 18 25 18
M10 48 35 49 36
M12 83 61 88 65
M14 132 97 140 103
M16 200 148 210 155
M20 390 288 425 313
M24 675 498 720 531
Property Class 10.9
ZINC-PLATED Coarse Thread Fine Thread
SIZE Nm ft. lbs. Nm ft. lbs.
M6 14 10 14 10
M8 34 25 35 26
M10 67 49 68 50
M12 117 86 125 92
M14 185 136 192 142
M16 285 210 295 218
M20 550 406 600 443
M24 950 701 1000 738
Property Class 12.9
ZINC-PLATED Coarse Thread Fine Thread
SIZE Nm ft. lbs. Nm ft. lbs.
M6 16.5 12 16.5 12
M8 40 30 42 31
M10 81 60 82 60
M12 140 103 150 111
M14 220 162 235 173
M16 340 251 350 258
M20 660 487 720 531
M24 1140 841 1200 885
Conversion Factor: 1 ft. lb. = 1.3558 Nm

- 16 -
Operation Introduction/Determining the
Right Machine
Congratulations on your purchase of Stone's
Saw Devil! You've made an excellent choice!
The Sawdevil has been specifically designed as
the ideal machine for the professional contractor
who is engaged in concrete and asphalt flat
sawing
Stone Saw Devils are used for the primary
purpose of flat sawing This type of sawing is
described as flat because the pavement is cut
somewhere close to a horizontal plane It is the
most common type of diamond blade cutting
Concrete saws in the industry are available in a
variety of types, sizes and styles They range
from manual or self propelled in horsepower
from 7-72hp It is possible to cut both concrete
(green or cured, with or without rebar) or asphalt
with a concrete saw
The Stone Saw Devil line represents the most
popular sizes and configurations on the market
Youll find manual or self propelled models
powered by gasoline engines ranging from 7hp -
20hp capable of accepting blades of up to 20
inches in diameter They are designed to cut
horizontal slabs to depths of a maximum of 7-1/
2 inches
You will find a Stone Saw Devil to fit a wide
variety of job applications
Upon receipt of your Saw Devil, CARE-
FULLY CHECK FOR ANY FREIGHT
DAMAGE. Any damage should be immediately
reported to the carrier and a claim registered
The Saw Devil is manufactured to the strictest
specifications and inspection procedures If any
material or manufacturing defects are found,
return the tag on the machine with assembler's
signature and your findings to the manufacturer
We want to know when a product is less than
perfect We also welcome any and all input on
how the product may serve you better
DETERMINING THE RIGHT MACHINE
CS1--Used for small sawing jobs such as floor
and pavement patching and repair, expansion
joint cutting, conduit channel cutting and other
flat work
CS2--Utilized for jobs requiring precision
cutting including floors, pavements, walkways,
ramps and other flat sawing applications
CSP3--Ideal for parking lots, streets, driveways,
floors, building and restoration projects

- 17 -
Operation Operating Principle/Delivery Checks/
Installing Blade/Types of Cutting
OPERATING PRINCIPLE
The following instructions were compiled to
provide you information on how to obtain long
and trouble free use of the unit Periodic
maintenance of this unit is essential Read the
manual in its entirety and follow the instructions
carefully Failure to do so may injure yourself
or a bystander
DELIVERY CHECKS
Immediately upon taking delivery of your new
equipment and before putting it into service:
 Read the handbook completely--it could save
a great deal of unnecessary expense
 Read the engine manual supplied
 Check the general condition of the equip-
ment--has it been damaged during delivery?
 Check engine oil level
 Check fuel levels
Recommended lubricants are detailed in the
CARE AND MAINTENANCE section
INSTALLING BLADE
1 Be certain that the spark plug is disconnected
or saw is unplugged
2 Remove the blade shaft nut, right hand
thread, and take off outside blade shaft collar
3 Clean off any foreign particles on the clamp-
ing surfaces of collars and on the mounting
surface of the blade
4 Place the blade on the blade shaft, lining up
the offset drive pin in the blade with the drive
pin in the mounting collar If your blade has a
directional rotational arrow, position arrow
for down cut (diamond tail trailing for down
cut)
5 Replace the outside blade shaft collar on the
blade shaft Drive pin on the inside collar
must project through the drive hole in the
blade and into the outside collar
6 Tighten the blade shaft nut (right-hand thread)
securely against star washer and outside
collar, using two wrenches supplied
7 Reconnect the spark plug or (with switch
"off") plug in the electric supply cord
TYPES OF CUTTING
Cut speed depends entirely on using the correct
blade for the material to be cut Wet or dry,
diamond blades of various specifications are
available for cutting concrete or asphalt
Manual Saws - require the operator to push the
saw through the material They are ideal for
small jobs where high productivity is not
required Stone Saw Devils are available in 7-16
hp models
Self Propelled Saws - Designed for maximum
productivity and reduced operator fatigue They
allow deeper cutting at a faster forward speed
Hydrostatic drive is typically standard on self-
propelled saws with horsepower ranges from 13-
65 Saw Devils are available in 13, 16, 18 and
20 hp models

- 18 -
Operation Before Starting/Cold Start/Hot
Start/To Start Sawing
BEFORE STARTING
1 Use correct blade for cutting conditions
2 Ensure arbors and collars are clean and
undamaged
3 Mount blade and tighten securely using both
wrenches
4 When wet cutting, check water jets for
adequate flow
5 Disengage transmission on self-propelled
models
6 Align pointer with saw blade
Cautio - Set u it up i a ope area. Avoid
close proximity to structures or other equip-
me t. Failure to do so may cause i adverte t
i jury to operator or other perso s i the area.
Cold Start - Open the fuel valve under the gas
tank all the way Position the engine stop
switch, located on the engine, to run Open the
throttle approximately half way and apply the
choke Pull the starter rope sharply When the
engine starts, open the choke and adjust the
throttle as necessary to keep it running Allow
the engine to warm up for a few minutes before
placing it under the load If the engine doesn't
start after (3) pulls, open choke slightly to
prevent flooding Always operate the engine at
full throttle when under load
Hot Start - Open the valve under the gas tank
all the way if it has been shut off Open the
throttle approximately half way Do not apply
the choke Pull the starter rope sharply until the
engine starts When the engine starts, adjust the
throttle Always operate the engine at full
throttle when under load
NOTE: These starting instructions are general
guidelines only Since many engine options are
available, consult the Engine Manual included
with this unit for specific instructions
Cautio - Gasoli e E gi es - To improve the
e gi e service life, allow the e gi e to idle
without load for (2) to (5) mi utes before shut-
ti g it dow . Whe the idli g period is up,
use the stop switch located o the e gi e a d
tur it to stop. Close the fuel valve u der the
gas ta k. E gi e floodi g ca occur if the
valve is left ope duri g tra sport.
TO START SAWING
1 Start engine and let engine warm up All
sawing is done at full throttle
2 Align blade and saw with cut If wet sawing,
open water valve and turn water safety
switch on (CSP3)
3 Lower blade to touch surface and re-zero
depth gauge (CS2 and CSP3 models)
4 Lower blade into cut slowly
5 Put speed control in neutral, engage trans-
mission and move speed control lever slowly
toward forward position (CSP3 model
only)

- 19 -
Operation Cutting/Belts & Pulleys
6 Cut as fast as blade will allow If blade
climbs out of cut, reduce forward speed or
depth of cut
7 Use only enough side pressure on saw
handles to follow cutting line
CUTTING
Lower the blade into concrete to required depth
by turning the tilt crank counterclockwise Ease
the saw slowly forward Slow forward pressure
if the saw begins to stall
Note: For deeper cuts (4 inches/102 mm or
more), several cuts should be made in incremen-
tal steps of 1-1/2 inch (38 mm) to 2 inches (51
mm) until the desired depth is reached
Push the saw steadily forward using the front
pointer as a guide Exert enough forward
pressure so that the engine/motor begins to
labor, but does not slow down If the saw begins
to stall, retard forward movement until full RPM
is restored to the blade If saw stalls, raise the
blade out of the cut before restarting Avoid
excessive side pressure or twisting of the blade
in the cut
BELTS & PULLEYS
NEVER MAKE ADJUSTMENTS TO V-BELTS
AND PULLEYS WHILE ENGINE IS RUNNING.
1 The best tension for a v-belt drive is the
lowest tension at which the belts will not slip
under full load
2 Take up tension until the belts are snug in the
grooves Run the drive for about five (5)
minutes to "seat" the belts Then impose the
peak load If the belts slip, tighten them until
they no longer slip at peak load Most new
belts will need additional tensioning after
seating
3 Remember, too much tension shortens belt
and bearing life
4 Check the belt tension frequently during the
first day of operation Check the belt tension
periodically thereafter and make any neces-
sary adjustments
5 The two most common causes of sheave
misalignment are:
a) The engine drive shaft and the blade shaft are
not parallel
b) The pulleys are not located properly on the
shafts

- 20 -
Operation
Figure 1 cs002a
Dry Cutting
6 To check alignment, use a steel straight edge
See Figure 1
7 Line up the straight edge along the outside
face of both pulleys shown in the drawing
All pulleys have (2) set screws in the bottom
of their grooves Set screws require thread
locking lock tite
8 Misalignment will show up as a gap between
the pulley face and straight edge Make sure
there is clearance between arbor pulley and
saw base on both sides
DRY CUTTING
 Never operate a y saw without safety
guards i place.
 Do ot exceed maximum operati g speed
established for blade diameter.
 Do ot force blade i to material: allow
blade to cut at its ow speed.
 Do ot make lo g co ti uous cuts. Never
dry cut for more tha 30 seco ds at a time.
Allow blade to cool.
 Do ot cut or gri d with side of blade or
cut a curve or radius.
 Do ot cut dry with blades recomme ded
for wet cutti g.
 Do ot operate saw with blade diameter
larger tha machi e's capacity.
