INSTALLATION GUIDE
TOOL MAX SINGLE
[email protected]Contact us at:
Questions or Concerns?

IMPORTANT INFORMATION
WARNING! The Tool Max Single is NOT intended for use by any person under the age of 18
years old. You must be over the age of 18 to install or use the Tool Max Single.
WARNING! Strictly follow all instructions to avoid an accident, damage to property,
personal injury or death.
WARNING! Do not use this product for human suspension. Components can fail causing
person to fall, possibly resulting in serious injury or death.
WARNING! When operating system, make sure the area below object is clear of persons. If
object comes down too quickly, this can cause an accident.
READ THE ENTIRE USER MANUAL BEFORE INSTALLATION
The User Manual you received with your Tool Max Single provides instructions on how to install
and use your Tool Max Single. The instructions are written for a person with a basic understand-
ing of tools and procedures. Read the entire manual before proceeding. If you do not under-
stand any portion of the instructions, do not attempt installation, and email
[email protected].
CORRECTLY INSTALL THE PRODUCT
Read and follow all instructions carefully.
Failure to properly install and use the Tool Max Single could allow the product to detach from
the wall, injuring persons or personal property in the process. Accordingly, it is critical that the
Tool Max Single be installed correctly and according to the instructions in the User Manual.
USE TOOLS SAFELY
The procedures in the User Manual may require climbing ladders and/or operating power tools.
Make sure you are familiar with these tools and their safety procedures before attempting to
use such tools during installation. Always be aware of electrical wires during installation. Failure
to do so could result in an electrical shock or death.
WARNING!
Contact with wires can give you a severe electrical shock, which may cause injury or death. If you
do not know where wires are, have the work done by an experienced professional.
Tool Max Single
Manufactured for Spire LLC by Tellbe in Vietnam
Quantity: 1
IMPORTANT INFORMATION
CAUTION
It is the consumer’s responsibility to install this system in accordance with all codes, ordinances,
and local regulations.
When installing Tool Max Single, it is the consumer’s responsibility to ensure the structural
integrity of the structure it is being mounted to.
The Tool Max Single is intended for the storage of tools only. Do not use it for any other pur-
pose.
This system has a maximum capacity of 50 lbs. per unit. Overloading the system could result in
damage to property or injury.
Use extreme caution when loading and unloading equipment from this system.
It is the consumer’s responsibility to ensure that the system is in proper working condition
before loading objects onto the system. Check tightness of all bolts and screws periodically.
Failure to properly maintain the system could result in damage to property or injury.
WARNING AND DISCLAIMER
Spire LLC (d/b/a StoreYourBoard) expressly disclaims any and all liability for personal injury,
property damage or loss, whether direct, indirect, incidental, resulting from the incorrect
mounting, improper use, inadequate maintenance, or neglect of this system.

Wall Rack
Qty: 1
Wall Screws
Qty:2
Machine Washers
Qty:2
Drill/Driver
Drill bits
Socket/Driver
Level
Tape measure
Pencil
Stud finder
50 lbs. max per unit
RECOMMENDED TOOLS: WEIGHT LIMITS:
INSTALLATION NOTE: Tool Max Single must be mounted to a wall stud to achieve the advertised weight limit
Use a stud finder to find a wall stud where you want to mount the product and mark the
location with a pencil.
1
Hold the rack up to the wall where you want to mount it and align the mounting hole with
the stud location. Use a level to ensure the rack sits flat to the ground and mark the
mounting holes along the stud.
2
Use a 3/16 inch (4.7mm) drill bit to drill pilot holes into the stud where you marked them.
A Machine Washer (C) should be used between the Wall Rack (A) and the Wall Screw (B) as
shown in the figure below. Insert the Wall Screws (B) with Machine Washers (C) into the pilot
holes to mount the rack.
3
4
A
B
C
