STRATAIR Raketenwurm 4b User manual

STRATAIR- Modelltechnik GmbH, Batthyanystrasse 1, A-2454 Trautmannsdorf, Tel: [phone], [email protected]
www.stratair.com, UID-Nr.: ATU 612 284 88, FN : 253148 b
1
Raketenwurm 4b
Fuselage:
Put wooden servo mounting together, fix them with CA, insert M3 nut into wood.

STRATAIR- Modelltechnik GmbH, Batthyanystrasse 1, A-2454 Trautmannsdorf, Tel: [phone], [email protected]
www.stratair.com, UID-Nr.: ATU 612 284 88, FN : 253148 b
2
_
Glue M2 rods into 4/2mm carbon tube. Solder 1,5mm steel wire into coupler
_

STRATAIR- Modelltechnik GmbH, Batthyanystrasse 1, A-2454 Trautmannsdorf, Tel: [phone], [email protected]
www.stratair.com, UID-Nr.: ATU 612 284 88, FN : 253148 b
3
Fix 2,5mm ball bearing with CA into bell crank
_
Slide servo + pushrod into fuse and fix it with M3 screws
_
Inserst bell crank and secure it with short 2,5mm steel bolt. Screw pushrod into clevis of bellcrank
_

STRATAIR- Modelltechnik GmbH, Batthyanystrasse 1, A-2454 Trautmannsdorf, Tel: [phone], [email protected]
www.stratair.com, UID-Nr.: ATU 612 284 88, FN : 253148 b
4
Lift clevis of pushrod to servo and connect it with bell crank.
__
Secure removable nose with some windings of tape or drill 2mm hole left and right side and drill M3
thread through fuselage & nose.
Glue motormount with UHU plus Endfest 300 or something similar into nose cone
Do NOT press needless the fuselage in area between end of wing until beginning of vertical
stabilizer.
Wing:
Servocables are ready to use. If you have to change a wingservo remove cover and open surface.

STRATAIR- Modelltechnik GmbH, Batthyanystrasse 1, A-2454 Trautmannsdorf, Tel: [phone], [email protected]
www.stratair.com, UID-Nr.: ATU 612 284 88, FN : 253148 b
5
Pushrods for ailerons and flaps are preinstalled. Just connect servos to receiver or tester and
pushrods will be visible.
Flap horn installation & glueing.
Aileron horn installation & glueing
Neutral position of aileron servos should be neutral of aileron. Never the less it can vary
because of different RC-products.
Neutral position of flap servos = 30° flap down. Flap is in neutral if you move servo to around
-120%. +120% = 60° flap down.
Use 2 pcs. M3 screws to connect wing-fuselage. In the back of the wing tape the small tongue of
the wing with fuselage
Powerdrive + RC:
Motor and ESC cables as short as possible
Battery Setup:
Motor battery can be installed from the front or through the opening in wing area.
Max. dimensions:
- 34x43x230mm
- 37x37x230mm

STRATAIR- Modelltechnik GmbH, Batthyanystrasse 1, A-2454 Trautmannsdorf, Tel: [phone], [email protected]
www.stratair.com, UID-Nr.: ATU 612 284 88, FN : 253148 b
6
Try that RX and RX powersupply are positioned as far as possible in the rear. Especially if you split
motor battery.
Settings:
CQ: 58-61mm
Level flight: fuselage on flat surface. Hor. Stabilizer trailing edge 126mm above surface
Speed flight
oNeutral: all 0
oHor. stab: +9 / -7 mm (20% Expo)
oAileron: +8 /-5 mm
oSnapFlap: flap -8mm if stabilizer full up
oSnap Flap: flap +2mm if stabilizer full down
oSnap Flap: aileron1mm less than flap = 1mm difference at flap-aileron position = small
sewing
Motor ON
oSnap Flap deactivate
oButterfly deactivate
Gliding / time flight
oNeutral
flaps -5mm
aileron 0,5mm less than flaps = 1mm difference at ail-flap position = small
sewing
oAileron: +8 /-1 mm (+90% Differentiation)
Butterfly
oflaps: ca. 45° down
oaileron: ca 20° up
oelevator: -5mm at max. Butterfly
oaileron deflection to max.
oaileron differentiation: reduce (also – 80% Diff possible)
+ = up
- = down

STRATAIR- Modelltechnik GmbH, Batthyanystrasse 1, A-2454 Trautmannsdorf, Tel: [phone], [email protected]
www.stratair.com, UID-Nr.: ATU 612 284 88, FN : 253148 b
7
Checklist:
Verify RC-functions and servos before each start.
Inspect model on damages
After each flight check all movement areas
Hor. Stabilizer tolerance check
Attention:
The Raketenwurm 4 is no model for beginners. Because of high speed you could threaten
material and persons if there are any model or stearing faults. STRATAIR does not assume
liability for damages!
Technical data:
Wingspan: 1870mm
Length: 1200mm
Area: 27dm²
Max. FAI weight: 2025g
Empty weight incl. servos&cables aprox. 640g
Spinnerdiameter: 32 or 36mm
Components:
Wing servos: 4x MKS DS6100
Hor. Stab servo: MKS DS6188
Motor: 6S Lipol: Leomotion L4031 – 2050 6,7:1 oder NEU 1512 1,5D 6,7:1
10A Lipol: Leomotion L4031 – 3300 6,7:1 oder NEU 1512 2,5D 6,7:1
ESC: YGE 150HV oder YGE 200HV FAI
Battery: 6S Lipol 2650mAh, 10S Lipol 2200mAh
Propeller: up to 19”
RX battery: 400-800mAh or external-BEC (max. 5,5V!!!!)
Powerdrive-Setups:
1: moderate power – high power
MEGA 16/40/1 + 5,2:1 Motor
YGE 160 FAI ESC
5S 2650 mAh Lipol Battery
16x17S RF Prop
2000W Power
2: F5B power
Leomotion 4031 – 2050 6,7:1 Motor
YGE 150HV ESC
2x5S 1800-2200mAh Lipo Battery
17x18 RF + 5-7° twisted spinner Prop
6000-7000W Power
