Stream SV8W User manual

SV8W Quick Start Guide
Tel: [phone] E-mail: [email protected]om.au Web: www.steamaustralia.com.au
1
SV8W SV8W Display SV8W Hose Controls
_______________________________________________________________________________________________
Preparing the SV8W
Steam Operation:
1. Plug cable into a wall outlet.
NOTE: Do NOT use multi-outlet power-boards and
avoid using low-quality extension cables.
2. Open water tank filler cap (iii), fill tank with clean
tap water up to the top then close filler cap.
NOTE: Do NOT use de-mineralised water and do NOT
fill with any chemicals.
3. Turn SV8W on using the ON/OFF switch (i), making
sure the steam level lights on the display (g) light up
after a few seconds.
4. Connect hose into the SV8W by opening the
protective plastic flap located on the front of the
machine (ii) and pushing the plug end of the hose in
with the round red button on the top side of the hose
until it clicks.
Proceed to “Vacuum Operation” and/or “Water Injection
Operation” section if you are planning on using the vacuum
and/or water injection functions together with the steam
functions.
Vacuum Operation:
1. Turn the vacuum on from the hose controls by
quick-pressing (V).
The SV8W will make a beeping noise and
the vacuum waste tank lights
(b) will flash on the display.
2. Open the transparent
vacuum cover (iv), remove
blue foam filter and slowly fill
clean tap water into the
rectangular hole on top of the
vacuum waste tank until the
vacuum waste tank lights (b)
stops flashing.
3. Replace the blue foam filter
and the transparent vacuum cover (iv).
NOTE: If the vacuum waste tank
lights (b) still flashes after filling
the tank up, remove the plastic
part with the rectangular hole,
then remove the plastic divider
underneath. You will see a
white float, make sure the
white float’s surrounding areas
and the float itself is clean and
can move freely. Re-assemble
the waste tank, fill the tank with clean tap water until
the vacuum waste tank lights (b) stops flashing then
put the blue foam filter and transparent vacuum
cover (iv) back on.
Hose Handle Operations
Steam Functions:
1. After 5-6 minutes the ‘Steam Ready’ lights (d) will
light up on the display and the steam function is ready
for use. Make sure the steam level lights (g) is on,
otherwise quick-press the RED steam button (S) until
the steam level lights turn on to prepare the steam
function for use.
2. If the SV8W makes a beeping noise and the ‘Low
Water’ lights (c) flashes, proceed to Step 2 of
“Preparing the SV8W | Steam Operations”.
3. Press and hold the RED steam button (S)to select
between 3 steam levels: low, medium, or high. The
steam level lights (g) display will light up in
correspondence to the different steam levels: 1 =
Low, 2= Medium and 3= High.
4. Once you have selected which steam levels you
want, press the trigger located underneath the hose
handle (T)to release steam from the nozzle.
WARNING: Do NOT operate hose with steam nozzle
pointing at persons, animals or electrical machinery
[S]
[L]
[V]
[T]
[i]
[ii]
[iii]
[iv]
[f]
[g]
[e]
[b][c][d]

SV8W Quick Start Guide
Tel: [phone] E-mail: [email protected]om.au Web: www.steamaustralia.com.au
2
/equipment/outlets/sensors that are sensitive to
water and heat (especially near fire alarm sensors).
Vacuum Functions:
1. Press the BLACK & WHITE vacuum button (V)to
engage the vacuum function. The vacuum will turn on
and you will feel suction from the vacuum nozzle.
2. If the vacuum stops, a beeping noise is heard and
the vacuum waste tank lights (b) flashes, check for any
water present in the waste tank. Remove any water
present and proceed to Step 2 & 3 of “Preparing the
SV8W | Vacuum Operations” (page 1).
3. Press and hold the BLACK & WHITE vacuum button
(V)to select 3 vacuum levels: low, medium, or high.
The vacuum level lights display will light up in
correspondence to the different vacuum levels: 1=
Low, 2= Medium and 3= High.
Water Injection Functions:
1. The water injection function only works when the
steam function is active. Water gets injected together
with steam when it is activated.
2. To activate the water injection, press the BLUE
water injection (L)button on the hose. The water
injection light (e) will light up on the display.
3. If the SV8W makes a beeping noise and the ‘Water
tank low’light (c) flashes on the display, proceed to
Step 2 of “Preparing the SV8W | Steam
Operations”(page 1).
NOTE: Using the water injection continuously will
quickly drain the water tank, therefore it is advised
that the water injection function is to be used only
when cleaning hard to remove stained areas.
Warning Lights
The SV8W will make a beeping noise and a
red light will flash on certain conditions:
- Water tank low level (c)
- Vacuum waste tank no water/too much
waste (b)
For water tank low level, refer to Step 2 of “Preparing
the SV8W | Steam Operations”.
For vacuum waste tank issues, clean out the waste
tank and proceed to Step 2 & 3 of “Preparing the
SV8W | Vacuum Operations”.
Cleaning the SV8W
Draining the SV8W’s boiler once a month ensures that
the machine operates at optimal conditions.
WARNING: Ensure machine has cooled down before
attempting to clean out the boiler by checking that
the machine does not feel warm on the bottom part
and machine is free from any pressure.
You will need:
- A pan or container that can hold at least 5L of water
- A rag
- Flathead screwdriver
- Supplied socket wrench
1. Ensure the machine is not plugged into a power
source and the machine does not feel warm with no
pressure present.
2. Using a flathead screwdriver, remove the black
plastic cover concealing the boiler drain plug located
underneath the SV8W by inserting the screwdriver
into the slit and turning counter clockwise.
3. Once the brass boiler plug is exposed, prepare the
SV8W by positioning it on top of a pan or container.
4. Using the supplied socket wrench, unscrew the
boiler plug by slowly turning counter clockwise. You
may need to use a rag to hold the plug as you unscrew
the plug by hand after loosening using the socket
wrench. Let the water drain, then screw the plug back
on and tighten with supplied socket wrench.

SV8W Accessories Guide
Tel: [phone] E-mail: [email protected]om.au Web: www.steamaustralia.com.au
3
Floor Steam + Vacuum Tool
Triangular Brush (Optional Accessory)
AC8000061 Triangular Brush
S/O Red Bristles
AC8000041 Adapter S/V to
S/O
Microfibre Cloth
For cleaning skirting boards, kitchen
benchtops, underneath kitchen
cabinets, rangehoods, car interior and
other areas.
Use the brush and steam to remove dirt
on hard surfaces only.
If using on gentle upholstery surfaces
such as leather, wrap the triangular
brush with a microfibre cloth to steam
clean.
AC8000034 Floor Tool
S/V 300mm
AC8000025 Insert Dual
Squeegee 300mm
AC8000012 Insert S/V
Carpet Glider 300mm
2 x AE0000011
Extension Tube S/V
500mm
For hard floor surfaces such as:
- Tiles
- Marble
- Most sealed hardwood
- Linoleum & Vinyl
- Carpets
- Non-slip surfaces
First, use high steam pressure to lift dirt
off the floor. Then disengage the steam
and turn on the vacuum to suck the
floor dry.
When using with carpets, set steam
pressure to medium and vacuum level
to high.

SV8W Accessories Guide
Tel: [phone] E-mail: [email protected]om.au Web: www.steamaustralia.com.au
4
Detailing Extension
AC8000024 Nozzle Detail
w/Extension
For cleaning and sanitizing areas such
as:
- Sinks
- Toilets
- Car interior & exterior
- Hard to reach nooks & crannies
150mm S/V Head
AC8000027 Head S/V
150mm
AC8000029 Insert
Window Squeegee
250mm
AC0020004 Small Sockette
150mm
As window squeegee function:
Attach the AC8000029 squeegee insert.
Spray a stream of steam in a circular
motion onto the glass surface, then use
the rubber squeegee part to remove
water condensation and clean the
surface. Turning on the vacuum helps
sucking excess water droplets while
cleaning.
If using in areas with frosty climates,
warm the windows or mirrors by
spraying a high stream of steam for a
slightly prolonged time before cleaning.
As flat surface cleaner:
Attach small sockette. Use medium
steam level and wipe across surface.
Suitable for doors, kitchen benchtops
and upholstery.

SV8W Accessories Guide
Tel: [phone] E-mail: [email protected]om.au Web: www.steamaustralia.com.au
5
S/V Detailing Nozzle + Small Nylon Brush
AC8000023 Nozzle S/V
Detail
2 x AE0000011 Extension
Tube S/V 500mm
AC0010022 Brush
Round Nylon 30mm
Optional Accessories:
AC0010023 Brush Round
Stainless Steel 30mm
AC0010020 Brush Round
Brass 30mm
For detail cleaning in kitchens,
bathrooms and other areas:
- Tile grouts (walls and floors)
- Drains
- Cooktops
- Bathtubs
For best results, hold brush on angle to
clean sides of the grout line, and then
tilt in other direction to clean the other
side of the grout line. Turn the Water
Injection function on, for cleaning
tougher grout stains. (refer to
“Preparing the SV8W | Water Injection
Operation” on page 1)
Optional stainless steel and/or brass
brushes can be fitted onto the detailing
nozzle to scrub off certain hard-to-
remove stains in nooks and crannies.
Stainless steel is particularly effective on
grout.
Be wary that the stainless steel and
brass brushes may scratch certain
surfaces, leaving unwanted scratch
marks. Always test areas in an
inconspicuous spot before proceeding.

SV8W Accessories Guide
Tel: [phone] E-mail: [email protected]om.au Web: www.steamaustralia.com.au
6
Floor Mop Head + Microfibre Mop Pad (Optional Accessory)
AC8000016 Mop Head Floor
390mm
AC0020002 Microfibre Mop
Pad Floor 390mm
AC8000041 Adapter S/V to
S/O
2 x AE0000011
Extension Tube S/V
500mm
For cleaning non-carpeted hard-floor
surfaces.
Use medium steam flow and move
forwards and backwards quickly over
the floor surface.
Wall Mop Head + Microfibre Mop Pad (Optional Accessory)
AC8000040 Mop Head Wall
250mm
AC0020001 Microfibre
Mop Pad Wall 250mm
AC8000041 Adapter S/V to
S/O
2 x AE0000011
Extension Tube S/V
500mm
For hard wall surfaces and ceilings.
Used for cleaning dirt, dust and food
stains off walls. Can also be used to
sanitise walls in kitchens and other
areas.
Upholstery Tool (Optional Accessory)
AC8000067 Upholstery
Tool
For cleaning fabric upholsteries such as
sofas, office chairs, car seats and car
fabric interiors.
Best used with the Water Injection
function. Engage the water injection
function. Turn vacuum on to high and
steam pressure to high. Press and hold
the trigger to let steam and water out
while vacuuming.
