Streetwize SWDAB2 User manual

In Car DAB Radio Adapter
SWDAB2
Intention For Use
Thank you for purchasing this In-Car DAB Radio Adaptor With Bluetooth Connectivity from
Streetwize. This product is intended for motorists that want to listen to their favourite
DAB radio stations in their vehicle. This device also comes with bluetooth connectivity for
connecting your smartphone for answering & rejecting calls hands-free and play music
stored on your device or via streaming services such as Spotify, Amazon Prime & YouTube.
before using this product, we recommend reading all the information in this document. please keep this
document for future reference.
1. Centre console fixed leg
2. Air vent clip
3. Rotary shaft setting
4. Clip adjust place
5. TF card slot
6. Audio output
7. MIC
8. LCD display
9. Previous button
10. TX Button (CH ≠activation/DAB automatically searching)
11. Answer/Play/Volume adjustment
12. Mode shift (DAB/Bluetooth/TF card)
13. Next button 14. Antenna jack
15. Power adaptor
16. USB output: 5V/1A
17. USB output: QC3.0
18. Antenna
19. AUX cable
Product Elements

To operate this DAB adaptor, you will need to securely fit the antenna
onto your vehicle’s windscreen, and then connect the antenna to the
DAB adaptor via anthenna jack. Please follow the instructions below:
1. Remove the product out of its packaging and dispose of the packaging
in the correct manner.
2. Open the driver side door of your vehicle and carefully remove the
interior panel from the right-hand frame of the windscreen. This will
reveal a metal pillar.
Important: Please refer to your vehicle’s handbook for
safe and proper removal of the interal panel.
3. With the antenna, carefully remove the protective paper from both
the clear adhesive film and the black adhesive film. Discard both
protective papers in the correct manner.
4. Then attach the black adhesive film to the metal pillar and the
transparent film onto the windscreen. Please ensure that you attach
the antenna properly so that you can reinstall the panel later.
5. Thread the antenna’s wiring along the metal pillar, towards the bottom
and allow the connector-end of the wire to rest on your vehicle’s
dashboard. Ensure you have enough wire to connect the DAB adaptor
when mounted on either the dashboard or air vent mount.
Important: Becareful not to overstrech the wire when doing so.
6. Reinstall the panel back. Important: Please refer to the vehicle
handbook for safe and proper installation.
7. Mount the antenna to either the air vent or dashboard (see Mounting
The DAB adaptor).
8. Connect the antenna to the DAB adaptor.
9. Plug in the DAB adaptor to your vehicle’s 12V socket and switch on
your vehicle to turn on the DAB adaptor.
Vent Clip
To attach the vent clip, loosen the rotary shaft,
then insert the ball joint of the vent clip into
the socket. Once inserted, tighten the rotary
shaft to secure the vent clip in place.
To mount the DAB adaptor using the vent clip,
press the button to open the clip so that it can
be slotted into the vehicle’s air vent. Once the
vent clip is in the air vent, release the button
to secure in place.
Dashboard/Windscreen
To mount the DAB adaptor to your dashboard
or windscreen, you will need to attach the vent
clip to the DAB adaptor (see section above).
With the vent clip in place, insert the clip onto
the central fixing console.
Important: If you intend to mount the DAB adaptor
using the central fixing console, please note that the
adhesive backing can only be used once. We advise
that you first position the console in different places
on your windscreen/dashboard before peeling off the
white protective film.
Once you have found your desired position to
mount the console, carefully peel off the white
protective film from the reverse side of the
central fixing console to reveal the adhesive
backing and secure the console onto your
dashboard/windscreen.
Set Up & Installation Mounting the DAB Adaptor

Using The DAB Adaptor Using The DAB Adaptor
Setting FM Frequency To Link The DAB Adaptor
1. With the DAB adaptor switched on, press & hold the TX button for the adaptor to
prompt you to set the FM frequency to link the adaptor to your vehicle’s FM stereo.
See Figure 1.
Scanning/Listening to DAB Radio Stations
To scan and listen to DAB radio stations, please follow the instructions:
1. Press the Mode button until you enter DAB mode.
2. To seach for DAB stations, press the TX button and the adaptor will start to scan DAB
stations. See Figure 2.
3. Once the DAB scan has been complete, you can select your channel by pressing either
or .
4. You can adjust the volume by rotating the knob.
2. Press either or to set your desired frequency.
Long pressing / will change the frequency quickly,
short press will change the frequency slowly.
You can also rotate the knob to change the frequency.
3. You can set the frequency anywhere from 87.5MHz to 108MHz.
Important: When selecting your frequency, please ensure that your chosen frequency is empty.
4. Then, switch on the vehicle’s FM stereo and adjust the radio’s frequency so that it
matches the FM frequency that you’ve set in your DAB adaptor.
Fig. 1
Fig. 2

Connecting Your Smartphone to the DAB Adaptor Via Bluetooth
To link your smartphone or tablet device to the DAB adaptor via Bluetooth, please follow
the instructions below:
1. On the adaptor, press the Mode button until you have entered Bluetooth mode.
2. To connect your smartphone/tablet to the adaptor, please make sure your Bluetooth is
enabled on your smartphone/tablet device.
3. Then, on your smartphone/tablet, search for ‘DAB-CarKit’ when searching for nearby
Bluetooth devices. Select ‘DAB-CarKit’ to pair your device with the adaptor.
4. The adaptor will sound a confirmation tone and the LCD display will show ‘Bluetooth
Connected’. See Figure 3
Handsfree Calling
When your phone is connected
via Bluetooth, you can answer,
reject, hang up and redial the
last call via the adaptor. Please
see Table 1 for instructions:
TF (Micro SD) Card Mode
You can also play music stored on a TF card (Micro SD card). To do so, please follow the
instructions below:
1. Insert the TF card into the slot located on the left side of the DAB adaptor.
2. On the DAB adaptor, press the Mode button until you’ve entered TF mode. Entering this
mode will enable the adaptor to read the TF card.
3. To play/pause music, press . To change track press either or .
AUX Input
Using the supplied AUX cable, connect one of the cables to the 3.5mm output jack port of
your audio device (i.e. portable MP3 player) and the other end of the cable to the input AUX
jack on the DAB adaptor.
When a connection via AUX has been made, you will see the headphone icon appear on the
LCD display.
Please note: You can only play/pause music and change tracks via the audio device.
You can’t change tracks or play/pause via the DAB adaptor itself.
Table 1
Action Command
Answer incoming call Short press
Hang up current call Short press during call
Reject incoming call Long press
Redial last call Double press
87.5MH z00 05
Bl uetoot h Connected
Pause
Playing Music From Your Phone/Tablet
To link your smartphone or tablet device to the DAB adaptor via Bluetooth, please follow
the instructions below:
Once your device is connected to the adaptor via Bluetooth, you are able to play music
from your smartphone to your vehicle’s stereo system. You can play music stored on your
device or you can play music from streaming services such as Spotify, Amazon Prime &
YouTube.
When playing music from your device you can press to play or pause the audio track.
And you can skip/change tracks by pressing either or .
Plus, you can adjust the volume by rotating the knob.
Charging Devices Via 12V USB Charge Ports
The 12V plug that powers the DAB adaptor features two
USB charge ports (see Figure 4). These USB charge ports
are suitable for charging your smartphone, tablet or any
other portable USB device
To charge a device, connect the DAB adaptor’s plug into
your vehicle’s 12V socket. Switch on your vehicle and then
connect your device via the USB ports to commence charge. Figure 4
Fig. 3

Technical Support & Spare Parts
If you require any technical support or spare parts for your product within the warranty
period, please contact us on [email protected] and provide the
product name and supplier code (see Technical Specifications) along with the technical
query and proof of purchase.
Technical Specification
Product Streetwize In-Car DAB Radio Adaptor With Bluetooth Connectivity
Supplier code SWDAB2
Rate working voltage 12V or 24V
Limited working voltage 9V - 26V
USB 1 output 5V/1A
USB 2 output QC3.0
Working temperature <60°C
Music Format MP3
TF card compatibility 1GB to 32GB
Bluetooth version 4.2 x EDR
Modulation system QPSK
DAB frequency 177MHz to 240MHz
Auto power-off memory Yes
FM Frequency 87.5MHx to 108MHz
Emission distance 0.5m to 2m
Bluetooth emission distance <10m
DAB Frequency
177MHz to 240MHz
Auto power-o memory
Ye s
FM Frequency
87.5MHz to 108MHs
Emission Distance
0.5m to 2m
Bluetooth Emission Distance
<10m
