Lectronix Navion R5000 User manual

R5000
Installation Instructions for
RV’s
Read these instructions carefully before installing this product and keep this manual for
future reference.

ii
© 2006, 2007 Lectronix, Inc.
16733-A.0

iii
DISCLAIMER
THIS IS A DISCLAIMER OF LIABILITY AND DAMAGE RESPONSIBILITY AS
REGARDS TO LECTRONIX, INC. AND GARMIN RELATING TO YOUR USE
OF THE LECTRONIX R5000 SYSTEM. READ IT CAREFULLY. YOU
ASSUME TOTAL RESPONSIBILITY AND RISK FOR USING THIS SYSTEM.
Failure to properly focus on the operation of your motor vehicle can result in death,
serious injury and property damage. This R5000 device should never be used at a time or
in a manner that distracts you from properly focusing on operation of the motor vehicle in
which it is installed. Our concern is for your safety. We ask that you fully cooperate with
and share that concern.
Always operate the vehicle in a safe manner and in full compliance with speed limits, road
safety signs and all other laws and devices, which regulate operation of a motor vehicle.
Be and remain aware of driving conditions at all times when using this system while
operating a motor vehicle.
Operation of this unit, including its camera, navigation, audio and other features can be
distracting to your operation of the motor vehicle. While the system is intended to provide
both entertainment and helpful vehicle and navigation information, it is not intended to,
nor should you allow it to distract you from properly focusing on operating the motor
vehicle in which it is installed. It is up to you to minimize or prevent such distraction.
Learn how to use this system before placing the vehicle in operation. Minimize the amount of
time spent viewing the screen of the unit while driving and use voice prompts whenever possible.
Do not attempt to adjust settings of the system or resolve any malfunction with it while driving.
Instead, pull off the road in a safe and legal manner and then adjust its settings or deal with any
malfunction. In the event of malfunction, disable the unit (turn power off or remove power from
the system).
In addition to its multiple other functions, your R5000 system may be equipped with the optional
Garmin GVN52 navigation unit. The navigation functions are provided by Garmin and are
displayed on the R5000 screen. The use of such navigation functions are the subject of a
separate Disclaimer from Garmin contained in the Garmin GVN52 Owner’s Manual made
available to you before use. Read that Garmin Disclaimer as it is also applicable to your use of
this system.
When navigating, carefully compare information displayed on the unit to all available navigation
sources, including information from street signs, visual sightings, and maps. Do not enter
destinations, change settings or access any functions requiring prolonged use of the controls of
the unit while operating your motor vehicle. For safety, pull off the road before making any
adjustments to the system or resolving any navigation discrepancies or questions.

iv
Table of Contents
Safety Information......................................................................................................................... 1
Warnings .................................................................................................................................... 1
Cautions ..................................................................................................................................... 3
Notes on Use: Liquid Crystal Panel ........................................................................................... 3
Getting Started............................................................................................................................... 4
Understanding Your R5000........................................................................................................4
Garmin GVN 52 Owner’s Manual............................................................................................... 4
Satellite Radio User’s Guide ...................................................................................................... 5
Controls, Applications and Functions......................................................................................... 5
Turning the R5000 On and Off................................................................................................... 5
Standby Operation ..................................................................................................................... 5
Selecting Applications and Functions ........................................................................................ 6
The R5000 Display..................................................................................................................... 7
Using the Sound Controls .......................................................................................................... 8
Adjusting Sound Settings........................................................................................................... 8
Adjusting the Display.................................................................................................................. 9
Installation of the R5000 ............................................................................................................. 10
Dimensions of the R5000.........................................................................................................10
Wiring the R5000 Unit to the Vehicle’s Power and Speakers.................................................. 13
Diagram of the Rear Connection of the R5000........................................................................ 13
Operation instructions .............................................................................................................. 13
Sirius Satellite Radio................................................................................................................... 14
Installation instructions for the Sirius Satellite Vehicle Tuner .................................................. 14
Sirius Interface Cable............................................................................................................... 14
Reference Picture for Mounting Location of Satellite Antenna: ............................................... 15
Operation instructions .............................................................................................................. 15
Camera System (CAM)................................................................................................................ 16
Rear Camera Mounting............................................................................................................16
Installation instructions for the Sony Side Camera System ..................................................... 17
Reference Pictures for Mounting Location of the Side Cameras:............................................ 20
Painting Recommendations for Sony Side Camera’s.............................................................. 21
Operation instructions .............................................................................................................. 21
Tire Pressure Antenna Mounting Location............................................................................... 22
Mounting the Tire Pressure Antenna to the Vehicle................................................................ 23
Tire Pressure Monitor (Tires) ..................................................................................................... 24
Tire Pressure Sensor Operation............................................................................................... 24
Installing Tire Pressure Sensors .............................................................................................. 25
Removing Tire Pressure Sensors ............................................................................................ 26
Replacing Tire Pressure Sensors............................................................................................. 26
Tire Pressure Alarms................................................................................................................ 26
Garmin Navigation....................................................................................................................... 27
Installation instructions for the Garmin Navigation System...................................................... 27

v
Garmin GVN52 Interface Cable ............................................................................................... 27
Operation instructions .............................................................................................................. 27
Maintenance................................................................................................................................. 28
Troubleshooting .......................................................................................................................... 29
If You Suspect something is wrong.......................................................................................... 29
Common Problems................................................................................................................... 29
Appendix A: One Year Limited Warranty.................................................................................. 31
Appendix B: Service and Technical Support............................................................................ 32
Contact Lectronix, Inc............................................................................................................... 32
Appendix D: R5000 Coach Adapter Cable ................................................................................ 33
Appendix E: Tire Pressure Monitoring Option......................................................................... 35
Sensor Specifications............................................................................................................... 35

IMPORTANT SAFETY INFORMATION
1
Safety Information
Read the operating instructions for the R5000 and all other components of the system carefully
before using the system. They contain instructions about how to use the system in a safe and
effective manner. FAILURE TO OBSERVE THE INSTRUCTIONS GIVEN IN THIS MANUAL
MAY CAUSE INJURY OR DAMAGE AND VOID THE WARRANTY.
This manual uses pictographs to show you how to use the product safely and to alert you to
potential dangers resulting from improper connections and operations. The meanings of the
pictographs are explained below. It is important that you fully understand the meanings of the
pictographs in order to use this manual and the system properly.
Warning This pictograph intends to alert you to the presence of
important operation instruction and installation
instructions. Failure to heed the instructions may result
in severe injury or death.
Caution This pictograph intends to alert you to the presence of
important operation instruction and installation instructions.
Failure to heed the instructions may result in injury or material
damage.
Warnings
Warning Observe the following warnings when using
this unit.
• The driver should neither watch the display nor operate the system while driving.
Watching the display or operating the system will distract the driver from looking ahead of
the vehicle and can cause accidents. Always stop the vehicle in a safe location and use
the parking brake before watching the display or operating the system.
• Use the proper power supply.
This product is designed for operation with a negative grounded 12 V DC battery
systems. Never operate this product with other battery systems, especially a 24 V DC
battery system.
• Protect the deck mechanism.
Do not insert any foreign objects into the slot of this unit.
• Do not disassemble or modify the unit.
Do not disassemble, modify the unit or attempt to repair the product yourself. If the
product needs repair, consult your dealer or contact technical support (see Appendix B).
• Do not use the unit when it is out of order.
If the unit is out of order (no power, no sound) or in an abnormal state (has foreign
objects in it, is exposed to water, is smoking, or smells), turn it off immediately and
consult your dealer.
• Refer installation to qualified personnel.

IMPORTANT SAFETY INFORMATION
2
Warning Observe the following warnings when
installing.
• Disconnect the lead from the negative (–) battery terminal before installation.
Wiring and installation with the negative (–) battery terminal connected may cause
electrical shock and injury due to a short circuit. Some vehicles equipped with the
electrical safety system have specific procedures of battery terminal disconnection.
FAILURE TO FOLLOW THIS PROCEDURE MAY LEAD TO THE UNINTENDED
ACTIVATION OF THE ELECTRICAL SAFETY SYSTEM RESULTING IN DAMAGE TO
THE VEHICLE AND PERSONAL INJURY OR DEATH.
• Never use safety-related components for installation, grounding, and other such
functions.
Do not use safety-related vehicle components (fuel tank, brake, suspension, steering
wheel, pedals, airbag, etc.) for wiring or fixing the product or its accessories.
• Do not install the product on the air bag cover or in a location where it interferes
with airbag operation.
• Check for piping, gasoline tank, electric wiring, and other items before installing
the product.
If you need to open a hole in the vehicle chassis to attach or wire the product, first check
where the wire harness, gasoline tank, and electric wiring are located. Then open the
hole from outside if possible.
• Never install the product in a location where it interferes with the driver’s field of
vision.
• Never branch the power cord to supply other equipment with power.
• After installation and wiring, you should check the normal operation of other
electrical equipment.
Using electrical equipment that is not operating normally may cause fire, electrical shock
or a traffic accident.
• In the case of installation to an airbag-equipped vehicle, confirm warnings and
cautions of the vehicle manufacturer before installation.
• Make sure the leads do not interfere with driving or getting in and out of the
vehicle.
• Insulate all exposed wires to prevent short-circuiting.

IMPORTANT SAFETY INFORMATION
3
Cautions
Caution FOLLOW THE LAWS AND REGULATIONS OF YOUR
STATE, PROVINCE OR COUNTRY FOR INSTALLATION.
Caution THIS PRODUCT IS A CLASS I LASER PRODUCT.
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR BY
YOURSELF. REFER SERVICING TO QUALIFIED
PERSONNEL.
Notes on Use: Liquid Crystal Panel
• Do not cause impact to the liquid crystal panel.
• When the temperature is very cold or very hot, the image may appear unclear or may
move slowly.
• In order to protect the liquid crystal panel, keep it out of direct sunlight while the unit is not
in use.
• Sudden changes in the temperature inside the vehicle such as those which occur
immediately after the vehicle’s air conditioner or heater has been turned on may cause
condensation (droplets of water) to form and, as a result, the panel may not work
properly. Do not use the unit while these symptoms are in evidence but leave the unit
standing for about an hour, and then resume or start use.

INTRODUCTION
4
Getting Started
Understanding Your R5000
The R5000 combines radio, CD/MP3 player, rear-view camera system, and advanced engine,
coach, and trip monitors into a single integrated system designed specifically for use in
Recreational Vehicles. The unit installs easily in the same dashboard space commonly used for
existing camera monitors, and replaces three separate systems (camera, radio, and vehicle
computer) with one. The R5000 also allows navigation, satellite radio and tire pressure monitoring
as options accessible from one common interface.
System Overview
• Integrated Audio Entertainment,
Camera, Vehicle Monitor, and Trip
Computer
• In-Dash Controller Unit with 7.0” Color
TFT LCD Display
• CD Reader for Regular and
Compressed Audio (MP3/WMA)
• Integrated 200W Amplifier for Four (4)
Audio Channels at 50W Each
• Clock
• Video Output (allows screen, any
camera, or navigation to be routed to
additional monitor)
Camera Display
• Supports Three (3) Cameras
• Automatic Camera Select by Reverse
and Turn Indicators
• Supports Rear Camera Microphone
Advanced Digital Audio Subsystem
• Digital AM / FM / WB Tuner
• Satellite Radio Controller (External
Tuner Module)*
• CD Audio
• Compressed Audio (MP3) from CDs &
USB Memory Sticks
• DSP-based Digital Audio Processing
• 5-Band Parametric Equalizer
Trip Computer
• Multiple Trip Odometers
• Speed and Distance Tracking
• Fuel Consumption
Vehicle Monitor
• Monitor Coach and Engine Data from
Vehicle Busses
• Alarms for Fault and Out of Range
Conditions
• Operator Checklists for RV Arrival,
Departure, and Storage Tasks
• Maintenance Scheduling & Reminders
• Vehicle Bus connections for J1939
Expansion Options
• Navigation (Video, and Audio)*
• Sirius Satellite Radio * †
• Audio Input for MP3 Players or other
Portable Audio Devices
• USB Interface for Future Expansion
• Audio Line out (1 stereo)
• Video Output (NTSC)
• Tire Pressure Monitoring System*
*Some features are optional and may not be installed with your R5000.
† A subscription is required to use this service.
Garmin GVN 52 Owner’s Manual
If your R5000 includes the optional Garmin GVN 52 navigation system, please refer to the
Garmin GVN 52 Owner’s Manual included with your vehicle for information regarding the
operation of this service.
