Strobepro X60S User manual

User Manual
Ver. 1.0

2
For your safety
To prevent damage to your product or injury to you or
to others, read the following safety precautions in their
entirety before using this device. Failure to observe
the precautions listed in this section could result in
damage to the product.
▲Do not disassemble or modify
▲Keep dry
▲Do not handle with wet hands or immerse in or
expose to water or rain
▲Do not use in the presence of ammable gas
▲Keep out of reach of children
▲Turn off the speedlite immediately in the event of
malfunction
▲Do not expose to high temperature
▲Do not leave the device in a closed vehicle in the
sun or in other areas subject to high temperature
▲Observe precautions when handling batteries
Table of contents
Quick Start ....................................3
Select Mode ..................................3
Connect to XTS .............................4
Setting Custom Functions ............5
Technical Data ..............................6
Multi Mode ....................................6

3
Quick startSelect Mode
1
2
3
2
Select Mode
TTL Mode
Add Flash
Exposure
Compensation
(FEC) if desired
Multi Mode
Adjust Repeat
Mode
Manual
Mode
Adjust the
power
Press the MODE
button to switch
between TTL,
Manual and Multi
Press the button
below the ± symbol
Change the value
using the Select Dial
(-3 to +3)
Use Select Dial to
change the power
(1/128 low to 1/1
high)
Click to change
number of
 ashes
Click to change
the power
Click to
change the
Frequency
using Select
Dial.
See page 6
Quick start
Install 4 AA
batteries
(Eneloop
Recommended)
Turn on
Mount
on hot
shoe and
tighten
lock
Quick Start
1 3
2

4
Connect to
Turn on
your X60S
speedlite
Press the
wireless
selection
button until
SLAVE
in mode is
highlighted in
the LCD, the
LCD backlight
switches to red
colour
Now you should be able to see the
Group (Gr) and the Channel (CH)
menu in the LCD screen
Select the
group
On XTS
Select the
channel
number
Press the button
below the Channel
(CH) menu
The Channel
indicator is
highlighted in LCD
screen
Using the Select
Dial set the
channel number
Using the Select
Dial set the
speedlite power
Press GR button
once to change
the power
Rotate the Select
Dial to same group
of the spedlite
Press CH once
to change the
channel. Use the
Select Dial to
change channel
number to the
same on the
speedlite
Press the button below
the Group (Gr) menu to
select group A, B or C
1 3
2
4
5

5
Setting Custom
Functions (C.Fn)
Press the
ZOOM/Fn-
button for 3
seconds
Press the SET
button to activate
the function
Use Select Dial to
select a function
1
2
3
Function Description Values
m/ft Distance indicator m, feet
APO Auto Power Off On, Off
FEB ACL Flash Exposure Bracketing auto
cancel
On, Off
AF Auto Focus assist beam On, Off
SvApot Slave auto power off timer 60 min, 30 min
Beep Recycling beep On, Off
Light Backlight time Turn off in 12 seconds, Off, On
LCD LCD contrast level 10 levels, from 0 to 9

6
Power 4 x AA batteries. LR6 alkaline or Ni-MH rechargeable batteries (preferred)
Guide No. (m ISO 100) 60 (1/1 ZOOM 105)
Vertical rotation angle -10 - 90 degrees
Horizontal rotation angle 0 - 270 degrees
Colour temperature 5600k ± 200k
Recycle time Approximately 0.1 - 5 seconds (alkaline batteries used)
Flash duration 1/300s - 1/2000s
Multi Flash 1-99 times; 1-99 Hz
Dimension 83mm x 154mm x 112mm
Net weight 380g
Flash Output 1 Hz 2 Hz 3 Hz 4 Hz 5 Hz 6-7 Hz 8-9 Hz
1/4 7854445
1/8 14 14 12 10 8 6 5
1/16 30 30 30 20 20 20 10
1/32 60 60 60 50 50 40 30
1/64 90 90 90 80 80 70 60
1/128 100 100 100 100 100 90 80
Flash Output 10 Hz 11 Hz 12-14 Hz 15-19 Hz 20-50 Hz 60-199 Hz
1/4222222
1/8444444
1/16 8 8 8 8 8 8
1/32 20 20 20 18 16 12
1/64 50 40 40 35 30 20
1/128 70 70 60 50 40 40
If the number of ashes is displayed as “--”, the maximum number of ashes will be as shown in the following table regardless
of the ash frequency:
Flash Output 1/4 1/8 1/16 1/32 1/64 1/128
Number of ashes 2 4 8 12 20 40
Technical Data
Multi Mode Maximum Flashes
