Studebaker Master Blaster SB2149 User manual

SB2149 OWNER’S MANUAL
Master Blaster Bluetooth Boombox
with CD Player, AM/FM Stereo Radio,
CD/USB MP3 Playback, 10 Watts RMS output,
3-way Power Operation (AC/DC/Car-Boat adaptor)

1
WARNING
The Caution Marking is located at the back enclosure of the apparatus.
The Rating plate is located at the back enclosure of the apparatus
IMPORTANT SAFETY INSTRUCTIONS
TO PREVENT FIRE OF SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION
CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY
INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that product heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for a long
period of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
15. This appliance shall not be exposed to dripping or splashing water and that no object filled
with liquids such as vases shall be placed on the apparatus

2
SAVE THESE INSTRUCTIONS
16. Do not overload wall outlet. Use only power source as indicated.
17. Use replacement part as specified by the manufacturer.
18. Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks.
19. Power Sources - This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company. For products intended to
operate from battery power, or other sources, refer to the operating instruction.
20. Object and Liquid Entry - Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or short-out parts that could result
in a fire or electric shock. Never spill liquid of any kind on the product.
21. Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will often require extensive
work by a qualified technician to restore the product to its normal operation.
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this indicates a need for
service.
22. Mains plug is used as disconnect device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the mains completely, the mains
plug should be disconnected from the mains socket outlet completely.
23. Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
24. Excessive sound pressure from earphones and headphone can cause hearing loss.
25. Minimum distances of 4 inches around the apparatus for sufficient ventilation.
26. The ventilation should not be impeded by covering the ventilation openings with items,
such as newspapers, table-cloths, curtains, etc.
27. No naked flame sources, such as lighted candles, should be placed on the apparatus.
28. The use of apparatus in moderate climates.
29. Attention should be drawn to the environmental aspects of battery disposal.

3
COMPLIANCE WITH FCC REGULATIONS
FCC ID: 2ANH76961401USB
WARNING
Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
CAUTION
Follow the advice below for safe operations.
ON PROTECTION AGAINST LASER ENERGY EXPOSURE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B Digital Device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
• As the laser beam used in this compact disc player is harmful to the eyes, do not attempt to
disassemble the casing.
• Stop operation immediately if any liquid or solid object should fall into the cabinet.
• Do not touch the lens or poke at it. If you do, you may damage the lens and the player may not
operate properly.
• Do not put anything in the safety slot. If you do, the laser diode will be ON when the CD door is
still open.
• If the unit is not to be used for a long period of time, make sure that all power sources are
disconnected from the unit. Remove all batteries from the battery compartment.
• This unit employs a laser. The use of controls or adjustment or performance of procedures other
than those specified here may result in exposure to hazardous radiation.

4
PROTECT YOUR FURNITURE
Caution:
- Any use of the controls or performing any of the procedures in a way other than those specified
herein may result in hazardous radiation exposure.
- This unit should not be adjusted or repaired by anyone except qualified service personnel.
ON PLACEMENT
• Do not use the unit in places which are extremely hot, cold, dusty or humid.
• Place the unit on a flat and even surface.
• Do not restrict the air-flow of the unit by placing it in a place with poor ventilation, by covering
it with a cloth or by placing it on a carpet.
ON CONDENSATION
• When left in a heated room where it is warm and damp, water droplets or condensation may
form inside the unit.
• When there is condensation inside the unit, the unit may not function normally. Let it stand for
1 to 2 hours before turning the power on, or gradually heat the room up and dry the unit
before use.
Should any trouble occur, disconnect the AC Adapter and refer servicing to qualified
personnel.
This system is equipped with non-skid rubber ‘feet’ to prevent the product from moving when you
operate the controls. These ‘feet’ are made from non-migrating rubber material specially
formulated to avoid leaving any marks or stains on your furniture. However certain types of oil
based furniture polishes, wood preservatives, or cleaning sprays may cause the rubber ‘feet’ to
soften, and leave marks or a rubber residue on the furniture.
To prevent any damage to your furniture we strongly recommend that you purchase small
self-adhesive felt pads, available at hardware stores and home improvement centers
everywhere and apply these pads to the bottom of the rubber ‘feet’ before you place the product
on fine wooden furniture.

5
DEAR STUDEBAKER ® CUSTOMER
Model Number: SB2149 Serial Number:
CONTENTS OF YOUR PRODUCT
Selecting fine audio equipment such as the unit you've just purchased is only the start of your
musical enjoyment. Now it's time to consider how you can maximize the fun and excitement your
equipment offers. This manufacturer and the Electronic Industries Association's Consumer
Electronics Group want you to get the most out of your equipment by playing it at a safe level. One
that lets the sound come through loud and clear without annoying blaring or distortion and, most
importantly, without affecting your sensitive hearing. Sound can be deceiving. Over time your
hearing "comfort level" adapts to higher volumes of sound. So what sounds "normal" can actually be
loud and harmful to your hearing. Guard against this by setting your equipment at a safe level
BEFORE your hearing adapts.
To establish a safe level:
● Start your volume control at a low setting.
● Slowly increase the sound until you can hear it comfortably and clearly, and without distortion.
Once you have established a comfortable sound level:
● Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future. After all, we
want you listening for a lifetime.
We Want You Listening For a Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since hearing
damage from loud noise is often undetectable until it is too late, this manufacturer and the Electronic
Industries Association's Consumer Electronics Group recommend you avoid prolonged exposure to
excessive noise.
Customer's Record:
The serial number of this product is found on its back cover. You should note the serial number of
this unit in the space provided as a permanent record of your purchase to aid in identification in the
event of theft of loss.
● Main Unit X 1
● AC adaptor (DC 12V 1.5A ) X 1
● Car-Boat Adaptor X 1
● User Manual X 1

C
CHARGE FM ST. POWER
OFF
POWER
/AUX
REPEAT/
PROGRAM
AM kHz
FM 88 90 92 94 96 98 100 102 104 106 108
54 60 70 80 90 100 120 140 170
x10
USB
MASTER
VOLUME
TREBLE BASS BALANCE
MIN MAX MIN MAX L R
FUNCTION BAND
AUX
IN
TUNING
+10
CD/USB/
PAIR/
LIGHT SHOW
RADIO
AM
FM
FM ST.
CD/USB
USB
PLAYBACK
DC 12V
1.5A
AM kHz
FM 88 90 92 94 96 98 100 102 104 106 108
54 60 70 80 90 100 120 140 170
x10
USB
1 MASTER VOLUME
2 TREBLE KNOB
3 BASS KNOB
4 BALANCE KNOB
5 FM TELESCOPIC ANTENNA
6 CHARGE INDICATOR
7 FM ST. INDICATOR
8 BT INDICATOR
9 POWER INDICATOR
10 FUNCTION SWITCH
11 BAND SWITCH
12 AUX IN JACK
13 TUNING KNOB
14 LED DISPLAY
15 STOP BUTTON
16 +10 BUTTON
17 SKIP/FAST BACKWARD BUTTON
18 REPEAT/PROGRAM BUTTON
19 CD/USB MODE; PLAY/PAUSE ;
BLUETOOTH PAIR BUTTON
20 LIGHT SHOW BUTTON
21 SKIP/FAST FORWARD BUTTON
22 DIAL POINTER
23 USB PORT
24 HEADPHONE JACK
25 TWEETER
26 MULTI COLOR LIGHT SHOW LED
27 WOOFER
28 CD COMPARTMENT
29 CARRYING HANDLE
30 DC INPUT JACK
31 CD DOOR LATCH
6
LOCATION OF CONTROLS
12
3456789 10
11 12 13
14 15 16 17 1819 20 21 2 2 23 24
25 26 25
27 2728 31 3029

7
POWER SOURCE
1.5A
1.5A
This unit can be operated using either AC power or the built-in Li-Polymer rechargeable battery
AC POWER OPERATION
An AC-DC Adaptor with the output of DC 12V, 1.5A (included) is required for operating the main
unit when using AC power mode. To connect the AC-DC Adaptor to the unit and 120V~ 60Hz AC
Outlet:
1.
Firmly and securely insert the DC plug of the adaptor into the DC Jack on the back of the unit.
2. Plug the AC Adaptor plug into the 120V AC outlet. CHARGE LED will be lighting Red during
battery charging. Connecting this system to any other power source may cause damage to
the system
3.
Slide the FUNCTION switch on the top panel to RADIO,CD/USB or BLUETOOTH/AUX mode to
turn on the unit, the POWER INDICATOR will light.
Note: When the unit is not operated for long periods of time, unplug the AC adapter from the unit
and wall outlet.
BUILT-IN RECHARGEABLE BATTERY OPERATION
1. This unit will also operate using the built-in Lithium rechargeable battery. Fully charge the
built-in rechargeable battery before first use, the CHARGE INDICATOR will turn from Red to
Green when the built-in battery is fully charged.
2. Unplug the DC INPUT jack of main unit. The unit will enter Battery Operating mode
automatically.
LOW BATTERY INDICATION
1. When the build-in battery power remains around 5%, the CHARGE INDICATOR will light Red
and flash, please connect the unit to AC adaptor for charging.
2. After prolonged use, the battery voltage may discharge and operation might become
intermittent. When this happens, please recharge the internal battery.
CAR-BOAT ADAPTOR OPERATION
A Car-Boat Adaptor is required for operating the main unit when using DC 12V car battery power
mode. To connect the Car-Boat Adaptor to your car:
1. Firmly and securely insert the DC plug of the adaptor into the DC Jack on the back of the unit.
2. Plug the Car-Boat Adaptor plug into the 12V DC outlet of your car battery. CHARGE LED will
be lighting Red during battery charging. Connecting this unit to any other power source may
cause damage to the system
3. Press the POWER button on the top panel to turn on the unit, the POWER INDICATOR will
light.
Note: When the unit is not operated for long periods of time, unplug the Car-Boat Adaptor from the
unit and your car.

CHARGING THE BATTERY WITH THE INCLUDED AC ADAPTOR
1. Charge the built-in Lithium battery a minimum of 5 hours prior to first use. Firmly and securely
insert the DC plug of the adaptor into the DC Jack on the back of the unit.
2. Plug the AC Adaptor plug into the 120V AC outlet. Connecting this system to any other power
source may cause damage to the system.
3. When the AC power is connected, the battery charging indicator will light solid Red showing
that the internal battery is being charged.
4. After the battery is fully charged, the charging indicator will turn to solid Green.
Notes:
1.) Charging time will vary if you are listening to music while charging the internal battery. We
recommend you place the unit in Power off mode during the charging process or until SB2149
batteries are fully charged.
2.) To prolong the life of a rechargeable battery, it is recommended to completely discharge it
before fully charging it again.
3.) Rechargeable batteries need to be cycled for maximum performance and longer battery life. If
you don’t use the player that often, be sure to recharge the battery at least once a month in
order to keep the internal battery working properly.
Battery Note and Care
• Do not burn or bury batteries.
• Do not puncture or crush.
• Do not disassemble.
• Recycle Lithium batteries. Do not dispose of in the trash.
• Use only chargers rated for Lithium cells. Be sure the charger’s voltage and current
settings are correct for the battery pack being charged.
• Charge batteries on a fireproof surface away from flammable items or liquids.
• Batteries should NEVER be left unattended while charging. Only adults should charge the
batteries.
• Follow the manufacturer’s instructions for charging the product and do not charge longer
than recommended. Unplug the charger when the battery is charged or not in use.
NOTE: These speakers are not magnetically shielded and may cause color distortion on the
screen of some TVs or video monitors. To avoid this, you may need to move the speakers
further away from the TV or monitor if unnatural color shifts or image distortion occurs.
1. Slide the FUNCTION switch to RADIO position, the unit will be "On" and power LED indica-
tor lights.
2. Select the desired FM mode by switching the FM/FM ST. BAND SELECTOR on unit top
panel.
3. Tune to your desired station with the TUNING knob. If FM STEREO mode is selected and
you tune to an FM Stereo station, the FM STEREO LED Indicator will light.
4. Adjust the MASTER VOLUME knob to obtain the desired sound level.
FM & FM-STEREO RECEPTION
● Set the BAND SELECTOR to “FM” position. Stations will now be received in MONO mode.
When a FM station is weak or distorted, listening is usually improved by switching the band
selector to the FM (mono) position.
● Set the band selector to “FM-ST” position to receive stereo broadcasts. The FM-Stereo LED
indicator will light up to show a FM stereo station is detected.
8
CHARGING INSTRUCTIONS
RADIO OPERATION

9
CD OPERATION
TIPS FOR BEST RADIO RECEPTION
AM - The AM antenna is built inside the radio. If AM reception is weak, change the position of the
unit until the internal antenna picks up the strongest signal.
FM - If a stereo broadcast program is being received, the FM STEREO INDICATOR will light.
During FM Stereo reception, always keep the FM TELESCOPIC ANTENNA fully extended
for best performance. However, if FM reception is weak, try repositioning the unit near an
open window until you get the best reception.
PLEASE READ THIS IMPORTANT INFORMATION:
CD mechanisms used in devices like this are designed to fully read all commercial CDs. They
will also read self-compiled CD-R/CD-RW discs but it may take up to 10 seconds for playback to
start. If playback does not start, it is likely due to the quality of the CD-R/RW disc and/or the
compatibility of the CD compilation software. Manufacturer is not responsible for the playback
quality of CD-R/RW discs.
Do not attach a label or seal to either side of the CD-R/RW disc. It may cause a malfunction.
1. Slide the FUNCTION switch to CD/USB position. The display will show “- -“ briefly. If no CD
has been loaded in the CD compartment, LED display will change to show “no”.
2. Grip the “OPEN” mark on the CD Door and pull gently to open it.
3. Carefully load an audio CD with its label side OUTward in the CD compartment then gently
close the CD door.
4. The player will start reading TOC of the disc, total number of tracks on the CD will appear
on the LED DISPLAY after a few seconds.
5. Press the PLAY/PAUSE button to start playing.
6. Adjust the MASTER VOLUME knob to obtain the desired sound.
7. To temporarily stop playing, press the PLAY/PAUSE Button. The play/pause indicator
will be flashing. To resume playing, press the PLAY/PAUSE Button again. The
play/pause indicator will be solid on.
8. You can skip up or down to a specific track number by pressing the SKIP BACKWARD
button or SKIP FORWARD button. The LED Display will indicate the correct track
number selected.
9. To locate a particular section within a track, press and hold the / button until the
section is found.
10. To stop playing, press the STOP button
11. Slide the Function switch to POWER OFF position to off the unit after listening.
+10 button control
Press the +10 button once to advance the music search by increment of 10 tracks.
REPEAT MODE
Repeat 1
To repeat the current track, press the REPEAT BUTTON once, the REPEAT INDICATOR will
flash in LED display. The track will continue to play until the repeat function is turned off.
Repeat All
To repeat all the tracks, press the REPEAT BUTTON twice, the REPEAT INDICATOR will be
solid on. All the tracks on the disc will be played repeatedly.
To Cancel Repeat Function: Press the REPEAT BUTTON until REPEAT indicator goes off
from LED display.

10
USING TREBLE/BASS/BALANCECONTROLKNOBS
USB OPERATION
• TREBLE: Adjust TREBLE level of music playback.
• BASS : Adjust BASS level of music playback.
• BALANCE : Adjust BALANCE for balance left and right speaker.
PROGRAM OPERATION
This function allows the tracks to be played in a programmed sequence.
NOTE: Programs can only be set in STOP mode.
1. In CD stop mode, press REPEAT/PROGRAM button, the PROG indicator will light and
Program Number “P01” will show on LED display.
2. Press the SKIP or button to select the desired track. The track number “1” (001 for
MP3 CD) will blink on the LED display to prompt for input.
3. Press the PROGRAM button to confirm the selection. Program Number advances to “P02”.
4. Repeat step 2 to 3 to program up to maximum of 20 tracks.
5. When maximum of 20 tracks have been programmed, the LED display will show “FUL” to
indicate program is full.
6. When you have completed programming, press the PLAY/PAUSE button to start
playing. Both PROG and Play/Pause indicators are lighting steadily.
7. To cancel programmed play, press the STOP button twice. PROG indicator goes off.
The unit is designed to play MP3 files stored in the USB flash-drive. If the files on the USB device
do not conform to the standard, they may not be played.
1. Slide the FUNCTION switch to CD/USB position. Press and hold the CD/USB/PAIR/
button until USB mode indication “USB” shows on LED display and USB indicator flashing.
2. Insert your USB flash-drive into the USB port, unit starts to read the USB flash-drive.
Notes:
1.) USB supports flash drive capacity up to 32 GB maximum.
2.) Due to various USB flash drives in the market, please always fold down the carrying
handle before insert USB flash drive into the USB port.
3.) When carrying this unit, be sure your USB flash drive is not taller than the space under
the carrying handle to avoid damaging.
3. After reading the USB flash-drive, the unit will display the total number of files on the
flash-drive.
USB playback
After reading the USB flash-drive, press the PLAY/PAUSE button once, the first track/file on
the USB flash-drive will be played back. The “USB” and “PLAY/PAUSE” indicators will be solid
on during playback.
Play/Pause Control
To temporarily stop playing, press the button, music playback will be paused and the
PLAY/PAUSE indicator will be blinking. Press the button again to resume playback.
Stop playback
To stop playback, press the STOP button on the unit. The total number of tracks/files on the
USB flash-drive will be shown on the LED display.
Skip track
During playback, press the SKIP backward or forward buttons to skip to the previous
or next track/file.

11
+10 control
Press the +10 button to advance the music search by increments of 10 tracks.
REPEAT MODE
Repeat 1
To repeat the current track, press the REPEAT/PROGRAM BUTTON once, the REPEAT
INDICATOR will flash in LED display. The track will continue to play until the repeat function is
turned off.
Repeat All
To repeat all the tracks, press the REPEAT BUTTON twice, the REPEAT INDICATOR will be
solid on. All the tracks on the disc will be played repeatedly.
To Cancel Repeat Function: Press the REPEAT BUTTON until REPEAT indicator goes off
from LED display.
Programmed USB playback
This unit can be programmed to play up to 20 tracks/files in USB mode.
1. Plugged in your flash-drive into USB port, make sure unit is in stop mode.
2. Press REPEAT/PROGRAM button, the PROGRAM Indicator will light and program Chan-
nel Number "P01" will show on the LED DISPLAY.
3. Press or button to select the track to be programmed. The track number “001” will
blink on the LED DISPLAY to prompt for input.
4. Press the PROGRAM button again to store selection. The Program Channel Number will
change to “P02”.
5. You may repeat steps 2 - 3 to program as many as 20 tracks. When the memory full, “FUL”
will show on the LED DISPLAY.
6. Press the PLAY/PAUSE button to start the programmed play.
7. Press STOP button once to stop playback.
8. Press the button to resume programmed play.
9. To cancel programmed play, press the STOP button twice.
BLUETOOTH OPERATION
PAIRING A SMARTPHONE OR BLUETOOTH ENABLED DEVICE
The Bluetooth feature enables you to stream and play the digital music on your Bluetooth
enabled device to your unit. (make sure AUX IN jack is no plug in AUX cable)
1. Slide the FUNCTION switch to Bluetooth /AUX position, the Bluetooth indicator will
flash.
2. The unit will start in auto connection mode and search for a previously paired device that is
active and in range (30 feet/10 meters). If found, a brief welcome melody will be heard and
Bluetooth indicator will change to solid on. If no active device is found, the unit will switch to
interactive pairing mode and the Bluetooth indicator keeps flashing.
3. To establish a new link, turn on the Bluetooth function of your Bluetooth enabled device and
enable the search or scan feature to find “SB2149” in the list of discoverable Bluetooth
devices. Select the “SB2149” from your available device list when it appears on its screen
and a brief welcome melody will be heard if pairing and connection is successful. If you are
asked for a password, enter “0000”.
4. If no successful pairing and connection is made within 5 minutes, the unit can enter manual
pairing mode. You need to press and hold the PAIR button until Bluetooth indicator flashes
to initiate a pairing/connecting request to a new or old Bluetooth enabled device. Follow
step #3 to complete the process.

12
5. After successfully pairing and connecting your device with SB2149, the unit will emit a brief
welcome melody and the Bluetooth indicator will change to solid on. You can now play
music from your Bluetooth enabled device wirelessly to the SB2149.
6. If you want to connect the SB2149 to another new external Bluetooth enabled device while
paired with another device, press and hold the PAIR button for few seconds to disconnect
the existing connection. The unit will emit two short beeps and Bluetooth indicator will
change to flash. Repeat steps #3 to #4 above to make a new link.
7. Rotate the VOLUME CONTROL on the top panel to increase the listening volume gradually
until a comfortable listening level is reached.
8. Press the PLAY/PAUSE BUTTON to control play/pause.
9. Press the SKIP FORWARD BUTTON to skip to next song and SKIP BACKWARD
BUTTON to skip to previous song.
Notes:
• If you cannot pair the unit with your Bluetooth enabled device, try solving the problem by
turning the unit power off, then power on, and then starting the pairing process again.
• The Bluetooth function of the unit will remain paired unless the paired device goes out of
range of 30 feet (10 meters). If the broken link is re-established within 20 seconds, the
SB2149 will reconnect to the current paired device automatically. Otherwise you will need
to make a manual connection again later.
• You may need to turn off the Bluetooth function of the paired external device first before
make a new link.
• Refer to manual of your smartphone or external Bluetooth enabled device for correct
Bluetooth operation instructions since it may vary from model to model.
• If your Bluetooth enabled device does not support A2DP, it will not play the music through
the SB2149 system even after it is paired and connected successfully.
• If you are pairing and connecting your personal computer to the SB2149 using Bluetooth,
you may need to set the SB2149 as your computer’s default sound device.
RE-LINKING TO A SMARTPHONE OR BLUETOOTH ENABLED DEVICE
Even if your smartphone or Bluetooth device is already paired with the SB2149 and with both
Bluetooth functions turned on, they can become unlinked at some point due to intentional
manual disconnection or undesirable external signal interferences or over-range for more than
10 seconds. If this happens, the unit will emit two short beeps. You can re-link them and resume
play by:
1. Select “SB2149” from the device list on your smartphone or Bluetooth device. The SB2149
should re-link to your Bluetooth enabled device within 5 seconds.
2. Tap the play button of the music player on your Bluetooth enabled device to resume
playback.
AUX IN OPERATION
You can play other music sources (iPod, MP3 or other digital audio players) through the speak-
ers of the unit by connecting the AUX IN JACK to your external player’s audio out jack or
headphone jack.
1. Plug one end of a 3.5mm audio cable (not included) into the AUX IN JACK and the other
end of the cable to the headphone jack of your digital audio player.
2. Slide the FUNCTION switch to the Bluetooth /AUX position.
3. Turn on and start playing the external device you plugged into the AUX IN JACK.
4. Slowly adjust both the volume controls of your unit and the external device until you reach
a comfortable listening level.
5. Turn off both the external audio player and this unit after use. Unplug the audio cable from
AUX IN jack

13
USE HEADPHONES (NOT INCLUDED)
LLEEDD LLIIGGHHTT SSHHOOWW
RREESSEETTTTIINNGG TTHHEE UUNNIITT
CARE AND MAINTENANCE
Inserting the plug of your stereo headphones (not included) into the headphone jack located on
the top panel will enable you to listen in private. When using headphones, the speakers will be
disconnected.
Read this Important Information before Using Your Headphones
1.) Avoid extended play at very high volume as it may impair your hearing.
2.) If you experience ringing in your ears, reduce the volume or shut off the unit.
3.) Keep the volume at a reasonable level even if your headset is an open-air type designed to
allow you to hear outside sounds. Please note that excessively high volume may still block
outside sounds.
- To turn off the LED light show, press the LIGHT SHOW button.
- To turn on the LED light show, press the LIGHT SHOW button once again.
Note: If the brightness is glaring, turn on room lights or turn off LED light show.
1. Do not subject the unit to excessive force, shock, dust or extreme temperature.
2. Do not tamper the internal components of the unit.
3. Clean your unit with a dry cloth. Solvent or detergent should never be used.
4. Avoid leaving your unit in direct sunlight or in hot, humid or dusty places.
5. Keep your unit away from heating appliances and sources of electrical noise such as
fluorescent lamps or motors.
6. If drop-outs or interruptions occur in the music during CD play, or if the
CD fails to play at all, its bottom surface may require cleaning. Before
playing, wipe the disc from the center outwards with a good soft
cleaning cloth.
CLEANING THE UNIT
• To prevent fire or shock hazard, disconnect your unit from the AC power source when
cleaning.
• The finish on the unit may be cleaned with a dust cloth and cared for as other furniture, Use
caution when cleaning and wiping the plastic parts.
• If the cabinet becomes dusty wipe it with a soft dry dust cloth. Do not use any wax or polish
sprays on the cabinet.
• If the front panel becomes dirty or smudged with fingerprints it may be cleaned with a soft
cloth slightly dampened with a mild soap and water solution. Never use abrasive cloths or
polishes as these will damage the finish of your unit.
CAUTION: Never allow any water or other liquids to get inside the unit while cleaning.
In case of malfunction due to electrostatic discharge, reset the unit by slide the FUCTION switch
to POWER OFF position to reset the unit. Wait for 30 seconds before power on the unit again.
Notes:
• If you connect the unit to the Line-Out Jack of your external device, you only need to adjust
the VOLUME CONTROL of your unit. If you connect to the Headphone Jack of your external
device, you may need to adjust both the volume controls of your external device and the unit
to obtain the desirable listening level.
• Remember to turn off the unit when you have finished listening. Don't forget to switch off the
power of your external audio device as well.

14
TROUBLE SHOOTING GUIDE
Symptom
The unit does not
respond (no power)
Unit is ON but there is
low or no volume
AM/FM no sound
Bluetooth No Sound
Noise or sound distorted
on FM broadcast
USB player will not play
CD player will not play
CD skips while playing
Intermittent sound from
CD Player
Sound is distorted
Unit gets warm after
extended play at high
volume
Possible Cause
The unit is disconnected from
the AC outlet.
The AC outlet has not power.
Volume set too low.
Unit not in Radio mode.
Unit is not linked with your
Bluetooth enabled device.
Unit placement out of range.
Your Bluetooth enabled device
Volume set too low.
Station not tuned properly.
FM: telescopic antenna is not
fully extended.
AM: Internal antenna is not
positioned correctly.
Unit not in USB function mode.
Can’t read USB data
Unit not in CD function mode.
CD is installed incorrectly.
If the CD is self-compiled, the
media used may not be
compatible with the player.
Disc is dirty or scratched.
Dirty or defective disc.
Dirty pick up lens.
Player is subject to excessive
shock or vibration.
Volume level is set too high.
Sound source is distorted.
This is normal.
Solution
Reconnect to the AC outlet.
Try the unit on another outlet.
Slowly rotate the MASTER VOLUME
knob to increase the volume level.
Slide FUNCTION switch to select
RADIO.
Go through “Bluetooth Operations”
process to link the speakers.
Relocate the unit within Bluetooth
operating range (30 feet)
Increase Volume level of your
Bluetooth enabled device.
Fine tune the FM broadcast station.
Fully extend the FM telescopic
antenna.
Reposition the unit until the best
reception is obtained.
Slide FUNCTION switch to CD/USB
and long press the CD/USB/PAIR/
button until USB indicator is flashing.
USB flash drive fault, change another
good one.
Slide FUNCTION switch to select CD.
Insert CD with label side outward.
Use better quality blank media and
retest.
Wipe CD with clean cloth or use
another disc.
Clean or replace the defective disc.
Use a CD-lens cleaning disc to clean
the lens.
Relocate the player away from shock
or vibration.
Decrease the volume.
Try a different sound source.
If you are using an external sound
source like older generation of iPod,
try reducing the output volume on the
device itself. Also try turning bass
boost OFF or change the EQ setting.
Turn the unit off for a period
of time or lower volume

15
SPECIFICATION
Radio Frequency Range : AM: 530 – 1710 KHz
: FM: 88 – 108 MHz
Audio Output Power : 2 X 5W (RMS)
Tweeter : 2 x 1.5 inch / 6 ohms
Woofer : 2 x 4 inch / 6 ohms
Bluetooth : V4.2 + EDR
USB : Support USB device up to 32GB
Power Source :
AC Adapter : Input AC 120V~ 60Hz
Output DC 12V 1.5A
Built-in Rechargeable Lithium Battery : DC 7.4V , 2200mAh
Due to continuing improvement, the features and the design are subject to change without
notice.
At Spectra, environmental and social responsibility is a core value
of our business. We are dedicated to continuous implementation of
responsible initiatives with an aim to conserve and maintain the
environment through responsible recycling.
Please visit us at http://www.spectraintl.com/green.htm for more
information on Spectra‟s green initiatives or to find a recycler in
your area.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by Spectra Merchandising Intl, Inc. is under license. Other
trademarks and trade names are those of their respective owners.

16
90 DAY LIMITED WARRANTY AND SERVICE
VALID IN THE U.S.A. ONLY
0718 Printed in China
SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be free from defective materials or
factory workmanship for a period of 90 days from the date of original customer purchase and provided the product
is utilized within the U.S.A. This warranty is not assignable or transferable. Our obligation under this warranty is
the repair or replacement of the defective unit or any part thereof, except batteries, when it is returned to the
SPECTRA Service Department, accompanied by proof of the date of original consumer purchase, such as a
duplicate copy of a sales receipt.
You must pay all shipping charges required to ship the product to SPECTRA for warranty service. If the product
is repaired or replaced under warranty, the return charges will be at SPECTRA’s expense. There are no other
express warranties other than those stated herein.
This warranty is valid only in accordance with the conditions set forth below:
1. The warranty applies to the SPECTRA product only while:
a. It remains in the possession of the original purchaser and proof of purchase is demonstrated.
b. It has not been subjected to accident, misuse, abuse, improper service, usage outside the descriptions
and warnings covered within the user manual or non-SPECTRA approved modifications.
c. Claims are made within the warranty period.
2. This warranty does not cover damage or equipment failure caused by electrical wiring not in compliance with
electrical codes or SPECTRA user manual specifications, or failure to provide reasonable care and
necessary maintenance as outlined in the user manual.
3. Warranty of all SPECTRA products applies to residential use only and is void when products are used in a
nonresidential environment or installed outside the United States.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
TO OBTAIN SERVICE please remove all batteries (if any) and pack the unit carefully and send it freight prepaid
to SPECTRA at the address shown below. IF THE UNIT IS RETURNED WITHIN THE WARRANTY PERIOD
shown above, please include a proof of purchase (dated cash register receipt) so that we may establish your
eligibility for warranty service and repair of the unit without cost. Also include a note with a description explaining
how the unit is defective. A customer service representative may need to contact you regarding the status of your
repair, so please include your name, address, phone number and email address to expedite the process.
IF THE UNIT IS OUTSIDE THE WARRANTY PERIOD, please include a check for $70.00 to cover the cost of
repair, handling and return postage. All out of warranty returns must be sent prepaid.
It is recommended that you contact SPECTRA first at 1-800-777-5331 or by email at [email protected]
for updated information on the unit requiring service. In some cases the model you have may be discontinued,
and SPECTRA reserves the right to offer alternative options for repair or replacement.
SPECTRA MERCHANDISING INTERNATIONAL, INC.
4230 North Normandy Avenue,
Chicago, IL 60634, USA.
1-800-777-5331
To register your product, visit the link below to enter your information.
http://www.spectraintl.com/wform.htm
