Studebaker SB2150 User manual

E-1
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN
BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR
SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
The Caution Marking is located at the back enclosure of the apparatus.
The Rating plate is located at the back enclosure of the apparatus.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that product heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the product.
When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused
for a long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.

E-2
15. This appliance shall not be exposed to dripping or splashing water and that no
object filled with liquids such as vases shall be placed on the apparatus.
16. Do not overload wall outlet. Use only power source as indicated.
17. Use replacement part as specified by the manufacturer.
18. Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks.
19. Power Sources - This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your product dealer or local power company. For
products intended to operate from battery power, or other sources, refer to the
operating instruction.
20. Object and Liquid Entry - Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or short-out parts that
could result in a fire or electric shock. Never spill liquid of any kind on the product.
21. Damage Requiring Service - Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in damage
and will often require extensive work by a qualified technician to restore the
product to its normal operation.
e) If the product has been dropped or damaged in any way, and
f)When the product exhibits a distinct change in performance - this indicates a
need for service.
22. Mains plug is used as disconnect device and it should remain readily operable
during intended use. In order to disconnect the apparatus from the mains
completely, the mains plug should be disconnected from the mains socket outlet
completely.
23. Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
24. Minimum distances of 10 cm around the apparatus for sufficient ventilation.
25. The ventilation should not be impeded by covering the ventilation openings with
items, such as newspapers, table-cloths, curtains, etc.
26. No naked flame sources, such as lighted candles, should be placed on the
apparatus.
27. The use of apparatus in moderate climates.
28. Attention should be drawn to the environmental aspects of battery disposal.
29. CAUTION: Risk of explosion if the battery is replaced by an incorrect type.
30. High or low extreme temperatures that a battery cannot be subjected to during
use, storage or transportation and low air pressure at high altitude.
31. Replacement of a battery with an incorrect type that can defeat a safeguard.
32. Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting
of a battery, that can result in an explosion.
33. Leaving battery in an extremely high temperature surrounding environment that
can result in an explosion or the leakage of flammable liquid or gas. A battery
subjected to extremely low air pressure that may result in an explosion or the
leakage of flammable liquid or gas.

E-3
This symbol indicates that this product incorporates doub le
insulation between hazardous mains voltage and user
accessible p a r ts.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT. FULLY INSERT THE PLUG TO MAIN
POWER SOCKET.
SAVE THESE INSTRUCTIONS
COMPLIANCE WITH FCC
REGULATIONS
FCC ID: 2ATT8-SB2150
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Information
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator and your body.
CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.

E-4
CAUTION
Follow the advice below for safe operations.
ON PROTECTION AGAINST LASER ENERGY EXPOSURE
As the laser beam used in this compact disc player is harmful to the eyes, do not attempt to
disassemble the casing.
Stop operation immediately if any liquid or solid object should fall into the cabinet.
Do not touch the lens or poke at it. If you do, you may damage the lens and the player may
not operate properly.
Do not put anything in the safety slot. If you do, the laser diode will be ON when the CD door
is still open.
If the unit is not to be used for a long period of time, make sure that all power sources are
disconnected from the unit. Remove all batteries from the battery compartment.
This unit employs a laser. The use of controls or adjustment or performance of procedures
other than those specified here may result in exposure to hazardous radiation.
Should any trouble occur, remove the power source and refer servicing to qualified personnel.
PROTECT YOUR FURNITURE
This model is equipped with non-skid rubber 'feet' to prevent the product from
moving when you operate the controls. These 'feet' are made from non-migrating
rubber material specially formulated to avoid leaving any marks or stains on your
furniture. However certain types of oil-based furniture polishes, wood preservatives,
or cleaning sprays may cause the 'feet' to soften and leave marks or a rubber
residue on the furniture. To prevent any damage to your furniture we strongly
recommend that you purchase small self-adhesive felt pads, available at hardware
stores and home improvement centers everywhere, and apply these pads to the
bottom of the rubber 'feet' before you place the product on fine wooden furniture.

E-5
DEAR STUDEBAKER CUSTOMER
Selecting fine audio equipment such as the unit you've just purchased is only the
start of your musical enjoyment. Now it's time to consider how you can maximize the
fun and excitement your equipment offers. This manufacturer and the Electronic
Industries Association's Consumer Electronics Group want you to get the most out of
your equipment by playing it at a safe level. One that lets the sound come through
loud and clear without annoying blaring or distortion and, most importantly, without
affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing "comfort level" adapts to higher
volumes of sound. So what sounds "normal" can actually be loud and harmful to your
hearing. Guard against this by setting your equipment at a safe level BEFORE your
hearing adapts.
To establish a safe level:
Start your volume control at a low setting.
Slowly increase the sound until you can hear it comfortably and clearly, and
without distortion.
Once you have established a comfortable sound level:
Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the
future. After all, we want you listening for a lifetime.
We Want You Listening For a Lifetime
Used wisely, your new sound equipment will provide a
lifetime of fun and enjoyment. Since hearing damage
from loud noise is often undetectable until it is too late,
this manufacturer and the Electronic Industries
Association's Consumer Electronics Group
recommend you avoid prolonged exposure to
excessive noise.
Customer's Record:
The serial number of this product is found on its bottom. You should note the serial
number of this unit in the space provided as a permanent record of your purchase to
aid in identification in the event of theft of loss.
Model Number: SB2150 Serial Number:

E-6
LOCATION OF CONTROLS

E-7
1
POWER BUTTON
15
VOLUME - BUTTON
2
PHONE JACK
16
VOLUME + BUTTON
3
REPEAT BUTTON
17
FUNCTION BUTTON
4
PROGRAM / FLODER + BUTTON
18
AUX IN JACK
5
SKIP
19
CARRYING HANDLE
6
SKIP
20
CD DOOR ACCESS POINT
7
CASSETTE PAUSE BUTTON
21
CD COMPARTMENT
8
CASSETTE STOP/EJECT BUTTON
22
SPEAKERS
9
CASSETTE F.FORWARDBUTTON
23
LCD DISPLAY
10
CASSETTE REWIND BUTTON
24
CASSETTE HOLDER
11
CASSETTE PLAYBUTTON
25
MICROPHONE
12
CASSETTE RECORDBUTTON
26
FM TELESCOPIC ANTENNA
13
CD STOP BUTTON
27
BATTERY COMPARTMENT
14
PAIR / PLAY/PAUSE BUTTON
28
AC SOCKET

E-8
POWER SOURCE
The SB2150 operates using standard AC 120V~ 60Hz household power or 6 x “C”
size (UM-2) batteries (Not included).
BATTERY OPERATION
NOTES:
Disconnect the AC power cord.
For best performance and longer operating time, we recommend the use of alkaline
batteries.
1. Remove the Battery Door on the back of the unit.
2. Following the polarity diagram shown in the BATTERY COMPARTMENT (#27)
to insert 6 X `C' size (UM-2) batteries and close the door.
BATTERY WARNING
1.Be sure that the batteries are installed correctly. Wrong polarity may damage the
unit.
2. Use only the size and type of batteries specified.
3. Only use good quality/name brand batteries.
4. Do not mix old and new batteries.
5. Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium)
batteries.
6. If the unit is not to be used for an extended period of time, remove the batteries.
Old or leaking batteries can cause damage to the unit and may void the
warranty.
7. Do not try to recharge batteries not intended to be recharged; they can overheat
and rupture. (Follow battery manufacturer’s directions).
8. Do not dispose of batteries in fire, batteries may leak or explode.
AC POWER CONNECTION
1. Insert one end of power cord to the AC SOCKET (#28) at the back of the SB2150.
2. Connect the power cord to AC power source.
3. When the unit is operated from AC power source, the internal battery source will
automatically be disconnected

E-9
RADIO OPERATION
Listening to the radio:
1. Press and hold the POWER BUTTON (#1) to turn the unit on.
2. If you repeatedly tap the FUNCTION BUTTON (#17), you will step through the
different modes available: CD -> FM Radio -> AM Radio -> Bluetooth (bt) - >
AUX -> Cassette (CASS)
3. Tap the FUNCTION BUTTON (#17) repeatedly to select either FM or AM Radio
mode.
4. The FM or AM frequency will show on the LCD display (#23).
5. Manual Tuning: Repeatedly tap the SKIP BUTTON (#5) or SKIP 
BUTTON (#6) to manually adjust the frequency.
6. Automatic Tuning: Press and hold the SKIP BUTTON (#5) or SKIP 
BUTTON (#6) to automatically tune to the previous or next available station.
7. Tap the VOL - / + BUTTONS (#15 / #16) to obtain the desired volume level.
8. Press and hold the POWER BUTTON (#1) to turn the radio off.
Notes:
Use Manual Tuning to select weaker stations that might be skipped during
Automatic Tuning.
If the Automatic Tuning does not stop on the exact frequency of the station, for
example, it stops on 88.9 MHz instead of 88.8 MHz, use the manual tuning
method to “fine tune” to the exact frequency of the desired station.
Manual Preset Radio Stations
You can store up to total of 30 FM and 30 AM radio stations in the memory.
1. Set to FM or AM mode
2. Tune to the desired radio station by “MANUAL” or “AUTO” tuning method.
3. Press and hold the PROGRAM BUTTON (#4) until “PXX” show on the LCD
DISPLAY (#23) and flashing.
4. Tap the SKIP BUTTON (#5) or SKIP BUTTON (#6) repeatedly to select
select a preset number.
5. Tap the PROGRAM BUTTON (#4) again to confirm the preset.
6. Repeat step 2 to 5 to store other stations if necessary.
Auto Preset Radio Stations
1. During radio mode (AM or FM), press and hold the PLAY/PAUSE button (#14),
the unit will automatically scan the radio frequency. When the clear signal is
found, it will automatically store the radio station starting from program number
P01.
2. The number of stations can be found and stored is depended on the reception of
different area and countries
Recalling the Preset Stations
In FM or AM radio mode, tap the PROGRAM BUTTON (#4). The preset number will
show on the LCD DISPLAY (#23). Tap the SKIP BUTTON (#5) or SKIP 
BUTTON (#6) repeatedly to select the preset station.
NOTE:
You can overwrite a present station by storing another frequency in its place.

E-10
TIPS FOR BEST RADIO RECEPTION
AM - The AM antenna is built inside the radio. If AM reception is weak, change the
position of the unit until the internal antenna picks up the strongest signal.
FM - If FM reception is weak, fully extend the FM ANTENNA (#26) and vary the
position and location of the antenna until you find the strongest signal.
CD OPERATION
PLEASE READ THIS IMPORTANT INFORMATION:
CD mechanisms used in devices like this are designed to fully read all commercial
CDs. They will also read self-compiled CD-R/CD-RW discs but it may take up to 10
seconds for playback to start. If playback does not start, it is likely due to the quality
of the CD-R/RW disc and/or the compatibility of the CD compilation software.
Manufacturer is not responsible for the playback quality of CD-R/RW discs.
Do not attach a label or seal to either side of the CD-R/RW disc. It may cause a
malfunction.
FOR WINDOWS USERS:
When using the “Burn a CD” feature to create an MP3 CD in Windows, you must
select the “With a CD/DVD player” option when it asks “How do you want to use
the disc?” The MP3 CD will not play on this unit if you select the “Like a USB
flash drive” option or if the MP3 CD is not finalized
PLAYING A COMMERCIAL CD
1. Press and hold the POWER BUTTON (#1) to turn on the unit.
2. Tap the FUNCTION BUTTON #17) repeatedly to select CD mode.
3. Open the CD door, load a CD with the label side facing upward and close the
CD door.
4. The CD will spin and start reading the disc information. When finished, the LCD
DISPLAY(#23) will show the total number of tracks on the CD.
5. Press the CD PLAY/PAUSE BUTTON (#14) to start playing the CD. The
current track number and time will show on the LCD DISPLAY (#23) alternately.
6. While playing, press the PLAY/PAUSE BUTTON (#14) to pause playback. The
current track time will blink on the LCD DISPLAY (#23). Press the PLAY/PAUSE
BUTTON (#14) again to resume playing.
7. Tap the VOLUME -/+ BUTTONS (#15/16) repeatedly to the desired volume level.
8. Press the CD STOP BUTTON (#13 to stop playing.
9. To turn off the unit, Press and hold the POWER BUTTON (#1).
REPEAT MODE PLAYING A COMMERCIAL CD
REPEAT 1:
When you first start playing a CD, press the REPEAT BUTTON (#3) once. The
REPEAT icon will show on the LCD DISPLAY(#23). The current track playing will
now repeat continuously until you stop playback or change the mode.
REPEAT ALL:
Press the REPEAT BUTTON (#3) again, the REPEAT ALL icon appears on the LCD
DISPLAY(#23). All tracks on the CD will play in order and will repeat continuously

E-11
until you stop playback or change the mode.
RANDOM PLAY:
Press the REPEAT BUTTON (#3) again, the RANDOM icon will show on the LCD
DISPLAY(#23). All tracks on the CD will play in random order until you stop
playback or change the mode.
CANCELLING THE REPEAT MODES:
Press the REPEAT BUTTON (#3) again or until all the icons on the LCD DISPLAY
(#23)turn off.
PLAYING AN CD MP3
1. Press and hold the POWER BUTTON (#1) to turn on the unit.
2. Tap the FUNCTION BUTTON #17) repeatedly to select CD mode.
3. Open the CD DOOR and load an MP3 CD with the label or print side facing
upward and close the CD door.
4. The CD will spin and start reading the disc information. When finished, the
LCD DISPLAY (#23) will show the total number folders followed by the total
number of tracks on the MP3 CD.
5. Press the CD PLAY/PAUSE BUTTON (#14) to start playing the MP3 CD.
The current track number and time will show on the LCD DISPLAY (#23)
alternately.
6. While playing, press the CD PLAY/PAUSE BUTTON (#14) to pause playback.
The current track time will blink on the LCD DISPLAY (#23). Press the
PLAY/PAUSE BUTTON (#14) again to resume playing.
7. Pressing the PROGRAM / FOLDER + BUTTON (#4) allows you to switch folders
(if available on your MP3 CD). Repeatedly press the PROGRAM / FOLDER +
BUTTON (#4) to step through all the available folders on the MP3 CD. The LCD
DISPLAY(#23) will show F 01 is folder #1, F 02 is folder #2 and so on.
8. Tap the VOLUME -/+ BUTTONS (#15/16) repeatedly to the desired volume level.
9. Press the CD STOP BUTTON (#13) to stop playing.
10.To turn off the unit, press and hold the POWER BUTTON (#1).
REPEAT MODE PLAYING AN CD MP3
REPEAT 1:
When you first start playing a CD MP3, press the REPEAT BUTTON (#3) once. The
REPEAT icon will show on the LCD DISPLAY(#23). The current track playing will
now repeat continuously until you stop playback or change the mode.
REPEAT FOLDER
Press the REPEAT BUTTON (#3) again, the REPEAT FOLDER icon appears on the
LCD DISPLAY(#23). All tracks in the current folder will play in order and will repeat
continuously until you stop playback or change the mode
REPEAT ALL:
Press the REPEAT BUTTON (#3) again, the REPEAT ALL icon appears on the LCD
DISPLAY(#23). All tracks on the CD MP3 will play in order and will repeat
continuously until you stop playback or change the mode.
RANDOM PLAY:
Press the REPEAT BUTTON (#3) again, the RANDOM icon will show on the LCD

E-12
DISPLAY(#23). All tracks on the CD MP3 will play in random order until you stop
playback or change the mode.
CANCELLING THE REPEAT MODES:
Press the REPEAT BUTTON (#3) again or until all the icons on the LCD DISPLAY(#23)turn
off.
SKIP AND SEARCH MODE (COMMERCIAL CD and CD MP3)
1. During Play or Pause mode, tap the SKIP BUTTON (#6) or SKIP BUTTON
(#5) to go to the next track or go back to the beginning of the current track.
2. During play mode or Pause mode, press and hold the the SKIP BUTTON (#6)
or SKIP BUTTON (#5) to search within the current track at high speed
playback.
3. During CD MP3 Play mode, press and hold the PROGRAM / FLODER +
BUTTON (#4), to go to the next folder.
PROGRAM PLAY MODE (COMMERCIAL CD and CD MP3)
This function allows music tracks to be played in a programmed sequence.
NOTE: Program can only be set in STOP mode.
1. Tap the PROGRAM /FLODER + BUTTON (#4) once. The program number P01
and the “MEMORY”will blink on the LCD DISPLAY (#23).
2. Press the SKIP BUTTON (#6) or SKIP BUTTON (#5) to select the track to
be programmed.
3. Press the PROGRAM / FOLDER + BUTTON (#4) again to store the selection.
The program number will advance to P02 and flash to prompt for the next input.
4. You may repeat steps 2 to 3 to program up to:
5. 20 tracks when playing a COMMERCIAL CD or
6. 99 tracks or when playing an CD MP3.
7. Once the storage capacity has been reached, “FULL” will show on the LCD
DISPLAY (#23).
8. Press the CD PLAY/PAUSE BUTTON (#14) to start program play. “MEMORY”
will appear on the LCD DISPLAY(#23).
9. Press the PLAY/PAUSE BUTTON (#14) again to stop the playback while
retaining the program.
10.To play the programmed back again, press the PLAY/PAUSE BUTTON (#14).
11.To delete the program, press the STOP BUTTON (#13) twice. “MEMORY” will
turn off on the LCD DISPLAY(#23).
NOTES:
If skipping occurs during CD play, try turning the volume down.
Do not open the CD DOOR when a CD is playing.

E-13
BLUETOOTH OPERATION
Pairing a Bluetooth enabled device with the SB2150.
1. Press and hold the POWER BUTTON (#1) to turn on the unit.
2. Tap the FUNCTION BUTTON #17) repeatedly to select Bluetooth Mode.
3. “bt” will blink on the LCD DISPLAY (#23).
4. Turn on the Bluetooth function of your device and enable the search or scan
function to find the SB2150.
5. Select the SB2150 from the device list when it appears on your device’s screen.
If required, enter the pass code “0000” to pair (link) the SB2150 with your device.
6. If you are pairing (linking) your computer to the SB2150 using Bluetooth, you may
need to set the SB2150 as your computer’s default sound device.
7. After pairing the SB2150 with your Bluetooth device successfully, the “bt”will light
steadily.
8. If you want the SB2150 to pair with another Bluetooth device, press and hold the
PAIR / PLAY/PAUSE BUTTON (#14) until the “bt”blink on the LCD DISPLAY
(#23). The unit will go into Pairing/Discoverable mode.
9. Repeat steps 4 & 5.
Now you can play music from your Bluetooth device wirelessly to the SB2150
1. Select a song and press the Play/Pause Button on your Bluetooth device or
PLAY/PAUSE (#14) on the SB2150 to play or pause the Bluetooth device
playback.
2. Tap the SKIP BACKWARD BUTTON (#5) or SKIP FORWARD BUTTON (#6) to
select the Previous or Next track.
3. Slowly adjust both the volume controls on the SB2150 and on the Bluetooth
device until you reach a comfortable listening level.
Notes:
Refer to the manual of your cell phone, tablet PC, computer or other Bluetooth
enabled devices for Bluetooth operation since it may vary from model to model.
If your Bluetooth enabled device does not support A2DP profile, it will not play the
music through the speaker, even if paired (linked).
Remember to turn off the SB2150 when you have finished listening.
Don't forget to switch off the power of your Bluetooth device as well.
AUX OPERATION
This unit provides an AUX IN JACK (#18) for connecting external audio devices like
MP3 players, CD players, smart phones and iPods (except iPod shuffle 3rd
generation) to listen to your external source through the speakers of this system.
1. You need an audio cable (not included) with one 3.5 mm stereo plug on each
end of the cable.
2. Plug one end of the cable into the AUX IN JACK (#18) located on the top right
side of the unit and the other end of the cable into the Line-out Jack or
Headphone Jack of your external audio device.
3. Turn on the external audio device.
4. Turn on the unit and tap the FUNCTION BUTTON (#17) repeatedly to select
AUX Mode. The “AUX” will show on the LCD DISPLAY (#23).
5. The volume level can now be controlled through the VOLUME –BUTTON (#15)
and VOLUME + BUTTON (#16) of the unit. Operate all other functions on the

E-14
auxiliary device as usual.
6. Press and hold the POWER BUTTON (#1) to turn off the unit.
Notes:
If you connected the Line-out Jack of your external device then you only need to
adjust the volume control of this system. If you connected the Headphone Jack of
your external device then you may need to adjust both the volume control of your
external device and the volume control of this system to find the most desirable
volume setting.
Remove the audio cable from AUX IN JACK (#18) when you finish listening. Don't
forget to switch off the power on your external device as well.
TAPE OPERATION
Playing a tape
1. Press and hold the POWER BUTTON (#1) to turn on the unit.
2. Tap the FUNCTION BUTTON (#17) repeatedly to select cassette mode.
3. Press STOP/ EJECT BUTTON (#8) to open the CASSETTE HOLDER (#24).
4. Insert a tape and close the CASSETTE HOLDER (#24).
5. Press CASSETTE PLAYBUTTON (#11) to start playback.
6. Tap the VOLUME -/+ BUTTONS (#15/16) repeatedly to the desired volume level.
7. To pause playback, press the CASSETTE PAUSE BUTTON (#7). Press the
CASSETTE PAUSE BUTTON (#7) again to resume playback.
8. To stop playback, press CASSETTE STOP/ EJECT BUTTON (#8).
9. To search backward or forward, press REW. BUTTON or F.FWD BUTTON
(#10 or #9) and press CASSETTE PLAY BUTTON (#11) or CASSETTE
STOP/ EJECT BUTTON (#8) at the point you want stop.
Recording from CD/FM/AM/BT/AUX
1. Press and hold the POWER BUTTON (#1) to turn on the unit.
2. Press CASSETTE STOP/EJECT BUTTON (#8) to open the CASSETTE
HOLDER (#24).
3. Insert a tape and close the CASSETTE HOLDER (#24).
4. Tap the FUNCTION BUTTON (#17) repeatedly to select CD, FM, AM, Bluetooth
or AUX mode which you want to record.
In CD mode, start to playback the CD.
In radio (FM or AM) mode, tune to your desired radio station.
In Bluetooth mode, start playback from your Bluetooth device.
In AUX mode, start playback from your auxiliary source.
5. Press CASSETTE RECORD BUTTON (#12). CASSETTE PLAYBUTTON
(#11) is depressed automatically.
6. To pause recording, press CASSETTE PAUSE BUTTON (#7). Press the
CASSETTE PAUSE BUTTON (#7) again to resume recording.
7. To stop recording, press CASSETTE STOP/EJECT BUTTON (#8).
8. To listen to your recording, tap the FUNCTION BUTTON (#17) repeatedly to
select cassette mode. Press REW. BUTTON (#10) to rewind the tape to
search your recording, then press PLAYBUTTON (#11) to listen.

E-15
Recording from the built-in microphone
1. Press and hold the POWER BUTTON (#1) to turn on the unit.
2. Tap the FUNCTION BUTTON (#17) repeatedly to select cassette mode. CASS
will light on the LCD DISPLAY (#23).
2. Press STOP/EJECT BUTTON (#8) to open the CASSETTE HOLDER (#24).
3. Insert a tape and close the CASSETTE HOLDER (#24).
4. Press RECORD BUTTON (#12). PLAYBUTTON (#11) is depressed
automatically.
5. To pause recording, press the PAUSE BUTTON (#7). Press the PAUSE
BUTTON (#7) again to resume recording.
6. To stop recording, press the STOP/EJECT BUTTON (#8).
7. To listen to your recording, tap the FUNCTION BUTTON (#17) repeatedly to
select cassette mode. Press REW. BUTTON (#10) to rewind the tape to
search your recording, then press PLAYBUTTON (#11) to listen.
Note: The Built-in MICROPHONE (#25) is located on the front right of the unit. Place
the recorder near the sound source to be recorded.
CARE AND MAINTENANCE
1. Do not subject the unit to excessive force, shock, dust or extreme temperature.
2. Do not tamper the internal components of the unit.
3. Clean your unit with a dry cloth. Solvent or detergent should never be used.
4. Avoid leaving your unit in direct sunlight or in hot, humid or dusty places.
5. Keep your unit away from heating appliances and sources of electrical
noise such as fluorescent lamps or motors.
6. If drop-outs or interruptions occur in the music during
CD play, or if the CD fails to play at all, its bottom
surface may require cleaning. Before playing, wipe the
disc from the center outwards with a good soft cleaning
cloth
ABOUT CASSETTE TAPES
Whenever you record on a cassette any previously recorded material is erased as
the new material is recorded. To prevent you from accidentally erasing material
which you wish to save, blank cassettes are equipped with erase prevention tabs for
each side of the tape. If the erase prevention tab for side A is removed, you cannot
accidentally record on side A. The Record key cannot be depressed if the erase
prevention tab on the cassette has been removed.
To prevent accidental erasing on side A of a cassette use a small screw driver or
similar tool to break off the erase prevention tab for side A. This prevents the record
key form locking.

E-16
If later you do wish to record on side A of the cassette, cover the tab opening with a
piece of cellophane tape. This will allow the Record to function again.
CASSETTE CARE
Two common causes of trouble experienced when using cassettes are:
1) Tape Jamming –Leading to uneven speed in playback, and
2) Tape Tangling –Where the tape wraps itself around ital parts of the
mechanism.
To reduce the likelihood of these problems occurring, the following precautions
should be observed:
Check that there are no loose layers of tape visible through the cassette center window
(see Fig. 1). Take up any loose layers, using a pencil or hexagonal barreled ballpoint pen,
before inserting the cassette into the machine (see Fig.2)
If the cassette feels tight while performing operation shown (see Fig.2), the tape
may be jamming due to ridges formed in the winding of the tape (visible through
the center window). These may be removed, in most cases, by fast winding of the
cassette from one end to the other and back again.
Use only well-known brands of tape. Avoid use of C-120 cassettes.
Furthermore, do not expose cassettes to direct sunlight, dust or oil, and do not
touch the tape surfaces.
HEAD CLEANING
The tape heads, pinch roller and capstan require periodic cleaning. This removes
particles of the metal oxide coating that wear off the tape and accumulate on these
parts and impair performance. Switch off the power, press the STOP/EJECT
BUTTON (#8) to open the cassette door, and press the PLAYBUTTON (#11).
Clean the tape heads, pinch roller and capstan with a soft cloth or cotton pad
dampened in isopropyl alcohol or special tape head cleaner.
1. Avoid operating your unit under direct sunlight or in hot, humid or dusty places.
2. Keep your unit away from heating appliances and sources of electrical noise
such as fluorescent lamps or motors.
3. For better Display clarity, avoid operating the unit under direct sunlight or in
strong room illumination.

E-17
4. Unplug the unit from the electrical power outlet immediately in case of
malfunction. TROUBLE SHOOTING
If you experience difficulties in the use of this music system, please check the
followings or call 1-800-777-5331 for Customer Service.
Symptom
Possible Cause
Solution
Noise or sound
distorted on AM or
FM broadcast.
Station not tuned properly for
AM or FM.
FM: Telescopic antenna is not
extended.
AM: The bar antenna is not
positioned correctly.
Retune the AM or FM
broadcast station.
Fully extend the FM
telescopic antenna.
Reposition the unit until the
best reception is obtained.
AM or FM no
sound.
Unit not set to AM or FM band.
Volume at minimum.
Select AM or FM Mode
Increase Volume.
CD player will not
play.
Unit not in CD function mode.
CD is inserted incorrectly.
If the CD is self-compiled, the
media used may not be
compatible with the player.
Select CD function mode.
Insert CD with label side up.
Use better quality blank
media and retest.
CD skips while
playing
Disc is dirty or scratched.
Wipe CD with clean cloth or use
another disc.
CD Intermittent
sound
Dirty or defective disc.
Dirty Pick Up lens.
Player is subject to excessive
shock or vibration
Clean or replace the
defective disc.
Use a CD-lens cleaning disc
to clean the lens.
Relocate the player away
from shock or vibration
Tape Playback
muffled or fuzzy
Tape head dirty
Clean tape head using head
cleaning cassette
Cassette Player no
sound
- Unit not at TAPE function mode
- Volume at minimum
- SELECT Cassette Mode
- Increase volume
Sound distorted
Dirty tape head
Clean the head
Speed varies
- Tape old or worn
- Dirty roller and capstan
- Replace the tape
- Clean roller and capstan
Cassette Recorder
will not record
Prevention tab removed
Cover hole with tape
Distorted sound on
playback
Defective tape or dirty tape head
Replace tape or clean tape
head
Sound appears
distorted at high
volume setting
Volume control is set to maximum.
Adjust Volume control to a
lower comfortable level.
SPECIFICATION
POWER SUPPLY AC 120V~ 60Hz, 14 W
DC 6 x1.5V type R14/ UM-2/ “C” size batteries (not included)
FREQUENCY RANGE FM 88 -108 MHz

E-18
AM 520 -1710 kHz
90 DAY LIMITED WARRANTY AND SERVICE
VALID IN THE U.S.A. ONLY
SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be free from
defective materials or factory workmanship for a period of 90 days from the date of
original customer purchase and provided the product is utilized within the U.S.A. This
warranty is not assignable or transferable. Our obligation under this warranty is the repair
or replacement of the defective unit or any part thereof, except batteries, when it is
returned to the SPECTRA Service Department, accompanied by proof of the date of original
consumer purchase, such as a duplicate copy of a sales receipt.
You must pay all shipping charges required to ship the product to SPECTRA for warranty
service. If the product is repaired or replaced under warranty, the return charges will be at
SPECTRA’s expense. There are no other express warranties other than those stated herein.
This warranty is valid only in accordance with the conditions set forth below:
1. The warranty applies to the SPECTRA product only while:
a. It remains in the possession of the original purchaser and proof of purchase is
demonstrated.
b. It has not been subjected to accident, misuse, abuse, improper service, usage
outside the descriptions and warnings covered within the user manual or non-
SPECTRA approved modifications.
c. Claims are made within the warranty period.
2. This warranty does not cover damage or equipment failure caused by electrical wiring not
in compliance with electrical codes or SPECTRA user manual specifications, or
failure to provide reasonable care and necessary maintenance as outlined in the user
manual.
3. Warranty of all SPECTRA products applies to residential use only and is void when
products are used in nonresidential environment or installed outside the United States.
This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state. TO OBTAIN SERVICE please remove all batteries (if any) and pack the
unit carefully and send it freight prepaid to SPECTRA at the address shown below. IF THE
UNIT IS RETURNED WITHIN THE WARRANTY PERIOD shown above, please include a
proof of purchase (dated cash register receipt) so that we may establish your eligibility for
warranty service and repair of the unit without cost. Also include a note with a description
explaining how the unit is defective. A customer service representative may need to
contact you regarding the status of your repair, so please include your name, address,
phone number and email address to expedite the process.
IF THE UNIT IS OUTSIDE THE WARRANTY PERIOD, please include a check for $45.00 to
cover the cost of repair, handling and return postage. All out of warranty returns must be
sent prepaid.
It is recommended that you contact SPECTRA first at 1-800-777-5331 or by email at
[e-mail] for updated information on the unit requiring service. In some
cases, the model you have may be discontinued, and SPECTRA reserves the right to offer
alternative options for repair or replacement.
SPECTRA MERCHANDISING INTERNATIONAL, INC.
4230 North Normandy Avenue,
Chicago, IL60634, USA. 1-800-777-5331
To register your product, visit the link on the website below to enter your information.
http://www.spectraintl.com/wform.htm
0621 Printed in China
