Studebaker SB2140 User manual

SOUND STATION PORTABLE STEREO BLUETOOTH / CD /
AM-FM RADIO / CASSETTE RECORDER BOOMBOX
MODEL: SB2140
USER MANUAL
PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS UNIT AND
RETAIN THIS BOOKLET FOR FUTURE REFERENCE

WARNING
TO PREVENT FIRE OF SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN
EXTENSION
CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY
INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK
HAZARD,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
The Caution Marking is located at the bottom enclosure of the apparatus.
The Rating plate is located at the bottom enclosure of the apparatus
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that product heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for a long
period of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.

15. This appliance shall not be exposed to dripping or splashing water and that no object filled
with liquids such as vases shall be placed on the apparatus.
16. Do not overload wall outlet. Use only power source as indicated.
17. Use replacement part as specified by the manufacturer.
18. Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks.
19. Power Sources - This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to your home,
consult your product dealer or local power company. For products intended to operate from
battery power, or other sources, refer to the operating instruction.
20. Object and Liquid Entry - Never push objects of any kind into this product through openings
as they may touch dangerous voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.
21. Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will often require extensive work
by a qualified technician to restore the product to its normal operation.
e) If the product has been dropped or damaged in any way, and
f)When the product exhibits a distinct change in performance - this indicates a need for
service.
22. Mains plug is used as disconnect device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the mains completely, the mains
plug should be disconnected from the mains socket outlet completely.
23. Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
24. Excessive sound pressure from earphones and headphone can cause hearing loss.
25. Minimum distances of 4 inches around the apparatus for sufficient ventilation.
26. The ventilation should not be impeded by covering the ventilation openings with items, such
as newspapers, table-cloths, curtains, etc.
27. No naked flame sources, such as lighted candles, should be placed on the apparatus.
28. The use of apparatus in moderate climates.
29. Attention should be drawn to the environmental aspects of battery disposal.
SAVE THESE INSTRUCTIONS

COMPLIANCE WITH FCC & IC REGULATIONS
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B Digital Device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING
Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
The equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. The equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
The distance between user and products should be no less than 20cm
Cet appareil est conforme aux CNR exemptes de licence d'Industrie Canada . Son
fonctionnement est soumis aux deux conditions suivantes :
( 1 ) Ce dispositif ne peut causer d'interférences ; et
( 2 ) Ce dispositif doit accepter toute interférence , y compris les interférences qui peuvent
causer un mauvais fonctionnement de l'appareil.
la distance entre l'utilisateur et les produits devraient être au moins 20 cm
Changes or modifications not expressly approved by the party responsible for compliance could
void your authority to operate the equipment.

CAUTION
Follow the advice below for safe operations.
ON PROTECTION AGAINST LASER ENERGY EXPOSURE
As the laser beam used in this compact disc player is harmful to the eyes, do not attempt to
disassemble the casing.
Stop operation immediately if any liquid or solid object should fall into the cabinet.
Do not touch the lens or poke at it. If you do, you may damage the lens and the player may
not operate properly.
Do not put anything in the safety slot. If you do, the laser diode will be ON when the CD door
is still open.
If the unit is not to be used for a long period of time, make sure that all power sources are
disconnected from the unit. Remove all batteries from the battery compartment.
This unit employs a laser. The use of controls or adjustment or performance of procedures
other than those specified here may result in exposure to hazardous radiation.
Caution:
- Any use of the controls or performing any of the procedures in a way other than those specified
herein may result in hazardous radiation exposure.
- This unit should not be adjusted or repaired by anyone except qualified service personnel.
ON PLACEMENT
•Do not use the unit in places which are extremely hot, cold, dusty or humid.
•Place the unit on a flat and even surface.
•Do not restrict the air-flow of the unit by placing it in a place with poor ventilation, by covering
it with a cloth or by placing it on a carpet.
ON CONDENSATION
•When left in a heated room where it is warm and damp, water droplets or condensation may
form inside the unit.
•When there is condensation inside the unit, the unit may not function normally. Let it stand for
1 to 2 hours before turning the power on, or gradually heat the room up and dry the unit
before use.
Should any trouble occur, remove the power source and refer servicing to qualified personnel.
KEEP YOUR SB2140 WITHIN ACCEPTABLE OPERATING TEMPERATURES
The built-in rechargeable battery should not be exposed to excessive heat such as sunshine, fire
and humidity. Use this unit where the ambient temperature is between 0º and 45ºC (32º to
113ºF). Using this unit in very hot conditions can permanently shorten battery life and deform the
enclosure which is not covered by the warranty. Store this unit where the temperature is between
–20º and 60ºC (-4º to 140ºF). Do not leave the unit in your car because temperatures in parked
cars can exceed this range.

Protect your SB2140 from higher temperature conditions and activities that might cause
damage to the unit or affect performance
• Do not leave this unit in direct sunlight.
• Do not leave this unit in a car on a hot day.
• Do not use certain features in hot conditions or direct sunlight for an extended period of time.
PROTECT YOUR FURNITURE
This system is equipped with non-skid rubber ‘feet’ to prevent the product from moving when
you operate the controls. These ‘feet’ are made from non-migrating rubber material specially
formulated to avoid leaving any marks or stains on your furniture. However certain types of oil
based
furniture polishes, wood preservatives, or cleaning sprays may cause the rubber ‘feet’
to soften, and
leave marks or a rubber residue on the furniture.
To prevent any damage to your furniture we strongly recommend that you purchase small
self- adhesive felt pads, available at hardware stores and home improvement centers
everywhere
and apply these pads to the bottom of the rubber ‘feet’ before you place the
product on fine
wooden furniture.

LOCATION OF CONTROLS
1 MASTER VOLUME 20 DIAL SCALE
2 TREBLE KNOB 21 BLUETOOTH OUT
3 BASS KNOB 22
CD / USB / PAIR / BUTTON
4 BALANCE KNOB 23 BUTTON
5 FM ANTENNA 24 HEADPHONE JACK
6 CHARGE INDICATOR 25 TREBLE SPEAKER
7 BT INDICATOR 26 VU METER
8 FM ST. INDICATOR 27 CD COMPARTMENT
9 POWER INDICATOR 28 CD LATCH
10 FUNCTION SWITCH 29 BASS SPEAKER
11 BAND SWITCH 30 CASSETTE RECORD BUTTON
12 USB PORT 31 CASSETTE PLAY BUTTON
13 AUX IN JACK 32 CASSETTE REW BUTTON
14 TUNING KNOB 33 CASSETTE F.FWD BUTTON
15 LED DISPLAY 34 CASSETTE STOP/EJ BUTTON
16 BUTTON 35 CASSETTE PAUSE BUTTON
17 BUTTON 36 CASSETTE COMPARTMENT
18 +10 / LIGHT SHOW BUTTON 37 CARRY HANDLE
19 REPEAT / PROGRAM BUTTON 38 DC INPUT JACK

POWER SOURCE
This unit can be operated using either AC power or the built-in Li-Polymer rechargeable battery
AC POWER OPERATION
Plug the included AC adapter into the
standard AC power outlet to power the unit.
Connect small end to DC INPUT jack of main
unit.
After adapter connection, press the POWER
button to turn on / off the unit.
BATTERY (build-in) OPERATION
Unplug the DC INPUT jack of main unit. The unit will enter Battery Operating mode automatically.
LOW BATTERY INDICATION
1. When the build-in battery power remains around 5%, the CHARGE INDICATOR will light Red
and flash, please connect the unit to AC adaptor for charging.
2. After prolonged use, the battery voltage may discharge and operation might become
intermittent. When this happens, please recharge the internal battery.
CHARGING INSTRUCTIONS
CHARGING THE BATTERY WITH THE INCLUDED AC ADAPTOR
1. Charge the built-in Lithium battery a minimum of 5 hours prior to first use. Firmly and securely
insert the DC plug of the adaptor into the DC Jack on the back of the unit.
2. Plug the AC Adaptor plug into the 120V AC outlet. Connecting this system to any other power
source may cause damage to the system.
3. When the AC power is connected, the battery charging indicator will light solid Red showing
that the internal battery is being charged.
4. After the battery is fully charged, the charging indicator will turn to solid Green.
Notes:
1.) Charging time will vary if you are listening to music while charging the internal battery. We
recommend you place the unit in Power off mode during the charging process or until SB2140
batteries are fully charged.
2.) To prolong the life of a rechargeable battery, it is recommended to completely discharge it
before fully charging it again.
3.) Rechargeable batteries need to be cycled for maximum performance and longer battery life. If
you don’t use the player that often, be sure to recharge the battery at least once a month in
order to keep the internal battery working properly.
Battery Note and Care
• Do not burn or bury batteries.
• Do not puncture or crush.
• Do not disassemble.
• Recycle Lithium batteries. Do not dispose of in the trash.
• Use only chargers rated for Lithium cells. Be sure the charger’s voltage and current
settings are correct for the battery pack being charged.
• Charge batteries on a fireproof surface away from flammable items or liquids.
• Batteries should NEVER be left unattended while charging. Only adults should charge the
batteries.
• Follow the manufacturer’s instructions for charging the product and do not charge longer
than recommended. Unplug the charger when the battery is charged or not in use.

NOTE: These speakers are not magnetically shielded and may cause color distortion on the
screen of some TVs or video monitors. To avoid this, you may need to move the speakers
further away from the TV or monitor if unnatural color shifts or image distortion occurs.
RADIO OPERATION
1. Slide the FUNCTION SWITCH to RADIO position.
2. Select the desired FM mode by switching the FM/FM ST. BAND SELECTOR on unit tip
panel.
3. Tune to your desired station with the TUNING knob. If FM STEREO mode is selected and
you tune to an FM Stereo station, the FM STEREO LED Indicator will light.
4. Adjust the MASTER VOLUME knob to obtain the desired sound level.
FM & FM-STEREO RECEPTION
● Set the BAND SELECTOR to “FM” position. Stations will now be received in MONO mode.
When a FM station is weak or distorted, listening is usually improved by switching the band
selector to the FM (mono) position.
● Set the band selector to “FM-ST” position to receive stereo broadcasts. The FM-Stereo LED
indicator will light up to show a FM stereo station is detected.
TIPS FOR BEST RADIO RECEPTION
AM - The AM antenna is built inside the radio. If AM reception is weak, change the position of the
unit until the internal antenna picks up the strongest signal.
FM - If a stereo broadcast program is being received, the FM STEREO INDICATOR will light.
During FM Stereo reception, always keep the FM TELESCOPIC ANTENNA fully extended
for best performance. However, if FM reception is weak, try repositioning the unit near an
open window until you get the best reception.
CD OPERATION
PLEASE READ THIS IMPORTANT INFORMATION:
CD mechanisms used in devices like this are designed to fully read all commercial CDs. They
will also read self-compiled CD-R/CD-RW discs but it may take up to 10 seconds for playback to
start. If playback does not start, it is likely due to the quality of the CD-R/RW disc and/or the
compatibility of the CD compilation software. Manufacturer is not responsible for the playback
quality of CD-R/RW discs.
Do not attach a label or seal to either side of the CD-R/RW disc. It may cause a malfunction.
1. Slide the FUNCTION switch to CD/USB position. The display will show “- -“ briefly. If no CD
2. Grip the “OPEN” mark on the CD Door and pull gently to open it.
3. Carefully load an audio CD with its label side OUT ward in the CD compartment then
gently close the CD door.
4. The player will start reading TOC of the disc, total number of tracks on the CD will appear
on the LED DISPLAY after a few seconds.
5. Press the PLAY/PAUSE button to start to play.
6. Adjust the MASTER VOLUME knob to obtain the desired sound.
7. To suspend playing, press the PLAY/PAUSE Button. The play/pause indicator will be
flashing. To resume playing, press the PLAY/PAUSE Button again. The play/pause
indicator will be solid on.
8. You can skip up or down to a specific track number by pressing the SKIP BACKWARD
button or skip forward button. The LED Display will indicate the correct track number
selected.

9. To locate a particular section within a track, press and hold the / button until the
section is found.
10. To stop playing, press the STOP button
11. Slide the FUNCTION switch to POWER OFF position to turn off the unit
+10 button control
Press the +10 button once to advance the music search by increment of 10 tracks.
REPEAT MODE
Repeat 1
To repeat the current track, press the REPEAT BUTTON once, the REPEAT INDICATOR will
flash in LED display. The track will continue to play until the repeat function is turned off.
Repeat All
To repeat all the tracks, press the REPEAT BUTTON twice, the REPEAT INDICATOR will be
solid on. All the tracks on the disc will be played repeatedly.
To Cancel Repeat Function: Press the REPEAT BUTTON until REPEAT indicator goes off
from LED display.
PROGRAM OPERATION
This function allows the tracks to be played in a programmed sequence.
NOTE: Programs can be set in STOP mode.
1. In CD stop mode, press REPEAT/PROGRAM button, the PROG indicator will light and
Program Number “P01” will show on LED display.
2. Press the SKIP or button to select the desired track. The track number “1” (001 for
MP3 CD) will blink on the LED display to prompt for input.
3. Press the PROGRAM button to confirm the selection. Program Number advances to “P02”.
4. Repeat step 2 to 3 to program up to maximum of 20 tracks.
5. When maximum of 20 tracks have been programmed, the LED display will show “FUL” to
indicate program is full.
6. When you have completed programming, press the PLAY/PAUSE button to start
playing. Both PROG and Play/Pause indicators are lighting steadily.
7. To cancel programmed play, press the STOP button twice. PROG indicator goes off.
USING TREBLE / BASS / BALANCE CONTROL KNOBS
• TREBLE: Adjust TREBLE level of music playback.
• BASS : Adjust BASS level of music playback.
• BALANCE : Adjust BALANCE for balance left and right speaker.
USB OPERATION
The unit is designed to play MP3 files stored in the USB flash-drive. If the files on the USB
device do not conform to the standard, they may not be played.
1. Slide the FUNCTION switch to CD/USB/AUX position. Press and hold the CD/USB/PAIR/
button until USB mode indication “USB” shows on LED display and USB indicator flashing.

2. Insert your USB flash-drive into the USB port, unit starts to read the USB flash-drive.
Notes:
1.) USB supports flash drive capacity up to 32 GB maximum.
2.) Due to various USB flash drives in the market, please always fold down the carrying
handle before insert USB flash drive into the USB port.
3.) When carrying this unit, be sure your USB flash drive is not taller than the space under
the carrying handle to avoid damaging.
3. After reading the USB flash-drive, the unit will display the total number of files on the
flash-drive.
USB playback
After reading the USB flash-drive, press the PLAY/PAUSE button once, the first track/file on
the USB flash-drive will be played back. The “USB” and “PLAY/PAUSE” indicators will be solid
on during playback.
Play/Pause Control
To temporarily stop playing, press the button, music playback will be paused and the
PLAY/PAUSE indicator will be blinking. Press the button again to resume playback.
Stop playback
To stop playback, press the STOP button on the unit. The total number of tracks/files on the
USB flash-drive will be shown on the LED display.
Skip track
During playback, press the SKIP backward or forward buttons to skip to the previous
or next track/file.
+10 control
Press the +10 button to advance the music search by increments of 10 tracks.
REPEAT MODE
Repeat 1
To repeat the current track, press the REPEAT/PROGRAM BUTTON once, the REPEAT
INDICATOR will flash in LED display. The track will continue to play until the repeat function is
turned off.
Repeat All
To repeat all the tracks, press the REPEAT BUTTON twice, the REPEAT INDICATOR will be
solid on. All the tracks on the disc will be played repeatedly.
To Cancel Repeat Function: Press the REPEAT BUTTON until REPEAT indicator goes off
from LED display.
Programmed USB playback
This unit can be programmed to play up to 20 tracks/files in USB mode.
1. Plugged in your flash-drive into USB port, make sure unit is in stop mode.
2. Press REPEAT/PROGRAM button, the PROGRAM Indicator will light and program Channel
Number "P01" will show on the LED DISPLAY.
3. Press or button to select the track to be programmed. The track number “001” will

blink on the LED DISPLAY to prompt for input.
4. Press the PROGRAM button again to store selection. The Program Channel Number will
change to “P02”.
5. You may repeat steps 2 - 3 to program as many as 20 tracks. When the memory full, “FUL”
will show on the LED DISPLAY.
6. Press the PLAY/PAUSE button to start the programmed play.
7. Press STOP button once to stop playback.
8. Press the button to resume programmed play.
9. To cancel programmed play, press the STOP button twice.
BLUETOOTH OPERATION
PAIRING A SMARTPHONE OR BLUETOOTH ENABLED DEVICE
The Bluetooth feature enables you to stream and play the digital music on your Bluetooth
enabled device to your unit. (make sure AUX IN jack is no plug in AUX cable)
1. Slide the FUNCTION switch to Bluetooth /AUX position, the Bluetooth indicator will
flash.
2. The unit will start in auto connection mode and search for a previously paired device that is
active and in range (30 feet/10 meters). If found, a brief welcome melody will be heard and
Bluetooth indicator will change to solid on. If no active device is found, the unit will switch to
interactive pairing mode and the Bluetooth indicator keeps flashing.
3. To establish a new link, turn on the Bluetooth function of your Bluetooth enabled device and
enable the search or scan feature to find “SB2140” in the list of discoverable Bluetooth
devices. Select the “SB2140” from your available device list when it appears on its screen
and a brief welcome melody will be heard if pairing and connection is successful. If you are
asked for a password, enter “0000”.
4. If no successful pairing and connection is made within 5 minutes, the unit can enter manual
pairing mode. You need to press and hold the PAIR button until Bluetooth indicator flashes
to initiate a pairing/connecting request to a new or old Bluetooth enabled device. Follow
step #3 to complete the process.
5. After successfully pairing and connecting your device with SB2140, the unit will emit a brief
welcome melody and the Bluetooth indicator will change to solid on. You can now play
music from your Bluetooth enabled device wirelessly to the SB2140.
6. If you want to connect the SB2140 to another new external Bluetooth enabled device while
paired with another device, press and hold the PAIR button for few seconds to disconnect
the existing connection. The unit will emit two short beeps and Bluetooth indicator will
change to flash. Repeat steps #3 to #4 above to make a new link.
7. Rotate the VOLUME CONTROL on the top panel to increase the listening volume gradually
until a comfortable listening level is reached.
8. Press the PLAY/PAUSE BUTTON to control play/pause.
9. Press the SKIP FORWARD BUTTON to skip to next song and SKIP BACKWARD
BUTTON to skip to previous song.
Notes:
• If you cannot pair the unit with your Bluetooth enabled device, try solving the problem by
turning the unit power off, then power on, and then starting the pairing process again.
•The Bluetooth function of the unit will remain paired unless the paired device goes out of
range of 30 feet (10 meters). If the broken link is re-established within 20 seconds, the
SB2140 will reconnect to the current paired device automatically. Otherwise you will need
to make a manual connection again later.
•You may need to turn off the Bluetooth function of the paired external device first before
make a new link.
•Refer to manual of your smartphone or external Bluetooth enabled device for correct
Bluetooth operation instructions since it may vary from model to model.

•If your Bluetooth enabled device does not support A2DP, it will not play the music through
the SB2140 system even after it is paired and connected successfully.
• If you are pairing and connecting your personal computer to the SB2140 using Bluetooth,
you may need to set the SB2140 as your computer’s default sound device.
RE-LINKING TO A SMARTPHONE OR BLUETOOTH ENABLED DEVICE
Even if your smartphone or Bluetooth device is already paired with the SB2140 and with both
Bluetooth functions turned on, they can become unlinked at some point due to intentional
manual disconnection or undesirable external signal interferences or over-range for more than
10 seconds. If this happens, the unit will emit two short beeps. You can re-link them and resume
play by:
1. Select “SB2140” from the device list on your smartphone or Bluetooth device. The SB2140
should re-link to your Bluetooth enabled device within 5 seconds.
2. Tap the play button of the music player on your Bluetooth enabled device to resume
playback
Bluetooth Transmitter
1. POWER on the unit, Press BLUETOOTH OUT button (except for Radio mode and
Bluetooth mode)
2. unit is in Bluetooth transmit pairing mode and BT indicator flash Green
3. Set the Bluetooth received function of your external device to ON and begin searching for
devices.
NOTE: The effective distance between your external device and this apparatus is 10 meters (30
feet)
4. Pair indicator is lighted Green steadily indicates a connection has been established
5. If you want change to pair with another Bluetooth Enable Device. Press and hold the
BLUETOOTH OUT button. The indicator will flash green and the unit will go into Pairing /
Discoverable mode again.
AUX IN OPERATION
You can play other music sources (iPod, MP3 or other digital audio players) through the
speakers of the unit by connecting the AUX IN JACK to your external player’s audio out jack or
headphone jack.
1. Plug one end of an audio cable (not included) into the AUX IN JACK and the other end of the
cable to the headphone jack of your digital audio player.
2. Slide the FUNCTION SWITCH to the CD/USB/AUX IN position.
3. Turn on and start playing the external device you plugged into the AUX IN JACK.
4. Slowly adjust both the volume controls of your unit and the external device until you reach a
comfortable listening level.
5. Turn off both the external audio player and this unit after use. Unplug the audio cable from
AUX IN jack
Notes:
• If you connect the unit to the Line-Out Jack of your external device, you only need to adjust
the VOLUME CONTROL of your unit. If you connect to the Headphone Jack of your
external device, you may need to adjust both the volume controls of your external device
and the unit to obtain the desirable listening level.
• Remember to turn off the unit when you have finished listening. Don't forget to switch off the
power of your external audio device as well.

USE EARPHONES (NOT INCLUDED)
Inserting the plug of your stereo headphones (not included) into the headphone jack located on
the top panel will enable you to listen in private. When using headphones, the speakers will be
disconnected.
Read this Important Information before Using Your Headphones
1.) Avoid extended play at very high volume as it may impair your hearing.
2.) If you experience ringing in your ears, reduce the volume or shut off the unit.
3.) Keep the volume at a reasonable level even if your headset is an open-air type designed to
allow you to hear outside sounds. Please note that excessively high volume may still block
outside sounds.
CASSETTE OPERATION
Insert or Remove a Cassette Tape:
1. To insert your cassette tape: Press the Stop/Eject button to open the cassette door. Insert
your cassette tape into the compartment with the exposed section of the tape facing upward.
The side that you wish to listen to record onto should be facing towards you. Push the
cassette door unit it locks in place.
2. To remove your cassette tape: Press the Stop/Eject button to open the door then lift the
cassette out.
Playing Cassettes:
1. Slide the Function switch to the Tape position.
2. Press the Stop/Eject button to open the cassette door.
3. Insert the cassette tape and press the PLAY button.
3. The unit will automatically stop playing when it has reached the end of the cassette. If you
wish to continue playing the cassette; please press Stop/Eject, remove the cassette, flip the
cassette over to the other side, reinsert the cassette and press Play.
4. Press the Stop/Eject button to stop the tape. Press the Stop/Eject button again to open the
cassette door.
5. Press F.FWD or REW button to fast forward or rewind through the tape.
Note:
To avoid damage to the unit and your cassette, press the Stop/Eject in between each
operation. For example; when fast forwarding your cassette while playing, always press
Stop/Eject before pressing F.FWD.
Recording from the built-in microphone
1. Press the Stop/Eject button to open the cassette door.
2. Insert a cassette and push the cassette door unit it locks in place.
3. Press the Record button to start recording
4. If the unit in TAPE mode, you can speak into the unit to record your voice. For best results, make sure
you are facing the cassette door.
5. To stop recording, press the Stop/Eject button once.
6. To playback the recording, press the REW button to rewind, then press the Play button to
start playing.

Recording from the built-in Radio
1. Slide the FUNCTION switch to "Radio" position. The POWER indicator will light.
2. Select the BAND switch to the desired band position.
3. Adjust the
ANTENNA appropriately to obtain best reception
4. Insert the cassette into the Cassette Compartment.
5. Press the PAUSE button.
6. Press the RECORD button.
7. Release the PAUSE button to begin recording.
8. Adjust the VOLOUME, if necessary.
9. To stop recording, press STOP/EJECT button. When the tape operate to the
end recording will be stop automatically.
Recording from Discs
1. Slide the FUNCTION switch to "CD" position. The POWER indicator will light.
2. Grip the “OPEN” mark on the CD Door and pull gently to open it.
3. Carefully load an audio CD with its label side OUT ward in the CD compartment then gently
close the CD door
4. The player will start reading TOC of the disc, total number of tracks on the CD will appear on
the LED DISPLAY after a few seconds.
5. Insert the cassette into the Cassette Compartment.
6. Press the PAUSE button.
7. Press the RECORD button.
8. Press the PLAY/PAUSE button to start to play.
9. Release the PAUSE button to begin recording.
10.Adjust the VOLUME, if necessary.
11. To stop recording, press STOP/EJECT button. When the tape operate to the end recording
will be stop automatically.
Recording from the USB
1. Slide the FUNCTION switch to "USB" position. The POWER indicator will light.
2. Insert your USB flash-drive into the USB port, unit starts to read the USB flash-drive.
3. After reading the USB flash-drive, the unit will display the total number of files on the flash-
drive
4. Insert the cassette into the Cassette Compartment.
5. Press the PAUSE button.
6. Press the RECORD button.
7. Press the PLAY/PAUSE button to start to play.
8. Release the PAUSE button to begin recording.
9. Adjust the VOLUME, if necessary.
10. To stop recording, press STOP/EJECT button. When the tape operate to the end recording
will be stop automatically.
Recording from the Aux In
1. Slide the FUNCTION switch to "Aux" position. The POWER indicator will light.
2. Plug one end of an audio cable (not included) into the AUX IN JACK and the other end of the
cable to the headphone jack of your digital audio player.
3. Turn on and start playing the external device you plugged into the AUX IN JACK.
4. Insert the cassette into the Cassette Compartment.
5. Press the PAUSE button.

6. Press the RECORD button.
7. Press the PLAY/PAUSE button to start to play.
8. Release the PAUSE button to begin recording.
9. Adjust the VOLUME, if necessary.
10. To stop recording, press STOP/EJECT button. When the tape operate to the end recording
will be stop automatically.
Recording from the Bluetooth
1. Slide the FUNCTION switch to "BT “position. The POWER indicator will light.
2. Follow the Bluetooth operation section to pair the unit and external BT device
3. Play the song through the SB2140 unit.
4. Insert the cassette into the Cassette Compartment.
5. Press the PAUSE button.
6. Press the RECORD button.
7. Press the PLAY/PAUSE button to start to play.
8. Release the PAUSE button to begin recording.
9. Adjust the VOLUME, if necessary.
To stop recording, press STOP/EJECT button. When the tape operate to the end recording will
be stop automatically.
LED LIGHT SHOW
- To turn off the LED light show, press and hold the LIGHT SHOW button.
- To turn on the LED light show, press and hold the LIGHT SHOW button once again.
Note: If the brightness is glaring, turn on room lights or turn off LED light show.
RESETTING THE UNIT
In case of malfunction due to electrostatic discharge, reset the unit by slide the FUCTION switch
to POWER OFF position to reset the unit. Wait for 30 seconds before power on the unit again.
CARE AND MAINTENANCE
About Cassette Tape
If the tape is loose in its cassette, take up the slack by
inserting a pencil in one of the reels and rotating.
If the tape is loose it may get stretched, cut or
caught in the cassette player.
Do not touch the tape surface.
To prevent recordings from being erased accidentally,remove
the tab(s) A and B.
To record after the tabs have been broken off, reseal the A
and B with a piece of adhesive tape.

Cleaning the Tape Heads and Tape Path
For continued high performance from your cassette deck, periodically clean the head, pinch
roller, and capstan. We recommend cleaning after every 20-30 hours of operation.
To clean the tape deck, press the STOP/EJECT key to open the deck door. Remove any
tape in the deck. Make sure that the power to the unit is OFF. Moisten a cotton swab with
isopropyl alcohol or a special head cleaning fluid. Carefully rub the face of each head, pinch
roller, and capstan with the moistened cotton swab.
About Disc
1. Do not subject the unit to excessive force, shock, dust or extreme temperature.
2. Do not tamper the internal components of the unit.
3. Clean your unit with a dry cloth. Solvent or detergent should never be used.
4. Avoid leaving your unit in direct sunlight or in hot, humid or dusty
places.
5. Keep your unit away from heating appliances and sources of
electrical noise such as fluorescent lamps or motors.
6. If drop-outs or interruptions occur in the music during CD play, or
if the CD fails to play at all, its bottom surface may require
cleaning. Before playing, wipe the disc from the center outwards with
a good soft cleaning cloth.
CLEANING THE UNIT
•To prevent fire or shock hazard, disconnect your unit from the AC power source when
cleaning.
•The finish on the unit may be cleaned with a dust cloth and cared for as other furniture, Use
caution when cleaning and wiping the plastic parts.
•If the cabinet becomes dusty wipe it with a soft dry dust cloth. Do not use any wax or polish
sprays on the cabinet.
•If the front panel becomes dirty or smudged with fingerprints it may be cleaned with a soft
cloth slightly dampened with a mild soap and water solution. Never use abrasive cloths or
polishes as these will damage the finish of your unit.
CAUTION: Never allow any water or other liquids to get inside the unit while cleaning.
TROUBLE SHOOTING GUIDE
If you experience difficulties in the use of this unit, please check the following:
S y m p t o m Possible Ca u s e S o l u t i on
Noise o
r
sound
distorted on FM
broadcast
Station not tuned p
r
operly for FM.
Telescopic antenna is not fully
extended.
Fine tune the FM
broadcast station.
Fully extend the FM
Telescopic antenna.
FM no sound Unit not in Radio mode,
Master Volume at minimum Slide Function switch to select
RADIO.
Increase Master Volume level.

Poor cassette sound
quality
Recording does not
work
Dust and dirt on the heads,
capstan or pinch roller
Cassette tab(s) maybe broken out
Clean the heads etc…
Apply a piece of adhesive tape
over the missing tab space
CD pla
y
e
r
will not
play Unit not in CD function mode. CD is installed incorrectly.
If the CD is self-compiled, the
media used may not be compatible
with the player.
Slide Function switch to CD.
Insert CD with label side up.
Use better quality blank media
and retest.
CD skips while
playing Disc is dirty o
r
sc
r
atched. Wipe CD with clean cloth or
use another disc.
Inte
r
mittent sound
from CD Player Dirty o
r
defective disc.
Dirty pick up lens.
Player is subject to excessive
shock or vibration
Clean or
r
eplace the defective
disc.
Use a CD-lens cleaning disc
to clean the lens.
Relocate the player away
from shock or vibration
BT No Sound Unit is not linked with
the Bluetooth enabled
device.
Unit placement out of
range
Volume set too low
Go through “BLUETOOTH
OPERATION” process to link
the speaker.
Relocate the unit within
Bluetooth operating range
(30 feet)
Increase Volume level.
SPECIFICATION
Radio Frequency Range : AM: 530 – 1710 KHz
: FM: 88 – 108 MHz
Audio Output Power : 2 X 5W (RMS)
Tweeter : 2 x 1.5 inch / 6 ohms
Woofer : 2 x 4 inch / 6 ohms
Bluetooth : V5.0 + EDR
USB : Support USB device up to 32GB
Power Source :
AC Adapter : Input AC 120V~ 60Hz
: Output DC 12V
,1.5A
Built-in Rechargeable Lithium Battery : DC 7.4V , 2200mAh
Due to continuing improvement, the features and the design are subject to change without
notice.
