Studymate SM2DRWFCWE User manual

1/10
ASSEMBLY INSTRUCTIONS
2 DRAWER FILE CABINET
This design and instruction booklet is subject to copyright.
www.officeworks.com.au
SM2DRWFCWE

Officeworks Ltd. I 236-262 East Boundary Road I East Bentleigh I 3165 I AUSTRALIA
2/10
Tools required for assembly
Recommend 2 adults to assemble
Assemble item on a clean flat surface
Please check you have all hardware before assembling.
If you think you are missing any hardware, please contact the store of purchase.
Please ensure you have the name of the item and hardware part required and quantity.
Please retain your receipt for proof of purchase to validate warranty. Enjoy your new purchase.
At least every 4 months, check all bolts, screws and knobs to be sure they are tight.
If parts are missing, broken, damaged or worn, stop using of the product until repairs are made,
using factory authorised parts.
Failure to follow these warnings could result in serious injury.
WARNING
.
.
.
.
Do not tighten the screws before all of the screws are in the correct place.
.
.
.
.
.
Do not use this cabinet unless all bolts, screws and knobs are firmly secured.

1pc
PARTS LIST
HARDWARE LIST
1 2 3 4
56 7 8
910
A B C D
FG H I
K L
E
J
M N O
8pcs 16pcs 12pcs 8pcs 16pcs
2pcs 2pcs 2pcs 2pcs 4pcs
2pcs 4pcs 8pcs 14pcs 4pcs
1pc 1pc 1pc
2pcs2pcs 2pcs
2pcs 2pcs
2pcs
3/10
o
6x30mm
M6x35mm
o
15x12mm
o
15x9mm
o
3x12mm
o
4x30mm
o
4x25mm
350mm 350mm 350mm 350mm

4/10
Step 1
Step 2
B
4pcs
A
2pcs
F
FH
H
B
B
E
E
E
E
E
E
E
E
B
B
23
E
E
H
AA
A
C
C
C
2
5
5
E F H
8pcs 2pcs 2pcs
2pcs
C

5/10
Step 3
Step 4
A
2pcs
C
2pcs
B
4pcs
C
C
C
A
A
A
3
5
5
B
B
B
B
B
1

6/10
Step 5
Step 6
N
14pcs
4pcs
O
A
A
A
A
A
C
C
C
C
1
2
3
A
4pcs
C
4pcs
XX=YY
N
O
O
O
O
4
3
2
4
XX
YY
N
N
Note: Partially hammer the nails 2/3
into back panel at this step for easy
removal. After the drawers are fully
aligned and travel smoothly, fully
hammer nails to inside back panel.

7/10
Step 7
Step 8
D
8pcs
B
B
B
B
B
B
6
x2
D
D
D
DD
6
7
9
x2
8pcs
B
C
C
C
4pcs
D

8/10
Step 9
Step 10
10
x2
MM
MM
M
M
8
J
J
x2
M
8pcs
Holes for A4
suspension files
Holes for foolscap
suspension files
Could decide during installation if you want foolscap or A4

9/10
Step 11
Step 12 K
2pcs
x2
I
9
7
G
E
E
E
E
E
E
l
K
L
L
6
x2
K
L
L
E
8pcs
G
2pcs
I
2pcs
L
4pcs

10/10
Step 13
MAXIMUM WEIGHT CAPACITY
Step 14
Thank you for purchasing our product! Please retain your receipt to validate warranty.
lf you’d like to know more about Officeworks’ furniture products, please visit our website.www.officeworks.com.au
If the drawer’s two side gaps were not aligned,
please pull out the back panel nails and adjust
the cabinet angles to ensure the frame angles
are square. After the drawers are fully aligned
and travel smoothly, fully hammer nails to inside
back panel.
NOTE: Filing drawer 10kg
CAUTION: This product is intended to hold the maximum weight indicated. Exceeding the
maximum weight will result in instability and may cause injury.
