Studymate SMSHEFPU User manual

Quality Assurance Guide
This stool has a load rating of 120kgs
This design and instruction booklet is subject to copyright
www officeworks com au
For spare parts or hardware call :[phone] or email:[email protected]
SHE IELD CHAIR
F
SMSHEFPU / SMSHEFPK / SMSHEFBL
SMSHEFGR
ASSEMBLY INSTRUCTIONS
Weight capacity: 80kgs
1 CTN
F
1 / 8

[phone]
•Please check you have all hardware before assembly.
•If you are missing any hardware, please contact Kyvas on [phone] or
email [email protected]
•Please ensure you have the name of the item, required hardware part and quantity.
•Please retain your receipt as proof of purchase to validate your warranty.
NOTE
• Do not tighten screws before all screws are in the right place.
• Do not use this product unless all bolts, screws and knobs are firmly secured.
• Check that all bolts, screws and knobs are securely tightened at least every 4 months.
CAUTION
• If parts are missing, broken, damaged or worn stop using the product until all repairs
are made using manufacturer authorised parts.
• Failure to follow these warnings could result in serious injury.
WARNING
•
Officeworks Ltd. | 236-262 East Boundary Road | Bentleigh East VIC 3165 | AUSTRALIA
DANGER
20min
2 / 8
CHILDREN MUST BE SUPERVISED DURING ASSEMBLY.

Furniture Assembly Instructions Style Guide
PART LIST
HARDWARE LIST
x1
x1
x1
x1
x1
x3 x4 x3 x4 x1
x5
ABCD
EF
GHIJK
3 / 8
M6 X 30MM M6 X 20MM

Furniture Assembly Instructions Style Guide
Step 1
Step 2
Note: Turn the Star Base (E) upside down. Push the Castors (F) into holes at the end of each leg.
Turn the Star Base (E) upright and insert Gas Lift (D) into the center hole of Star Base (E).
Note: Attach Back (A) to the Seat Cushion (B) using 3 x Screws (G) & Washer (I)
Tighten the 3 x screws (G) and 3 x washers (I) with Allen Key (K).
4 / 8
used to complete
this step.
G
3 Pcs
used to complete
this step.
I
used to complete
this step.
used to complete
this step.
3 Pcs3 Pcs
3 Pcs3 Pcs3 Pcs
FRONT
K
M6 x 30MM
Do not tighten screws fully until you have completed assembly

Step 4
Note: Place assembled seat on the Gas Lift (D). Push down firmly until connection is secure.
5 / 8
Step 3
used to complete
this step.
H
used to complete
this step.
J
used to complete
this step.
used to complete
this step.
4 Pcs4 Pcs4 Pcs4 Pcs
4 Pcs4 Pcs4 Pcs4 Pcs
Note: Align the Seat Plate (C) so the FRONT of the Seat Plate matches the FRONT label
FRONT
Tighten the 4 x screws (H) and 4 x washers (J) with Allen Key (K).
FRONT
M6 x 20MM
on Seat Base(B).
Do not tighten screws fully until you have completed assembly

Care Instructions - fabric chair

- Turn continuously to adjust how
quickly chair tilts back & forth.
Note: if adjusting while sitting in chair:
Turn knob left to tighten tension
Turn knob right to loosen tension
9/9
Thank you for your purchase Please retain your receipt to validate warranty
If you would like to know more about our furniture products, please visit
www officeworks com au
6 / 8
Step 5
Your Sheffield Chair is now complete and ready for use
IMPORTANT NOTE: Periodically check and re-tighten screws
Spot clean fabric with upholstery shampoo or dry cleaning powder only.
Do not saturate fabric. Apply proprietary cleaning products strictly according to instructions.
Wipe dry immediately with an absorbent dry cloth.
Treat spills on fabric material immediately with an absorbent cloth by blotting the spill.
Do not use detergents, solvents or abrasive cleaners.
Keep away and protect from direct sunlight and heat.
Avoid contact with skin, in particular during high temperatures and humidity.
Clean, check and tighten all parts regularly.
Vacuum regularly.








Furniture Assembly Instructions Style Guide
Functionality
- To increase chair height pull
lever upward while lifting body
weight slightly off the seat.
- Release lever at desired height.
- To lower chair height sit fully into
the chair and pull lever upward.
- Release lever at desired height.
Your feet should be resting flat on
the floor.
- Turn continuously to adjust how
quickly chair tilts back & forth.
Note: if adjusting while sitting in chair:
Turn knob left to tighten tension
Turn knob right to loosen tension
9/9
SHE IELD CHAIR
FF
7 / 8

Furniture
Warranty 3 years
Product Warranty – valid for Australian customers only
Officeworks Ltd warrants that this product will be free from defects and work as
intended for 3 years from the date of purchase by the original customer.
If the product has any defects or does not work as intended during the Warranty Period,
Officeworks will, at its election and at its expense, repair or replace the product.
This warranty does not apply:
to cosmetic damage;
to damage caused by consumables used in connection with the product (such as
cleaning products);
where the product has not been used in accordance with all provided instructions;
to damage arising from fair wear and tear;
where the product has not been subject to reasonable use;
where the product has been intentionally or negligently damaged; and/or
if the customer has attempted to repair the product.
To make a claim under this warranty, please return your product with your receipt or
proof of purchase to your nearest Officeworks store or contact 1300 633 423.
This warranty is provided in addition to any rights you may be entitled to under the
Competitions & Consumer Act 2010.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
●
●
●
●
●
●
●
8 / 8
