Sub-Zero IC-27FI User manual

It is the elegant evolution o re rigeration
design that designers have been asking
or, executed as only Sub-Zero can— illed
with more aesthetic and technological
innovation than you would expect in such
a slender orm. This 27" all reezer
column enables you to pair with ull-size
integrated re rigeration or drawers to
customize your design in countless new
ways. This model is ENERGY STAR®
quali ied or energy e iciency.
27" Integrated
All Freezer—Column
FEATURES
•Custom front panel and hardware allows
for infinite design options.
•Point-of-use refrigeration that can be
placed anywhere in the home.
•Integrated design allows for dual installa-
tion with another integrated unit.
•Microprocessor maintains precise control,
within 1° of set temperature.
•Easy-access, illuminated touch control
panel.
•Bright interior lighting.
•Adjustable wire shelves and door shelves.
•Soft-close glide system on storage
drawers.
•Door alarm has an audible beep if door is
left open.
•Automatic ice maker provides crescent
shaped ice.
•90° door stop built into hinge.
•Star-K compliant with harness kit.
ACCESSORIES
•Stainless steel front panel with tubular or
pro handle—81" or 84" finished height.
•Stainless steel tubular and pro handles.
•Dual installation kits for installation with
column, tall or drawer model.
Accessories re v il ble through your Sub-Zero
de ler. For loc l de ler inform tion, visit the find
showroom section of our website, subzero.com.
INTERIOR FEATURES
•Freezer
3 Adjustable Wire Shelves
3 Storage Drawers with Dividers
6 Adjustable Door Shelves
Automatic Defrost
Automatic Ice Maker
MODEL IC-27FI
Design Integrated
Model IC-27FI shown in du l inst ll tion with model IC-27R ll refriger tor with tubul r h ndles.
Also shown is Wolf model SO30-2U/S built-in oven nd Wolf model WWD30 w rming dr wer.

INSTALLATION NOTES
Stainless steel panels with handles are
available as accessories. These panels are
not installed at the factory.
Complete installation specifications, including
panel sizes, can be found on our website,
subzero.com/specs.
Unit dimensions m y v ry by ± 1/8".
SPECIFICATIONS
Overall Width 27"
Overall Height 81"
Overall Depth 24"
Door Clearance 251/2"
Freezer Capacity 16.3 cu ft
Opening Width 27"
Opening Height 81"
Opening Depth 25"*
Electrical equirements 115 V AC, 60 Hz
15 amp dedicated circuit
Plumbing equirements 1/4" OD copper line
20–100 psi
Annual Energy Usage $65**
Shipping Weight 360 lbs
*Depth is 24" from the front of the unit to its b ck.
Your design m y necessit te moving the unit b ck,
or c binets forw rd to chieve flush fit. This will
require minimum opening depth of 25".
**B sed on 10.65 cents per kilow tt hour.
INSTALLATION SPECIFICATIONS
Opening Dimensions
Location of Electrical Supply Location of Water Supply
OVERALL DIMENSIONS
27" Integrated
All Freezer—Column
Dimensions in p rentheses re in
millimeters unless otherwise specified.
©Sub-Zero, Inc. ll rights reserved. Fe tures nd specific tions re subject to ch nge t ny time without notice. 2/10
27" (686)
14"(356)
15/8"
(41)
81"
(2057)
TO TOP OF
OPENNG
24" (610)
789/16"
(1995)
93/4"(248)
4"
(102)
1/2"(13) ± ADJUSTMENT IN LEVELING LEGS
24"
(610)
251/2"
(648)
45/8"
(117)
DIMENSIONS WILL VARY WITH PANEL THICKNESS
13" (330)
1/4"(6)
41/2"
(114)
POSITION OUTLET WITH
GROUNDING PRONG
TO THE RIGHT
FLOOR
21/2"(64)
FRONT VIEW
3" (76)
9"
(229)
3/4"
(19)
FLOOR
21/2"(64)
FRONT VIEW
9"
(229)
6"
(152)
TOP VIEW
11/2"
(38)
21/2"
(64)
BACK
WALL
27" (686)
OPENING WIDTH
25" (635)
OPENING DEPTH
81" (2057)
OPENING
HEIGHT
FRONT VIEWSIDE VIEW
25" (635)
OPENING
DEPTH
TOP VIEW
