Sub-Zero 600 Series BI-36F User manual

In a dual installation with all refrigerator
Model BI-36R, the all freezer Model BI-36F
offers maximum refrigeration capacity.
The new water filtration system removes
suspended particles, chemical pollutants,
viruses and bacteria from the ice.
Framed, overlay/flush inset and stainless
steel models are available. A new flush
inset installation option allows the unit to
sit flush with surrounding cabinetry.
Model BI-36F is Energy Star qualified.
New Built-In Model BI-36F
All Freezer
Interior Features
Freezer
22.8 cu ft Capacity
Water Filtration System
Automatic Ice Maker
3 Adjustable Wire Shelves
1 Stationary Glass Shelf
3 Storage Drawers with Dividers
3 Adjustable Door Shelves
2 Stationary Door Shelves
Stainless steel Models BI-36F and BI-36R shown with tubular handles.
Accessories
Louvered, panel and stainless steel grilles
for 83", 84" and 88" finished heights
Stainless steel front panels for framed,
flush inset and dual flush inset applications
with stainless steel finish and handle
options
Side panels in classic stainless steel and
white
Stainless steel tubular, pro or curved
handles and full-length extended handles
Dual installation kit
90° door stop kit
Accessories are available through your Sub-Zero
dealer. To obtain local dealer information, visit the
Showroom Locator section of our website,
subzero.com.
Features
Framed, overlay/flush inset and
stainless steel design applications
Flush inset installation option allows unit
to sit flush with surrounding cabinetry
Water filtration system
Energy Star qualified
Flip-up grille for easy access to condenser
Adjustable wire shelves
Door shelves are adjustable in one-inch
increments
Max ice feature to increase rate of ice
production for a 24-hour period
This appliance is certified by Star-K
to meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.
Flip-Up Grille Low Profile Hinges
Model Options BI-36F/F BI-36F/O BI-36F/S/TH BI-36F/S/PH BI-36F/S/CH
Design Framed Overlay/Flush Inset Stainless Stainless Stainless
Grille Louvered Panel Stainless Stainless Stainless
Handle Full-Length * Tubular Pro Curved
*Handle not included to allow for design flexibility.
Model BI-36R shown.

Installation Notes
Built-In models may be used in a standard
installation or in a flush inset installation which
allows the unit to be flush with surrounding
cabinetry.
Built-In all refrigerator and all freezer models
with opposite hinges can be used in a dual
installation.
Complete installation specifications, including
panel sizes, can be found on our website,
subzero.com.
Specifications
Overall Dimensions 36"W x 84"H x 24"D
Door Clearance Standard 371/4"
Flush Inset 373/4"
Opening Width 351/2"
Flush Inset Width 38"
Opening Height 833/4"
Flush Inset Height 84"
Opening Depth 24"
Flush Inset Depth 263/16"
Electrical Requirements 115 V AC, 60 Hz
15 amp circuit
Plumbing Requirements 1/4" OD copper line
30–100 psi
Shipping Weight 378–406 lbs
Built-In Model BI-36F
Unit dimensions may
vary by ±
1
/ 8 " (3).
Overall Dimensions
36"
(914)
84"
(2134)
24"
(610)
237/8"
(606)
BEHIND
FRAME
36"
(914)
371/4"
(946)
351/4"
(895)
751/2"
(1918)
7"
(178)
6"
(152)
E
LOCATE
ELECTRICAL
WITHIN
SHADED AREA
1/2"
(13)
18" (457)*6"
(152)
24" (610)
OPENING
DEPTH
263/16"
(665)
FLUSH INSET
DEPTH
SHUT-OFF
VALVE
OUTLINE
OF FLUSH INSET
APPLICATION WITH
3/4"(19) PANEL
18"
(457)
W
LOCATE WATER SUPPLY
WITHIN SHADED AREA
6"
(152)
FRONT VIEWSIDE VIEW
TOP VIEW
833/4"
(2127)
OPENING
HEIGHT
84"
(2134)
FLUSH
INSET
HEIGHT
1/4" (6) 23/16"
(56)**
3" (76)
351/2" (902)
OPENING WIDTH
38" (965)
FLUSH INSET WIDTH
11/4"
(32)
11/4"
(32)
23/16"
(56)**
24" (610)
OPENING
DEPTH
263/16" (665)
FLUSH INSET
DEPTH
*ANTI-TIP BRACKET MUST NOT
INTERFERE WITH WATER LINE.
REFER TO INSTALLATION
INSTRUCTIONS FOR COMPLETE
DETAILS.
**ASSUMES 3/4"(19) PANEL
THICKNESS.
EXTEND WATER LINE APPROX
36" (914) FROM BACK WALL.
WATER LINE
1/4"
(6)
11/4"
(32)
FLUSH INSET
DETAIL
23/16"
(56) 24" (610)
OPENING
DEPTH
751/2"
(1918)
7"
(178)
6"
(152)
E
LOCATE
ELECTRICAL
WITHIN
SHADED AREA
18"
(457)
W
LOCATE WATER SUPPLY
WITHIN SHADED AREA
6"
(152)
FRONT VIEWSIDE VIEW
833/4"
(2127)
OPENING
HEIGHT
351/2" (902)
OPENING WIDTH
3" (76)
24" (610)
OPENING
DEPTH
1/2"
(13)
18" (457)*6"
(152)
24" (610)
OPENING
DEPTH
SHUT-OFF
VALVE
OUTLINE OF
FRAMED, OVERLAY
OR STAINLESS
STEEL MODEL
TOP VIEW
*ANTI-TIP BRACKET MUST NOT
INTERFERE
WITH WATER LINE.
REFER TO INSTALLATION
INSTRUCTIONS FOR COMPLETE
DETAILS.
EXTEND WATER LINE APPROX
36" (914) FROM BACK WALL.
WATER LINE
Flush Inset Installation
*Anti-tip bracket must not interfere
with water line. Extend water line
approximately 36" from back wall.
**Dimensions based on
3
/ 4 " (19)
panels.
Installation Specifications
Standard Installation
*Anti-tip bracket must not interfere
with water line. Extend water line
approximately 36" from back wall.
Dimensions in parentheses are in
millimeters unless otherwise specified.
