Sub-zero 736tfi User manual

Integrated re rigeration can be used

anywhere in the home. It merges seam-

lessly into the décor, with no visible

hinges or grilles. Model 736TFI is a 36"

wide tall unit with reezer storage in the

upper cabinet and lower drawers. This

model is ENERGY STAR®quali ied or

energy e iciency.

36" Integrated

All Freezer—Tall

FEATURES

•Custom front panels and hardware allow

for infinite design options.

•Point-of-use refrigeration that can be

placed anywhere in the home.

•Microprocessor maintains precise control,

within 1° of set temperature.

•Easy-access, illuminated touch control

panel.

•Bright interior lighting in cabinet and

drawers.

•Adjustable wire shelves and door shelves.

•mooth-glide, full-extension storage

drawers.

•Door alarm has an audible beep if door or

drawer is left open.

•Automatic ice maker provides crescent

shaped ice.

•90° door stop built into hinge.

•tar-K compliant with harness kit.

ACCESSORIES

•tainless steel front panels with tubular or

pro handles—80" or 84" finished height.

•tainless steel tubular and pro handles.

•Dual installation kits for installation with

column, tall or drawer model.

Accessories are available t roug your Sub-Zero

dealer. For local dealer information, visit t e find a

s owroom section of our website, subzero.com.

INTERIOR FEATURES

•Freezer

1 Temperature Zone

3 Adjustable Wire helves

1 tationary helf

2 torage Drawers

2 Removable Drawer Dividers

4 Adjustable Door helves

Automatic Defrost

Automatic Ice Maker

MODEL 736TFI

Design Integrated

INSTALLATION NOTES

tainless steel panels with handles are

available as accessories. These panels are

not installed at the factory.

Complete installation specifications, including

panel sizes, can be found on our website,

subzero.com/specs.

SPECIFICATIONS

Overall Width 36"

Overall Height 80"

Overall Depth 24"

Door Clearance 341/2"

Drawer Clearance 191/2"

Freezer Capacity 21.5 cu ft

Finished Opening 36" W x 80" H x 25" D*

Electrical Requirements 115 V AC, 60 Hz

15 amp dedicated circuit

Plumbing Requirements 1/4" OD copper line

20–100 psi

Annual Energy Usage $84**

hipping Weight 480 lbs

*Dept is 24" from t e front of t e unit to its back.

Your design may necessitate moving t e unit back,

or cabinets forward to ac ieve a flus fit. T is will

require a minimum opening dept of 25".

**Based on 10.65 cents per kilowatt our.

36" Integrated

All Freezer—Tall

©Sub-Zero, Inc. all rig ts reserved. Features and specifications are subject to c ange at any time wit out notice. 2/10

Unit dimensions may vary by ± 1/8".

INSTALLATION SPECIFICATIONS

Opening Dimensions

Location of Electrical upply Location of Water upply

OVERALL DIMENSIONS

Dimensions in parent eses are in

millimeters unless ot erwise specified.

36" (914)

14"(356)

80"

(2032)

TO TOP OF

OPENNG

24" (610)

15/16"

(33)

7713/16"

(1976)

341/2"

(876)

203/8"

(518)

101/4"

(260)

131/4"

(337)

93/4"

(248)

(102)

1/2"

(13)

3/8"

(10)

HEIGHT DIMENSIONS ± 1/2"(13)

24"

(610)

DIMENSIONS WILL VARY WITH PANEL THICKNESS

191/2"

(495)

341/2"

(876)

7" (178)

171/2"(445)

41/2"

(114)

POSITION OUTLET WITH

GROUNDING PRONG

TO THE RIGHT

FRONT VIEW

FLOOR

21/2"(64)

1/4"(6)

131/2"

(343)

3" (76)

FRONT VIEW

3/4"

(19)

FLOOR

21/2"(64)

131/2"

(343)

TOP VIEW

(152) 11/2"

(38)

21/2"

(64)

BACK

WALL

36" (914)

OPENING WIDTH

25" (635)

OPENING DEPTH

80" (2032)

OPENING

HEIGHT

FRONT VIEWSIDE VIEW

25" (635)

OPENING

DEPTH

TOP VIEW
