Subaru 2001 Forester User manual

This service manual has been prepared
to provide SUBARU service personnel
with the necessary information and data
for the correct maintenance and repair of
SUBARU vehicles.
This manual includes the procedures for
maintenance, disassembling, reassem-
bling, inspection and adjustment of com-
ponents and diagnostics for guidance of
experienced mechanics.
Please peruse and utilize this manual
fully to ensure complete repair work for
satisfying our customers by keeping their
vehicle in optimum condition. When
replacement of parts during repair work is
needed, be sure to use SUBARU genu-
ine parts.
All information, illustration and specifica-
tions contained in this manual are based
on the latest product information avail-
able at the time of publication approval.
FUJI HEAVY INDUSTRIES LTD.
2001 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX
BODY SECTION
G8050GE6

SECURITY AND LOCKS SL
Page
1. General Description.....................................................................................2
2. Door Lock Control System..........................................................................8
3. Keyless Entry System...............................................................................14
4. Front Inner Remote...................................................................................27
5. Front Outer Handle ...................................................................................28
6. Front Door Latch Assembly.......................................................................29
7. Front Door Lock Actuator..........................................................................30
8. Rear Inner Remote....................................................................................31
9. Rear Outer Handle....................................................................................32
10. Rear Door Latch Assembly.......................................................................33
11. Rear Door Lock Actuator...........................................................................34
12. Rear Gate Outer Handle...........................................................................35
13. Rear Gate Latch Assembly.......................................................................36
14. Rear Gate Latch Lock Actuator.................................................................37
15. Front Hood Lock Assembly.......................................................................38
16. Remote Openers.......................................................................................39
17. Ignition Key Lock.......................................................................................40
18. Key Lock Cylinders ...................................................................................41
19. Immobilizer Control Module ......................................................................42
20. Immobilizer Antenna..................................................................................43
21. Keyless Entry Control Module...................................................................44
22. Keyless Transmitter...................................................................................45

1. General Description S909001
A: SPECIFICATIONS S909001E49
B: COMPONENT S909001A05
1. DOOR LOCK ASSEMBLY S909001A0501
S5M0444A
(1) Inner remote ASSY
(2) Bell crank
(3) Auto-door lock actuator
(4) Door latch
(5) Striker
(6) Door outer handle
(7) Key cylinder Tightening torque: N·m (kgf-m, ft-lb)
T1: 6.4 (0.65, 4.7)
T2: 7.4 (0.75, 5.4)
T3: 14 (1.4, 10.1)
SL-2
GENERAL DESCRIPTION
Security and Locks

2. REAR GATE LOCK S909001A0502
S5M0445A
(1) Key cylinder
(2) Rear gate latch
(3) Striker
(4) Rear gate outer handle
(5) Rear gate actuator Tightening torque: N·m (kgf-m, ft-lb)
T1: 7.4 (0.75, 5.4)
T2: 25 (2.5, 18.1)
SL-3
GENERAL DESCRIPTION Security and Locks

3. HOOD LOCK AND REMOTE OPENERS S909001A0503
S5M0446A
(1) Hood lock ASSY
(2) Lever ASSY
(3) Cable
(4) Pull handle ASSY Tightening torque: N·m (kgf-m, ft-lb)
T1: 6.4 (0.65, 4.7)
T2: 32 (3.3, 23.9)
SL-4
GENERAL DESCRIPTION
Security and Locks

4. IMMOBILIZER SYSTEM S909001A0509
S6M0413A
(1) Antenna
(2) Immobilizer indicator light (LED
bulb)
(3) Immobilizer control module (IMM
ECM): LHD model
(4) Transponder
NOTE:
IMM ECM location for RHD model is symmetrically
opposite.
SL-5
GENERAL DESCRIPTION Security and Locks

5. KEYLESS ENTRY SYSTEM S909001A0505
S5M0447A
(1) Keyless entry control module (2) Rear gate latch switch (3) Door switch
C: CAUTION S909001A03
쐌Before disassembling or reassembling parts,
always disconnect battery ground cable. When
repairing radio, control module, etc. which are
provided with memory functions, record
memory contents before disconnecting battery
ground cable. Otherwise, these contents are
cancelled upon disconnection.
쐌Reassemble parts in reverse order of disas-
sembly procedure unless otherwise indicated.
쐌Adjust parts to specifications contained in
this manual if so designated.
쐌Connect connectors and hoses securely dur-
ing reassembly.
쐌After reassembly, ensure functional parts
operate smoothly.
쐌Airbag system wiring harness is routed near
the electrical parts and switch.
쐌All airbag system wiring harness and con-
nectors are colored yellow. Do not use electri-
cal test equipment on these circuits.
쐌Be careful not to damage Airbag system wir-
ing harness when servicing the ignition key
cylinder.
SL-6
GENERAL DESCRIPTION
Security and Locks

D: PREPARATION TOOL S909001A17
1. SPECIAL TOOLS S909001A1701
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
B5M1120
925580000 PULLER Used for removing trim clip
2. GENERAL TOOLS S909001A1702
TOOL NAME REMARKS
Circuit Tester Used for measuring resistance and voltage.
Drill Used for replacing ignition key lock.
SL-7
GENERAL DESCRIPTION Security and Locks

2. Door Lock Control System S909348
A: SCHEMATIC S909348A21
1. DOOR LOCK CONTROL LHD MODEL S909348A2106
SL73-20
SL-8
DOOR LOCK CONTROL SYSTEM
Security and Locks

2. DOOR LOCK CONTROL RHD MODEL S909348A2107
SR73-20
SL-9
DOOR LOCK CONTROL SYSTEM Security and Locks

B: INSPECTION S909348A10
1. SYMPTOM CHART S909348A1001
Symptom Repair order Reference
The door lock control system does
not operate. 1. Check the fuse. <Ref. to SL-10 CHECK FUSE, INSPECTION, Door Lock Control
System.>
2. Check the power supply and ground circuit for
the keyless entry control module. <Ref. to SL-11 CHECK POWER SUPPLY AND GROUND CIRCUIT,
INSPECTION, Door Lock Control
System.>
3. Check the door lock switch and the circuit. <Ref. to SL-11 CHECK DOOR
LOCK SWITCH AND CIRCUIT,
INSPECTION, Door Lock Control
System.>
4. Check the door lock actuator and the circuit. <Ref. to SL-12 CHECK DOOR
LOCK ACTUATOR AND CIRCUIT,
INSPECTION, Door Lock Control
System.>
The door lock switch (knob) does not
operate. Check the door lock switch and the circuit. <Ref. to SL-11 CHECK DOOR LOCK SWITCH AND CIRCUIT,
INSPECTION, Door Lock Control
System.>
A specific door lock actuator does not
operate. Check the door lock actuator and the circuit. <Ref. to SL-12 CHECK DOOR LOCK ACTUATOR AND CIRCUIT,
INSPECTION, Door Lock Control
System.>
2. CHECK FUSE S909348A1002
No. Step Check Yes No
1 CHECK FUSE.
Remove and visually check fuse No. 2 (in the
main fuse box) and No. 3 (in the fuse and
relay box).
Is the fuse blown (15A)? Replace the fuse
with a new one. Check power sup- ply and ground
circuit. <Ref. to
SL-11 CHECK
POWER SUPPLY
AND GROUND
CIRCUIT,
INSPECTION,
Door Lock Control
System.>
SL-10
DOOR LOCK CONTROL SYSTEM
Security and Locks

3. CHECK POWER SUPPLY AND
GROUND CIRCUIT S909348A1003
No. Step Check Yes No
1 CHECK POWER SUPPLY.
1) Disconnect the door lock timer or keyless
entry control module harness connector.
2) Measure the voltage between the harness
connector terminal and chassis ground.
Connector & terminal
(B176) No. 5 (+) —Chassis ground (–):
(B176) No. 16 (+) —Chassis ground
(–):
Is the voltage more than 10
V? Go to step 2. Check the har- ness for open cir-
cuits or shorts
between the key-
less entry control
module and the
fuse.
2 CHECK GROUND CIRCUIT.
Measure the resistance between the harness
connector terminal and chassis ground.
Connector & terminal
(B176) No. 14 (+) —Chassis ground
(–):
Is the resistance less than
10 Ω?Power supply and ground circuit is
OK.
Repair harness.
4. CHECK DOOR LOCK SWITCH AND
CIRCUIT S909348A1004
No. Step Check Yes No
1 CHECK DOOR LOCK SWITCH CIRCUIT.
1) Disconnect the keyless entry control mod-
ule harness connector.
2) Measure the resistance between the har-
ness connector terminal and chassis ground
when moving the driver’s door lock knob to
UNLOCK.
Connector & terminal
(B176) No. 7 (+) —Chassis ground (–):
Is the resistance less than
10 Ω?Go to step 2. Go to step 3.
2 CHECK DOOR LOCK SWITCH CIRCUIT.
Measure the resistance between the harness
connector terminal and chassis ground when
the driver’s door lock knob is moved to LOCK.
Connector & terminal
(B176) No. 7 (+) —Chassis ground (–):
Is the resistance less than
10 Ω?Go to step 3. The door lock switch is OK.
3 CHECK DOOR LOCK SWITCH.
1) Disconnect the driver’s door lock switch
(actuator) harness connector.
2) Check the continuity between the door lock
switch terminals when moving the door lock
knob to UNLOCK.
Terminal
No. 1 —No. 3:
Does continuity exist? Go to step 4. Replace the door
lock switch
(actuator).
4 CHECK DOOR LOCK SWITCH.
Check the continuity between the door lock
switch terminals when moving the door lock
knob to LOCK.
Terminal
No. 1 —No. 3:
Does continuity exist? Replace the door
lock switch
(actuator).
Check the har-
ness for open cir-
cuits or shorts
between the key-
less entry control
module and the
door lock switch.
SL-11
DOOR LOCK CONTROL SYSTEM Security and Locks

5. CHECK DOOR LOCK ACTUATOR AND
CIRCUIT S909348A1005
No. Step Check Yes No
1 CHECK OUTPUT SIGNAL.
Measure the voltage between the harness
connector terminal and chassis ground when
moving the door lock knob to LOCK.
Connector & terminal
(B176) No. 18 (+) —Chassis ground
(–):
Is the voltage more than 10
V? Go to step 2. Replace the key- less entry control
module.
2 CHECK OUTPUT SIGNAL.
Measure the voltage between the harness
connector terminal and chassis ground when
moving the door lock knob to UNLOCK.
Connector & terminal
(B176) No. 17 (+) —Chassis ground
(–):
Is the voltage more than 10
V? Go to step 3. Replace the key- less entry control
module.
3 CHECK DOOR LOCK ACTUATOR.
Check the door lock actuator.
Front door lock actuator: <Ref. to SL-30 Front
Door Lock Actuator.>
Rear door lock actuator: <Ref. to SL-34 Rear
Door Lock Actuator.>
Rear gate latch lock actuator: <Ref. to SL-37
Rear Gate Latch Lock Actuator.>
Is the door lock actuator
OK? Check the har- ness for open cir-
cuits or shorts
between the key-
less entry control
module and the
door lock actuator.
Replace the door
lock actuator.
SL-12
DOOR LOCK CONTROL SYSTEM
Security and Locks

MEMO:
SL-13
DOOR LOCK CONTROL SYSTEM Security and Locks

3. Keyless Entry System S909345
A: SCHEMATIC S909345A21
1. KEYLESS ENTRY LHD MODEL S909345A2101
SL77-20A
SL-14
KEYLESS ENTRY SYSTEM
Security and Locks

SL77-20B
SL-15
KEYLESS ENTRY SYSTEM Security and Locks

SL77-20C
SL-16
KEYLESS ENTRY SYSTEM
Security and Locks

2. KEYLESS ENTRY RHD MODEL S909345A2102
SR77-20A
SL-17
KEYLESS ENTRY SYSTEM Security and Locks

SR77-20B
SL-18
KEYLESS ENTRY SYSTEM
Security and Locks

SR77-20C
SL-19
KEYLESS ENTRY SYSTEM Security and Locks
