Subaru 2001 Forester User manual

This service manual has been prepared
to provide SUBARU service personnel
with the necessary information and data
for the correct maintenance and repair of
SUBARU vehicles.
This manual includes the procedures for
maintenance, disassembling, reassem-
bling, inspection and adjustment of com-
ponents and diagnostics for guidance of
experienced mechanics.
Please peruse and utilize this manual
fully to ensure complete repair work for
satisfying our customers by keeping their
vehicle in optimum condition. When
replacement of parts during repair work is
needed, be sure to use SUBARU genu-
ine parts.
All information, illustration and specifica-
tions contained in this manual are based
on the latest product information avail-
able at the time of publication approval.
FUJI HEAVY INDUSTRIES LTD.
2001 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX
BODY SECTION
G8050GE6

GLASS/WINDOWS/MIRRORS GW
Page
1. General Description.....................................................................................2
2. Power Window System...............................................................................9
3. Rear Window Defogger System................................................................19
4. Windshield Wiper Deicer System..............................................................23
5. Remote Control Mirror System .................................................................25
6. Front Door Glass.......................................................................................28
7. Front Regulator and Motor Assembly.......................................................31
8. Rear Door Glass .......................................................................................32
9. Rear Regulator and Motor Assembly........................................................34
10. Windshield Glass.......................................................................................35
11. Rear Gate Glass .......................................................................................38
12. Rear Quarter Glass...................................................................................39
13. Roof Window Glass...................................................................................41
14. Inner Rearview Mirror................................................................................42
15. Power Window Control Switch..................................................................43
16. Rear Window Defogger Switch.................................................................46
17. Rear Window Defogger.............................................................................48
18. Outer Mirror Assembly ..............................................................................49
19. Outer Mirror...............................................................................................51
20. Remote Control Mirror Switch...................................................................52
21. Wiper Deicer..............................................................................................54
22. Wiper Deicer Switch..................................................................................55

1. General Description S905001
A: COMPONENT S905001A05
GW-2
GENERAL DESCRIPTION
Glass/Windows/Mirrors

1. FIXED GLASS S905001A0506
S5M0497A
(1) Windshield glass
(2) Dam rubber
(3) Molding
(4) Rearview mirror mount
(5) Side molding
(6) Rear quarter glass
(7) Locate pin
(8) Rear quarter garnish
(9) Rear gate glass
(10) Spring
GW-3
GENERAL DESCRIPTION Glass/Windows/Mirrors

2. FRONT DOOR GLASS S905001A0503
S5M0509A
(1) Door sash (Front)
(2) Glass
(3) Door sash (Rear)
(4) Regulator ASSY
(5) Motor ASSY Tightening torque: N·m (kgf-m, ft-lb)
T1: 7.35 (0.75, 5.4)
T2: 14 (1.4, 10.1)
GW-4
GENERAL DESCRIPTION
Glass/Windows/Mirrors

3. REAR DOOR GLASS S905001A0504
S5M0510A
(1) Door sash (Front)
(2) Glass
(3) Door sash (Rear)
(4) Regulator ASSY
(5) Motor ASSY Tightening torque: N·m (kgf-m, ft-lb)
T1: 7.35 (0.75, 5.4)
T2: 14 (1.4, 10.1)
GW-5
GENERAL DESCRIPTION Glass/Windows/Mirrors

4. MIRRORS S905001A0505
S5M0457A
(1) Outer mirror
(2) Inner rearview mirror (3) Mount (4) Spring (5) Mirror
GW-6
GENERAL DESCRIPTION
Glass/Windows/Mirrors

B: CAUTION S905001A03
쐌When electrical connectors are disconnected,
always conduct an operational check after con-
necting them again.
쐌Avoid impact and damage to the glass.
GW-7
GENERAL DESCRIPTION Glass/Windows/Mirrors

C: PREPARATION TOOL S905001A17
TOOL NAME REMARKS
Circuit Tester Used for checking voltage and continuity.
Piano Wire Used for window glass removal.
Windshield Knife Used for window glass removal.
GW-8
GENERAL DESCRIPTION
Glass/Windows/Mirrors

2. Power Window System S905456
A: SCHEMATIC S905456A21
GW-9
POWER WINDOW SYSTEM Glass/Windows/Mirrors

1. POWER WINDOW LHD MODEL S905456A2101
SL70-20A
GW-10
POWER WINDOW SYSTEM
Glass/Windows/Mirrors

SL70-20B
GW-11
POWER WINDOW SYSTEM Glass/Windows/Mirrors

SL70-20C
GW-12
POWER WINDOW SYSTEM
Glass/Windows/Mirrors

SL70-20D
GW-13
POWER WINDOW SYSTEM Glass/Windows/Mirrors

2. POWER WINDOW RHD MODEL S905456A2102
SR70-20A
GW-14
POWER WINDOW SYSTEM
Glass/Windows/Mirrors

SR70-20B
GW-15
POWER WINDOW SYSTEM Glass/Windows/Mirrors

SR70-20C
GW-16
POWER WINDOW SYSTEM
Glass/Windows/Mirrors

SR70-20D
GW-17
POWER WINDOW SYSTEM Glass/Windows/Mirrors

B: INSPECTION S905456A10
Symptom Repair order
All power windows does not operate.
(1) Fuse (SBF-6) (F/B No. 18)
(2) Power window circuit breaker
(3) Power window relay
(4) Wire harness
One window does not operate.
(1) Power window main switch
(2) Power window sub switch
(3) Power window motor
(4) Wire harness
“Window Lock”does not operate. (1) Power window main switch
GW-18
POWER WINDOW SYSTEM
Glass/Windows/Mirrors

3. Rear Window Defogger System S905455
A: SCHEMATIC S905455A21
GW-19
REAR WINDOW DEFOGGER SYSTEM Glass/Windows/Mirrors
