Subaru 2002 Impreza User manual

2002 Model Year
PDF Service Manual
GENERAL INFORMATION SECTION (Pub.No.G1840GE1)
ENGINE 1 SECTION (Pub.No.G1840GE2)
ENGINE 2 SECTION (Pub.No.G1840GE3)
TRANSMISSION SECTION (Pub.No.G1840GE4)
CHASSIS SECTION (Pub.No.G1840GE5)
BODY SECTION (Pub.No.G1840GE6)
WIRING SYSTEM SECTION (Pub.No.G1840GE7)

FUJI HEAVY INDUSTRIES LTD. G1840GE1
2002 IMPREZA SERVICE MANUAL QUICK REFERENCE INDEX
GENERAL INFORMATION
SECTION
This service manual has been prepared
to provide SUBARU service personnel
with the necessary information and data
for the correct maintenance and repair
of SUBARU vehicles.
This manual includes the procedures
for maintenance, disassembling, reas-
sembling, inspection and adjustment of
components and diagnostics for guid-
ance of experienced mechanics.
Please peruse and utilize this manual
fully to ensure complete repair work for
satisfying our customers by keeping
their vehicle in optimum condition.
When replacement of parts during
repair work is needed, be sure to use
SUBARU genuine parts.
All information, illustration and specifi-
cations contained in this manual are
based on the latest product information
available at the time of publication
approval.
FOREWORD FW
HOW TO USE THIS MANUALS HU
SPECIFICATIONS SPC
PRECAUTION PC
NOTE NT
IDENTIFICATION ID
RECOMMENDED MATERIALS RM
PRE-DELIVERY INSPECTION PI
PERIODIC MAINTENANCE SERVICES PM

FOREWORD
FW
Page
1. Foreword .....................................................................................................2

FW-2
FOREWORD
FOREWORD
1. Foreword
A: FOREWORD
These manuals are used when performing mainte-
nance, repair, or diagnosis of the Subaru IMPRE-
ZA.
Applied model: GG***** and GD***** from 2002MY.
The additional manuals below are also available:
AUTOMATIC TRANSMISSION SERVICE MANU-
AL (Pub. No. G0864ZE)
The manuals contain the latest information at the
time of publication. Changes in specifications,
methods, etc. may be made without notice.

HOW TO USE THIS MANUALS
HU
Page
1. How to Use This Manuals ...........................................................................2

HU-2
HOW TO USE THIS MANUALS
HOW TO USE THIS MANUALS
1. How to Use This Manuals
A: HOW TO USE THIS MANUALS
1. STRUCTURE
Each section consists of SCT that are broken down
into SC that are divided into sections for each com-
ponent. The specification, maintenance and other
information for the components are included, and
diagnosis information has also been added where
necessary.
2. INDEX
The first page has an index with tabs. And at the
end of each section is an alphabetical index.
3. COMPONENTS
For each component, a composition drawing is in-
cluded.
4. SPECIFICATIONS
If necessary, specifications are also included.
5. INSPECTION
Inspections are included to be carried out before
and after maintenance.
6. MAINTENANCE
Maintenance instructions are provided for each
component. When multiple components comprise
one process, refer to the instructions for that pro-
cess for each component.
7. DIAGNOSIS
Tables showing a step-by-step process make it
easy to conduct diagnosis.
8. SI UNITS
Measurements in these manuals are according to
the SI units. Metric and yard/pound measurements
are also included.

SPECIFICATIONS
SPC
Page
1. Impreza SA08731 .......................................................................................2

SPC-2
SPECIFICATIONS
IMPREZA
1. Impreza SA08731
A: DIMENSIONS SA08731G28
★1: 1.6 L
★2: 2.0 L
★3: 2.0 L Turbo
★4: With roof rail
★5: With sun roof
B: ENGINE SA08731G29
Model Sedan Wagon OUTBACK
Overall length mm (in) 4,405 (173.4)
Overall width mm (in) 1,730 (68.1) 1,695 (66.7) 1,710 (67.3)
Overall height (at C.W.) mm (in) 1,440 (56.7) 1,465 (57.7),
1,485 (58.5)★4
1,475 (58.1),
1,495 (58.9)★4
Compartment Length mm (in) 1,890 (74.4) 1,845 (72.6)
Width mm (in) 1,380 (54.3)
Height mm (in) 1,180 (46.5),
1,125 (44.3)★5
1,200 (47.2),
1,150 (45.3)★5
1,200 (47.2),
1,150 (45.3)★5
Wheelbase mm (in) 2,525 (99.4)
Tread Front mm (in) 1,485 (58.5) 1,460 (57.5)★1,
1,465 (57.7) 1,460 (57.5)
Rear mm (in) 1,475 (58.1),
1,480 (58.3)★3
1,450 (57.1)★1,
1,455 (57.3) 1,455 (57.3)
Minimum road
clearance
Without catalytic
converter
mm (in) 150 (5.9),
155 (6.1)★2
150 (5.9),
155 (6.1)★2160 (6.3)
With catalytic
converter
mm (in) 150 (5.9),
155 (6.1)★3
150 (5.9),
155 (6.1)★3160 (6.3)
Model 1.6 L Non-Turbo 2.0 L Turbo 2.0 L 2.5 L
Engine type Horizontally opposed, liquid cooled, 4-cylinder, 4-stroke gasoline engine
Valve arrangement Overhead camshaft type
Bore ×Stroke mm (in) 87.9 ×65.8
(3.461 ×2.591)
92 ×75
(3.62 ×2.95)
99.5 ×79
(3.92 ×3.11)
Displacement cm3(cu in) 1,597 (97.45) 1,994 (121.67) 2,475 (151.03)
Compression ratio 10.0 ±0.2 8.0 ±0.2 10.0 ±0.2
Firing order 1 — 3 — 2 — 4
Idle speed at Park/Neutral
position
rpm 700 ±100 750 ±100 700 ±100
Maximum output kW (HP)/rpm 70 (94)/5,200 92 (123)/5,600 160 (215)/5,600 112 (150)/5,600
Maximum torque N·m (kgf-m, ft-lb)/rpm 143 (14.6, 105.5)
/3,600
184 (18.8, 136.0)
/3,600
292 (29.8, 215.4)
/3,600
223 (22.7, 164.5)
/3,600

SPC-3
SPECIFICATIONS
IMPREZA
C: ELECTRICAL SA08731G30
D: TRANSMISSION SA08731G31
5MT: 5 forward speeds with synchromesh and 1-reverse
4AT: Electronically controlled fully-automatic, 4-forward speeds and 1-reverse
DSPD: Dry Single Plate Diaphragm
TCC: Torque Converter Clutch
★1: Australia spec vehicle
Model 1.6 L Non-turbo 2.0 L Turbo 2.0 L 2.5 L
Ignition timing at
idling speed
BTDC/rpm 5°±10°/700 10°±10°/700 12°±10°/750 MT: 10°±10°/700
AT: 15°±10°/700
Spark
plug
Type and
manufacturer
Without
OBD
NGK: BKR6E
(without catalyst)
CHAMPION:
RC8YC4
(with catalyst)
NGK: BKR6E-11
(with catalyst)
NGK: BKR6E
(without catalyst)
CHAMPION:
RC10YC4
(with catalyst)
NGK: BKR5E-11
(with catalyst)
—
NGK: BKR6E (without
catalyst)
CHAMPION: RC10YC4
(with catalyst)
NGK: BKR5E-11 (with
catalyst)
With OBD CHAMPION:
RC8YC4
CHAMPION:
RC10YC4 NGK: PFR6G
CHAMPION: RC10YC4
Alternate
NGK: BKR6E-11
Alternate
NGK: BKR5E-11
Alternate
NGK: BKR6E-11
Generator 12V — 75A
Battery Type and
capacity
(5HR)
For
Europe
and South
America
12V — 48AH
(55D23L)
MT: 12V — 48AH (55D23L)
AT: 12V — 52AH (65D23L)
MT: 12V — 48AH
(55D23L)
AT: 12V — 52AH
(75D23L)
Others 12V — 27AH (34B19L)
Model 1.6 L Non-turbo 2.0 L Turbo 2.0 L 2.5 L
Transmission type 5MT 4AT 5MT 4AT 5MT 4AT 5MT 4AT
Clutch type DSPD TCC DSPD TCC DSPD TCC DSPD TCC
Gear ratio 1st 3.454 2.785 3.454 2.785 3.454,
3.166★12.785 3.454 2.785
2nd 2.062 1.545 2.062 1.545 1.947,
1.882★11.545 2.062 1.545
3rd 1.448 1.000 1.448 1.000 1.366,
1.296★11.000 1.448 1.000
4th 1.088 0.694 1.088 0.694 0.972 0.694 1.088 0.694
5th 0.825 — 0.825 — 0.738 — 0.871,
0.780★1—
Reverse 3.333 2.272 3.333 2.272 3.333 2.272 3.333 2.272
Dual range 1.447 — 1.447 — — — — —
Reduction
gear (Front
drive)
1st
reduction
Type of gear — Helical — Helical — Helical — Helical
Gear ratio — 1.000 — 1.000 — 1.000 — 1.000
Final
reduction
Type of gear Hypoid Hypoid Hypoid Hypoid Hypoid Hypoid Hypoid Hypoid
Gear ratio 4.111 4.444 3.900 4.111 3.900,
4.444★14.111 3.700,
4.111★14.111
Reduction
gear (Rear
drive)
Transfer
reduction
Type of gear Helical — Helical — Helical — Helical —
Gear ratio 1.000 — 1.000 — 1.100,
1.000★1—1.000—
Final
reduction
Type of gear Hypoid Hypoid Hypoid Hypoid Hypoid Hypoid Hypoid Hypoid
Gear ratio 4.111 4.444 3.900 4.111 3.545,
4.444★14.111 3.700,
4.111★14.111

SPC-4
SPECIFICATIONS
IMPREZA
E: STEERING SA08731G32
F: SUSPENSION SA08731G33
G: BRAKE SA08731G34
H: TIRE SA08731G35
I: CAPACITY SA08731G36
★1: Dual range
Model Turbo 2.0 L, 2.5 L OUTBACK OTHERS
Type Rack and Pinion
Turns, lock to lock RHD: 2.7
LHD: 3.0 3.0 3.2
Minimum turning circle m (ft) Curb to curb 11.0 (36.1) 10.8 (35.4) 10.4 (34.1)
Wall to wall 12.0 (39.4) 11.6 (38.1) 11.2 (36.7)
Front Macpherson strut type, Independent, Coil spring
Rear Dual-link type, Independent, Coil spring
Model 1.6 L Non-turbo 2.0 L, 2.5 L Turbo 2.0 L
Service brake system Dual circuit hydraulic with vacuum suspended power unit
Front Ventilated disc brake
Rear Drum brake Disc brake Ventilated disc brake
Parking brake Mechanical on rear brakes
Rim size 14 ×51/2JJ 15 ×6JJ 16 ×61/2JJ 17 ×7JJ
Tire size 175/70R14 84T
185/70R14 88H
185/65R15 88H
195/60R15 88H
P205/55R16 89V
205/50R16 87V
215/45R17 87W
Type Steel belted radial, Tubeless
Model 1.6 L Non-turbo 2.0 L Turbo 2.0 L 2.5 L
5MT 4AT 5MT 4AT 5MT 4AT 5MT 4AT
Fuel tank 2(US gal, Imp gal) 50 (13.2, 11.0) 50 (13.2, 11.0) 60 (15.9, 13.2)
Engine
oil
Total
capacity
2(US qt, Imp qt) 4.5 (4.8, 4.0) 5.0 (5.3, 4.4) 4.5 (4.8, 4.0)
Engine
oil
amount
for refill
2(US qt, Imp qt)
Approx. 4.5 (4.8, 4.0) Approx.
5.0 (5.3, 4.4)
Approx.
4.5 (4.8, 4.0)
Transmission
gear oil
2(US qt, Imp qt) 3.5
(3.7, 3.1),
4.0
(4.2, 3.5)
★1
—
3.5
(3.7, 3.1),
4.0
(4.2, 3.5)
★1
—3.5
(3.7, 3.1) —3.5
(3.7, 3.1) —
Automatic trans-
mission fluid
2(US qt, Imp qt) —8.4
(8.9, 7.4) —8.4
(8.9, 7.4) —9.3
(9.8, 8.2) —9.3
(9.8, 8.2)
AT differential
gear oil
2(US qt, Imp qt) —1.2
(1.3, 1.1) —1.2
(1.3, 1.1) —1.2
(1.3, 1.1) —1.2
(1.3, 1.1)
AWD rear differ-
ential gear oil
2(US qt, Imp qt) 0.8 (0.8, 0.6)
Power steering
fluid
2(US qt, Imp qt) 0.7 (0.7, 0.6)
Engine coolant 2(US qt, Imp qt) 7.4
(7.8, 6.5)
7.3
(7.7, 6.4)
7.0
(7.4, 6.2)
6.9
(7.3, 6.1)
7.7
(8.1, 6.8)
7.7
(8.1, 6.8)
7.0
(7.4, 6.2)
6.9
(7.3, 6.1)

SPC-5
SPECIFICATIONS
IMPREZA
J: WEIGHT SA08731G37
1. LHD VEHICLE SA08731G3703
Sedan
★1: For option code, refer to ID section. <Ref. to ID-7, Option code.>
Option code★1ECK4K0KS
Model 1.6 L
AWD
TS
5MT 4AT 5MT 4AT 5MT 4AT 5MT 4AT
Curb weight (C.W.) Front kgf (lb) 730
(1,609)
750
(1,654)
750
(1,654)
770
(1,698)
750
(1,654)
770
(1,698)
740
(1,631)
760
(1,676)
Rear kgf (lb) 520
(1,146)
520
(1,146)
520
(1,146)
520
(1,146)
520
(1,146)
520
(1,146)
535
(1,179)
535
(1,179)
Total kgf (lb) 1,250
(2,755)
1,270
(2,800)
1,270
(2,800)
1,290
(2,844)
1,270
(2,800)
1,290
(2,844)
1,275
(2,810)
1,295
(2,855)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
Rear kgf (lb) 890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,700
(3,748)
1,700
(3,748)
1,700
(3,748)
1,700
(3,748)
1,700
(3,748)
1,700
(3,748)
1,700
(3,748)
1,700
(3,748)
Option Air conditioner — — ❍❍❍❍❍❍
Cruisecontrol————————
ABS ————————
Aluminiumwheel————————
Rearspoiler ————————
Spoilerpac ————————
Option code★1ECK4K0KS
Model 2.0 L
AWD
GX
5MT 4AT 5MT 4AT 5MT 4AT 5MT 4AT
Curb weight (C.W.) Front kgf (lb) 745
(1,643)
770
(1,698)
765
(1,687)
790
(1,742)
760
(1,676)
795
(1,753)
750
(1,653)
780
(1,720)
Rear kgf (lb) 535
(1,179)
530
(1,168)
530
(1,168)
525
(1,157)
525
(1,157)
530
(1,168)
550
(1,213)
545
(1,202)
Total kgf (lb) 1,280
(2,822)
1,300
(2,866)
1,295
(2,855)
1,315
(2,899)
1,285
(2,833)
1,325
(2,921)
1,300
(2,866)
1,325
(2,922)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
Rear kgf (lb) 910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,760
(3,880)
1,760
(3,880)
1,760
(3,880)
1,760
(3,880)
1,760
(3,880)
1,760
(3,880)
1,760
(3,880)
1,760
(3,880)
Option Air conditioner — — ❍❍❍❍❍❍
Cruisecontrol————————
ABS — — ❍❍❍❍—❍
Aluminium wheel — — ❍❍——❍❍
Rearspoiler ——————❍❍
Spoilerpac ————————

SPC-6
SPECIFICATIONS
IMPREZA
★1: For option code, refer to ID section. <Ref. to ID-7, Option code.>
Option code★1EC
Model 2.5 L 2.0 L Turbo
AWD
RS WRX
5MT 4AT 5MT
Curb weight (C.W.) Front kgf (lb) 760 (1,676) 785 (1,731) 815 (1,797)
Rear kgf (lb) 535 (1,179) 530 (1,168) 550 (1,213)
Total kgf (lb) 1,295 (2,855) 1,315 (2,899) 1,365 (3,009)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 930 (2,050) 930 (2,050) 970 (2,138)
Rear kgf (lb) 910 (2,006) 910 (2,006) 920 (2,028)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,780 (3,924) 1,780 (3,924) 1,850 (4,079)
Option Air conditioner — — —
Cruise control — — —
ABS ❍❍❍
Aluminiumwheel———
Rearspoiler———
Spoiler pac — — —

SPC-7
SPECIFICATIONS
IMPREZA
Wagon
D/R: Dual range
★1: For option code, refer to ID section. <Ref. to ID-7, Option code.>
Option code★1ECK4K0KS
Model 1.6 L
AWD
TS
D/R 4AT D/R 4AT D/R 4AT D/R 4AT
Curb weight (C.W.) Front kgf (lb) 735
(1,620)
750
(1,653)
755
(1,664)
770
(1,698)
755
(1,664)
770
(1,698)
745
(1,642)
760
(1,676)
Rear kgf (lb) 545
(1,202)
545
(1,202)
545
(1,202)
545
(1,202)
545
(1,202)
545
(1,202)
560
(1,235)
560
(1,235)
Total kgf (lb) 1,280
(2,822)
1,295
(2,855)
1,300
(2,866)
1,315
(2,900)
1,300
(2,866)
1,315
(2,900)
1,305
(2,877)
1,320
(2,911)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 900
(1,984)
900
(1,984)
900
(1,984)
900
(1,984)
900
(1,984)
900
(1,984)
900
(1,984)
900
(1,984)
Rear kgf (lb) 910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,730
(3,814)
1,730
(3,814)
1,730
(3,814)
1,730
(3,814)
1,730
(3,814)
1,730
(3,814)
1,730
(3,814)
1,730
(3,814)
Option Air conditioner — — ❍❍❍❍❍❍
Cruisecontrol————————
ABS ————————
Aluminiumwheel————————
Rearspoiler ————————
Spoilerpac ————————
Option code★1ECK4K0KS
Model 2.0 L
AWD
GX
D/R 4AT D/R 4AT D/R 4AT D/R 4AT
Curb weight (C.W.) Front kgf (lb) 755
(1,664)
770
(1,698)
775
(1,709)
790
(1,742)
780
(1,720)
795
(1,753)
760
(1,676)
780
(1,720)
Rear kgf (lb) 570
(1,257)
565
(1,246)
565
(1,246)
560
(1,235)
570
(1,257)
565
(1,246)
580
(1,279)
575
(1,268)
Total kgf (lb) 1,325
(2,921)
1,335
(2,944)
1,340
(2,955)
1,350
(2,977)
1,350
(2,977)
1,360
(2,999)
1,340
(2,955)
1,355
(2,988)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
Rear kgf (lb) 960
(2,116)
960
(2,116)
960
(2,116)
960
(2,116)
960
(2,116)
960
(2,116)
960
(2,116)
960
(2,116)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,800
(3,969)
1,800
(3,969)
1,800
(3,969)
1,800
(3,969)
1,800
(3,969)
1,800
(3,969)
1,800
(3,969)
1,800
(3,969)
Option Air conditioner — — ❍❍❍❍❍❍
Cruisecontrol————————
ABS — — ❍❍❍❍—❍
Aluminium wheel — — ❍❍——❍❍
Rearspoiler ————————
Spoilerpac ————————

SPC-8
SPECIFICATIONS
IMPREZA
D/R: Dual range
★1: For option code, refer to ID section. <Ref. to ID-7, Option code.>
Option code★1ECK4
Model 2.0 L Turbo
AWD
WRX
5MT
Curb weight (C.W.) Front kgf (lb) 805 (1,775) 825 (1,819)
Rear kgf (lb) 585 (1,290) 585 (1,290)
Total kgf (lb) 1,390 (3,065) 1,410 (3,109)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 970 (2,138) 970 (2,138)
Rear kgf (lb) 950 (2,094) 950 (2,094)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,860 (4,101) 1,860 (4,101)
Option Air conditioner — ❍
Cruise control — —
ABS ❍❍
Aluminium wheel — —
Rear spoiler — —
Spoiler pac — —

SPC-9
SPECIFICATIONS
IMPREZA
2. RHD VEHICLE SA08731G3704
Sedan
★1: For option code, refer to ID section. <Ref. to ID-7, Option code.>
Option code★1EKK1
Model 1.6 L
AWD
TS
5MT 4AT 5MT 4AT
Curb weight (C.W.) Front kgf (lb) 735 (1,621) 755 (1,665) 750 (1,654) 770 (1,698)
Rear kgf (lb) 520 (1,146) 520 (1,146) 520 (1,146) 520 (1,146)
Total kgf (lb) 1,255 (2,767) 1,275 (2,811) 1,270 (2,800) 1,290 (2,844)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 890 (1,962) 890 (1,962) 890 (1,962) 890 (1,962)
Rear kgf (lb) 890 (1,962) 890 (1,962) 890 (1,962) 890 (1,962)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,700 (3,748) 1,700 (3,748) 1,700 (3,748) 1,700 (3,748)
Option Air conditioner — — ❍❍
Cruise control — — — —
ABS ❍❍——
Aluminiumwheel————
Rearspoiler————
Spoiler pac ❍❍——
Option code★1EKK1
Model 2.0 L
AWD
GX
5MT 4AT 5MT 4AT
Curb weight (C.W.) Front kgf (lb) 765 (1,687) 790 (1,742) 770 (1,698) 795 (1,753)
Rear kgf (lb) 535 (1,179) 530 (1,168) 535 (1,179) 530 (1,168)
Total kgf (lb) 1,300 (2,866) 1,320 (2,910) 1,305 (2,877) 1,325 (2,921)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 920 (2,028) 920 (2,028) 920 (2,028) 920 (2,028)
Rear kgf (lb) 910 (2,006) 910 (2,006) 910 (2,006) 910 (2,006)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,760 (3,880) 1,760 (3,880) 1,760 (3,880) 1,760 (3,880)
Option Air conditioner ❍❍❍❍
Cruise control — — — —
ABS ❍❍❍❍
Aluminium wheel ❍❍——
Rear spoiler ❍❍——
Spoiler pac ❍❍——

SPC-10
SPECIFICATIONS
IMPREZA
★1: For option code, refer to ID section. <Ref. to ID-7, Option code.>
Option code★1KAEK
Model 2.0 L 2.5 L 2.0 L Turbo
AWD
GX RS WRX
5MT 4AT 5MT 4AT 5MT 4AT 5MT
Curb weight (C.W.) Front kgf (lb) 750
(1,653)
775
(1,709)
780
(1,720)
805
(1,775)
830
(1,830)
855
(1,885)
830
(1,830)
Rear kgf (lb) 535
(1,179)
530
(1,168)
540
(1,191)
535
(1,179)
560
(1,235)
555
(1,224)
560
(1,235)
Total kgf (lb) 1,285
(2,833)
1,305
(2,877)
1,320
(2,910)
1,340
(2,954)
1,390
(3,065)
1,410
(3,109)
1,390
(3,065)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 920
(2,028)
920
(2,028)
930
(2,050)
930
(2,050)
970
(2,138)
970
(2,138)
970
(2,138)
Rear kgf (lb) 910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
920
(2,028)
920
(2,028)
920
(2,028)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,760
(3,880)
1,760
(3,880)
1,780
(3,924)
1,780
(3,924)
1,850
(4,079)
1,850
(4,079)
1,850
(4,079)
Option Air conditioner — — ❍❍❍❍❍
Cruise control ❍❍❍❍❍❍—
ABS ❍❍❍❍❍❍❍
Aluminiumwheel———————
Rear spoiler — — ❍❍❍❍❍
Spoilerpac ———————

SPC-11
SPECIFICATIONS
IMPREZA
Wagon
D/R: Dual range
★1: For option code, refer to ID section. <Ref. to ID-7, Option code.>
Option code★1EKK1
Model 1.6 L
AWD
TS
D/R4ATD/R4AT
Curb weight (C.W.) Front kgf (lb) 740 (1,631) 755 (1,664) 755 (1,664) 770 (1,698)
Rear kgf (lb) 545 (1,202) 545 (1,202) 545 (1,202) 545 (1,202)
Total kgf (lb) 1,285 (2,833) 1,300 (2,866) 1,300 (2,866) 1,315 (2,900)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 900 (1,984) 900 (1,984) 900 (1,984) 900 (1,984)
Rear kgf (lb) 910 (2,006) 910 (2,006) 910 (2,006) 910 (2,006)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,730 (3,814) 1,730 (3,814) 1,730 (3,814) 1,730 (3,814)
Option Air conditioner — — ❍❍
Cruise control — — — —
ABS ❍❍——
Aluminiumwheel————
Rearspoiler————
Spoiler pac — — — —
Option code★1EKK1
Model 2.0 L
AWD
GX
D/R4ATD/R4AT
Curb weight (C.W.) Front kgf (lb) 775 (1,709) 790 (1,742) 780 (1,720) 795 (1,753)
Rear kgf (lb) 570 (1,257) 565 (1,246) 570 (1,257) 565 (1,246)
Total kgf (lb) 1,345 (2,965) 1,355 (2,987) 1,350 (2,977) 1,360 (2,999)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 920 (2,028) 920 (2,028) 920 (2,028) 920 (2,028)
Rear kgf (lb) 960 (2,116) 960 (2,116) 960 (2,116) 960 (2,116)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,800 (3,968) 1,800 (3,968) 1,800 (3,968) 1,800 (3,968)
Option Air conditioner ❍❍❍❍
Cruise control — — — —
ABS ❍❍❍❍
Aluminium wheel ❍❍——
Rearspoiler————
Spoiler pac ❍❍——

SPC-12
SPECIFICATIONS
IMPREZA
D/R: Dual range
★1: For option code, refer to ID section. <Ref. to ID-7, Option code.>
Option code★1KA
Model 2.0 L
AWD
GX OUT BACK
D/R4ATD/R4AT
Curb weight (C.W.) Front kgf (lb) 760 (1,676) 775 (1,709) 750 (1,653) 765 (1,687)
Rear kgf (lb) 570 (1,257) 565 (1,246) 570 (1,257) 570 (1,257)
Total kgf (lb) 1,330 (2,932) 1,340 (2,954) 1,320 (2,910) 1,335 (2,943)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 920 (2,028) 920 (2,028) 920 (2,028) 920 (2,028)
Rear kgf (lb) 960 (2,116) 960 (2,116) 960 (2,116) 960 (2,116)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,800 (3,968) 1,800 (3,968) 1,800 (3,968) 1,800 (3,968)
Option Air conditioner — — — —
Cruise control ❍❍❍❍
ABS ❍❍❍❍
Aluminiumwheel————
Rearspoiler————
Spoiler pac — — — —
Option code★1EXKA
Model 2.0 L Turbo
AWD
WRX
5MT 5MT 4AT
Curb weight (C.W.) Front kgf (lb) 825 (1,819) 825 (1,819) 850 (1,874)
Rear kgf (lb) 585 (1,290) 585 (1,290) 585 (1,290)
Total kgf (lb) 1,410 (3,109) 1,410 (3,109) 1,435 (3,164)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 970 (2,138) 970 (2,138) 970 (2,138)
Rear kgf (lb) 950 (2,094) 950 (2,094) 950 (2,094)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,860 (4,101) 1,860 (4,101) 1,860 (4,101)
Option Air conditioner ❍❍❍
Cruise control — ❍❍
ABS ❍❍❍
Aluminiumwheel———
Rearspoiler———
Spoiler pac — — —
