Table of Contents
Getting Started
Instrument Panel
Gauges
Personalize
Controls
While Operating
Safety/In Case of Emergency
Additional Information
2 - 3
4 - 5
6 - 7
8 - 13
14 - 23
24 - 25
26 - 27
28 - 29
1608242_14b_XV_Crosstrek_QRG_112613.indd 5 11/26/13 3:03 PM

2
Remote Keyless Entry
Lock/Arm
 •Presstolockalldoors
and rear gate and activate
the security alarm.
 •Ifanyofthedoorsorthe
rear gate are not fully closed,
an electronic chirp will
sound ve times and the
hazard lights will ash ve
times to alert you that the
doors or the rear gate are
not properly closed.
 •Toactivatethevehiclender
function, press three times
(within ve seconds).
If you are within 30 feet of
the vehicle, the horn will
sound one time and the
hazard lights will ash
three times.
Unlock/Disarm
 •Pressoncetounlock
the driver’s door.
 •Presstwice(withinve
seconds) to unlock all doors.
 •Whenthe“Unlock/Disarm”
button is pressed, the dome
and map lights will illuminate
if the dome light switch is in
the middle position.
Opening the
Rear Gate
Press to unlock the rear gate.
An electronic chirp
will sound twice and the
hazard lights will ash twice.
Panic Alarm
 •Pressonceandthe
horn will sound and the
hazard lights will ash.
 •Pressanybuttonon
the remote to deactivate.
Immobilizer
When the security alarm is
activated, the immobilizer
interrupts the starter motor
to prevent an intruder from
starting your vehicle without
a registered key.
1608242_14b_XV_Crosstrek_QRG_112613.indd 2 11/26/13 3:03 PM

3
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety / In Case
of Emergency
Additional
Information
3
Getting
Started
Seating
Seat Controls
1. Forward/Backward
Pull up on the lever below the front
of the driver’s seat to move the seat
forward or backward.
2. Raise/Lower Seat Cushion
To adjust the height of the driver’s
seat, push or pull the seat height
adjustment lever located on the
lower left side front of the seat.
3. Recline Seatback
To adjust the seatback to the desired
position, pull up on the recline lever
located on the lower left rear of the
driver’s seat or lower right rear of the
passenger’sseat.Donotadjustseats
while driving.
Heated Seats
(if equipped)
Switches are located on the center
console between the driver and
passenger seats; choose low
(bottom of switch) for normal
heating or high (top of switch) for
rapid heating. Choose the center
position to turn off the seat heaters.
123
Getting
Started
Folding Down the
Rear Seats
Lower the headrests. Pull up on the
release tab on the seat side that
you want to fold down. To return the
seatback to its original position, raise
the seatback until it locks into place and
make sure that it is securely locked.
1608242_14b_XV_Crosstrek_QRG_112613.indd 3 11/26/13 3:04 PM

4
Instrument Panel
pg. 14 pg. 6-7 pg. 15pg. 14 pg. 23pg. 24 pg. 22
1608242_14b_XV_Crosstrek_QRG_112613.indd 4 11/26/13 3:04 PM

5
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety / In Case
of Emergency
Additional
Information
pg. 16-17 pg. 18-21pg. 25
Clock
Pressthe“+”buttontoadvancethetimeorthe
“–”buttontoreversethetime.Vehicleswitha
navigation system, please refer to the separate
“OperatingInstructionsforNavigationSystem.”
Instrument
Panel
1608242_14b_XV_Crosstrek_QRG_112613.indd 5 11/26/13 3:04 PM

6
Gauges
Trip meter A/B selection
and trip meter reset knob
Tachometer
Fuel gauge, trip meter and odometer
Seatbelt warning
Front passenger
seatbelt warning
SRS airbag system
Security indicator light
Dooropen
Charge warning
Oil pressure warning
Power steering warning
Brake system
Hot coolant temperature /
Cold coolant temperature
High beam indicator light
AT OIL TEMP
(Automatic Transmission)
ABS warning
Low fuel
All-WheelDrive
(Automatic Transmission)
VehicleDynamicsControl
/VehicleDynamics
Control operation
Immediate Attention
Caution
Informational
1608242_14b_XV_Crosstrek_QRG_112613.indd 6 11/26/13 3:04 PM

7
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety / In Case
of Emergency
Additional
Information
Gauges
Speedometer
MPG Gauge
Info Knob
VehicleDynamicsControlOFF
CHECKENGINE/
Malfunction indicator
Tire pressure warning light
Front passenger frontal
airbagON
Front passenger frontal
airbag OFF
Engine oil level warning light
Windshield washer
uid warning
Incline Start Assist
Turn signals
Front fog light indicator
light (if equipped)
Cruise control
indicator light
Cruise control set
indicator light
1608242_14b_XV_Crosstrek_QRG_112613.indd 7 11/26/13 3:04 PM

8
Bluetooth for AM/FM Stereo with
Single Disc CD Player and AM/Stereo
HD Radio® with Disc CD Player
Pairing Your Cell Phone
Press the
phone off hook button
and listen to phone prompts.
Press the
talk button
and name your phone.
These buttons will be used in the instructions and images that follow.
Press the
talk button
and follow the phone prompts.
You may need to set the language before pairing your phone.
phone off
hook button
phone on
hook button
talk button
1608242_14b_XV_Crosstrek_QRG_112613.indd 8 11/26/13 3:04 PM

9
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety / In Case
of Emergency
Additional
Information
Personalize
Press the
talk button
andsay“Conrm.”
Put your phone into Bluetooth pairing mode and pair your phone to the system
using the pass-key provided. When your phone is successfully paired, you will hear
“Thephoneispairedandreadyforuse.”
The pass-key for pairing will be given audibly as well as be displayed on the radio.
1608242_14b_XV_Crosstrek_QRG_112613.indd 9 11/26/13 3:04 PM

10
Bluetooth for AM/FM Stereo HD Radio®
with Single Disc CD Player and
Navigation System
Pairing Your Cell Phone
Press the
audio button
. Touch the up and down arrows at the top or
bottomofthecolumnonthedisplayuntilthe“Info”softkeyappears.
Touchthe“Info”softkey.
Thentouch“Bluetooth.”
audio button
1608242_14b_XV_Crosstrek_QRG_112613.indd 10 11/26/13 3:04 PM

11
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety / In Case
of Emergency
Additional
Information
Personalize
Nowtouch“ConnectPhone.”
A pass-key pairing number will appear on the screen. Put your phone into
Bluetoothpairing,searchordiscoverablemode.Dependingonthephone’s
make, model and software; the phone may connect automatically or the pass-key
number may need to be inputted on the phone. Pair your phone to the system.
When the phone is successfully paired, the screen will show the phone’s
name on the list.
Touch“AddNew.”
1608242_14b_XV_Crosstrek_QRG_112613.indd 11 11/26/13 3:04 PM

12
Personalize
Tilt Steering Column
Push the lever down rmly to adjust the
height and lengthwise position of the column;
rmly push the lever back up to lock the
columninplace.Donotadjustwhiledriving.
Power Exterior Mirrors
Turntheknobtothe“L”sidetoadjustthe
left-handmirrorortothe“R”sidetoadjust
the right-hand mirror. Move the knob in the
direction you want to move the mirror. Then
return the knob to the neutral/center position.
1608242_14b_XV_Crosstrek_QRG_112613.indd 12 11/26/13 3:04 PM

13
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety / In Case
of Emergency
Additional
Information
1
3
4
2
Personalize
Power Moonroof (if equipped)
With the moonroof in the fully closed position,
press the switch 4to tilt the moonroof up.
Press and hold the switch 3to lower the
moonroof. Press the switch 2to fully open
the moonroof. Press the switch 1to close the
moonroof. To stop the moonroof in a midway
position while opening or closing, momentarily
press the switch to side 1or side 2.
1608242_14b_XV_Crosstrek_QRG_112613.indd 13 11/26/13 3:04 PM

14
Controls
While the light switch
is on, rotate the dial
downward to dim
the instrument panel
illumination. Rotate the
dial upward to make the
illumination brighter. When
the dial is fully rotated
upward, the instrument
panel illumination
becomes fully bright.
Light Controls
AUTO (if equipped): The vehicle’s
lights are automatically turned on or off
depending on the level of the outside light.
Turns on headlights,
instrument panel
illumination, parking
lights, tail lights and
license plate lights.
Turns on
fog lights
(if equipped).
Push up for right
turn signal.
Turns on instrument panel
lights, tail lights, parking lights
and license plate lights.
Push down for
left turn signal.
1608242_14b_XV_Crosstrek_QRG_112613.indd 14 11/26/13 3:05 PM

15
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety / In Case
of Emergency
Additional
Information
Controls
Windshield Wipers
To turn on the wipers, press the wiper control lever down one level for
intermittent, two levels for low, or three levels for high speed. Return the
levertothe“OFF”positiontostopthewipers.Forasinglewipe,movethe
lever up. To spray washer uid, pull and hold the lever toward you.
Rear Wiper
To operate the rear wiper, rotate the end of the knob upward to the
intermittent, continuous, or wash position. When the rear wiper is off,
rotate the knob downward to wash and wipe the rear window.
Daytime Running Lights
Daytimerunninglightsarestandardonyourvehicle.Areducedbrightness
high beam will be automatically turned on when the engine has started
andtheparkingbrakeisfullyreleasedorthelightswitchisinthe“OFF”
or“ ”position.Thebrightnessoftheilluminationofthehighbeam
headlights is reduced by the daytime running light system. You must
always switch on your headlights when it’s dark outside by turning the light
switchtothe“ ”position.
OFF
1
2
3
INT.
LOW
HIGH
1608242_14b_XV_Crosstrek_QRG_112613.indd 15 11/26/13 3:05 PM

16
Controls
Manual HVAC System
1. Air Flow Control Dial
The air ow control dial allows you to
choose the direction of air ow. Rotate the
dial for the desired air ow position.
Defrost / Defog
To clear the windshield and front door
windows of fog or frost, rotate the air ow
control dial to the defrost position, set the
temperature control to the red position, and
set the fan speed control to the fastest speed.
1
2
3
45
6
Automatic Climate
Control System (if equipped)
1. Air Flow Control Dial
On the automatic setting, the system
determines the air ow location to
achieve the desired temperature or you
can manually choose the direction of air
ow. Rotate the dial for the desired air
ow position.
Defrost / Defog
To clear the windshield and front door
windows of fog or frost, rotate the air
ow control dial to the defrost position,
set the temperature control to the red
position, and set the fan speed control of
the fastest speed.
1
2
3
45
6
1608242_14b_XV_Crosstrek_QRG_112613.indd 16 11/26/13 3:05 PM
