\7
L,
INSTALLATION AND OPERATION MANUAL
DIRECT VENT
GAS WATER HEATER
MODELS
SWGDEL. SWlODEL. SW12DEL. SWl6DEL
Direct Spark lgnition, Electric Element
FOR INSTALLATION IN RECREATIONAL
VEHICLES AND MOBILE HOUSING
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
. DO NOT TRY TO LIGHTANYAPPLIANCE.
' DO NOT TOUCH ANY ELECTRIC SWITCH: DO NOT USE ANY PHONE tN YOUR
VEH ICLE.
. IMMEDIATELY CALL YOUR GAS SUPPLIER FROM A NEIGHBOR'S PHONE.
FOLLOW THE GAS SUPPLIER'S INSTRUCTIONS.
. IF YOU CANNOT REACH YOUR GAS SUPPLIER, CALL THE FIRE DEPARTMENT.
FREEZE WARNING
DRAIN HEATER IF SUBJECTTO FREEZING TEMPERATURES.
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATIoN, SERVICE
OR MAINTENANCE CAN CAUSE INJURY OR PROPERTY DAMAGE. REFER TO
THIS MANUAL. FOR ASSISTANCE OR ADDITIONAL INFORMATION, CONSULT A
QUALIFIED INSTALLER, SERVICE AGENCY OR THE GAS SUPPLIER.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER COMBUSTIBLE MATERIALS OR
LIQUIDS NEAR OR ADJACENT TO THIS HEATER OR ANY OTHER APPLIANCE. THIS
APPLIANCE SHALL NOT BE INSTALLED IN ANY LOCATION WHERE FLAMMABLE
LIQUIDS OR VAPORSARE LIKELY TO BE PRESENT.
AN ODORANT IS ADDED TO THE GAS USED BY THIS WATER HEATER.
INSTALLER: AFFIX THESE INSTRUCTIONS To oRADJACENT To WATER HEATER.
OWNER: RETAIN THESE INSTRUCTIONS AND WARRANTY FoR FUTURE REFERENCE,
ALL TECHNICALAND WARRANry QUESTIONS SHOULD BE DIRECTED TO THE COMPANY
LISTED ON THE WARRANTY OR RATING PLATE WHICH CAME WITH YOUR WATER HEATER.
@suburban AIRXCEL, INC. - SUBURBAN DIVISION
676 Broadway Street
Dayton,Tennessee 37321
423-775-2131
www.RVGomfort.com
Part Number 204539
06-06-201 3

Do not alter the operation of your water heater nor change the design/
construction of your water heater. Accessories are being marketed for
RV products which we do not recommend. For your safety, only factory
authorized parts are to be used on yourwater heater.
SAFETY WARNINGS
WARNING! lt is imperative that the water heater tank be filled with water
before operating the water heater. Operation of the water heater without
water in the tank may result in damage to the tank andior controls. This
type of damage is not covered by the limited warranty.
WARNING! Hydrogen gas may result if you have not used this heater
fortwo weeks or more. HYDROGEN GAS lS EXTREMELY FLAMMABLE.
To reduce the risk of injury under these conditions, open the hot water
faucet for several minutes at the kitchen sink before you use any electrical
appliance connected to the hot water system. lf hydrogen is present, you
probably will hear an unusual sound such as air escaping through the
pipe as the water begins to flow.
Hydrogen gas may be present even after water has been drained from the
tank. Open faucet at sink and allow system to vent for several minutes
(5-10 minutes).
Do not smoke or have any open flame near the open faucet. Do not
attempt to light pilot or main burner. On DSI models, be sure the switch
is "OFF".
Should overheating occur, or the gas supply fail to shut off, shut off
the manual gas valve to the appliance before shutting off the electrical
supply.
Do not use this appliance if any part has been submerged under water.
lmmediately call a qualified service technician to inspect the appliance
and to replace any part of the control system and any gas control that has
been submerged under water.
CAUTION: Due to the differences in vinyl siding, this appliance should not
be installed on vinyl siding without first consulting with the manufacturer
of the siding or cutting the siding away from the area around the appliance
vent.
CAUTION: ln any installation in which the vent of this appliance can be
covered due to the construction of the RV or some special feature of the
RV such as slide out, pop-up etc., always insure that the appliance cannot
be operated by shutting off all electrical and gas supply to the appliance.
CAUTION: Do not install this appliance so the vent terminates below a slide-
out. This appliance is not to be installed under any overhang. lt must be free
and clear of any type overhang.
This installation must conform with the requirements of the authority having
jurisdiction or in the absence of such requirements with the latest edition of the
National Fuel Gas Code ANSI 2223.1/NFPA 54; and the latest edition of the
American National Standard for Recreational Vehicles-NFPA i192. ln Canada the
installation should conform with the following standards:
A. For installation in Recreational Vehicle
1. Gas - CSA standard CAN/CSA 2240.4.2-08 lnstallation Requirements for
Propane Appliances and Equipment in Recreations Vehicles.
2. Electrical - CSA standard CAN/CSA 2240.6.2-08tC22.2 No. 148-08
Electrical Requirements for Recreational Vehicles.
3. Plumbing - CSA standard CSA 2240.3.2 Plumbing Requirements for
Recreational Vehicles.
B. For installation in Mobile Housing
1. Gas - CSA standard CSA 2240.41 lnstallation Requirements for Gas
Burning Appliances and Equipment in Mobile Homes.
2. Electrical - CSA standard CSA C22.1 Canadian Electrical Code part .l.
3. Plumbing - CSA standard CSA 2240.3.1 Plumbing Requirements for Mobile
V
Homes.
For installation in mobile housing, refer to Figure 13 for Direct
Clearances.
The appliance shall be disconnected from the gas supply piping
any pressure testjng ofthe sysiem in excess of 1/2 PSIG.
The appliance and its gas connections shall be leak tested before placing the
appliance in operation.
All air for combustion must be supplied from outside the structure. Air for
combustion must not be supplied from occupied spaces.
!NSTALLATION INSTRUCTIONS
Minimum clearance from combustible construction on sides, top, floor and rear =
0 inches. Provide room for access to rear of heater for servicing.
Provide an opening flush with floor in outer wall of coach as shown. Wall of
coach should be framed as shown in Figure 1 SWODEL; FigurelA SW1oDEL/
SWl2DEL/SW16DEL. Maintain insrde dimensions listed below. Do not install on
carpet unless the carpet js covered by a metal or wood shield covering the entire
area underneath the water heater. lf you prefer, you may cut away the carpet from
this area.
\l
INSTALLATION USING HINGED DOOR
(See Figure 3 SW6DEL)
Position heater into framed opening as illustrated.
On mesa or yoder type sidewalls, flatten the wall area around the opening.
Caulk around framed opening (trailer skin) as illustrated.
Lay a bead of silicone caulking (or suitable caulking) around the inner edge of
the control housing (top, bottom and sides). See detail "A" in ilustration. This
will seal frame to control housing.
Apply a bead of silicone caulking (or suitable caulking) around back side of
door frame. See detail "A" in illustration: This will seal frame to coach skin.
Fit the door frame into control housing (over the caulking already applied) and
pull frame tight to control housing using the three (3) No. 8-1 5 x 3 1/2" screws
provided.
Push water heater into framed opening until back side of door frame (now
attached to control housing) is against the side of the coach and flrmly attach
with screws around the perimeter of the frame. NOTE: The tvvo (2) holes in
bottom of frame identifled as "A" in Figure 3 are also used to mount door hinge
to the frame.
lnstall chocks, one on each side ofwater heater, as illustrated in Figure 18.
Attach door to frame as illustrated.
Close the door so that the door latch protrudes through the slot in the door.
Turn latch 90 degrees to fasten door.
K. The module board on model SW6DEL, is not secured to the water heater. lt
is to be permanently mounted by the installer.
The module board must be mounted so it is accessible for servjce yet out of
way of children. lt should be located in a place where it cannot be subjected to
moisture, cleaning chemicals, flammable vapors and liquids, etc.
The board and all wiring to the board must be protected in order to prevent
damages and accidental contact with these parts. The module board may be \.,
mounted with two (2) No. 6 x 5/8 screws or other suitable hardware
Vent Termrnal
system during
Periodically inspect the vent for obstructions or presence of soot. Soot is
formed whenever combustion is incomplete. This is your visual warning
that the water heater is operating in an unsafe manner. lf soot is present,
immediately shut the water heater down and contact your dealer or a
qualified service person.
When considering add-on rooms, porch or patio, attention must be given
to the venting of your water heater. For your safety, do not terminate the
vent on your water heater inside add-on rooms, screen porch or onto
patios. Doing so will result in products of combustion being vented into
the rooms or occupied areas.
Never operate the heater if you smell gas. Do not assume that the smell
of gas in your RV is normal. Any time you detect the odor of gas, it is
to be considered life threatening and corrected immediately. Extinguish
any open flames including cigarettes and evacuate all persons from the
vehicle. Shut off gas supply at LP gas bottle. (See the Safety notice on
front cover of this manual.)
NOTE: Always open both the cold and hot water faucets when filling
vehicle water tank to allow air pockets to be forced out of the water
heater, When water flows from the faucets, close both faucets.
WARNING! Do not store or use combustible materials or liquids near
or adjacent to this heater. The appliance shall not be installed in any
location where flammable liquids or vapors are likely to be present.
Be sure the power is "OFF" to the water heater ignition system during
any type of refueling and while vehicle is in motion or being towed.
The thermostat on your water heater is not adjustable. lt is a temperature
sensing limit designed to maintain a water temperature of 13dF (5&).
Water temperatures over 13fi (54C) can cause severe burns instantly or
death from scalds; therefore, be careful when using hot water. Children,
disabled and elderly are at highest risk of being scalded. Always feel
water before bathing or showering.
INSTALLATION REQU IREMENTS
WARNING! lnstallation of this appliance must be made in accordance with
the written instructions provided in this manual. No agent, representative
or employee of Suburban or other person has the authority to change,
modify or waive any provision of the instructions contained in this
manual.
CAUTION: lf possible, do not install the water heater so the vent can be
covered or obstructed when any door on the trailer is opened. lf this is not
possible, then the travel ofthe door must be restricted in orderto provide
a 6" minimum clearance between the water heater vent and any door
whenever the door is opened.
A.
B.
c.
D.
E.
F.
U.
H.
t.
J.
2-

INNER COACH WALL
WATER HEATER AS VIEWED FROM INSIDE R.V.
Figure 1B
DC JUNCTION BOX
FRAMED OPENING
FLOOR
FRAMED
PLACE SCREW OR SUITABLE FASTENER
SPECIAL SCREW
CONTROL
INNER COACH WALL
Figure 1A
IV]OUNTING SCREWS (SPECIAL)
(3) REO',D.
DOOR TATCH
FRAMING
FRAMING
\-
\,
OUTER COACH WALL
( o=',rst4-+1t.'-o-
' B=12314"+118"-O"
FLOORING 1. OUTER COACH WALL
A = 16 3/8"11116"
B = 16 3/8"11/16"
LOORING
CAULKAROUND OPENING
AC JUNCTION BOX
CONIROL
CAULKALL THE WAY AROUND DOOR FRAME TO
SEAL FRANIE WATER TIGHT (USE TWO BEADS
AS SHOWN IN DETAILA)
AS SHOVVN. DOOR FRAIME WHEN INSTALLED
MUST NOT OVERLAP ONTO HEAD OR
FASTENER.
FLUSH MOUNT DOOR FRAIVIE
WTH GASKET
Figure 2
-3-
Figure 1
SECURE CHOCKS, ONE ON EACH SIDE, TIGHTLY AGAINST WATER HEATER JACKET
AND FASTEN TO VEHICLE FLOOR TO PREVENT iilOVEIVIENT. CHOCKS SHOULD BE
APPROXIMATELY 2" X 2" X 6"
DETAILA
#i
\, SW6DEL +

CAULKAROUND OPENING
AC JUNCTION BOX
EXTERIOR
COACH SKIN
IMOUNTING SCREWS (SPECIAL)
(4) REQ'D.
DOOR LATCH
FRAMED OPE
SPECIAL
CONTROL HOUSING
CAULKALL THE WAYAROUND DOOR FRAME TO
SEAL FMME WATER TIGHT (USE TWO BEADS
AS SHOWN IN DETAILA)
FLUSH MOUNT DOOR FRAME
WTH GASKET
CAULKAROUND OPENING
TO SEAL CONTROL HOUSING
TO SKIN. WATER TIGHT
AC JUNCIION BOX
FRAMED OPENING
(SEE FIGURE NO. 1)
COACH SKIN
CONTROL
DC JUNCTION BOX FRAIV]ED OPENING
PLACE SCREW OR SUITABLE FASTENER
AS SHOWN. DOOR FRAME WHEN INSTALLED
MUST NOT OVERLAP ONTO SCREW HEAD
OR FASTENER.
SPECIAL SCREW
CONTROL HOUSING
>'-\t-DooR PIN
+
Figure 2A
DC JUNCTION BOX
MOUNTING SCREWS, FRAME TO COACH WALL
(11) REO'D.
I\4OUNTING SCREW(SPECIAL) J
DOOR FRAME TO CONTROL HOUSING
Figure 3
SILICONE CAULKING INNER EDGE OF
CONTROL HOUSING
\#
\l
SWlODEL
SWl2DEL
SWl6DEL
CONTROL HOUSING
CAULKALLTHE WAYAROUND DOOR FRAME TO
SEAL FRAME TO CQACH WALL. WATER TIGHT
(SEE DETAILA)
DETAILA
SW6DEL (3) REQ'D.
-4-
RADIUS CORNER DOOR V

A.
.B.
v
INSTALLATION USING FLUSH MOUNT
FRAME & DOOR
(See Figure 2 SWGDEL; Figure 2A SW1oDEL, SWl2DEL, SWl6DEL)
Position heater into framed opening as illustrated. Slide unit into opening until
the front of the control housing is flush with the exterior coach skin.
Secure the control housing to the coach wall (framed opening) at the top
and sides of control housing compartment using screws or other suitable
fasteners. Recess the screws or fasteners back far enough from the front
edge of control housing (approximately 1 1/2") in order to clear the flange on
door frame. The door frame, when installed, must not overlap onto screw or
other fastener head. lf due to the wall thickness, it is not possible to secure
the water heater without covering the fastener head with the door frame, it is
important to not over tighten the fastener and distort the control housing. Over
tightening of the fastener may cause water heater leaks between the control
housing and the door frame.
NOTE: Caulk around screw or fastener heads to assure water tight seal.
C. lnstall chocks, one on each side ofwater heater, as illustrated in Figure 18.
D. On mesa or yoder type sidewalls, flatten the wall area around the opening.
E. Caulk around framed opening (trailer skin) as illustrated. .
F. Caulk around door frame using 2 beads of silicone caulking (or suiiable
caulking) - one on flange to seal to control housing and one around back side
of frame to seal to coach skin. (See detail A in illustration.)
G. lnsert door frame into control housing and secure with three (3) No. 8-1 5 x 3
1/2" screws provided.
H. To install door, place the two holes in the bottom of the door over the door
pins on the frame. Close the door so that the latch protrudes through the slot
in the door. Turn latch 90 degrees to fasten door.
I. The moduIe board on mode|S SW6DEL, SWlODEL, SW12DEL, SWl6DEL
is not secured to the water heater. lt is to be permanently mounted by the
installer.
The module board must be mounted so it is accessible for service yet out of way of
children. lt should be located in a place where it cannot be subjected to moisture,
cleaning chemicals, flammable vapors and liquids, etc.
The board and all wiring to the board must be protected in order to prevent
damages and accidental contact with these parts. The module board may be
mounted with two (2) No. 6 x 5/8 screws or other suitable hardware.
MAKING ELEGTRIGAL CONNEGTIONS
12 VOLTS D.C,
Refer to Figure 2 for location of D.C. junction box on SW6DEL.
The electrical connections must be made in accordance with local codes and
regulations. ln the absence of local codes and regulations, refer to the latest
edition of the National Electrical Code NFPA 70.
In Canada, the electrical installation should conform with CSA standard CAN/
CSA 2240.6.2-081C22.2 No. 148-08 Electrical Req uirements for Recreational
Vehicles and CSA C22.1 Canadian Electrical Code Part 1 when installing the
unit in recreational vehicles and mobile homes respectively.
C. Make the 12 Volt D.C. electrical connections following the wiring diagram
illustrated in Figure 4.
lf the power supply is to be from a converter, we recommend that the converter
system be wired in parallel with the battery. This will serve two purposes:
1. Provide a constant voltage supply
2. Filter any A.C. spikes or volt surges
We recommend insulated termlnals be used for all electrical connections.
MAKING ELEGTRICAL GONNECTIONS
120 VOLTS A.C.
A. Refer to Figure 2 for location of A.C. junction box.
B. The electrical connections must be made in accordance with local codes and
regulations. In the absence of local codes and regulations, refer to the latest
edition of the National Eleckical Code NFPA 70.
ln Canada, the electrical installation should conform with CSA standard CAN/
CSA 2240.6.2-OB|C22.2 No. 148-08. Electrical requirements for Recreational
Vehicles and CSA C22.1 Canadian Electrical Code Part 1 when installing the unit
in recreationai vehicles and mobile homes respectively.
C. Check rating plate and wiring diagram (Figure 5) before proceeding. lnstall a
fused safety switch or circuit breaker of adequate capacity between heater
and electrical power source. Attach the black and white wires from the fused
switch or breaker to corresponding colored wires in heater junction box. A
green wire from a well grounded source must be attached to the green ground
screw or nut in the junction box.
CAUTION: Before applying the 120 VAC power to the water heater junction
box, be sure the switch for electric element is in the "OFF" position.
WARNING! Before the switch for the electric element is turned to the
"ON" position, the water heater tank must be filled with water. See
"Safety Warnings".
MAKING WATER CONNECTIONS
A, Water connections are made at the rear of the water heater. See Figure 6.
Connect the hot and cold water lines to the 112" female pipe fitting provided
on rear of tank. These fittings are marked "HOT" and "COLD'. NOTE: Inside
each fitting is a plastic fill tube. lts purpose is to enhance water circulation. DO
NOT REMOVE PLASTIC FILL TUBE.
IMPORTANT: Use a pipe thread compound suitable for potable water or pipe
thread iape on all connections to assure they will not leak.
B. For ease of removal, it is suggested that a pipe union be installed in each
water line.
C. Fill tank with water. Open both hot and cold water faucets to expel air from
tank. \ /hen tank is filled and water flows from faucets, close both faucets and
check all connections for leaks.
CAUTION: lf you use air pressure to check for leaks, the pressure must not
exceed 30 PSI (in accordance with NFPA 1192).
NOTE: After leak testing, drain water from tank.
MAKING GAS GONNECTIONS
A. Connect a 3/8" gas supply line to the 3/8 flare fitting at gas valve located in the
control housing. \r'Vhen making the gas connection, hold the gas fltting on the
valve with a wrench when tightening the flare nut. Failure to hold fitting secure
could result in a gas leak due to fltting being damaged.
NOTE: ltwill be necessary to remove the grommet from the control housing, make
the gas connection at the valve, then reinstall grommet.
WARNING! lt is imperative that grommet and gas line through grommet
be caulked air tight. lf not tightly sealed, moisture and potential harmful
flue products could vent through opening and into living area of trailer.
(See Figure 7.)
B. Turn on gas and check all fittings and connections for leaks, using a soap and
water solution. Correct even the slightest leak immediately.
WARNING! Do not use an open flame to check for leaks!
SAFETY INFORMATION
FOR YOUR SAFETY READ BEFORE OPERATING
WARNING! lf the user of this appliance fails to maintain it in the condition
in which it was shipped from the factory or if the appliance is not
used solely for its intended purpose or if appliance is not maintained
in accordance with the instructions in this manual, then the risk of a
fire and/or the production of carbon monoxide exists which can cause
personal injury, property damage or loss of life.
OPERATING INSTRUGTIONS
-GAS-
WARNING! lf you do not follow these instructions exactly, a fire or
explosion may result causing property damage, personal injury or loss
of life.
WARNING: Before operating water heater, be sure tank is filled with
water. See "Safety Warnings".
This appliance does not have a pilot. lt is equipped with an ignition device
which automatrcally lights the burner. Do not try to light the burner by hand.
BEFORE LIGHTING smell all around the appliance area for gas. Be sure to
smell next to the floor because Some gas is heavier than air and will settle
on the floor.
WHAT TO DO IF YOU SMELL GAS
. Do not try to light any appliance.
. Do not touch any electric switch.
. Do not use any phone in your building.
. lmmediately call your gas supplier from a neighbor's phone. Follow the
gas supplier's instructions.
. lf you cannot reach your gas supplier, call the fire department.
This is an automatic gas valve, no adjustments are necessary. Do not attempt
to repair the gas valve. This may result in a fire or explosion.
Do not use this appliance if any part has been under water. lmmediately call
a qualified service technician to inspeci the appliance and to replace any part
of the control system and any gas control which has been under water.
Before operating water heater, check the location of the vent to make sure
it will not be blocked by the opening of any door on the trailer. lf it can be
blocked, do not operate the water heater with the door open.
A.
B.
\,
A.
B.
c.
D-
\.
-5-
E.

OPERATING INSTRUCTIONS FOR UNlTS
WITH DIRECT SPARK IGNITION GAS VALVE
1. STOPI Read the safety information provided.
2. Turn off all electric power to the appliance.
3. Turn "OFF" gas supply.
4. Wait five minutes for gas to clear the area. lf you smell gas then STOP! Follow
instructions in item B of the safety information. lf you don't smell gas, go to
next step.
5. Turn "ON" gas supply.
6. Turn on electrical power to the appliance.
7. Turn switch marked "GAS" in Figure B to "ON" position. lf the burner does not
light, the system will automatically attempt two more tries for ignition before
lock-out.
NOTE: Each ignition cycle will have a 15 second purge before spark cycle if
system is a three try system.
8. lf lockout occurs before main burner lights, turn switch to "OFF", wait five
seconds and turn switch to "ON' position. This will restart the ignition cycle.
The first start-up of the heater may require several ignition cycles before all
air is purged from the gas lines.
If the burner will not come on, the following items should be checked before calling
a service person.
1. Switch turned oft.
2. Gas supply to heater is empty or turned off.
3. Reset button on ECO is tripped. (see Figure 9)
4. lf burner fails to light, call a Suburban Service Center or a local RV service
agency.
OPERATING INSTRUCTIONS
- Electric Elements -
Electric water heaters are
designed to operate with a
minimum amount of service
problems; however, proper
operation and care is
essential.
By far the most common
trouble with electric water
heaters results from
energizing the water heater
before it is fllled with water
Even brief operation of the
electric element without
water in the tank will burn-out
the electric heating element.
Before the electric element EcoswrcH &r-srAr
will operate, the switchl2ovELEcrRrcELEMENroNLY
Iocated behind the water
heater door in the lower left
corner of the control housing
must be in the "ON' position.
To energize the electric
element, locate the Switch,
Lamp and Plate assembly
(see Figure 8) inside the RV
and turn the switch marked
'ELECTRIC' to the "ON"
position. The water heater
temperature will be regulated
by the thermostat.
lf the unit is not properly derated, lack of sufflcient orygen for combustion
may produce improper burner operation. Pilot outage ffiused by burner lifloff
or sooting from a yellow burner may occur indicatrng the possibility of carbon
monoxide. You may also notice a lack of efficiency in heating the water because
of incomplete combustion of the burner at these higher altitudes.
Consult with the local gas company, your dealer, an RV service agency or
Suburban Manufacturing Company for proper derating of the unit. Change-out of
the burner/orifice (derating) should be done by the dealer or a qualified service
agency.
NOTE: lt is important that once the unit has returned to lower elevation (below
4,500 feet), this high altitude deration and pilot adjustments (if equipped) be
reversed for proper operation of the unit.
TO TURN OFF WATER HEATER
Turn switch to "OFF'positlon.
Turn off electrical power to the appliance.
Turn off gas supply.
lf vehicle is to be stored or heater is going to be turned off whjle subject to
freezing temperature, drain water heater. (See "Draining and Storage
lnstructions.")
MAINTENANCE
WARNING! lf the user of this appliance fails to maintain it in the condition
in which it was shipped from the factory or if the appliance is not
used solely for its intended purpose or if appliance is not maintaindd
in accordance with the instructions in this manual, then the risk of a
fire and/or the production of carbon monoxide exists which can cause
personal injury, property damage or loss of life.
WARNINGT For your safety, all repairs should be performed by your
dealer or a gualified service person.
A. Main Bumer Do not allow the burner to burn with a yellow flame, because
sooting will occur. (See Safety Warnings). lf the burner flame is yellow and
has an enatic pattern, shut unit down and contact a qualified service agency.
Do not continue operating unit with improper burner flame. (See Figure 1 1 for
correct and incorrect burner flame appearance.)
B. Periodically inspect irnit for soot. lf soot is present anywhere on watef heater,
immediately shut unit down and contact your dealer or a qualified service
person. Soot is a sign of incomplete combustion and must be corrected
before operating water heater. Areas to check would include:
1. Check for an obstruction in burner or the flue box.
2. Check the screen in the door to see that no foreign material has
accumulated to prevent flow of combustion and ventilating air.
3. Check to be sure there is no flame present at burner oriflce or burner
wheneyer main gas valve is closed. This can be checked by turning the
OFF/ON switch to the "OFF" position.
C. Frequent checks should be made of the grommet on the gas inlet to assure
tight seal. (See "Making Gas Connections").
D. Periodically check wiring and wire connection to be sure wiring is not
damagedlfrayed and that all terminals and connections are t;ght and in
compliance with codes (See "Making Wre Connections").
DRAINING AND STORAGE INSTRUCTIONS
lf RV is to be stored during winter months, the water heater must be drained to
prevent damage from freezing.
1. Turn off electrical power to water heater eiiher at the switch from the electrical
element or at breaker.
2. Shut off gas supply to water heater.
3. Turn off pressure pump on water system.
4. Open both hot and cold water faucets.
5. Remove anode rod from tank.
5. Follow RV manufacturer's instructions for draining entire water system.
NOTE: Be certain to reflll water heater with water and remove all air from tank and
lines before re-lighting or before turning on electrical power.
1.
2.
3.
4.
\l-
v
THERMOSTAT AND MANUAL RESET
MODELS: SWGDEL, SW10DEL, SW12DEL, SWl6DEL (See Figure 9)
The model water heaters listed above are equipped with a high temperature limit
as a cufoffdevice. Temperature above 180"F will cause manual reset button to
trip shutting down main burner.
To activate burner, the water temperature must be below 11 0'F, push reset button
to re-activate burner. I'IIINTERIZING
lf your water heater plumbing system is equipped with a bypass kit, use it to
THERMOSTAT AND MANUAL RESET close off the water heater, drain the water heater completely and leave the water
MODELS SWGDEL, SW1oDEL, SW12DEL, SW{6DEL (See Figure 10) heater closed ofi (out of the system) in the bypass position BAI!!SUW|y if you are
The model water heaters listed above are equipped with a high temperature limit introducing antifeeze into the plumbing system.Antifreeze can be very corrosive
as a cut-off device. Temperature above 1 8ffi will cause manual reset button to trip to the anode rod creating premature failure and heavy sediment in the tank. lf the
shutting down the electric element. plumbing system is not equipped with a bypass kit, and you intend to winterize by
adding antifreeze to the system, remove the anode rod (storing it for the winter)
To activate element, the water temperature must be below '11 G, push reset button and replace it with a 3/4" drain plug.
to re-activate the electric element. ANODE PROTECTION
HIGH ALTITUDE DERATION The tank in thiswater heater is protected by a magnesium or aluminum anode to
Suburban water heaters are certified by nationally recognized testing laboratories prolong the life of the tank by absorbing the corrosive action of hot water. Under
for operation without modifications at altitudes up to 4,500 feet. Operation normal use, the anode rod will deteriorate and because of this, we recommend
above this elevation may require derating by 4 percent for every 1,000 feet it be replaced yearly. NOTE: Vlbter with high levels of iron and/or sulfate will
above sea level. For example, at 8,000 feet, the water heater should be derated increase the rate of deterioration, therefore, more frequent replacement may be
approximately 32 percent. ^ ;?XltJ.lrjt anode rod is mostly eaten away, replace it with a new one. (See
-b-
ECO SWTCB & TSTAT
GROMMET.ECO RESET BUrcN IS
BEHINDGROMMEI PUSH INON
GROMMEf TO RESETSYSTEM.
Y

\,
b
To prevent a water leak when replacing the anode rod, a pipe thread sealant
approved for potable water (such as Teflon tape) must be applied to the threads
of the anode rod. Proper application of a thread sealant will not interfere with the
anode's tank protection.
Operating the water heater without proper anode protection will decrease tank life
and will void your warranty on the tank. NOTE. Tank is drained by removing anode
rod (See "Drain and Storage'instructions).
To extend anode life, drain waterfrom tank whenever RV is not being used. Avoid
any extended time of non use with water in tank.
Also, refer to section on winterizing.
WARNING! Do not replace the anode rod with any non-Suburban
accessory part, such as an "add-on" electric heating element. ltems such
as these are not approved to be installed in Suburban products. They
could create an unsafe condition and will also void all warranties,
ODOR FROM HOT WATER SYSTEM
Odor from the hot water system is not a service problem and many water supplies
contain sufficient amounts of sulphur to produce an odor. The odor ts similar to
rotten eggs and is often referred to as "sulphur water". lt is not harmful - only
unpleasant to smell. Sulphur water can be caused by a chemical action or by
bacteria. The solution to eliminate is chlorination of the water system. Add about
six (6) ounces of chlorinated common household liquid bleach to each 10 gallons
in the water tank. Then run the chlorinated water throughout the system, opening
each faucet one at a time until you smell the chlorine. Let the RV sit for a few
days and the chlorine should take care of the problem. Then you will need to take
care of the chlorine. Remove the chlorine by flushing the system with fresh water.
This may take several attempts. You may consider adding a filtering system that
removes chlorine and prevents sulphur water. lf the sulphur or rotten egg smell
continues, flush the system once again as described above and replace anode
rod as necessary.
PRESSURE RELIEF VALVE
The temperature and pressure relief valve is designed to open if the temperature
of the water within the heater reaches 21 ffi, or if the water pressure in the heater
reaches 1 50 pounds. Recreational vehicle water systems are closed systems and
during the water heating cycle the pressure build-up in the water system will reach
150 pounds. \Men this pressure is reached, the pressure relief valve will open
and water will drip from the valve. This dripping will continue until the pressure is
reduced to below 150 pounds, and the valve closes. This condition is normal and
does not indicate a defective relief valve.
WARNING! Do not place a valve between the relief valve and the tank. Do
not plug the relief valve under any circumstances.
WATER WEEPING OR DRIPPING FROM
PRESSURE RELIEF VALVE
You may experience water weeping or dripping from your water heater's Pressure
and Temperature (P & T) Relief Valve when your water heater is operating. V\hter
weeping or dripping from the P & T Valve does not always mean the P & T Valve
is defective. As water is heated, it expands. The water system in a recreational
vehicle is a closed system and does not allow for the expansion of heated water.
When the pressure of the water system exceeds the relieving point of the P & T
Valve, the valve will relieve the excess pressure.
Suburban recommends that a check valve not be installed directly at the inlet
to the water heater tank. This will increase weeping of the pressure relief valve.
WARNING! Do not remove or plug the relief valve.
One way to reduce the frequency of this occurrence is to maintain an air pocket
at the top of the water heater tank. This air pocket will form in the tank by design.
However, it will be reduced over time by the everyday use of your water heater
To replenish this air pocket:
1. Turn offwater heater.
2. Turn off cold water supply line.
3. Open a faucet in the RV
4. Pull out on the handle of the Pressure Relief (P & T) Valve and allow
water to flow from the valve until it stops.
5. Release handle on P &TValve - it should snap closed.
6. Close faucet and turn on cold water supply; as the tank fllls, the air pocket
will develop.
Repeat this procedure as often as needed to reduce the frequency ofthe weeping
of the P & T Valve. lf the weeping persists after following this procedure, you may
elect to install an expansion or accumulator tank in the cold water line between
the tank and check valve to relieve the pressure caused by thermal expansion.
Contact your local dealer for assistance.
REMOVING WATER HEATER
'1. Shut off gas supply and disconnect gas supply line from water heater.
2. On all Electric Models, turn off electrical supply then disconnect 120 V.A.C.
supply at junction box mounted on heater.
3. On all DSI Models, disconnect 12 V.D.C. power supply at junction box on
heater.
4. Disconnect all wires at module board.
5. Shut off water supply. Drain water from tank following instructions under
'Draining and Storage'.
6. Disconnect hot and cold water lines from water heater.
7. Remove screws or nails securing control housing to framed opening.
8. Slide heater out. To reinstall, follow instructions in manual under "lnstallation
lnstructions".
PARTS AND SERVICE
Contact a conveniently located recommended Suburban Servlce Center.
Describe to them the nature of your problem, make an appointment, if necessary,
and provide for delivery of your RV with the appliance installed.
To obtain information on locating a local service agency, contact:
AIRXCEL, lnc., Suburban Division
Customer Service Department
676 Broadway Street
Dayton, TN 37321
[phone] Ext. 71 01
www. RVComfort.com
12 V.D.C. ONLY
IF ANY OF THE ORIGINAL WRE AS SUPPLIED WITH THE WATER
HEATER MUST BE REPLACED, IT MUST BE REPLACED WTH 18 GA..
105'C WRE OR EQUIVALENT.
IVlODULE BD
JUNCTION
BOX
( _ FACTORY WIR|NG)
(---- FTELD WIRtNG)
I
I
Ei
DISCONNECT POWER SUPPLY BEFORE SERVICING THERMOSTAT
AND HI-LIMIT I-INDFR ACCFSS COVFR
CAUTION: DO NOT HI-POT (DIELECTRIC HlcH VOLTAGE TEST) THtS
UNITAFTER INSTALLATION. TO DO SO MAY CAUSE COMPONENT
DAMAGE AND VOIDS WARRANry OF WATER HEATER.
"12VDC SIDE OF RELAY 340539
Figure 4
{20 v.A.G. ONLY
DISCONNECT POWER SUPPLY BEFORE REMOVING COVER
SUBURBAN N4ANUFACTURING CONNPANY DAYTON, TENNESSEE
120 VA.C SINGLE PHASE . ,I440 WATT ELEINENT - 60 CYCLE
TOTAL CONNECTED WATTS = 1440 -AMPS = 12
UUqUULUT
BK IBI ACK
W IWHITE
LIMIT
BK
ELECTRIC
ELEMENT
SWITCH K
A GROUNDING SCREW
IF ANY OF THE ORIGINAL WRE AS SUPPLIED WITH THE HEATER MUST
BE REPLACED, IT MUST BE REPLACED WITH 14 GA. 105"C WIRE OR
EOIJIVAI FNT
SI UN DES FILS ELECTIQUES LIVRESAVEC LE CHAUFFE-EAU DOIT
ETRE REMPLACE, UTILISER A CET EFFET UN FIL 14 GA, 1 05" OU
EOUIVALENT. .120VAC SIDE OF RELAY 340540
Figure 5
Y
7-
Figure 6

F
RESET BUTTON
GROIVIMET
(GAS INTET)
T-STAT
v
GAS VALVE
CAULKAND SEAL GROIV]MET (lNCLUDING SLIT
AND TUBING) ALL AROUND AIR TIGHT
Figure 7
120 V.A.C.
HI-LIMIT
Figure 10
SWITCH, LAMP AND PLATE ASSEMBLY
(GAS AND ELECTRTC) i
I
CORRECT INCORRECT
BLUE OR BLUE/ORANGE
WELL DEFINED PATTERN
YELLOW OR YELLOW
ORANGE
ERRATIC PATTERN
Figure 11
ANODE ROD 7s% coRRoDEDANODE ROD
Figure 12
V
RESET BUTTON
12 V.D.C.
HI-LIMIT
Figure I
u)),
LU t) \,
vJ)
\t
!_- (
o
m
RESET
E O WATERHEATER
trAb
F]
tnl
l ll
lLtl
ON
ELECTRIC
m
lll
trl
ON
Figure 8
NEWANODE ROD
T.STAT
-8-
Y,

!
o
z
6
o
Es
=n
E_-t
hiia
60ul
ul;'iXoYU
O<57
OQFF
-U
FJOo
<FtrE
)<
i xE = I
EF.e = "'=:= < -
?qE i E
o ilo il u
.(iE I E
e i? ., 2
= zL
*Eg B N
-U
< +g 2 o
E o> o z
= sH e I
1 94.4 \
- i i9 c 7
3 N dl : b
A N OUJ i Z
s g iE ts i
o < FT - X
F F QF A Y
z z uo Y '
U U E6 X I
r d x.- Y F
-E -E;ii i E
d d Ei 6 *
rtrtTgzY
a a=@ < =
ts ts 4^ d x
- - E= u 9
F i ga >tr X
: ; Oq iE 9
zz).-,^il4
3 6 *9 ;E *
d d *- p- =
o o I! trtr i
o o i- =< d
t\ t1 == >a =
< < q= trz il
2 - '< uu )
= = <L LO O
E
F
U
u
!:
>l
tro
a>
OU
AE
9p
do
JU
od
LE
i!o
H3
ol
:o
lu
6s
AE
IU
<h
=>ru
EI
=F
= 61
o9<
U>
bHE
EXU
uz6
uEk
Ou -J
x28
>)t
<E \
duE
EUH
oo >
I
v
z
v
o
o
u
o
z
P
u
o
z
t
U
o
I
E
U
z
E
o
o
o
F
f
o
P
o
z
d
U
t
o
o
u
F
1
tr
z
U
z
l
o
F
u
o
z
4
d
U
o
D
E
U
I
o
z
o-
#a
do
qd
ze
fy
uO
zu
f;E
rO
OL
ozLz
P=N:
e15=bE
,,,o1ut
air=E o ,
4\*6Y<
OHU< <tr
EEi6 T:;
tr F- > N er
&zoE 6t
UU6O -U
>><i 90
o
et
F
U
U
u
E-ff
>qE
guo
B?-d
<tr:
uo<
>a^
<ai[
g=k
ool
1
t
z
U
z
:
d
H=
oo
FO
a1
2=
<o
do
oo
o
z
*r
i.i
-z
>x
6E
59
Fir
Hr+
o
z
I
o
U
\U
FZ
uI
oa
zt
d)
un
O<
E
F
U
U
E
I
U
I
z
E
I
o
=
da
;fr
or
oo
1u
36
oi
F>
9k
Ec
53
oo
o
6^
trE
oc
Its
I'l Lg
dzH
rPu
uuo
+ O<
E
9
U
I
a
z
oor
IJ]q
Y6<a
YFFC
=ulQ<
3-6*
zIoo
s.a i?
o<oF
d
uio
o.
p6
;o
>I
oo
<d
rI
9<-
<92
trf;q
o>d
E
U
I
o
z
E
U
I
a
z
'v @
z
o
tr
I
)
*
z
@
)
o
z
I
F
J
^J
ua
t-a
lz
>:
fi<
Io
r{
^z
I
)
z
d
U
F
U
d
U
I
i
u
t
v/
a
z
o
-
k
)
)
F
@
z
a
f
,@
a<
UJ
F<
X'o
>z
--<
t>t ?
uz o
F
U
J
Z
.)
o
L
@
tr
Y$o
q{.
o
o
-9-
Figure 13
\b

TWO YEAR LIMITED WARRANTY
SUBURBAN RECREATIONAL VEHICLE WATER HEATER
TWO YEAR LIMITED WARRANry
This Suburban product .is _warranted -to the original purchaser to be free from defects in material and workmanship under normal use and
maintenance fo.r a period of two years f1o1n.datg of purchase whether or not actual use begins on that date. lt is the resp6nsibility of the consumer/
owner to establish the warranty period- Suburban does not use warranty registration cards for its standard warranty. You are iequired to furnish
proof of purchase date through a Bill of Sale or other payment records.
Suburban will.replace any parts that.are found defective within.the first two years and will pay a warranty service allowance directly to the
recommended Suburban Service Center ai rates mutually agreed upon betweeh Suburban and it! recommended service centers. Repldcement
parts will b.e sh-ipR-e{ iOB lle shipping point within the Continental United S.tates, Alaska and Canada to the recommended service center trierforming
such repairs. All freight,-shipping and delivery c_osts shall be the responsibility of the owner. The exchanged part or unit will be warranted for onl!
the unexpired portion_of t-he_9rlgi!glylrr-a!!y.B,=e&tqLqyilqry?rJqlly,rq recommended servic6
center for Suburban. DO NOT PAY THE SERVICE AGENCY FOR WARRANTY REPAIRS; SUCH pAyMENTS WLL NOi BE RETMBURSED.
Suburban reserves the right to examine the alleged defeet in the water heater or component parts, and it is the owner's obligation to return the
water heater and/or component parts to Suburban or its representative. When returning a water heater, it must include all component parts and
the serial number plate. Returned component parts must be individually tagged and identified with the water heater's model number, seriil number
and date of installation.
For warranty service, the ownerluser should contact the nearest recommended Suburban Service Center, advising them of the model and serial
numbers (locate-d on the water heater) and the nature of the defect. Transportation of the RV to and from the Servicetenter and/or travel expenses
of the_Service Center to your lo_qailon is the responsibility of the owner/user. A current listing of recommended service center may be obtained
from Suburban's website: www.RVComfort.com. lf you cannot locate a recommended service center locally, the service agency choden to perform
wa.rranty repairs must contact our Service Department al 423-775-2131 for authorization before making iepairs. Unauth-orizdd repairs m'ade will
not be paid by Suburban.
THREE YEAR LIMITED WARRANTY ON TANK
The inner tank is further warranted to be free from defects in material and workmanship during the third year after the date of original purchase. A
replacement water heater will be provided under the same conditions as stated in the two year warraniy-EXCEPT no labor reimdurseinent will be
provided.
LIMITATION OF WARRANTIES
ALL IMPLIED WARMNTIES (INCLUDING IMPLIED WARRANTIES OF MERCHANTABILIry) ARE HEREBY LIMITED IN DURATION TO THE
PERIOD FOR WHICH EACH LIMITED WARRANTY IS GIVEN. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS SO THE ABOVE LIMITATIONS MAY NOTAPPLY TO YOU. THE EXPRESSED WARRANTIES MADE IN THIS WARMNTY
ARE EXCLUSIVE AND MAY NOT BE ALTERED, ENLARGED, OR CHANGED BY ANY DISTRIBUTOR, DEALER OR OTHER PERSON
WHOMSOEVER.
SUBURBAN WILL NOT BE RESPONSIBLE FOR:
1. Normal maintenance as outlined in the installation, operating and service instructions owner's manual including cleaning of component parts
and cleaning or repLacement of the burner orifice. Any water damage arising, directly or indirectly, from any-defect in the waier heatbr or
component parts or from its use.
2. lnitial checkouts and subsequent checkouts which indicate the water heater is operating properly, or diagnosis without repair.
3. Damage or repairs required as a consequence of faulty or incorrect installation or application not in conformance with Suburban instructions.
4. Failure to start and/or operate due to loose or disconnected wires; water or dirt in controls, fuel lines and gas tanks, improper gas pressure; low
voltage.
5. Cleaning or adjustment of components; electrode, burner tube, pilot and thermocouple.
6. Costs incurred in gaining access to the water heater.
7. Parts or accessories not supplied by Suburban.
8. Freight charges incurred from parts replacements.
9. Damage or repairs needed as a consequence of any misapplication, abuse, unreasonable use, unauthorized alteration, improper service,
improper operation or failure to provide reasonable and necessary maintenance.
10. Suburban products whose serial number has been altered, defaced or removed.
11. Suburban products installed or warranty claims originating outside the Continental U.S.A., Alaska, Hawaii and Canada.
12. Damage as a result of floods, winds, lightning, accidents, corrosive atmosphere or other conditions beyond the control of Suburban.
13. ANYSPECIAL, INDIRECT OR CONSEQUENTIAL PROPERTY ECONOMIC OR COMMERCIAL DAMAGE OFANY NATURE WHATSOEVER.
Some states do not allow the exclusion of incidental or consequential damages, so the above limitation may not apply to you.
NO REPRESENTATIVE, DEALER, RECOMMENDED SERVICE CENTERS OR OTHER PERSON IS AUTHORIZED TO ASSUME FOR
SUBURBAN MANUFACTURING COMPANYANYADDITIONAL, DIFFERENT OR OTHER LIABILITY IN CONNECTION WITH THE SALE OF
THIS SUBURBAN PRODUCT.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
IF YOU HAVE A PRODUCT PROBLEM
FIRST lf your RV has its original water heater and is still under the RV manufacturer's warranty, follow the steps suggested by your dealer or
manufacturer of the RV.
SECOND: Contact a conveniently loc_ated recommended Suburban Service Center. Describe to them the nature of your problem, make an
appointment, if necessary, and provide for delivery of your RV to the selected service center.
THIRD: For the location of the nearest Service Center, refer to the listing provided or contact:
v
v.
AIRXCEL, INC. - SUBURBAN DIVISION
Customer Service Department
676 Broadway Street
Dayton, Tenness ee 37 321
[phone] , Ext. 71 01
www. RVComfort.com
FOR FUTURE REFERENCE, YOU SHOULD RECORD THE FOLLOWING INFORMATION:
MODEL NUMBER:
SERIAL NUMBER:
STOCK NUMBER:
DATE OF PURCHASE:
/ffi{r,r,r.* @suburban
Y,
