Subzero WD30 User manual

General Information 2
Installation Information 5
Controls & Operation 8
Component Access & Removal 17
Troubleshooting Guide 24
Technical Data 30
Wiring Diagrams 31
subzero.com 800.222.7820
WD30
Service Manual

Page 2
WARMING DRAWER
General Information
1-2
TECHNICAL ASSISTANCE
If you should have any questions regarding a Wolf
appliance and/or this manual, please contact:
Wolf Appliance Company, LLC.
ATTN: Service Department
P.O. Box 44988
Madison, WI 53744-4988
Customer Service & Parts / Warranty Claims
Phone #: (800) 332 - 9513
Technical Assistance
Phone #: (800) 919 - 8324
Customer Service & Technical Assistance
Facsimile #: (608) 441 - 5887
Parts / Warranty Claims
Facsimile #: (608) 441 - 5886
Service Department e-mail Address
[email protected]
Office Hours:
7:00 AM to 7:00 PM Central Time
Monday through Friday
This manual is designed to be used by Authorized Service Personnel only. Wolf Appliance Company, LLC.
assumes no responsibility for any repairs made to Wolf appliances by anyone other than Authorized
Service Technicians.
IMPORTANT SAFETY INFORMATION
Below are the Product Safety Labels used in this manu-
al. The "Signal Words" used are WARNING and
CAUTION.
Please note that these safety labels are placed in areas
where awareness of personal safety and product safety
should be taken.
INTRODUCTION
This Wolf Warming Drawer Technical Service and Parts Manual, Part #802981, has been compiled with information
provided by Watertown Metal Products, a division of Western Industries, Inc. This manual provides the most recent
technical service information that will enable the service technician to troubleshoot and diagnose malfunctions, per-
form necessary repairs and return a Wolf Warming Drawer to proper operational condition.
The Service Technician should read the complete instructions contained in this Technical Service and Parts Manual
before initiating any repairs on the Wolf Appliance.
INDICATES THAT HAZARDOUS OR UNSAFE PRAC-
TICES COULD RESULT IN SEVERE PERSONAL
INJURY OR DEATH
Indicates that hazardous or unsafe practices could
result in minor personal injury or product and/or
property damage
In addition, please pay attention to the signal word
“NOTE”, which highlights especially important informa-
tion within each section.
The information and images contained in this manual are the copyright property of Wolf Appliance Company, LLC.
Neither this manual nor any information or images contained herein may be copied or used in whole or in part with-
out the express written consent of Wolf Appliance Company, LLC. ©, all rights reserved.
#802981 Rev. A Jan. 2005

Page 3
WARMING DRAWER
General Information
1-4
WARRANTY INFORMATION
This page contains a summary of the 2 & 5 Year Warranty that is supplied with every Wolf product, followed by a
Non Residential Warranty summary, then notes about the warranties.
TWO & FIVE YEAR Warranty Summary
• Two year TOTAL PRODUCT warranty, parts and labor.
• Limited Parts Only Warranty for the 3rd through 5th year on the following parts: heat element, electronic control
system.
NOTE: This warranty only applies to products installed for normal residential use in the United States or Canada.
NON RESIDENTIAL Warranty Summary
• Two year TOTAL PRODUCT warranty, parts and labor.
NOTE: This warranty only applies to products installed in test kitchens, culinary and school kitchens, and other
installations which help promote Wolf Appliance products. Restaurant installations and other similar commercial
applications carry no warranty.
Warranty Notes:
•All warranties begin at the time of the
unit's initial installation.
•All Warranty and Service information
collected by Wolf Appliance Company,
LLC. is arranged and stored under the
unit serial number and/or the customer's
name. It is requested that you have the
model and serial number available
whenever contacting the factory or parts
distributor.
•See Figures 1-1 and 1-2 for serial tag
location and Figures 1-3 and 1-4 for
serial tag layout.
Wolf Appliance Company
FITCHBURG, WI 53719
MODEL NO.
WD30
SERIAL NO.
13000001
KW
.5
V.
120
UL
CUS
LISTED
USE ON 2 WIRE 60HZ AC ONLY
MADE IN USA
R
Figure 1-2. Serial Tag Layout
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Serial Tag Location
(back of drawer frame front plate)
Figure 1-1. Serial Tag Location
#802981 Rev. A Jan. 2005

Page 4
General Information
WARMING DRAWER
1-5
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Control Panel Layout
The diagram at right illustrates
the layout of the Warming
Drawer control panel.
NOTE: The control panel is
hidden when the drawer is
closed. When the drawer is
opened, the control panel can
be found at the right side of the
front plate.
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Wire Rack for
Stacking Food
Optional Drawer Fronts
Hidden Electronic Control
(when drawer is closed)
with Preset and Variable
Temperature Settings and
Programmable Automatic
Shut-off
Galvanized Exterior
Stainless Steel Interior
Removable Stainless
Steel Drawer Box
450-Watt Heating
Element (Not Shown)
Ball Bearing Drawer Glides
MODEL FEATURES
LED Temperature
Display
ON/OFF Key with
LED Indicator
Variable Temperature
Keys
Pre-set Temperature
Keys with LED
Indicators
#802981 Rev. A Jan. 2005

Page 5
WARMING DRAWER
Installation Information
2-2
INSTALLATION INFORMATION
The Wolf warming drawer is designed to be set into a built-in wall or cabinet installation.
This section of the manual covers some of the installation issues that a service technician may need to know when
servicing a Wolf warming drawer. If additional installation information is needed after reviewing this section of the
manual, please refer to the installation guide or contact the Wolf Appliance Customer Service Department.
Electrical Requirements
• 110 to 120 Volts AC, 60Hz, 15 ampere fused electrical supply
• Separate electrical circuit serving only this appliance
• A properly grounded 3-prong receptacle
Line
Voltage
(Power)
Neutral
Ground
•TOAVOID SHOCK HAZARD, THE INSTALLATION SITE MUST BE EQUIPPED WITH APROPERLY
GROUNDED 3-SLOT RECEPTACLE TO MATCH THE 3-PRONG (GROUNDED) POWER SUPPLYCORD
PROVIDED ON THE APPLIANCE.
•TOAVOID SHOCK HAZARD, NEVER REMOVE THE GROUND PRONG FROM THE PLUG OF THE POWER
SUPPLYCORD.
Ground Prong
Figure 2-1. Electrical Receptacle & Power Cord
#802981 Rev. A Jan. 2005

Page 6
FRAME
29-7/8"
(759)
23"
(584)
23-1/2" min
(597)
*28-1/2"
(724)
FRAME
10-1/4"
(260)
*9-1/4"
(235)
E
NOTE:
If installed below Wolf
wall oven, rail between
appliances must be
minimum 1-1/4” (318 mm) thick.
E
4"
(102)
5"
(127)
* Dimension may vary by ± 1/8" ( ± 3 mm)
= Electrical outlet location
NOTE:
1.5" X 1.5"
(3.8 mm X 3.8 mm)
A
nti-Tip Block
must be installed.
NOTE: Dimensions in parentheses are in millimeters.
Installation Information
WARMING DRAWER
2-3
Installation Specifications (Non-Integrated)
The warming drawer is designed to be set into a built-in installation alone, or in combination with a Wolf wall oven,
microwave oven or cooktop. The illustration below shows the rough-in dimensions for a “non-Integrated” warming
drawer installation below a wall oven (See Figure 2-2).
NOTE: Prior to serial #13005870, the warming drawer could not be installed in an Integrated application. See
rough-in dimensions for an Integrated application on following page.
For complete installation instructions, refer to the installation guide.
Figure 2-2. Non-Integrated Warming Drawer Installation below a Wall Oven
#802981 Rev. A Jan. 2005

Page 7
WARMING DRAWER
Installation Information
2-4
E
FRAME
29-7/8"
(759)
25-1/2" min
(648)
*29-15/16"
(760)
FRAME
10-1/4"
(260)
*10-3/8"
(264)
* Dimension may vary by ± 1/8" ( ± 3 mm)
4"
(102)
E
= Electrical outlet location
NOTE:
1.5" X 1.5"
(3.8 mm X 3.8 mm)
A
nti-Tip Block
must be installed.
5"
(127)
NOTE:
If installed below Wolf
wall oven, rail between
appliances must be
minimum 2-3/8” (60 mm) thick.
NOTE: Dimensions in parentheses are in millimeters.
23"
(584)
BACK OF
UNIT TO
BACK OF
FRAME
Minimum required cabinet width = 33" (838 mm)
Minimum required cabinet depth = 26" (660 mm)
NOTE:
Installation Specifications (Integrated) - Starting with Serial #13005870
The illustration below shows the rough-in dimensions for an “Integrated” warming drawer installation below a wall
oven (See Figure 2-3).
NOTE: Prior to serial #13005870, the warming drawer could not be installed in an Integrated application.
For complete installation instructions, refer to the installation guide.
Figure 2-3. Integrated Warming Drawer Installation below a Wall Oven
#802981 Rev. A Jan. 2005

Page 8
WARMING DRAWER
Electronic Control Information
3-2
Figure 3-1A. Electronic Control System Diagram (Prior to Serial #13005870)
CONTROL
BOARD
HEAT ELEMENT
POWER CORD
POWER
BOARD
TOUCH CONTROL
PANEL/BOARD
THERMAL
PROTECTOR
GREEN (GROUND)
GROUND TO BE MOUNTED
TO STUD ON CAVITY
WHITE
WHITE
4-PIN RIBBON
BLACK BLACK
8-PIN RIBBON
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
MOV MOV
FILTER
WHITE
BLACK
BLACK
P1 P2 P3 P4
MODEL WD30 ELECTRONIC CONTROL SYSTEM
Input operations for the electronic control system are performed at the control panel, which is located at the right
side of the faceplate. The control board, which is located directly behind the control panel, monitors the input opera-
tions performed at the control panel, supplies a signal to the power board to switch the heat element on and off and,
through the use of LED’s (Light Emitting Diodes), displays unit ON/OFF condition, temperature setting, actual tem-
perature and temperature range at various locations on the control panel. The power board provides 5 volts DC
power to the control board, a low volt temperature sense signal to the control board and 115 volts AC power to the
heat element. The auto-reset thermal protector provides overheat protection in the event of control failure. (See
Figures 3-1A & 3-1B) Input operations performed at the control panel are described on the following pages.
Figure 3-1B. Electronic Control System Diagram (Starting with Serial #13005870)
CONTROL
BOARD
HEAT ELEMENT
POWERCORD
POWER
BOARD
TOUCH CONTROL
PANEL/BOARD
THERMAL
PROTECTOR
GREEN (GROUND)
GROUNDTOBE MOUNTED
TOSTUD ON CAVITY
WHITE
WHITE
4-PIN RIBBON
8-PIN RIBBON
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
WHITE
BLACK
P1 P2 P3 P4
WHITE
BLACK
BLACK BLACK
#802981 Rev. A Jan. 2005

Page 9
Electronic Control Information
WARMING DRAWER
3-3
CONTROL PANEL LAYOUT
The diagram at right shows the layout of the control
panel, behind which is the control board. The LED
readout, ON/OFF indicator light and temperature range
indicator lights are part of the control board. (See
Figure 3-2)
NOTE: The control panel is hidden when the drawer is
closed. When the drawer is opened, the control panel
can be found at the right side of the front plate.
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Temp. Range
Indicators
ON/OFF
Indicator
LED Temp
Readout
ON/OFF Key
Variable
Temp
Adjustment
Keys
Preset Temp
Keys
BASIC ELECTRONIC CONTROL INPUT OPERATIONS
The following illustrations show the basic input operations performed and/or observed at the control panel. Power-
up mode, switching the unit ON and OFF, selecting preset temperature settings and adjusting temperature setting
with the adjustment keys will be explained.
WHEN IN OFF MODE, 115 VOLTS AC IS STILL
PRESENT AT POWER BOARD.
Figure 3-2. Control Panel Layout
Figure 3-3. Power-up Mode
Power-up Mode
When 115V AC is initially applied to the unit, all LED
segments of each digit on the temperature display illu-
minate individually, then the Power ON/OFF indicator
LED and temperature range indicator LED’s (from top to
bottom) will illuminate individually. This is followed by
all LED’s illuminate simultaneously for approximately
five seconds (See Figure 3-3). At the end of diagnostic
mode, the unit displays the software revision level
(number 100 at this writing), then enters OFF mode.
NOTE: This LED illumination sequence also occurs if
power to the unit is interrupted for more than four sec-
onds and/or diagnostic mode (which is covered later in
this manual) is initiated.
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
All LED seg-
ments of
each digit on
temp. display
illuminate
individually,
then ON/OFF
and tempera-
ture range
indicator
LED’s illumi-
nate individu-
ally, then all
LED’s illumi-
nate simulta-
neously for
approximate-
ly five sec-
onds.
#802981 Rev. A Jan. 2005

Page 10
WARMING DRAWER
Electronic Control Information
3-4
Unit ON/OFF
As mentioned earlier, the unit enters OFF mode after
power-up mode. By pressing and releasing the Power
ON/OFF key, ON mode is initiated and power is allowed
past the electronic control system to the heater circuit
and the LED’s. When ON mode is initiated, the unit
defaults to the preset low temperature setting (set at the
factory to 150°F) which will appear in the readout win-
dow and the low temperature range indicator will illumi-
nate. (See Figure 3-4)
When the temperature in the cavity is climbing up to
temperature setting, the heater will be energized con-
stantly until the cavity reaches 10°F below temperature
setting, then the heater will “duty cycle” on and off until
the temperature is 1°F above temperature setting; the
heater is then de-energized. When the temperature
falls 1°F below temperature setting, the heater again
duty cycles.
To switch the unit to OFF mode, press the Power
ON/OFF key while the unit is ON.
NOTE: Whenever the heat element is energized, the
far right decimal point will illuminate.
NOTE: After the last key stroke is performed in ON
mode, the electronic control begins the automatic shut-
off countdown. The automatic shut-off time interval is
set at the factory for four hours, but can be adjusted for
zero to four hours in one hour increments. This will be
covered later in the manual.
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
LOW
Indicator
Illuminates
ON/OFF
Indicator
Illuminates
Preset LOW
Temperature
Setting
Appears
Figure 3-4. Switching Unit ON
Selecting Preset Temperature Settings
After the unit has been switched to ON mode, there are
four preset temperature settings to choose from:
• HIGH (190°F)
• MEDIUM (170°F)
• LOW (150°F)
• PROOF (100°F)
By pressing the appropriate key, the preset temperature
setting will be initiated and that temperature setting will
appear in the temperature readout window. The MEDI-
UM preset temperature key was used in this example.
(See Figure 3-5)
NOTE: Preheat time (the time it takes to reach temper-
ature setting) is as follows:
• HIGH - 20 Minutes
• MEDIUM - 15 Minutes
• LOW - 8 Minutes
• PROOF - 0 Minutes
NOTE: When the temperature setting is changed by
pressing the preset keys, the new temperature setting
will be displayed for three seconds, then actual temper-
atures will be displayed until the new temperature set-
ting is achieved.
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Temp Range
Indicator
Illuminates
ON/OFF
Indicator is
Illuminated
Selected
Preset
Temperature
Setting
Appears
Figure 3-5. Selecting Preset Temperature Settings
Decimal
Point
Illuminates
when Heat
Element is
Energized
#802981 Rev. A Jan. 2005

Page 11
Electronic Control Information
WARMING DRAWER
3-5
Selecting Variable Temperature Settings
After the unit has been switched to ON mode, the tem-
perature setting can be increased and/or decreased by
pressing the arrow keys. Pressing the “up” arrow key
will increase the setting. Pressing the “down” arrow key
will decrease the setting. If either the “up” or “down”
arrow key are pressed and released, the temperature
setting will change accordingly by one degree. If either
key is pressed and held, the temperature setting will
change accordingly by approximately thirteen degrees
per second. (See Figure 3-6)
NOTE: There is a temperature range associated with
each temperature range indicator. Once the tempera-
ture setting exceeds the high or low end of the tempera-
ture range, the range indicator light will switch to the
next range accordingly. The temperature ranges are:
• HIGH (180°F - 200°F)
• MEDIUM (160° - 179°F)
• LOW (120°F - 159°F, Recommended: 145°F - 159°F)
• PROOF (70°F - 119°F, Recommended: 70°F - 100°F)
NOTE: When the temperature setting is changed by
pressing the up and down arrow keys, the new temper-
ature setting will be displayed for three seconds, then
actual temperatures will be displayed until the new tem-
perature setting is achieved.
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Temp Range
Indicator is
Illuminated
ON/OFF
Indicator is
Illuminated
Selected
Variable
Temperature
Setting
Appears
Figure 3-6. Selecting Variable Temperature Settings
Up and Down
Arrows can
be pressed
and held to
change temp
setting by
13°F per sec-
ond or can
be pressed in
multiple key
strokes.
#802981 Rev. A Jan. 2005

Page 12
WARMING DRAWER
Electronic Control Information
3-6
UNIQUE ELECTRONIC CONTROL INPUT OPERATIONS
Following are articles and illustrations which explain the unique input operations performed at the control panel.
Preset Value Adjust Mode, Automatic Shut-off Adjust Mode, Sabbath Mode, Initialization Mode and Diagnostic Mode
are explained.
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
While in OFF
mode, press
and hold
PROOF key,
then press
ON/OFF key.
Figure 3-7.
Initiate Value
Adjust Mode
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Press arrow
keys until
desired value
is displayed.
Figure 3-8.
Adjust to
Desired Value
Preset Value Adjust Mode
The preset temperature values for HIGH,
MEDIUM, LOW and PROOF can be adjust-
ed to any value within the total range of
70°F - 200°F.
To initiate preset value adjust mode, the
unit must first be in OFF mode. With the
unit OFF, press and hold the PROOF key,
then press the ON/OFF key, then release
both keys (See Figure 3-7). The unit is
now in preset adjust mode.
To adjust the preset values while in preset
adjust mode, press the “up” or “down”
arrow keys until the desired temperature is
displayed in the readout window (See
Figure 3-8). Then, press the preset key
which corresponds to the illuminated tem-
perature range indicator (See Figure 3-9).
NOTE: This will vary depending on the
temperature range that the new value falls
into.
After all temperature value adjustments
have been performed, press the ON/OFF
key to exit preset value adjust mode and to
save the new preset values to memory
(See Figure 3-10).
NOTES:
•If only one preset key is pressed during
preset value adjust mode, the other
three preset values will be retained.
•Preset temperature values are saved in
non-volatile memory, so if power is inter-
rupted the latest values entered will be
retained.
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Press preset
key which
corresponds
to illuminated
range indica-
tor.
Figure 3-9.
Press Approrriate
Preset Key
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Press
ON/OFF key
to save new
value and
exit preset
value adjust.
Figure 3-10.
Press ON/OFF
Key to Exit
#802981 Rev. A Jan. 2005

Page 13
Electronic Control Information
WARMING DRAWER
3-7
Automatic Shut-off Adjust Mode
The electronic control is programmed at the
factory to automatically switch the unit OFF
four hours after the last key stroke is per-
formed in the ON mode. This automatic
shut-off time interval can be adjusted for
zero to four hours in one hour increments.
To initiate automatic shut-off adjust mode,
the unit must first be in OFF mode. With
the unit OFF, press and hold the “down”
arrow key, then press the ON/OFF key,
then release both keys (See Figure 3-11).
The last programmed automatic shut-off
time interval along with the letters “hr” will
appear in the readout window, indicating
the unit is in automatic shut-off adjust mode
(See Figure 3-12).
To adjust time interval while in automatic
shut-off adjust mode, press either the the
“up” or “down” arrow keys until the desired
interval is displayed in the readout window
(See Figure 3-13). Then, press the
ON/OFF key to exit automatic shut-off
adjust mode and save the new setting to
memory (See Figure 3-14).
NOTE: The automatic shut-off time interval
is saved in non-volatile memory, so if power
is interrupted the latest interval entered will
be retained.
NOTE: If “0 hr” is selected and saved, the
unit will not switch off automatically (see
Sabbath Mode on next page).
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
While in OFF
mode, press
and hold
“down” arrow
key, then
press
ON/OFF key.
Figure 3-11.
Initiate Auto Shut-
off Adjust Mode
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Last pro-
grammed
auto shut-off
with letters
“hr” appears.
Figure 3-12.
Auto Shut-off Adjust
Mode Indicated
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Press arrow
keys until
desired shut-
off time inter-
val is dis-
played.
Figure 3-13.
Press Arrow
Keys
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Press
ON/OFF key
to save new
setting and
exit auto
shut-off
adjust mode.
Figure 3-14.
Press ON/OFF
Key to Exit
#802981 Rev. A Jan. 2005

Page 14
WARMING DRAWER
Electronic Control Information
3-8
Sabbath Mode
For the observance of certain religious
days, a Sabbath mode was incorporated
into the electronic control system. When in
Sabbath mode, the automatic shut-off is
disabled, allowing the unit to run continu-
ously.
Initiating Sabbath mode is accomplished
through automatic shut-off adjust mode.
The unit must first be in OFF mode. With
the unit OFF, press and hold the “down”
arrow key, then press the ON/OFF key,
then release both keys (See Figure 3-15).
The last programmed automatic shut-off
time interval along with the letters “hr” will
appear in the readout window (See Figure
3-16). Now, press the the “down” arrow
keys until “0 hr” is displayed in the readout
window (See Figure 3-17). Then, press the
ON/OFF key to exit automatic shut-off
adjust mode and save the new setting to
memory (See Figure 3-18).
The unit is now in Sabbath mode, so it will
run continuously until the ON/OFF key is
pressed.
NOTE: If the automatic shut-off time inter-
val is set to zero it will be saved in non-
volatile memory, so if power is interrupted
Sabbath mode will be retained.
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
While in OFF
mode, press
and hold
“down” arrow
key, then
press
ON/OFF key.
Figure 3-15.
Initiate
Sabbath Mode
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Last pro-
grammed
auto shut-off
time interval
with letters
“hr” appears.
Figure 3-16.
Auto Shut-off Adjust
Mode Indicated
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Press “down”
arrow key
until “0 HR” is
displayed.
Figure 3-17.
Press “Down”
Arrow Key until
“0hr” Appears
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Press
ON/OFF key
to save sab-
bath mode
setting and
exit auto
shut-off
adjust mode.
Figure 3-18.
Press ON/OFF
Key to Exit
When Sabbath mode is initiated, the
Automatic Shut-off feature is inopera-
tive, requiring the unit to be switched
OFF manually with the ON/OFF key.
#802981 Rev. A Jan. 2005

Page 15
Electronic Control Information
WARMING DRAWER
3-9
Initialization Mode
If adjustments to pre-set temperature val-
ues or automatic shut-off time intervals are
undesirable, the electronic control can be
set back to all factory default settings
through the initialization mode.
To initiate initialization mode, the unit must
first be in OFF mode. With the unit OFF,
press and hold the “up” and “down” arrow
keys, then press the ON/OFF key, then
release all three keys (See Figure 3-19).
The letters “ini” will appear in the readout
window, indicating the unit is in initialization
mode (See Figure 3-20). Now, press the
ON/OFF key to exit initialization mode and
restore the default settings to memory (See
Figure 3-21).
NOTE: The default settings will now be
saved in non-volatile memory, so if power is
interrupted the default settings will be
retained.
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
While in OFF
mode, press
and hold “up”
& “down”
arrow keys,
then press
ON/OFF key.
Figure 3-19.
Initiate
Initialization Mode
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
“ini” appears
in window
indicating ini-
tialization
mode initiat-
ed.
Figure 3-20.
Initialization Mode
Indicated
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Press
ON/OFF key
to reset
default set-
tings and exit
initialization
mode.
Figure 3-21.
Press ON/OFF
Key to Exit
#802981 Rev. A Jan. 2005

Page 16
WARMING DRAWER
Electronic Control Information
3-10
Diagnostic Mode
Diagnostic mode allows the service techni-
cian to verify proper function of the LED’s
and related circuits. In fact, diagnostic
mode performs the same functions as
power-up mode without having to access
the power cord or circuit breaker.
To initiate diagnostic mode, the unit must
first be in OFF mode. With the unit OFF,
press and hold the “up” arrow key, then
press the ON/OFF key, then release both
keys (See Figure 3-22).
After performing the key strokes listed
above, all LED segments of each digit on
the temperature display illuminate individu-
ally, then the ON/OFF indicator LED and
temperature range indicator LED’s (from
top to bottom) will illuminate individually.
This is followed by all LED’s illuminate
simultaneously for approximately five sec-
onds (See Figure 3-23). At the end of diag-
nostic mode, the unit displays the software
revision level (number 100 at this writing),
then enters OFF mode (See Figure 3-24).
NOTE: If the LED’s do not illuminate in the
sequence described above, refer to the
Troubleshooting Guide in this manual.
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
While in OFF
mode, press
and hold “up”
arrow key,
then press
ON/OFF key.
Figure 3-22.
Initiate Diagnostic
Mode
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
All LED seg-
ments of
each digit on
temp. display
illuminate
individually,
then ON/OFF
and tempera-
ture range
indicator
LED’s illumi-
nate individu-
ally, then all
LED’s illumi-
nate simulta-
neously for
approximate-
ly five sec-
onds.
Figure 3-23.
Diagnostic Mode
Indicated
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
At end of
diagnostic
mode, elec-
tronic control
displays soft-
ware rev.
level then
enters OFF
mode.
Figure 3-24.
Control Switches
to OFF Mode at
End of Diagnostic
Mode
#802981 Rev. A Jan. 2005

Page 17
WARMING DRAWER
Component Access & Removal
4-2
COMPONENT ACCESS AND REMOVAL
This section explains how to adjust, access and remove components in a model WD30 Warming Drawer.
An attempt has been made to arrange these procedures in such a way as to simulate which components would
need to be removed first in order to gain access to other components. When following a component removal proce-
dure, it may be necessary to reference another component removal procedure listed earlier in this section.
NOTE: Before continuing, please take note of the WARNINGS and CAUTIONS below.
-IF IT IS NECESSARYTO REMOVE AWARMING DRAWER FROM ITS INSTALLATION, REMEMBER THAT
THE UNIT IS HEAVY AND COULD TIP AND/OR FALL WHEN PULLED FORWARD BEYOND THE ANTI-TIP
COMPONENTS, RESULTING IN SERIOUS INJURYOR DEATH. PULLING AUNIT FROM ITS INSTALLA-
TION SHOULD ONLYBE PERFORMED BY AN AUTHORIZED SERVICE TECHNICIAN OR INSTALLER.
-TO AVOID ELECTRIC SHOCK, POWER TO THE UNIT MUST BE DISCONNECTED WHENEVER ACCESS-
ING AND/OR REMOVING COMPONENTS POWERED BY ELECTRICITY OR COMPONENTS NEAR OTHER
ELECTRICAL COMPONENTS. IF THE UNIT IS PLUGGED IN, BUT HAS NOT BEEN SWITCHED ON BY
PRESSING THE UNIT ON/OFF KEY, 115 VOLTS AC IS STILL PRESENT AT THE POWER BOARD.
-IF REMOVING THE DRAWER, REMEMBER IT IS HEAVY. IF IT WERE TO FALL IT COULD CAUSE SERI-
OUS PERSONAL INJURY.
-Metal edges may be sharp. Use caution when servicing the unit to avoid personal injury.
-The heating element can get very hot. To avoid personal injury use caution when servicing the unit,
making sure the heater has cooled before working on or around it.
-If accessing components under the shell, the insulation must be properly reinstalled and positioned.
Failure to do so may lead to damage to the surrounding cabinetry.
-Low voltage is used for most electronic control components. To avoid damaging the appliance, do NOT
apply 115V AC to electronic control components.
#802981 Rev. A Jan. 2005

Page 18
Component Access & Removal
WARMING DRAWER
4-3
Wire Rack
The wire rack sits in the stainless steel drawer box.
To remove the rack, open the drawer fully and lift the
rack out of the box. (See Figure 4-1)
Stainless Steel Drawer Box
The side and back flanges at the top of the stainless
steel drawer box rest on top of the drawer frame.
Begin removing the drawer box by opening the drawer
fully. Then, at the center of the right and left side
flanges, lift the drawer box up out of the drawer frame.
(See Figure 4-1)
Vent Slide Components
The back tabs and pegs of the slide knob fit into a slot
and holes in the vent slide.
Threaded studs are welded to the face of the drawer
frame. The vent slide is placed on the face of the draw-
er frame with the studs passing through slots in the
slide. A shoulder washer is placed over each stud to
take up the difference in size between the stud and the
slot. A lock washer and nut are placed on each stud
and the nuts are snugged down.
To remove the vent slide components, the drawer panel
will need to be removed first. With the panel removed,
the slide knob can be removed by depressing the tabs
at the rear and pushing the knob out of the slot in the
vent slide. (See Figure 4-2)
To remove the vent slide, extract the nuts, lock washers
and shoulder washers from the threaded studs and pull
the vent slide from the face of the drawer frame. (See
Figure 4-2)
Drawer Frame
The drawer frame is attached to the drawer glide
assemblies. Three tabs on each side of the frame (one
at the front, middle and back) lock into slots in the inner
rail of each glide assembly.
To remove the drawer frame, begin by opening the
drawer fully. At the center of either side, insert a
straight blade screwdriver down between the frame and
the glide rail far enough to disengage the middle locking
tab (See Figure 4-3), then lift the front of the frame up
to disengage the front tab. Repeat these steps for the
other side. Now, pull the frame forward while holding
the rails away from the frame to disengage the rear tab
from the rail.
POWER
ON/OFF
ADJUST
PRESET
HIGH
MEDIUM
LOW
PROOF
Figure 4-1. Wire Rack & Drawer Box Removal
Wire Rack
Drawer Box
Drawer Frame
Figure 4-2. Vent Slide Components
Vent Slide
Vent Knob
Drawer Frame
Washer
Nut
Shoulder Washer
Figure 4-3. Drawer Frame Removal
Front Tab Middle
Locking
Tab
(Rear Tab Not Shown)
#802981 Rev. A Jan. 2005

Page 19
WARMING DRAWER
Component Access & Removal
4-4
Drawer Glide Assembly
The drawer glide assemblies are attached to the side
walls of the warming drawer cavity by two tabs on the
back side of each glide, one at the rear pointing back
and one toward the front pointing down. The rear tab is
inserted back into a slot in the cavity side wall and the
front tab is inserted down into another slot in the side
wall. With the glide rails fully extended, a hex-head
mounting screw is inserted through a clearance hole of
the outer glide rail and into the mounting hole in the
glide frame. Once the mounting hole is aligned with the
hole in the side wall, the screw is tightened, holding the
drawer glide assembly in place.
To remove a drawer glide assembly, the drawer box
and drawer frame must first be removed. Then, fully
extend the glide rails. Locate the mounting screw
inside the clearance hole of the outer glide rail. With a
thin walled 1/4” nut-driver or socket, extract the mount-
ing screw (See Figure 4-4). Lift the front of the glide
assembly up and toward the middle of the appliance to
disengage the front tab from the slot in the side wall,
then pull the drawer glide assembly forward to disen-
gage the rear tab.
Wire Box Cover
The wire box cover is attached to the right side of the
warming drawer, toward the front, with screws.
To access the wire box cover, the appliance will first
need to be removed from its installation. Then, extract
the screws that secure the cover to the side of the
appliance and pull the cover off. (See Figure 4-5)
Heat Element
The electrical terminals of the heat element pass
through holes in the right side wall of the warming
drawer cavity. Wire leads are connected to the heat
element terminals behind the right side wall. The
bracket which holds the ends of the heat element is
secured to the right side wall with two screws. Two J-
clips hook over the top of the element and are secured
to the floor of the warming drawer cavity with screws.
To access the heat element, the drawer box and drawer
frame must first be removed; the appliance must then
be extracted from its installation and the wire box cover
must be removed. Then, extract the J-clip mounting
screws from the floor of the cavity and remove the J-
clips (See Figure 4-6). Unplug the electrical leads from
the terminals. Extract the element bracket mounting
screws from the right side wall. Pull the heat element
to the left so that the electrical terminals are in the cavi-
ty and lift the heat element out of the cavity.
Figure 4-6. Heat Element Removal
Screws &
J-Clips
Heat Element
Figure 4-4. Drawer Glide Removal
Mounting Screw
Outer Glide Rail
Figure 4-5. Wire Box Cover Removal
Wire Box cover
#802981 Rev. A Jan. 2005

Page 20
Component Access & Removal
WARMING DRAWER
4-5
Power Cord
The wire leads of the power cord pass through a hole in
the control panel cover. The wire grommet on the
power cord holds the cord in place in the control panel
cover. The power and neutral wires of the power cord
are attached to the power board, with the ground wire
attached to the grounding stud on the cavity.
To access the power cord, the appliance will first need
to be extracted from its installation and the wire box
cover will need to be removed. Then, gently pull the
insulation away from the appliance and unplug the
power and neutral wires from the power board.
Disconnect the ground wire from the grounding stud
and pull the wires through the hole in the control panel
cover. (See Figure 4-7)
NOTE: Prior to Serial #13005870, the MOV’s and filter
are part of the power cord assembly, and they must be
used with the power cord to avoid stray voltage issues.
Starting with Serial #13005870, the MOV’s and filter
were moved to the power board.
Control Panel Cover
The control panel cover is attached to the right side of
the warming drawer, toward the rear, with screws.
To access the control panel cover, the appliance will
first need to be removed from its installation. Then,
extract the screws that secure the cover to the side of
the appliance and pull the cover off. (See Figure 4-8)
Power Board
The power board is attached to the right side of the
drawer cavity with threaded studs and nuts. Spacers
on each threaded stud keep the power board from con-
tacting the cavity.
To access the power board, the appliance will first need
to be extracted from its installation and the wire box
cover will need to be removed. Then, unplug all wire
connections from the power board. Extract the nuts
from the threaded studs and pull the power board away
from the side of the cavity. (See Figure 4-9)
Figure 4-7. Power Cord Removal
Figure 4-8. Control Panel Cover Removal
Power Cord
Control Panel Cover
(Insulation not Shown)
Figure 4-9. Power Board Removal
Nut
Power Board
(Insulation not Shown)
#802981 Rev. A Jan. 2005
