Sugar JW-MRD-6001 User manual

Quick Start Guide
Wireless Gigabit Mobile Hotspot
Model:JW-MRD-6001
尺寸：110*90mm
工艺：105g双铜纸，过哑油，四色印刷

Gigabit Ethernet
Appearance
Power/Function button
Screen Display
USB Type-C
USB Type-A
LED
Micro-SIM slot
Micro SD slot
Reset
1 . Screen Display
2 . USB Type-A to charge other devices
3 . USB Type-C for data communication and power charging of the
device（JW-MRD-6001）
4 . Gigabit Ethernet
5 . Status LED for WiFi connectivity
6 . Micro-SIM slot
7 . Reset button：4-sec long-press for factory reset
8 . Micro SD slot (128GB in maximum)
9 . Power/Function button
Power button：3-sec long-press to turn on/off the device；
Function button：When the device is on, tap Function button
twice quickly for menu selection
尺寸：110*90mm
工艺：105g双铜纸，过哑油，四色印刷

Micro SD slot to expand the storage of device
Install SIM card to Micro-SIM slot as shown
Open the lid from here
Install the SIM card
WiFi :Lynx _2. 4G_ c14 3
60GHz:Disabled
psd:ee9d3f57
Double click to Setup
·Ensure your SIM card is properly inserted
·Long-press power button for 3-sec to turn on the device
·Check WLAN name (SSID) and password on display screen
·The WLAN name (SSID) and password able to be changed through
web UI and remote application of the device
Power/Function button
Connecting to the Internet
尺寸：110*90mm
工艺：105g双铜纸，过哑油，四色印刷

Type-C
WAN
·Share 4G LTE connection through WiFi with multiple mobile devices
or through USB Type-C (note: enable USB sharing through web UI
and remote application of the device)
WAN
·Connect cat.5e Ethernet cable to the gigabit Ethernet connector of the
device. Then, the device will offload data traffic to LAN to minimize the
usage of cellular network
WAN
WiFi Offoading
尺寸：110*90mm
工艺：105g双铜纸，过哑油，四色印刷

Type-C
USB
Type -A
·Able to charge other devices through USB Type-A
Type-C
·Via the power adapter and USB cable in the package of device
Charge Other Portable Devices
Charge your JW-MRD-6001
·Connect Web UI through the link: http://192.168.43.1
·Account name: admin
·Password: 23235656
Router settings
RF Exposure Information (SAR)
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram
of tissue. Device types JW-MRD-6001 (FCC ID: 2ARPAJW-MRD-
6001) has also been tested against this SAR limit
The highest SAR value reported under this standard during
product certification for use when properly worn on the body is
0.898W/Kg. Simultaneous RF exposure is 1.544W/Kg
This device was tested for typical body‐worn operations with the
back of the handset kept 10mm from the body.
FCC statements:This device complies with part 15 of the FCC
rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference.
(2) this device must accept any interference received, including
interference that may cause undesired operation.
·
·
·
尺寸：110*90mm
工艺：105g双铜纸，过哑油，四色印刷

·Keep the device away from water, fire, humidity or hot environments
·Do not attempt to disassemble or modify the device
·Do not use damaged power adapter or USB cables to charge the
device
·Do not use any chargers other than those recommended
·Do not use the device where/when wireless devices are not allowed
·Please follow the above instructions when operating the device. We
cannot guarantee that no accidents or damage will take place due
to improper use of the device. Please use with card and operate at
your own risk
Important safety information
Manufacturer：Shenzhen Jaguar Wave Technology Co., Ltd.
：Unit1002,2-ABuildingTungTaiCenter,No.6259,Bao-AnnBlvd.ADD
Bao-AnnDist.,ShenzhenCity
： [e-mail]
For more information, please visit our website: http://www.jaguarwave.com
NOTE: The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications or changes to
this equipment. Such modifications or changes could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.‐
Increase the separation between the equipment and receiver.‐
Connect the equipment into an outlet on a circuit different from ‐
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for ‐
help.
*
*
