Summit Appliance accucold ACR1718 Series User manual

PHARMACY REFRIGERATOR
RÉFRIGÉRATEUR PHARMACEUTIQUE
Models/Modèles: ACR1718 series
Instruction Manual
Mode d'emploi
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
AVANT UTILISATION, VEUILLEZ S'IL VOUS PLAÎT LIRE ET SUIVRE TOUTES LES RÈGLES DE SÉCURITÉ
ET LES INSTRUCTIONS DE FONCTIONNEMENT.
FELIX STORCH, INC.
An ISO 9001:2008 registered company
Summit Appliance Division
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
Write Serial No. (on back of unit) here:
Ecrire N ° de série (à l'arrière de l'appareil) ici:
_________________________________
ACCUCOLD® is a division of Summit Appliance
ACCUCOLD® est une division de Summit Appliance.

2
TABLE OF CONTENTS
Appliance Safety .........................................................................
3
Important Safeguards ................................................................
3 - 4
Special Cautions .........................................................................
5
Location of Parts ........................................................................
6
Handling & Transport .................................................................
6
Unit Review & Inspection ...........................................................
7
Installation Instructions .............................................................
7 - 9
Location ..................................................................................
7
Installing Shelves ....................................................................
8
Electrical System ....................................................................
8 - 9
Operation …………………………................................................
9 - 10
Compressor ………………………………………………………
9
Temperature Control ..............................................................
10
Alarm Settings .......................................................................
10
Energy-Saving Mode …………………………………………….
Lighting …..............................................................................
10
User Maintenance .......................................................................
11 - 12
Cabinet Cleaning ....................................................................
11
Condenser Cleaning ...............................................................
11
Care of the Alarm/Thermometer
11
Cleaning the Compressor/Fan Compartment .........................
12
Defrosting ...............................................................................
12
Security Lock ..........................................................................
12
Energy-Saving Tips ................................................................
12
Troubleshooting .........................................................................
14
Limited Warranty ........................................................................
15
French version of this manual ……………………………………
15 - 28

3
APPLIANCE SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read
and obey all safety messages.
This is the Safety Alert Symbol. The symbol alerts you to potential hazards that
can kill or injure you and others. All safety messages will follow the Safety
Alert Symbol and either the words "DANGER" or "WARNING".
Danger means that failure to heed this safety
statement may result in severe personal injury or
death.
Warning means that failure to heed this safety
statement may result in extensive product
damage, serious personal injury, or death.
All safety messages will alert you about the potential hazard, tell you how to reduce the chance of injury,
and let you know what can happen if the instructions are not followed.
IMPORTANT SAFEGUARDS
Before the appliance is used, it must be properly positioned and installed as
described in this manual, so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the appliance, follow basic precautions,
including the following:
Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and do
not use an extension cord.
Replace all panels before operating.
It is recommended that a separate circuit serving only your appliance be provided. Use receptacles
that cannot be turned off by a switch or pull chain.
Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or explosion.
And do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance. The fumes can create a fire hazard or explosion.
Before proceeding with cleaning and maintenance operations, make sure the power line of the unit is
disconnected.
Do not connect or disconnect the electric plug when your hands are wet.

4
Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result in
electrical shock or death.
Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in
this manual. All other servicing should be referred to a qualified technician.
FOLLOW WARNING CALLOUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL
 Use two or more people to move and install appliance. Failure to do so can result in back or other injury.
To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed.
Choose a well-ventilated area with temperatures above 60°F (16°C) and below 80.6°F (27°C). This
unit must be installed in an area protected from the elements, such as wind, rain, water spray or drips.
The appliance should not be located next to ovens, grills or other sources of high heat.
The appliance must be installed with all electrical, water and drain connections in accordance with
state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in
accordance with the National Electrical Code and local codes and ordinances, is required.
Do not place chemical substances (solvents, reagents) or food in this refrigerator. This equipment is
intended for the storage and display of vaccines, pharmaceuticals and other specimens requiring
refrigeration at precise temperatures.
Do not kink or pinch the power supply cord of the appliance.
The size of the fuse (or circuit breaker) should be 15 amperes.
It is important that the appliance be leveled in order to work properly. You may need to make several
adjustments to level it.
All installations must be in accordance with local plumbing code requirements.
Make certain that the pipes are not pinched, kinked or damaged during installation.
Check for leaks after connection.
Never allow children to operate, play with or crawl inside the appliance.
Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may damage
or discolor the interior.
Use this appliance only for its intended purpose as described in this Instruction Manual.
Keep fingers out of the “pinch point” areas. Clearances between the door and cabinet are necessarily
small. Be careful closing doors when children are in the area.
Risk of child entrapment!
Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances are
still dangerous, even if they will “just sit in the garage a few days”.
Before discarding your old refrigerator:
Take off the doors
Leave the shelves in place so that children may not easily climb inside.
- SAVE THESE INSTRUCTIONS -

5
SPECIAL CAUTIONS
DO NOT step on the front louver panel of your unit or use it as a step.
ONLY use polarized plugs to plug in your unit.
DO NOT CUT OR REMOVE the ground connection on the electrical cable.
CHECK that the electrical system is grounded BEFORE plugging in refrigerator for the first time.
The polyurethane in your unit contains cyclopentane gas as a foaming agent. When repairing, DO
NOT use other types of polyurethane or mix the existing polyurethane with other types. SUMMIT is
not responsible for changes in the refrigerator if repairs are made by the user or unauthorized
technicians. Contact an authorized distributor for repair information.
DO NOT place hands or other objects in the front louvers, rear grating or the fan guard while in
operation. This can cause personal injury and/or damage the unit.
BEFORE removing the front louver panel for maintenance and cleaning, DISCONNECT the unit’s
power supply to avoid accidents which may be caused by the oscillation of the blade of the fan motor.
KEEP HANDS AWAY from door pivot when door is open.
Before loading refrigerator, CHECK that shelves are fixed and have the number of supports indicated
for your model in the Instruction Manual.
CHECK that the front louver panel and rear grating are in place before plugging in unit.
DO NOT place chemical substances (solvents, reagents) or food in this refrigerator. This equipment
is intended for the storage and display of vaccines, pharmaceuticals and other specimens requiring
refrigeration at precise temperatures.
This equipment is intended to be located in a PHARMACY. The floor under the unit must be kept
clean.
DO NOT balance or tip unit at more than a 45° angle without the supervision of authorized personnel.
Severe injury can occur.
DO NOT try to repair unit by yourself. Always consult your authorized distributor for service.
BEFORE reporting a problem with your ACCUCOLD® refrigerator, check the plug and fuses or circuit
breaker. If this is not the cause of the problem, call your distributor immediately so a technician can
be sent.
The unit’s cooling capacity will decrease if:
–It is open for long periods,
–Excessive amounts of product are stored in it.
THIS WILL OVERLOAD UNIT AND INCREASE MALFUNCTION RISK.

6
LOCATION OF PARTS
HANDLING & TRANSPORT
DO NOT MOVE UNIT WITH PRODUCT INSIDE as loose product can break, spill, damage the appliance,
etc.
Adjustable shelves
Glass door
with stainless steel frame
Lighted header
Ventilation louvers
Leveling legs
Interior lighting
(around door)
Alarm/thermostat
Light switch
Handle *
Internal fan
Fig. 1
DO NOT TIP UNIT AT MORE THAN A 45°
ANGLE. DO NOT EXPOSE TO SUNLIGHT
OR STORE AT TEMPERATURES
HIGHER THAN 131°F (55°C).
WHEN HANDLING STATIC CONDENSER
MODELS SUCH AS THIS, MAKE SURE
THAT DOOR PIVOT IS LOCATED AS
SHOWN IN FIGURE ABOVE.
Static condenser
(on back of unit)
Compressor and fan
(behind louvers)
Stainless steel interior
Model descriptions:
ACR1718LH –left-hand door opening
ACR1718RH –right-hand door opening
Lock *
* Handle and position of lock are
subject to change.

7
UNIT REVIEW & INSPECTION
This refrigerator was completely inspected before leaving the factory. Check for signs of damage when
the unit is received. If there is any damage, contact your authorized distributor or manufacturer
immediately. Check that the following accessories are included with your refrigerator:
6 plastic (polycarbonate) shelves (packed in plastic wrap inside unit cabinet)
24 shelf clips (packed separately in a plastic bag inside the cabinet)
INSTALLATION INSTRUCTIONS
This model is designed for interior use at a maximum operation temperature of 80.6°F (27°C) and 55%
humidity. It is meant to be free-standing and not built into an enclosure.
Do not place the unit near heat sources such as stoves, grills, radiators, etc. and do not place in areas
where direct sunlight may reach the unit.
LOCATION
It is recommended that the rear portion and both sides of your refrigerator be at least 8 inches and 6
inches from the wall respectively, to allow air flow to the compressor and improve heat transfer.
Place your refrigerator on a level surface.
Minimum Distances
Once the unit is installed, check that it is level. If necessary, use the two front legs to adjust the height of
the unit.
CAUTION: This appliance is designed for storing and cooling pharma-
ceuticals, vaccines and other medical specimens. Do not use it to store
perishable food or chemical substances like solvents and reagents.
CAUTION: After unpacking you MUST allow this appliance to stand upright for at least 2
hours to allow the lubricant and refrigerant to drain back into the compressor and
stabilize. Failure to do so may adversely affect performance and the lifetime of this unit.

8
INSTALLING SHELVES
Your refrigerator contains 6 polycarbonate plastic shelves and 24 shelf clips.
To install shelves, first place the shelf clips in the slots in the pilasters in the cabinet interior. Use the
numbers on the pilasters as a guide in placing the clips at the same distance from the cabinet floor, with
the tab pointing up as shown. Once all clips are in place, install the shelves by placing them on the clips,
with the outside bar of the shelf on the inside of the clip tabs. Keep all stored items inside the limits of the
shelves. These allow airflow and should not be blocked when product is stocked in the unit.
ELECTRICAL SYSTEM
Proper electrical installation is required for your refrigerator to function correctly and to prolong the useful
life of electrical parts and compressor.
CAUTION: DO NOT STOCK PRODUCT UNTIL SHELVES ARE
CORRECTLY INSTALLED IN THE UNIT WITH SHELF CLIPS.
IMPORTANT: TO AVOID ACCIDENTS WHEN CLEANING INSIDE
OF UNIT, FIRST REMOVE SHELVES AND SHELF CLIPS.
BEFORE CONNECTING UNIT FOR FIRST TIME:
Verify that line voltage does not fluctuate more than
10% above the nominal value of 115 V, 60 Hz.
DO NOT use extension cords.
DO NOT connect refrigerator to multiple plugs or
plugs with another appliance connected.
The unit MUST be plugged into a grounded socket.
IMPORTANT:
Do not try to repair any portion of the electrical system yourself. Contact the nearest
authorized service center.
The unit must be grounded.
Ignoring any of the precautions in this manual invalidates the Warranty.
The unit must be connected to a circuit breaker with a 15-ampere fuse and installed
with a minimum 14-caliber wire.

9
Wiring Diagram
for ACR1718 models:
OPERATION
COMPRESSOR
The compressor in your ACCUCOLD® refrigerator is designed to function silently. DO NOT plug in the
unit immediately after moving it or changing its position. Allow a minimum of 2 hours for the pressures
inside the refrigeration system to equalize and the oils in the compressor to settle. After plugging the unit
in, let it run for one more hour without load or product. The refrigerator may then be loaded.
DO NOT TOUCH THE COMPRESSOR TOP COVER
while unit is running. It is designed for high
operational temperatures and its surface can
become very hot, which may cause burns.
(The compressor is located at the bottom of
the refrigerator, behind the front louvers.)

10
Face of alarm/thermostat
TEMPERATURE CONTROL
The temperature is controlled by a thermostat which is
located above the front ventilation louvers, just below the
door. The thermostat is factory-set to maintain the internal
temperature between 2 and 8°C (35.6 and 46.4°F). The
thermostat normally displays the temperature inside the
cabinet. The default setting is 2°C.
To change the set temperature,
1. Press and hold the set button for 5 seconds until “0”
appears on the screen.
2. Release the button and press it again to confirm the “0” command.
3. Press the UP or DOWN buttons until you see the parameter “St” on the screen.
4. Press the set button again to enter that parameter.
5. With the UP and DOWN buttons choose the desired operating temperature. (NOTE: Only
temperatures from 2 to 8°C are permitted.)
6. Press set again to confirm the temperature.
7. Wait 1 minute without touching any button while the unit accepts the changes. It will then start
running normally.
For information on changing the temperature range or any other parameters, please call our Customer
Service Line at 1-800-932-4267.
ALARM SETTINGS
Your refrigerator is designed to sound an alarm if the internal temperature rises above 10°C or falls below
0°C. If you wish to change these settings, call our Customer Service Line at 1-800-932-4267.
An alarm will also sound if the door is left open for more than 2 minutes.
To stop an alarm when it is sounding, press the set/mute button on the thermostat.
ENERGY-SAVING MODE
To save energy by limiting the length of operation time of the fan motors and compressor and by turning
off the interior light, you can put the refrigerator into Energy-Saving mode by pressing the UP arrow
(ECO) for 3 seconds. The display will show “ EnS “ when this mode is active. To deactivate the Energy-
Saving mode, press the UP arrow again and hold it for at least 3 seconds.
LIGHTING
LED lighting surrounds the glass on the interior side of the door. Additionally, the header panel above the
door is backlit.
Cabinet lighting is designed to function continuously or may be controlled with a switch, located inside the
unit to the left of the internal fan in the ceiling. See Wiring Diagram, page 9. Putting the refrigerator into
Energy-Saving mode (see section above) will also turn off the interior lighting.
NOTES:
If the unit is unplugged, or power is lost or turned off, you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the unit will not start.
When you use the unit for the first time or restart the unit after it has been shut off for a long
time, allow a few hours for the interior temperature to normalize.

11
USER MAINTENANCE
For better performance and user convenience, this refrigerator has been designed to function with the
least possible maintenance and to provide optimal energy consumption and serviceability. It is
recommended, however, that the unit be kept clean and that the following preventative maintenance be
performed.
CABINET CLEANING
Turn off the power, unplug the appliance, and remove all items, including shelves and shelf clips.
When cleaning cabinet interior, use a solution of warm water and mild soap.
Do not use steel wool, caustic or abrasive cleaners or bleach that may damage the stainless surface.
Once the cabinet interior is clean, dry it with a clean, dry cloth.
Wipe the door gasket with a solution of warm soapy water, then dry with a clean soft cloth.
Wash the shelves with a mild detergent solution, then dry them.
Wring excess water out of the sponge or cloth when cleaning the area where the controls are located,
or any electrical parts.
Clean the outside of the unit with an approved stainless steel cleaning product. Do not use steel wool
or a steel brush on the stainless steel surfaces.
NOTE: Do not use alcohol derivatives or thinner to clean the cabinet.
CONDENSER CLEANING
Disconnect the refrigerator's power supply before cleaning. The static condenser (on back of unit) should
be cleaned every 12 months for optimum performance. Use a soft-bristle brush to remove excess dust to
improve heat transfer to the surrounding air.
CARE OF THE ALARM/THERMOSTAT.
• Do not wash or expose the alarm/thermostat to water or other liquids.
• Clean the product by wiping with a soft, dry cloth.
• Never use volatile or abrasive liquids or cleaners to clean the product.
• Do not subject the product to sudden shock or impact.
CAUTION: Failure to unplug the appliance during cleaning could result in
electrical shock or other personal injury .

12
CLEANING THE COMPRESSOR/FAN COMPARTMENT
The compressor and fan are located behind the front louvers of the appliance.
To clean the compartment behind the front louvers,
1. Disconnect the power supply to the appliance.
2. Remove the two screws, as shown above.
3. Lift the front louver panel, then pull it toward you, being careful not to disconnect any attached wiring.
4. Clean the area with a damp cloth, then dry it.
5. Replace the louver panel and screw it back into place.
6. Reconnect power to the appliance.
DEFROSTING
It is not necessary to defrost your refrigerator. This is done automatically, using a forced-air system.
There is a defrost water evaporation pan in the compartment below the main cabinet. A hot gas line from
the compressor passes through this pan and evaporates the water. Check occasionally that the drain
hose is always inside the evaporation pan.
SECURITY LOCK
Your unit is provided with a lock and key combination.The lock may be found on the front of the
refrigerator. The keys are located inside the plastic bag that contains the Instruction Manual. After a key
has been used, remove it and put it in a secure place for safekeeping.
ENERGY-SAVING TIPS
DO NOT DISCONNECT UNIT AT NIGHT. Not only will contents most likely suffer damage, but
reconnecting next day will increase energy consumption.
DO NOT keep the door open any longer than necessary.
DO NOT OVERLOAD UNIT. Allow free air flow inside refrigerator.
DO NOT PLACE HEAVY AND/OR LARGE OBJECTS INSIDE UNIT.
It is important not to block air flow inside the refrigerator. Remember that it is designed exclusively for
cooling vaccines, pharmaceuticals and other medical specimens.
The appliance should be located in the coolest area of the room, away from heat-producing
appliances and out of direct sunlight.
Ensure that the unit is adequately ventilated. Never cover air vents.
DO NOT PLACE FOODS IN REFRIGERATOR. Not only will you risk contamination of medical
products, but the forced air system will absorb moisture from the food.
DISCONNECT THE UNIT’S POWER SUPPLY BEFORE
REMOVING THE FRONT LOUVER to avoid accidents that
may be caused by oscillation of the blade of the fan motor.
Front louvers
Door
Screws
Compressor
Fan

13
TROUBLESHOOTING
You can solve many common problems easily, saving you the cost of a possible service call. Try the
suggestions below to see if you can solve the problem before calling the servicer.
Troubleshooting Guide
PROBLEM
POSSIBLE CAUSE
The unit does not operate.
Not plugged in.
Voltage is outside specifications.
Tripped circuit breaker or blown fuse.
The unit is not cold enough.
Voltage is outside specifications.
Interior air flow is blocked.
There is a nearby heat source.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
Condenser needs cleaning.
Turns on and off frequently.
There is a nearby heat source.
Interior air flow is blocked.
A large amount of product has been added to the
refrigerator.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
Condenser needs cleaning.
The light does not work.
Not plugged in.
Tripped circuit breaker or blown fuse.
The light switch is OFF.
Ice forms on evaporator.
High relative humidity in environment.
The door is not closed properly.
The door is opened too often or for too long.
Interior air flow is blocked.
Vibrations
Appliance is not level.
Fan blades are out of balance.
Tubes or moving parts are grazing metallic parts.
The unit seems to make too much noise.
The rattling noise may come from the flow of the
refrigerant, which is normal.
As each cycle ends, you may hear gurgling sounds
caused by the flow of refrigerant in the unit.
Contraction and expansion of the inside walls may
cause popping and crackling noises.
The appliance is not level.
The door will not close properly.
The appliance is not level.
The gasket is dirty.
The shelves are out of position.
Excessive condensation in interior and on door.
High relative humidity in environment.
The door is not closed properly.
The door is opened too often or for too long.

14
LIMITED WARRANTY
ONE-YEAR LIMITED WARRANTY
Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and
maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified
parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated
service company. Outside the 48 states, all parts are warranted for one year from manufacturing defects. Plastic
parts, shelves and cabinets are warranted to be manufactured to commercially acceptable standards, and are not
covered from damage during handling or breakage.
5-YEAR COMPRESSOR WARRANTY
1. The compressor is covered for 5 years.
2. Replacement does not include labor.
ITEMS WARRANTOR WILL NOT PAY FOR:
1. Service calls to correct the installation of your appliance, to instruct you how to use your appliance, to replace or
repair fuses or to correct wiring or plumbing.
2. Service calls to repair or replace appliance light bulbs or broken shelves. Consumable parts (such as filters) are
excluded from warranty coverage.
3. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation,
installation not in accordance with electrical or plumbing codes, or use of products not approved by warrantor.
4. Replacement parts or repair labor costs for units operated outside the United States.
5. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
6. The removal and reinstallation of your appliance if it is installed in an inaccessible location or is not installed in
accordance with published installation instructions.
DISCLAIMER OF IMPLIED WARRANTIES –LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT
REPAIR AS PROVIDED HEREIN. IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR. WARRANTOR SHALL NOT BE
LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS, SO THESE EXCLUSIONS OR LIMITATIONS MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE
OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
WARNING! This product may contain chemicals known to the state of California
to cause cancer or birth defects or other reproductive harm. For more information,
visit: www.summitappliance.com/prop65
Chemicals known by the manufacturer to be present in this product in concentrations
higher than threshold limits: NONE.
Printed in Mexico
844-478-8799

15
TABLE DES MATIÈRES
Consignes de sécurité ...............................................................
16
Mise en garde importantes ........................................................
16 - 17
Mise en garde spéciales ...........................................................
18
Emplacements des pièces .........................................................
19
Transport et manutention .........................................................
19
Évaluation de l'unité et inspection ...........................................
20
Instructions pour l'installation ..................................................
20 - 22
Localisation .............................................................................
20
Installation des étagères.........................................................
21
Système électrique.................................................................
21 - 22
Fonctionnement ………………………….....................................
22- 23
Compresseur ……………………………………………………..
22
Contrôle de la température ....................................................
23
Réglages d'alarme ……………………………………………….
23
Mode d'économie d'énergie ....................................................
23
Éclairage .................................................................................
23
Entretien par l'utilisateur ...........................................................
24 - 26
Nettoyage de l'armoire ...........................................................
24
Nettoyage du condenseur ......................................................
24
Entretien de l'alarme / thermostat ……………………………
24
Nettoyage du compartiment du compresseur / ventilateur .....
25
Dégivrage ..............................................................................
25
Verrouillage de sécurité ..........................................................
25
Conseils pour économiser l'énergie .......................................
26
Dépannage ..................................................................................
27
Garantie limitée ...........................................................................
28

16
CONSIGNES DE SÉCURITÉ
Votre sécurité et celle des autres est très importante.
Nous avons fourni de nombreux messages de sécurité importants sur votre appareil
dans ce manuel. Toujours lire et respecter les consignes de sécurité.
DANGER est le symbole d'alerte de sécurité. Ce
symbole vous signale les dangers potentiels qui
pourraient tuer or blesser vous et les autres.
Tous les messages de sécurité suivront le
symbole d'alerte de sécurité, soit après le mot
"DANGER" ou "AVERTISSEMENT".
Le symbole AVERTISSEMENT signifie que le
non-respect de ce message de sécurité peut
entraîner des dommages importants au produit,
des blessures graves ou la mort.
Tous les messages de sécurité vous alertent au danger potentiel et vous expliquent comment réduire le
risque de blessure et les conséquences qui peuvent se produire si les instructions ne sont pas suivies.
MISES EN GARDE IMPORTANTES
Avant d'utiliser l'appareil, il doit être positionné correctement et installé comme décrit
dans ce manuel. Lisez le manuel attentivement. Pour réduire le risque d'incendie, de
choc électrique ou de blessure lors de l'utilisation de l'appareil, suivrez les précautions
de base, y compris ce qui suit:
Branchez sur une prise à 3 broches de sortie, ne retirez pas la broche de terre, ne pas utiliser un
adaptateur, et ne pas utiliser une rallonge.
Replacez tous les panneaux avant de faire fonctionnement l'appareil.
Il est recommandé d'utiliser un circuit distinct afin d'alimenter votre appareil uniquement. Utilisez des
récipients qui ne peuvent pas être désactivés par un interrupteur ou une chaîne de traction.
Ne jamais nettoyer des pièces d'appareils avec des liquides inflammables. Les émanations peuvent
provoquer un incendie ou une explosion. Ne pas stocker ni utiliser d'essence ou autres vapeurs et
liquides inflammables à proximité de cet appareil ou de tout autre. Les vapeurs peuvent créer un risque
d'incendie ou d'explosion.
Avant de procéder à des opérations de nettoyage et d'entretien, assurez-vous que la ligne
d'alimentation de l'appareil soit débranchée.
Ne pas brancher ou débrancher la prise électrique lorsque vos mains sont mouillées.
Débranchez l'appareil ou couper le courant avant de le nettoyer ou de le réparer. Le non-respect de
cette consigne peut entraîner un choc électrique ou la mort.
AVERTISSEMENT

17
Ne tentez pas de réparer ou de remplacer une partie quelconque de votre appareil à moins qu'il ne soit
spécifiquement recommandé de le faire dans ce manuel. Toute autre réparation doit être confiée à un
technicien qualifié.
Suivez la légende des consignes d' AVERTISSEMENT ci-dessous lorsque applicables à votre
modèle.
Il est important qu'au moins deux personnes déplacent et installent l'appareil. Le non-respect de cette
consigne peut entraîner des blessures au dos ou autres lésions.
Pour assurer une bonne ventilation de votre appareil, le devant de l'unité doit être complètement
dégagé. Choisissez un endroit bien aéré, avec des températures supérieures à 60°F (16°C) et au-
dessous de 90°F (32°C). Cet appareil doit être installé dans une zone protégée contre les éléments,
comme le vent, la pluie, les éclaboussures et les gouttes d'eau.
L'appareil ne doit pas être situé à proximité de fours, grilles chauffantes ou d'autres sources de chaleur
élevée.
L'appareil doit être installé avec toutes les connexions électriques, d'eau et de vidange conformément
aux codes nationaux et locaux. Une alimentation électrique standard (115 V CA seulement, 60 Hz),
correctement mise à terre en conformité avec le National Electrical Code et les codes et ordonnances
locaux, est requise.
Ne placez pas des substances chimiques (solvants, réactifs) ou de la nourriture dans le réfrigérateur.
Cet équipement est prévu pour le stockage et l'affichage des vaccins, des médicaments et d'autres
spécimens qui doivent être réfrigérés à des températures précises.
Ne pas plier ou pincer le cordon d'alimentation de l'appareil.
L'intensité du fusible (ou disjoncteur) doit être de 15 ampères.
Il est important que l'appareil soit mis à niveau afin de fonctionner correctement. Vous devrez peut-être
faire plusieurs ajustements pour y arriver.
Toutes les installations doivent être conformes aux exigences du code de plomberie local.
Assurez-vous que les tuyaux ne soient pas pincés, noués ou endommagés lors de l'installation.
Vérifier les fuites après la connexion.
Ne jamais laisser les enfants utiliser, jouer ou ramper à l'intérieur de l'appareil.
Ne pas utiliser de produits nettoyants à base de solvants ou de produits abrasifs à l'intérieur. Ces
produits peuvent endommager ou décolorer l'intérieur.
Utilisez cet appareil uniquement pour son usage, tel que décrit dans ce Manuel d'emploi.
Gardez les doigts hors des zones de "pinçage". Le dégagement entre la porte et le placard est toujours
étroit. Surveillez la fermeture des portes soigneusement lorsque les enfants se trouvent dans les
alentours.
DANGER! Risque d'emprisonnement pour les enfants!
Des enfants pris au piège et suffoqués n'est pas un scénario du passé. Les appareils jetés ou
abandonnés sont encore dangereux, même si ils sont "simplement entreposés dans le garage pendant
quelques jours".
Avant de jeter votre vieux réfrigérateur:
• Enlever les portes
• Laissez les étagères en place afin que les enfants ne peuvent pas y pénétrer facilement.
- CONSERVER CES INSTRUCTIONS -
AVERTISSEMENT

18
MISE EN GARDE SPÉCIALES
Ne marchez pas sur le panneau de volet avant de l'appareil ou de l'utiliser comme une marche.
Utilisez UNIQUEMENT des fiches polarisées de brancher votre appareil.
NE PAS couper ou enlever la terre sur le câble électrique.
Vérifiez que le système électrique soit mis à la terre avant de brancher le réfrigérateur pour la première
fois.
Le polyuréthane dans votre appareil contient du gaz cyclopentane comme agent moussant. Lors de la
réparation, NE PAS utiliser d'autres types de polyuréthane ou mélanger le polyuréthane existant avec
d'autres types d'agents. SUMMIT n'est pas responsable des changements du réfrigérateur si les
réparations sont effectuées par l'utilisateur ou des techniciens non-certifiés. Contactez un distributeur
autorisé pour des informations sur la réparation.
NE placez pas les mains ou d'autres objets dans les panneaux avant de l'appareil, les grilles situées à
l'arrière ou dans le ventilateur en fonctionnement. Cela peut entraîner des blessures corporelles et / ou
des dommages à l'unité.
Avant de retirer le panneau situé à l'avant pour l'entretien et le nettoyage, débranchez l'alimentation
électrique de l'appareil pour éviter les accidents qui peuvent être provoqués par l'oscillation de la lame
du moteur du ventilateur.
Gardez les mains éloignées du pivot de la porte lorsque la porte est ouverte.
Avant de charger le réfrigérateur, vérifiez que les étagères soient fixes et qu'elles contiennent le
nombre de supports indiqués pour votre modèle, tel que décrit dans le Mode d'emploi.
Vérifiez que le panneau de volet avant de l'appareil et les grilles de derrière soient en place avant de
brancher l'appareil.
NE PAS placer les substances chimiques (solvants, réactifs) ou de la nourriture dans le réfrigérateur.
Cet équipement est prévu pour le stockage et l'affichage des vaccins, de médicaments et d'autres
spécimens qui doivent être réfrigérés à des températures précises.
Cet appareil est destiné à être localisé dans une pharmacie. Le sol sous l'appareil doit être gardé
propre.
NE PAS mettre en équilibre ou incliner l'unité à plus d'un angle de 45° sans la supervision d'un
personnel autorisé. Des blessures graves peuvent survenir.
N'essayer pas de réparer l'unité vous-même. Consultez toujours votre distributeur autorisé de service.
Avant de signaler un problème avec votre réfrigérateur ACCUCOLD®, vérifiez la fiche et les fusibles,
ainsi que le disjoncteur. Si cela n'est pas la cause du problème, contactez votre distributeur
immédiatement afin qu'un technicien vous soit envoyé.
La capacité de refroidissement de l'unité diminuera si:
–La porte est ouverte pendant de longues périodes,
–Une quantité excessive de produit est stockée dans celle-ci.
Cela surchargera l'appareil et augmentera le risque de mauvais fonctionnement.

19
EMPLACEMENTS DES PIÈCES
TRANSPORT ET MANUTENTION
NE PAS DÉPLACER L 'UNITÉ AVEC LES PRODUITS À L'INTÉRIEUR, des produits mal fermés peuvent
se casser, se renverser, endommager l'appareil, etc.
Étagères réglables
Porte en verre
avec cadre en inox
Panneau lumineux
Panneaux de ventilation
Pieds de nivellement
Éclairage intérieur
(autour de la porte)
Alarme / thermostat
Commutateur d'éclairage
Poignée *
Ventilateur interne
Condenseur statique
(à l'arrière de l'appareil)
Compresseur et ventilateur
(derrière les panneaux)
Intérieur en inox
NE PAS PENCHER L'UNITÉ À UN ANGLE DE
PLUS DE 45 °. NE PAS EXPOSER AU
SOLEIL; NE PAS STOCKER À DES
TEMPÉRATURES SUPÉRIEURES À 131°F
(55°C).
LORSQUE VOUS MANIPULEZ UN APPAREIL
AVEC CONDENSEUR STATIQUE COMME
CELUI-CI, ASSUREZ-VOUS QUE LE PIVOT
DE PORTE SE TROUVE TEL QU'ILLUSTRÉ
DANS L'IMAGE CI-DESSUS.
DEVANT
MODÈLES AVEC CONDENSEUR
STATIQUE: MANIPULER DE CÔTÉ
SEULEMENT
CONDENSEUR STATIQUE
PIVOT DE LA PORTE
Descriptions des modèles:
ACR1718LH - ouverture de la porte à gauche
ACR1718RH - ouverture de la porte à droite
* La poignée et la position de la
serrure sont sujettes à changement.
Serrure *

20
ÉVALUATION DE L'UNITÉ ET INSPECTION
Ce réfrigérateur a été entièrement inspecté avant de quitter l'usine. Inspectez l'appareil pour des signes
de dommages lorsque vous le recevez. S'il ya un problème, contactez votre distributeur agréé ou le
fabricant immédiatement. Vérifiez que les accessoires suivants sont fournis avec votre réfrigérateur:
6 étagères en plastique (emballées dans une pellicule de plastique à l'intérieur de l'unité)
24 pinces pour étagères (emballées séparément dans un sac en plastique à l'intérieur de l'unité)
INSTRUCTIONS POUR L'INSTALLATION
Ce modèle est conçu pour un usage intérieur à une température de fonctionnement maximale de 27°C
(80,6°F) et un degré humidité de 55%. Il est destiné à être autonome et non intégré dans un boîtier.
Ne placez pas l'appareil près de sources de chaleur telles que poêles, grilles chauffantes, radiateurs, etc.,
et ne placez pas dans des zones où la lumière du soleil directe peut atteindre l'unité.
LOCALISATION
Il est recommandé que la partie arrière et les deux côtés de votre réfrigérateur soient à une distance
respective d'au moins 8 pouces et 6 pouces du mur, pour permettre l'écoulement de l'air du compresseur
et afin d'améliorer le transfert de chaleur.
Placez votre réfrigérateur sur une surface plane.
Les distances minimales
Une fois l'appareil installé, vérifiez qu'il est à niveau. Si nécessaire, utilisez les deux pattes avant pour
régler la hauteur de l'appareil.
ATTENTION: Cet appareil est conçu pour le stockage et la réfrigération de
médicaments, de vaccins et d'autres spécimens médicaux. Ne pas
l'utiliser pour entreposer les denrées périssables ou des substances
chimiques comme les solvants et les réactifs.
ATTENTION: Après le déballage vous DEVEZ permettre cet appareil de se tenir debout pendant
au moins 2 heures pour permettre aux lubrifiant et réfrigérant à écouler dans le compresseur et
se stabiliser. Ne pas le faire peut affecter les performances et la durée de vie de cette unité.
