Summit Professional DW18SS2 Series User manual

Installation Manual
Dishwasher
FOR MODELS (ADA Height)
DW18SS2*
USA

1. IMPORTANT SAFETY INSTRUCTIONS 1
1.1 INSPECT THE DISHWASHER 2
1.2 HOW TO CONTACT US : 2
2. TOOLS WHICH MAY BE NEEDED 3
3. MATERIALS WHICH MAY BE NEEDED 3
4. MATERIALS SUPPLIED 4
4.1 PARTS SUPPLIED 4
4.2 MANUAL BAG 4
4.3 DISHWASHER PARTS BAG 1 4
4.4 DISHWASHER PARTS BAG 2 4
4.5 PARTS ATTACHED TO THE REAR OF THE DISHWASHER 4
5. DISHWASHER SPECIFICATIONS 5
5.1 TECHNICAL FEATURES 5
6. ENCLOSURE PREPARATION 6
6.1 ELECTRICAL PREPARATION 6
6.2 PREPARATION FOR INSTALLING MOUNTING BRACKETS 6
6.3 ADJUSTING HEIGHT 6
6.4 PREPARING THE WATER CONNECTION (A) 9
6.5 DRAIN PREPARATION 10
6.7 STEAM PROTECTION FOIL 11
7. PLACEMENT OF DISHWASHER INTO THE OPENING 12
7.1 DRAIN HOSE CONNECTION, WATER SUPPLY & ELECTRICAL CONNECTIONS 12
7.2 ELECTRICAL CONNECTION 13
7.3 READJUSTING FOOT LEVELS 14
7.4 ADJUSTING THE MOVABLE TOE KICK 14
7.5 INSTALLING THE OUTER DOOR 16
8. INSTALLER CHECKLIST 21
9. FINAL INSTRUCTIONS 21
10. SELF HELP HINTS: 21
To prevent accidents, which could cause serious injury or death, as well as
machine damage read these instructions before installation and / or use.

1USA



INTRODUCTION
Please read this installation manual and
particularly the safety instructions completely
and carefully. They will save you time
and effort and help to ensure optimum
dishwasher performance.
Be sure to observe all listed warnings and
cautions. Look particularly for the icons with
exclamation marks inside. The information
icon also will provide important references.
WARNING
When installing the dishwasher, follow
basic precautions, including the
following:
• The dishwasher installation must
be performed in accordance with
this installation manual. If you did
not receive an installation manual,
order it by calling 1-800-287-8799
or you may also download it from
our web site at
www.summitappliance.com
• The dishwasher could only be
converted from cord-connected
to permanently connected by an
authorized service representative.
(If needed contact your dealer to
schedule an authorized service
agent for conversion with an
appropriate conversion kit)
• Installation and repair should be
performed by a qualied installer.
Work by unqualied persons could
be dangerous and may void the
warranty.
Notice :
The dishwasher should be installed by
an insured licensed plumber, contractor
or trained installer. Installation performed
by persons other than this could result in
improper installation and property damage.
• Do not operate the appliance if
damaged, malfunctioning, partially
disassembled or if it has missing
or broken parts.
• Also follow the safety instructions
of the user manual.
• To reduce the risk of electric
shock, re, or injury to persons,
the installer must ensure that the
dishwasher is completely enclosed
at the time of installation.
• Only connect the dishwasher
to the power supply when all
installation and plumbing work is
complete.
WARNING:
Indicates a potentially hazardous situation
which, if not avoided, could result in death or
serious injury.
CAUTION:
Indicates a potentially hazardous situation
which, if not avoided, may result in injury.
It may also be used to alert against unsafe
practices.
Notice:
Indicates a potentially hazardous situation
which, if not avoided, may result in damage
to the dishwasher, the table-ware, the
equipment or the environment.
1. IMPORTANT SAFETY
INSTRUCTIONS
In addition to these instructions, the
dishwasher shall be installed:
• In accordance with all local codes
or, in absence of a local code,
• In the United States, with the
National Electric Code,
• In Canada, with the Canadian
Electric Code C22.1-latest edition/
Provincial and Municipal codes and/
or local codes.
Notice :
Read these installation instructions
completely before installing and follow them
carefully. Save these installation instructions
and pass them on to any future user.

2USA
•If the dishwasher is installed in a
location that experiences freezing
temperatures (e.g. in a vacation
home, cabin, etc.), you must drain
all the water from the dishwasher’s
interior. Water system ruptures
that occur as a result of freezing
are not covered by warranty.
•Dishwasher must be secured
to adjacent cabinetry using the
brackets provided. Failure to
do this may cause damage to
property or bodily injury.
•Connect to a properly rated,
protected and sized power supply
circuit to avoid electrical overload.
The dishwasher is designed for an
electrical supply of 120 V (volts),
60 Hz (hertz), AC, connected to
a dishwasher-dedicated, properly
grounded electrical circuit with
a fuse or breakers rated for
15 amperes. Electrical supply
conductors shall be a minimum
of # 16 AWG copper wire rated
at 75 °C (167 °F) or higher.
These requirements must be met
to prevent injury and machine
damage. Consult a qualied
electrician if in doubt.
•Do not use any extension cord or
portable outlet device to connect
the dishwasher to a power supply.
•Ensure that any plastic wrappings,
bags, small pieces etc. are
disposed of safely and kept out of
the reach of children. Danger of
suffocation!
•Remove the door to the washing
compartment when removing
an old dishwasher from service
or discarding it. Ensure that the
appliance presents no danger to
children while being stored for
disposal.
•Old appliances may contain
materials that can be recycled.
Please contact your local recycling
authority about the possibility of
recycling these materials.
Notice :
•The dishwasher drain hose must
be installed with a drain loop at
least 28” (710mm) off the cabinet
oor; otherwise the dishwasher
may not drain properly.
•This dishwasher is intended for
residential use only, and should
not be used in commercial
establishments.
•New installation - If the
dishwasher is a new installation,
most of the work must be done
before the dishwasher is moved
into place.
•Replacement - If the dishwasher
is replacing another dishwasher,
check the existing dishwasher
connections for compatibility with
the new dishwasher, and replace
parts as necessary.
1.1 INSPECT THE DISHWASHER
After unpacking the dishwasher and prior
to installation, thoroughly inspect the
dishwasher for possible freight or cosmetic
damage. Report any damage immediately.
Notice :
•Cosmetic defects must be
reported within 10 days of
installation.
•Do not discard any bags or
items that come with the original
package until after the entire
installation has been completed.
1.2 HOW TO CONTACT US :
You may either call our Toll Free Number at
1-800-287-8799 or contact us via the web
site at
www.summitappliance.com

3USA
2. TOOLS WHICH MAY BE NEEDED
3. MATERIALS WHICH MAY BE NEEDED
(Additional materials may be required to comply with local codes)
Hot Water Supply Line - Minimum 3/8” O.D. copper tubing or metal braided
dishwasher supply line.
UL listed conduit connector or strain relief.
Teon tape or other pipe thread compound to seal plumbing connections.
Shut-off valve and fittings appropriate for hot water supply line (copper
tubing/compression fitting, or braided hose).
Silicone
Glue

4USA


 
 






































4. MATERIALS SUPPLIED
4.1 PARTS SUPPLIED
Parts for your dishwasher will come in several plastic bags.
Check your parts bags shown to make sure you have all the
parts as listed to the left.
4.2 MANUAL BAG
The dishwasher comes with a manual bag containing:
•User manual,
•Installation manual and
•Quick reference guide.
4.3 DISHWASHER PARTS BAG 1
This dishwasher bag comes with the following parts:
a. Side Trim Strips (Left)
b. Side Trim Strips (Right)
c. Adjusting Wrench
d. Screws Ø
1/8
” x
5/8
” (Ø 3.5mm x 14mm)
e. Mounting Bracket Left
f. Mounting Bracket Right
g. Spring Clamp
h. Screw Clamp
j. Rubber Connector
k. Toe Kick Bracket - Left
l. Toe Kick Bracket – Right
m. Edge Protector
n. Long Legs
o. Toe Kick (toe kick without slots)
p. Toe Kick
r. Toe Kick
s. Plastic Caps
t. Screws Ø
3/16
” x
1/4
” (Ø 4mm x 6mm)
z. Steam Protection Foil
aa. 90° elbow with 3/8” N.P.T. male threads on one leg, and
sized to fit your water supply line (copper tubing/compression
fitting, or braided hose) on the other leg.
4.4 DISHWASHER PARTS BAG 2
In addition to the manual bag and the dishwasher parts bag,
dishwasher models which can accept a customized door also
come with a door panel installation kit which contains:
v. Screws Ø
1/8
” x
5/8
” (Ø 3.5mm x 14mm)
y. Screws Ø
3/16
” x 1
3/4
” (Ø 4mm x 43mm)
4.5 PARTS ATTACHED TO THE REAR OF THE
DISHWASHER
a. Side Trim Strips (Left)
b. Side Trim Strips (Right)
o. Toe Kick (toe kick without slots)
p. Toe Kick
r. Toe Kick

5USA
5. DISHWASHER SPECIFICATIONS
5.1 TECHNICAL FEATURES
Load capacity 8 place settings
Permissible water
pressure 4.35 - 145 psi (0.3 - 10 bars)
Electrical connection 120 V (volts), 12 A (amps),
60 Hz (hertz)
Total power 1400 W (watts)
Heater power 1240 W (watts)
Notice :
Because we continually strive to improve our products, we may change our specifications
and design without prior notice. This device corresponds to the following directives:
UL 749 Household Dishwasher directive.

6USA
6. ENCLOSURE PREPARATION
6.1 ELECTRICAL PREPARATION
WARNING
The dishwasher is designed for an electrical supply of 120 V, 60 Hz, AC, connected to a
dishwasher-dedicated, properly grounded electrical circuit with a fuse or breaker rated
for 15 amperes.
6.2 PREPARATION FOR INSTALLING MOUNTING BRACKETS


WARNING
Dishwasher must be secured to adjacent
cabinetry using the mounting brackets
provided. Failure to do this may cause
damage to property or bodily injury.


Place the two mounting brackets into the
top corners of the dishwasher.
Bend sides of mounting brackets (A) in
order to fix from sides (if necessary).
Notice :
• For models with door frames,
extra bending is required on the
brackets, as shown.

6.3 ADJUSTING HEIGHT
Measure the height of the
enclosure.

7USA
6.3.1 INSTALLING THE FOOT SUPPORTS
Supplied (4)
If the height of the enclosure is 33
7/16
” to
34
1/4
” (850mm - 870mm) use short supports
as shown in the figure.
Supplied (4)
If the height of the enclosure is above
34
1/4
” (870mm) use long supports as
shown in the figure.

8USA

Adjust the front foot level with the adjusting
wrench to balance and raise the dishwasher to
the enclosure height.
Adjust the rear foot level with a screwdriver
to balance and raise the dishwasher to the
enclosure height.
Notice :
• Make sure the dishwasher is plumb
and notice dishwasher can be placed
with a small clearance under the
counter top.
• Turning the screwdriver in the
direction of the black arrows will bring
the dishwasher back feet up.
• Turning the screwdriver in the
direction of the white arrows will take
the dishwasher rear feet down.

9USA
6.4 PREPARING THE WATER CONNECTION (A)
Install an easily accessible shut-off valve (not supplied) in the water supply line. All solder
connections must be made before the water line is connected to the dishwasher’s water
inlet valve. Water can also be supplied to the dishwasher by using a exible braided hose
line.
Check with your plumbing supply sources for the proper hose and 90° elbow and
necessary fittings for the water supply line. This material is not supplied, and must be
purchased separately.
WARNING
Installation should be performed by a qualified installer. Work by unqualified
persons could be dangerous and may void the warranty.
If the dishwasher is installed in a location that experiences freezing temperatures
(e.g. in a vacation home, cabin etc.), you must drain all the water from the
dishwasher’s interior. Water system ruptures that occur as a result of freezing are
not covered by warranty.


6.4.1 INSTALLING THE 90° ELBOW FITTING (B)
CAUTION
Do not over tighten the 90° elbow. Doing so
may damage the water inlet valve and cause a
water leak.
If the water supply line is to be copper tubing,
make certain that the elbow has a compression
fitting. Apply Teon tape or other pipe sealant
when required. Orient the water supply connection
downwards as shown in the figure so the water line
can be easily pulled underneath or on the side of
the dishwasher.

10 USA
6.5 DRAIN PREPARATION
The dishwasher drain hose may be connected to the drain plumbing in one of three ways
(Figure A, B, C).
Notice :
• Either one of the above methods must be used or the dishwasher will not operate
properly.
• A hose that attaches to a sink spray can burst if it is installed on the same water
line as the dishwasher. If your sink has one, it is recommended that the hose be
disconnected and the hole plugged.
• The total length of the drain hose is 76
3/4
” (1950mm). If a hose extension is
required, a drainage hose of equal quality must be used.
• The maximum length must not exceed 157 ½” (4000mm). Otherwise, the cleaning
process is negatively inuenced.



6.5.1 UNDER THE SINK DRAIN
Install a Y-branch tail pipe. (Figure A)
Notice :
• You must add a loop at least 28” (710mm) above the oor
of the cabinet and above the drain connection in the drain
hose to prevent waste water from not draining properly,
and causing either poor washing results or a bad odor.
6.5.2 INSTALLING AN AIR GAP
If the local ordinance requires an air gap (Figure B).
Notice :
• Check with local ordinance for type of air gap required.
6.5.3 DISPOSAL
Remove the drain connection plug before attaching the drain
hose from the dishwasher.
Every disposal has a hook up for a dishwasher; consult your
disposer manual for correct connection. (Figure C)

11 USA

6.7 STEAM PROTECTION FOIL
Steam will form inside the dishwasher during operation. At the end of the cycle, when the
dishwasher door is opened, it is required to use a steam protection foil to prevent any
steam from collecting on the underside of the counter top.
6.6.2 FITTING THE PROTECTION FOIL
Before applying the steam protection foil to the
underside of the countertop, clean the area with
a damp cloth (as shown in Figure A). Once the
area dries, apply the steam protection foil.
CAUTION
Steam protection foil must be applied
where the steam escapes when door is
first opened. Failure to install the steam
protection foil during installation can
lead to damage to the cabinets and
countertop.

The steam protection
foil will be applied at the
location where the hot
steam escapes when you
first open the door (as
shown in Figure B).

12 USA
7. PLACEMENT OF DISHWASHER INTO THE OPENING
Now place the dishwasher into the opening and get ready to connect all hoses and electrical
connections.
CAUTION
Make sure all hoses
are pulled through the
side opening of the
cabinet, no hoses are
kinked and all slack is
taken out as shown in
the figure.
7.1 DRAIN HOSE CONNECTION, WATER SUPPLY & ELECTRICAL
CONNECTIONS
7.1.1 DRAIN HOSE CONNECTION
Connect the drain hose to the drain plumbing.
1. Use the supplied rubber connection hose and drain hose clamps to connect the dishwasher drain
hose to the plumbing drain connection.
2. Use the spring clamp to secure the rubber connection hose to the dishwasher drain hose. Use the
screw clamp to secure the rubber connection hose to the plumbing drain connection.
Note that the marks on the
rubber connection hose should
be on the drain hose side

13 USA
7.1.2 WATER SUPPLY CONNECTION
Water supply may be connected to the dishwasher in one of
two ways:
• With metal braided hose.
• With copper tubing.
7.1.3 BRAIDED HOSE/COPPER TUBING
After connections are made turn on the water supply to check
for leaks.
CAUTION
• Hot water supply line: Use minimum 3/8” O.D. copper tubing or metal braided dishwasher
supply line.
• Temperatures required for soldering and sweating will damage the dishwasher’s water inlet
valve so if any such operation is needed, keep the heat source min. 7
7/8
” (200mm) away
from the dishwasher’s water inlet valve.
• There should not be any sharp bends in the water line that may restrict the water ow.
• Teon tape or pipe thread compound must be used for sealing the connection. Before
connecting the copper water supply line to the dishwasher, ush it with hot water to clear any
foreign material.
Notice :
After connections are made turn on the water supply to check for leaks.
7.2 ELECTRICAL CONNECTION
WARNING
• Make sure the voltage and frequency listed on the data plate correspond with the
household electrical supply. This data must correspond to prevent injury and machine
damage. Consult a qualified electrician if in doubt.
• Only connect the dishwasher to the mains when all installation and plumbing work is
complete.
• Do not use any extension cord or portable outlet device to connect the dishwasher to
a power supply.
• The power-supply receptacle for the appliance shall be installed in a cabinet or on a
wall adjacent to the undercounter space in which the appliance is to be installed.
• The access hole of the supply cord to the installation compartment must be smooth
and rounded and it must be large enough for the attachment plug to pass through.
The longest dimension of the opening shall not be more than 1,5” (38 mm).If the
partition is metal, it needs to be covered with the edge protector (m).
• Care must be taken when the appliance is installed or removed, to reduce the
likelihood of damage to the power-supply cord.
7.2.1 GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce
the risk of electric shock by providing a path of least resistance for electric current. This appliance is
equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must
be plugged into an appropriate outlet that is installed and grounded in accordance with all local codes
and ordinances. This appliance must be connected to a grounded metal, permanent wiring system,
or an equipment-grounding conductor must be run with the circuit conductors and connected to the
equipment-grounding terminal or lead on the appliance.
WARNING
• Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualified electrician or service representative if you are
in doubt whether the appliance is properly grounded. Do not modify the plug provided
with the appliance, if it will not fit the outlet, have a proper outlet installed by a
qualified electrician.

14 USA


 


 



7.3 READJUSTING FOOT LEVELS
Now that the dishwasher is in the cabinet you
must readjust the feet to bring the dishwasher up
to the required height and attach it underneath the
countertop.
1. Readjust the front foot levels with adjusting
wrench to balance the dishwasher and raise it up
under the countertop, make sure the unit is level.
2. Readjust the rear foot levels with a screwdriver
to balance the dishwasher and raise it to the
required height using the brackets supplied.
3. Attach the dishwasher underneath the
countertop with the four screws supplied (Ø
1/8
”
x
1/8
” - Ø 3.5mm x 14mm). Make sure you do not
go through the top of the countertop or damage
granite.
7.4 ADJUSTING THE MOVABLE TOE KICK
Now that you have successfully installed the dishwasher, you need to
attach the toe kick to the dishwasher. The two piece toe kick can be
adjusted to the height and depth needed for your kitchen. Be sure to
use the slotted toe kick in the front and the other behind it. They slide
into each other.
1. Insert the movable toe kick brackets into the channel (A).
2. Make sure that the plastic tab to the left of the “L” opening on the
dishwasher has not closed the channel you will push the bracket
through.
Notice :
Be sure to notice there is a left and a right bracket.
Adjust the toe kick brackets forward or backwards so that they will
align with the kitchen toe kick (B).
Notice :
• For models with door frames, note
that you should keep the total
height of the dishwasher at 321/4”
(819mm) max.

15 USA




















Lock the toe kick brackets as shown with the plastic tab in
the figure C by pushing the plastic tab on the dishwasher
into the teeth of the bracket (C).
3. Now attach the toe kick to the bracket with the two
(Ø
3/16
” x
1/4
” - Ø 4mm x 6mm) screws and the caps
provided as follows.
If the enclosure height is below 33
1/16
” (840mm) use only
“o” labelled toe kick (toe kick without slots). Installation
should be done following the steps illustrated in the
Figures A, B and C respectively.
1. Bend tabs on toe kick (o) inwards (A).
2. Secure toe kick to brackets with screws (t) as shown in
the supply bags (B).
3. Attach caps (s) as shown in the supply bags (C).
If the enclosure height is above 33
1/16
” (840mm) use “o”
and “p” labelled toe kicks together. Make sure the slotted
toe kick “p” is on the outside so you can adjust height of
the toe kick. Installation should be done following the steps
illustrated in the figures A, B and C respectively.
1. Align the toe kick (o) and (p) (A).
2. Secure toe kicks to brackets with screws (t) after
adjusting the height of the slotted toe kick (p) (B).
3. Attach caps (s) as shown in the supply bags (C).
If the enclosure height is above 34
1/4
” (870mm) use “o”
and “r” labelled toe kicks together. Make sure the slotted
toe kick “r” is on the outside so you can adjust height of
the toe kick. Installation should be done following the steps
illustrated in the figures A, B and C respectively.
1. Align the toe kick (o) and (r) (A).
2. Secure toe kicks to brackets with screws (r) after
adjusting the height of the slotted toe kick (t) (B).
3. Attach caps (s) as shown in the supply bags (C).

16 USA










 

7.5 INSTALLING THE OUTER DOOR
Measure the height and width of the enclosure (Figure
A) and the toe kick. Determine how big the wooden
door can be. For example if the height is 33
7/8
”
(860mm) and if the toe kick is 3
15/16
” (100mm) the
door can not be taller than 29
15/16
” (760mm).
1. Prepare the wooden door with the mounting brackets.
Height : Height of the wooden door 28” (711mm)
Width : 17 ½” to 17 ¾” (442 mm - 448 mm)
Thickness : ¾ “ (19mm)
3. Mark the wooden door as shown in the
drawing (Figure C).

2. To take the plastic bracket out, remove the
screws on it. Screws will be used in 5th step
again. (Figure B).

17 USA





 

5. Attach the two mounting brackets to the wooden door
with 4 screws (Ø
1/8
” x
5/8
” (Ø 3.5mm x 14mm) (Figure
A).
6. Mount the wooden door onto the dishwasher with
the plastic mounting brackets which you have attached
(Figure B).


4. Place the plastic mounting brackets over the marked
holes and the side tabs must be ush with the edge of
the wooden door (Figure D).

18 USA










7. Open the door and remove the two caps and two
screws inside the door at position 1 and 3 (Figure C).
8. Using the four screws Ø
3/16
” x 1
11/16
” (Ø 4mm
x 43mm) provided, attach the wooden door to the
dishwasher at position 1 and 3 (Figure A).
9. Check the position of the wooden door and make
sure it is aligned properly (Figure B).
10. Tighten the screws in position 1 and 3 completely
after the final alignment (Figure C).
