Summit Professional ASDS1523 User manual

OUTDOOR & INDOOR FROST-FREE
REFRIGERATORS and FREEZERS
RÉFRIGÉRATEURS et CONGÉLATEURS
SANS GEL à l'EXTÉRIEUR et à l'INTÉRIEUR
MODELS / MODÈLES :
Refrigerators / Réfrigérateurs: ALR15B / FF1532B / FF1532X / FF1532XCSS
SPR316OS / AL54 / FF64B / FF64BSS / SPR627OS / SPR628BCSS
SPR629WCSS / ASDS1523 / LASS1544 / ADSS1553 / SDS1528 / LR1548
SDSS1557 / ASDS2413 / LASS2432 / ADSS2443 / SDS2417 / LRS2436
SDSS2447 / SPR618OSADA / LASD2418 / SPR618OS / ASDS2413CSS
LASS2432CSS / ADSS2443CSS
Freezers / Congélateurs: SCFF1533B / ALFZ53 / LFZ24A / SCFF53BSSADA
SCFF52W / SCFF53B / SCFF53BSS / SPFF51OS
Instruction Manual / Mode d’emploi
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
AVANT L'UTILISATION, VEUILLEZ LIRE ET SUIVRE TOUTES LES REGLES DE SECURITE ET LES
INSTRUCTIONS D'UTILISATION.
Felix Storch, Inc.
ISO 9001:2015 registered company
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
Write Model and Serial Nos. (on lower left corner
of inside cabinet) here:
Inscrivez les numéros de modèle et de série
(dans le coin inférieur gauche de l'armoire
intérieure) ici:
Model No.: _______________________
Serial No.: _______________________

2
TABLE OF CONTENTS
Appliance Safety
3
Important Safeguards
3-4
Location of Parts
5-8
Installation Instructions
9-11
Before Using Your Appliance
9
Installation of Your Appliance
9
Electrical Connection
9-10
Extension Cord
10
Reversing the Door Swing of Your Appliance
10-11
Adjusting the Height of the Unit
11
Adjusting the Kick-plate
11
Installing the Stainless Steel Handle
11
Operating Your Appliance
12-16
Control Panel for Refrigerators
12-14
Control Panel for Freezers
14-15
Sabbath Mode
15
Temperature Memory Function
15
Defrosting
15
Using the Freezer
15
Temperature Alarm / Door Alarm
16
Door Lock
16
Shelves
16
Care and Maintenance
17
Cleaning Your Appliance
17
Power Failure
17
Vacations
17
Moving Your Appliance
17
Energy-Saving Tips
17
Troubleshooting
18-19
Limited Warranty
20
French version of this manual
21-40

3
APPLIANCE SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read
and obey all safety messages.
This is the Safety Alert Symbol. The symbol alerts you to potential hazards that
can kill or injure you and others. All safety messages will follow the Safety
Alert Symbol and either the word DANGER or WARNING.
DANGER means that failure to heed this safety
statement may result in severe personal injury or
death.
WARNING means that failure to heed this safety
statement may result in extensive product
damage, serious personal injury, or death.
All safety messages will alert you about the potential hazard, tell you how to reduce the chance of injury,
and let you know what can happen if the instructions are not followed.
IMPORTANT SAFEGUARDS
Before the appliance is used, it must be properly positioned and installed as
described in this manual, so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the appliance, follow basic precautions,
including the following:
•Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and do
not use an extension cord.
•Replace all panels before operating.
•It is recommended that a separate circuit serving only your appliance be provided. Use receptacles
that cannot be turned off by a switch or pull chain.
•Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance. The fumes can create a fire hazard or explosion.
•Do not connect or disconnect the electric plug when your hands are wet.
•Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result in
electrical shock or death.
•Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in
this manual. All other servicing should be referred to a qualified technician.
•This appliance is CFC- and HFC-free and contains small quantities of Isobutane (R600a) which is
environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the
greenhouse effect. Care must be taken during transportation and setting up of the appliance that no
parts of the cooling system are damaged. Leaking coolant can ignite and may damage the eyes.
•In the event of any damage:
- Avoid open flames and anything which creates a spark,

4
- Disconnect from the power supply,
- Air the room in which the appliance is located for several minutes and
- Contact the Service Department for advice.
•The more coolant there is in an appliance, the larger the room it should be installed in. In the event of a
leakage, if the appliance is in a small room, there is the danger of combustible gases building up. For
every ounce of coolant at least 325 cubic feet of room space is required. The amount of coolant in the
appliance is stated on the data plate inside the appliance. It is hazardous for anyone other than an
Authorized Service Person to carry out servicing or repairs to this appliance.
•Take serious care when handling, moving and using the appliance to avoid either damaging the
refrigerant tubing or increasing the risk of a leak.
•Replacing component parts and servicing shall be done by factory authorized service personnel, so as
to minimize the risk of possible ignition due to incorrect parts or improper service.
FOLLOW WARNING CALLOUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL
•Use two or more people to move and install appliance. Failure to do so can result in back or other
injury.
•To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed.
Choose a well-ventilated area with temperatures above 44°F (7°C) and below 90°F (32°C).
•The appliance should not be located next to ovens, grills or other sources of high heat.
•The appliance must be installed with all electrical, water and drain connections in accordance with
state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in
accordance with the National Electrical Code and local codes and ordinances, is required.
•Do not kink or pinch the power supply cord of the appliance.
•The size of the fuse (or circuit breaker) should be 15 amperes.
•It is important that the appliance be leveled in order to work properly. You may need to make several
adjustments to level it.
•All installations must be in accordance with local plumbing code requirements.
•Make certain that the pipes are not pinched, kinked or damaged during installation.
•Check for leaks after connection.
•Never allow children to operate, play with or crawl inside the appliance.
•Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may damage
or discolor the interior.
•Use this appliance only for its intended purpose as described in this Instruction Manual.
•Keep fingers out of the “pinch point” areas. Clearances between the door and cabinet are necessarily
small. Be careful closing the door when children are in the area.
Risk of child entrapment!
Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances are
still dangerous, even if they will “just sit for a few days”.
Before discarding your old refrigerator:
•Take off the doors
•Leave the shelves in place so that children may not easily climb inside.
- SAVE THESE INSTRUCTIONS -

5
LOCATION OF PARTS
MODEL SPR627OS –OUTDOOR REFRIGERATOR
MODELS FF64B / FF64BSS –FROST-FREE REFRIGERATORS
Digital Control Panel
Shelves (3)
Bottom Grille
Adjustable Legs
LED Light
Security Lock
Stainless Steel Door
Stainless Steel Handle
MODEL SPFF51OS –OUTDOOR FREEZER
MODELS ALFZ53 / SCFF53BSSADA / LFZ24A / SCFF52W / SCFF53B / SCFF53BSS –FROST-FREE
FREEZERS
Shelves (3)
Bottom Grille
Adjustable Legs
LED Light
Security Lock
Door
Handle
Digital Control Panel

6
MODEL AL54 –FROST-FREE REFRIGERATOR
Digital Control Panel
Shelves (3)
Ventilation Grille
Adjustable Legs
LED Light
Security Lock
Stainless Steel Door
Stainless Steel Handle
Door Racks (2)
MODEL SPR628BCSS / SPR629WCSS –FROST-FREE REFRIGERATORS
Digital Control Panel
Shelves (3)
Kick-plate
Adjustable Legs
LED Light
Security Lock
Stainless Steel Door
Door Racks (2)

7
MODEL SPR316OS –OUTDOOR REFRIGERATOR
MODELS ALR15B / FF1532B / FF1532X / FF1532XCSS –FROST-FREE REFRIGERATORS
Digital Control Panel
LED Light
Shelves (3)
Door Racks
Kick-Plate
Adjustable Legs Security Lock
Stainless Steel Handle
Door
MODEL SCFF1533B –FROST-FREE FREEZER
Adjustable Legs
Kick-Plate
Shelves (3)
LED Light
Security Lock
Stainless Steel Handle
Door
Digital Control Panel

8
MODELS SPR618OSADA / LASD2418 / SPR618OS / ASDS2413CSS / LASS2432CSS /
ADSS2443CSS - OUTDOOR REFRIGERATORS
MODELS ASDS2413 / LASS2432 / ADSS2443 / SDS2417 / LRS2436 / SDSS2447 - FROST-FREE
REFRIGERATORS
MODELS ASDS1523 / LASS1544 / ADSS1553 / SDS1528 / LR1548 / SDSS1557 - FROST-FREE
REFRIGERATORS
NOTE: Models designated for outdoor use (find “OS” in suffix of model
number) have a reinforced exterior and heavy-duty cord to help
withstand the elements.
Shelves (3)
Digital Control
Panel
Ventilation
Grille
LED Light
Handle
Door
Security
Lock
Adjustable
Legs Cabinet
Shelves (3)
Handle
Door
Ventilation
Grille
LED Light
Security
Lock
Digital Control
Panel
Adjustable
Legs Cabinet

9
INSTALLATION INSTRUCTIONS
BEFORE USING YOUR APPLIANCE
•Remove the exterior and interior packing.
•Before connecting the appliance to the power source, let it stand upright for approximately 2 hours. This
will reduce the possibility of a malfunction in the cooling system from handling during transportation.
•Clean the interior surface with lukewarm water using a soft cloth.
•Install the handle on the door, if it is not already attached. (See page 11.)
INSTALLATION OF YOUR APPLIANCE
•The appliance is designed for built-in or recessed or free-standing installation for indoor use for models
ALR15B, FF1532B, FF1532X, FF1532XCSS, AL54, FF64B, FF64BSS, SCFF1533B, SPR628BCSS,
SPR629WCSS, ASDS1523, LASS1544, ADSS1553, SDS1528, LR1548, SDSS1557, ASDS2413,
LASS2432, ADSS2443, SDS2417, LRS2436, SDSS2447, SCFF52W, SCFF53B and SCFF53BSS, and
outdoor use for SPR316OS, SPR627OS, SPR618OSADA, LASD2418, SPR618OS, ASDS2413CSS,
LASS2432CSS, ADSS2443CSS and SPFF51OS.
•CAUTION: This appliance is not designed for the storage of medicine or other medical products.
•Place your appliance on a floor that is strong enough to support it when it is fully loaded. To level the
unit, adjust the front leveling legs.
•For free standing installation, 5”(127mm) of space between the back and sides of the unit, and 4”
(102mm) at the top, are suggested, which allows the proper air circulation to cool the compressor and
condenser. Even for built-in installation, it is a must to keep ¼” (6.35mm) space on each side and at the
top and 2” (51mm) at the rear. Take care that the air vent at the front of the appliance is never covered
or blocked in any way.
•NOTE: It is recommended that you do not install the appliance near an oven, radiator or other heating
source. Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Don’t install in a location where the temperature will fall below 44°F (7°C). For best
performance, do not install the appliance behind a cabinet door or block the base grille.
•Avoid locating the unit in moist areas.
•Plug the appliance into an exclusive, properly grounded wall outlet.
ELECTRICAL CONNECTION
This appliance should be properly grounded for your safety. The power cord of this appliance is equipped
with a three-prong plug which mates with standard three-prong wall outlets to minimize the possibility of
electrical shock.
Do not under any circumstances cut or remove the third (ground) prong from the power cord supplied. For
personal safety, this appliance must be properly grounded. Any questions concerning power and/or
grounding should be directed toward a certified electrician or an authorized service center.
This appliance requires a standard 115/120 Volt AC ~ 60Hz three-prong grounded electrical outlet. Have
the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly grounded.
When a standard 2-prong wall outlet is encountered, it is your responsibility and obligation to have it
replaced with a properly grounded 3-prong wall outlet.
WARNING
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by a qualified electrician or an authorized service center.

10
To prevent accidental injury, the cord should be secured behind the appliance and not left exposed or
dangling.
The appliance should always be plugged into its own individual electrical outlet which has a voltage rating
that matches the rating label on the appliance. This provides the best performance and also prevents
overloading house wiring circuits that could cause a fire hazard from overheating. Never unplug the
appliance by pulling on the power cord. Always grip the plug firmly and pull straight out from the receptacle.
Repair or replace immediately all power cords that have become frayed or otherwise damaged. Do not use
a cord that shows cracks or abrasion damage along its length or at either end. When moving the appliance,
be careful not to damage the power cord.
EXTENSION CORD
Because of potential safety hazards under certain conditions, it is strongly recommended that you do not
use an extension cord with this appliance. However, if you must use an extension cord, it is absolutely
necessary that it be a UL/CUL-Listed, 3-wire grounding type appliance extension cord having a grounding
type plug and outlet and that the electrical rating of the cord be 115 volts and at least 10 amperes.
REVERSING THE DOOR SWING OF YOUR APPLIANCE
This unit has the capability of the door opening from either the left or right side. The unit is delivered to
you with the door opening from the left side. Should you desire to reverse the opening direction, please
follow the reversal instructions shown below.
NOTE: All parts removed must be saved to allow the door swing to be reversed.
1. Remove the bottom hinge (2) by unscrewing the four lock screws (1). Be careful to hold the door firmly
after removing the screws. (Fig. 1)
2. Gently pull down to remove the door from the right top hinge and place it on a padded surface to avoid
the risk of damage. Then remove the right top hinge (4). (Figs. 3 & 4)

11
3. Unscrew and transfer pins (3) and (7) of the hinge plate to the opposite side. (Fig. 2)
4. Pop out the cover caps on the left side of the cabinet and use them to cover the screw holes on the
right-hand side.
5. Screw the alternative left top hinge (6), included in the fittings, on the left hand side of the cabinet. (Fig.
3)
6. Relocate the door to the designated position. Then screw the bottom hinge assembly on the left
designated position and tighten it after the door is leveled.
7. Remove the handle from the left side of the door and install it on the right side. (See Installing the
Stainless Steel Handle.)
ADJUSTING THE HEIGHT OF THE UNIT
The height of the ADA refrigerators can be increased by up to 3” by turning the adjustable legs. Once the
desired height has been achieved, the gap between the kick-plate and the floor can be covered by
lowering a hidden section of the kick-plate. See the next section for instructions.
ADJUSTING THE KICK-PLATE
The pre-fitted kick-plate of the appliance includes an adjustable kick-
plate section that is initially seated behind the upper section. In order
to adjust the kick-plate height, follow the instructions below:
1. Remove the screws (1) from both the top left- and top right-hand
sides of the kick-plate.
2. Loosen or remove the screws (2) from both the bottom left and
bottom right-hand sides of the kick-plate. Failure to loosen the
bottom screws sufficiently may cause damage to the lower trim
when adjusting it.
3. Carefully guide the lower trim down until the desired height is achieved.
4. Reinsert screws and tighten them.
INSTALLING THE STAINLESS STEEL HANDLE
This appliance includes a stainless steel handle that is not required to
operate the unit. To install the handle, follow the instructions below:
1. Use a screwdriver to remove the screws on the side of the door
where the handle is to be installed.
2. Align the handle with the screws removed in step # 1. Tighten the
screws using a Phillips head screwdriver until the handle is both
flush and secured tightly against the door side. (DO NOT over-
tighten as this will cause damage to the stainless steel door
surface.)
Handle
Door
Screw

12
OPERATING YOUR APPLIANCE
It is recommended you install the appliance in a place where the ambient temperature is between 44º and
90ºF (7º to 32ºC). If the ambient temperature is above or below the recommended temperatures, the
performance of the unit may be affected. For example, placing your unit in extreme cold or hot conditions
may cause interior temperatures to fluctuate. The operating temperature range may not be reached.
CONTROL PANEL for REFRIGERATORS
ON/OFF Power
To turn the appliance OFF, press the symbol and hold for 5 seconds.
To turn the appliance ON, press the symbol and hold for 1 seconds.
LIGHT
To turn the interior light on/off, press and hold the key for 5 seconds. The interior light indicator
will light up or go out to confirm the selection. The interior light indicator is the dot at the bottom
right of the display.
UP
Used to increase (warm) the set temperature by 1°C/1ºF.
DOWN
Used to decrease (cool) the set temperature by 1°C/1ºF.
DOWN
Used to decrease (cool) the set temperature by 1°C/1ºF.
Setting the Temperature Control
•You can set the temperature by touching the UP and DOWN symbols. When you push either of
the two buttons for the first time, the LED readout will show the original temperature set
previously. (The temperature preset at the factory is 38°F, or 3°C.)
•The temperature you are setting will increase by one degree each time you touch the UP
symbol, and will decrease by one degree each time you touch the DOWN symbol.
•The range of the temperature control is from 36°F to 43°F.
•To view the set temperature at any time, touch the UP or DOWN symbol. The set temperature
will flash in the display window for 5 seconds. After 5 seconds, the temperature inside the unit
will reappear in the display window.
Interior Light
•The interior light makes it easy to view your items. Pressing and holding the LIGHT symbol for 5
seconds toggles between 2 modes of operation for the internal lights: functional (default) mode
and showcase mode. If you are in functional (default) mode, the lights will turn on only when the
door is open. If you are in showcase mode, the lights will be on whether or not the door is open.

13
Settings Mode
Certain settings on the wine cabinet can only be selected in settings mode.
ºF/ºC Selection
▪Lightly press and hold the UP key for 5 seconds.
▪Use the UP and DOWN keys to select the temperature display setting in Fahrenheit or Celsius
degree.
▪Press the POWER key to confirm your selection.
▪Press and hold the UP key for 5 seconds to leave settings mode. Otherwise, the appliance exits
settings mode automatically after approximately one minute.
Display Brightness
▪Lightly press and hold the UP key for 5 seconds and then press the POWER key once.
▪Use the UP and DOWN keys to select the brightness of the display. The factory default setting is
d1. d1: Dimmest setting
d2: Medium setting
d3: Brightest setting
▪Press the POWER key to confirm your selection.
▪Press and hold the UP key for 5 seconds to leave settings mode. Otherwise, the appliance exits
settings mode automatically after approximately one minute.
Interior Lighting Brightness
▪Lightly press and hold the UP key for 5 seconds and then press the POWER key twice.
▪Use the UP and DOWN keys to select the brightness of the interior lighting. The factory default
setting is L3.
L1: Dimmest setting
L2: Medium setting
L3: Brightest setting
▪Press the POWER key to confirm your selection.
▪Press and hold the UP key for 5 seconds to leave settings mode. Otherwise, the appliance exits
settings mode automatically after approximately one minute.
Fan Mode
▪Lightly press and hold the UP key for 5 seconds and then press the POWER key three times.
▪Use the UP and DOWN keys to select the fan mode. The factory default setting is F0.
F0: Silent mode - Energy saving mode
F1: DynaClima mode - half time
F2: DynaClima mode - full time
▪Press the POWER key to confirm your selection.
▪Press and hold the UP key for 5 seconds to leave settings mode. Otherwise, the appliance exits
settings mode automatically after approximately one minute.
Audible Tones
▪Lightly press and hold the UP key for 5 seconds and then press the POWER key four times.
▪Use the UP and DOWN keys to select the audible tones. The factory default setting is S1.
S0: Sensor tone ON, alarm tone OFF
S1: Sensor tone ON, alarm tone ON

14
S2: Sensor tone OFF, alarm tone OFF
S3: Sensor tone OFF, alarm tone ON
▪Press the POWER key to confirm your selection.
▪Press and hold the UP key for 5 seconds to leave settings mode. Otherwise, the appliance exits
settings mode automatically after approximately one minute.
CONTROL PANEL for FREEZERS
ON/OFF Power
To turn the appliance ON or OFF, press and hold the POWER key for 5 seconds.
NOTE: Pressing the POWER key once can switch off the audible alarm when the alarm is on.
SuperFreeze
SuperFreeze is used to freeze fresh food quickly. The function overrides the thermostat control and
will make the compressor operate continuously. It is not necessary to adjust the thermostat setting
when using this function. When the function is selected, the SuperFreeze indicator (dot at the
bottom right of the display) will be ON. The function can be canceled by pressing the key again and
the indicator will turn OFF. SuperFreeze will turn off automatically after 8 hours.
UP
Used to increase (warm) the set temperature by 1°C/1ºF.
DOWN
Used to decrease (cool) the set temperature by 1°C/1ºF.
ºF/ºC Selector
Select the temperature display setting in Fahrenheit or Celsius degree. To change the temperature
from Fahrenheit to Celsius or from Celsius to Fahrenheit, press and hold the SUPERFREEZE key
for 5 seconds.
Setting the Temperature Control
•You can set the temperature by pressing the UP and DOWN keys. When you press either of the
two keys for the first time, the LED readout will show the original temperature set previously.
(The temperature preset at the factory is 0°F, or -18°C.)
•The temperature you are setting will increase by one degree each time you press the UP key,
and will decrease by one degree each time you press the DOWN key.
•The range of the temperature control is from -11°F to 11°F.
•To view the set temperature at any time, press the UP or DOWN key. The set temperature will
flash in the display window for 5 seconds. After 5 seconds, the temperature inside the unit will
reappear in the display window.
Interior Light
The unit is equipped with an interior LED light which will be turned ON when the door is open.

15
SABBATH MODE
Sabbath mode is available for the observance of certain religious holidays. This mode turns off the displays,
interior light and audible alarms and prevents them from turning on again. Normal cooling operations will
still take place.
To initiate Sabbath mode, press the POWER and LIGHT keys at the same time for at least 5 seconds for
the refrigerators, or press the POWER and SUPERFREEZE keys at the same time for at least 5 seconds
for the freezers. The temperature display will go out to confirm that the Sabbath mode is ON.
Sabbath mode can be canceled by repeating the above process. The Sabbath Mode will automatically turn
off after 48 hours.
TEMPERATURE MEMORY FUNCTION
•In the event of a power interruption (power surge, breaker switch, etc.), the unit can remember the
previous temperature settings, and when the power is recovered, the cabinet temperature will return
to the same setting temperature as before the power went off.
DEFROSTING
•The unit defrosts automatically in normal operating conditions.
•The evaporator behind the rear wall of the unit defrosts automatically. The condensate collects in the
drainage channel behind the rear wall of the unit, and flows through the drainage hole into the drip tray
by the compressor where it evaporates.
•However, frost may accumulate on the evaporator if the unit is repeatedly opened in a high heat or high
humidity location. If this frost pattern does not clear within 24 hours, your unit will require manual
defrosting.
USING THE FREEZER
•These freezers are designed for the long-term storage of frozen food. Storage time is up to three
months.
•The storage life of frozen foods varies and the recommended storage time should not be exceeded.
•Pre-packaged commercially frozen food should be stored in accordance with the frozen foods
manufacturer’s instructions for a three star frozen food storage compartment or home freezer.
•Place frozen food into the freezer as quickly as possible after purchase. If there are instructions on the
packet, carefully follow these instructions regarding storage times.
NOTE:
•If the unit is unplugged, or power is lost or turned off, you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the unit will not start.
•When you use the unit for the first time or restart the unit after it has been shut off for a long time,
there could be a few degrees variance between the temperature you select and the one indicated
on the LED readout. This is normal and is due to the length of the activation time. There should
not be a problem once the unit has been running for a few hours.

16
TEMPERATURE ALARM / DOOR ALARM
•An audible alarm sounds if the storage temperature is not cold enough. The temperature display
flashes at the same time.
•The cause of the temperature being too high may be:
–Warm fresh food was placed inside
–Too much warm ambient air flowed in when rearranging and removing food
–Power failure for some time
–The appliance is faulty
•The audible alarm is automatically silenced and the temperature display stops flashing when the
temperature is sufficiently cold again.
•If the door has been left open for more than 60 seconds, the alarm will sound. Pressing the POWER
key once can switch off the audible alarm.
DOOR LOCK
Your unit is provided with a lock and key combination.
The keys are located inside the plastic bag that contains the Instruction Manual. Insert the key into the
lock and turn it counter-clockwise to unlock the door. To lock the door, do the reverse operation, making
sure the metal pin is engaged completely. Remove the key and put it in a secure place for safekeeping.
SHELVES
To prevent damaging the door gasket, make sure to have the door all the way open when pulling the
shelves out of the rail compartment.
•Any of the shelves can be removed to store larger items.
•When removing the shelf out of the rail compartment, make
sure to remove all items first. Then move the shelf to the
position where the notch of the shelf is exactly under the
plastic post and lift the shelf. In order to replace the shelf,
repeat steps described above in reverse.

17
CARE AND MAINTENANCE
CLEANING YOUR APPLIANCE
•Turn off the power, unplug the appliance, and remove all items, including shelves.
•Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of baking
soda to a quart of water).
•Wash the shelves with a mild detergent solution.
•Wring excess water out of the sponge or cloth when cleaning the area where the controls are located,
or any electrical parts.
•Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with a
clean soft cloth.
•Use an approved stainless steel cleaner to clean the door and handle. Do not use steel wool or a steel
brush on the stainless steel.
CAUTION:
Failure to unplug the appliance during cleaning could result in electrical shock or other personal injury .
POWER FAILURE
Most power failures are corrected within a few hours and should not affect the temperature of your appliance
if you minimize the number of times the door is opened. If the power is going to be off for a longer period
of time, you need to take the proper steps to protect the contents.
VACATIONS
•Short vacations: Leave the appliance operating during vacations of less than three weeks.
•Long vacations: If the appliance will not be used for several months, remove all items and turn off the
appliance. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave the door
open slightly, blocking it open if necessary.
MOVING YOUR APPLIANCE
1. Remove all items.
2. Securely tape down all loose items (shelves) inside your appliance.
3. Turn the adjustable legs up to the base to avoid damage.
4. Tape the door shut.
5. Be sure the appliance stays secure in the upright position during transportation. Also, protect the
outside of the appliance with a blanket or similar item.
ENERGY-SAVING TIPS
•The appliance should be located in the coolest area of the room or outdoor location, away from heat-
producing appliances and out of direct sunlight.
•Ensure that the unit is adequately ventilated. Never cover air vents.
•Do not keep the door open any longer than necessary.
•Let hot foods cool to room temperature before placing in the unit. Overloading the unit forces the
compressor to run longer.
•Be sure to wrap foods properly, and wipe containers dry before placing them in the unit. This cuts down
on frost build-up inside the unit.
•Unit shelves and storage bins should not be lined with aluminum foil, wax paper, or paper toweling.
Liners interfere with cold air circulation, making the unit less efficient.
•Organize and label food to reduce door openings and extended searches. Remove as many items as
needed at one time, and close the door as soon as possible.

18
TROUBLESHOOTING
You can solve many common problems easily, saving you the cost of a possible service call. Try the
suggestions below to see if you can solve the problem before calling the servicer.
Troubleshooting Guide
PROBLEM
POSSIBLE CAUSE
REMEDY
Appliance
does not
operate.
•Appliance is not connected to a power
supply.
•The appliance is turned off.
•Tripped circuit breaker or a blown fuse.
•Connect the appliance.
•Switch on the appliance.
•Switch on circuit breaker or replace
fuse.
Appliance is
not cold
enough.
•The temperature is not set correctly.
•The ambient temperature could require
a lower temperature setting.
•The door was opened too often.
•The door was not closed completely.
•Door is not hermetically sealed.
•The condenser is too dirty.
•The ventilation opening is blocked or too
dusty.
•Check the set temperature.
•Set a lower temperature.
•Do not open the door more often than
necessary.
•Close door properly.
•Check the door seal and clean or
replace.
•Clean the condenser when
necessary.
•Clear the obstructions and clean the
dust.
Appliance
turns itself on
and off
frequently.
•The room temperature is higher than
average.
•A large amount of food has been added
to the unit.
•The door is open too often.
•The door is not closed completely.
•The door gasket does not seal properly.
•Put the appliance in a cooler place.
•Leave the appliance to work for a
while until the set temperature has
been reached.
•Do not open the door more often than
necessary.
•Close door properly.
•Check the door seal and clean or
replace.
The light does
not work.
•Appliance is not connected to a power
supply.
•Tripped circuit breaker or a blown fuse.
•The light was switched off on the
control panel.
•Connect the appliance.
•Switch on circuit breaker or replace
fuse.
•Switch on the light.
Vibrations
•The appliance is not properly leveled.
•Level the appliance with the
adjustable feet.
The appliance
seems to
make too
much noise.
The rattling noise may come from the flow of the refrigerant, which is normal. As each
cycle ends, you may hear gurgling sounds caused by the flow of refrigerant in your
appliance.
If temperature fluctuations occur, the contraction and expansion of the inner walls
may cause popping and crackling noises.
•The appliance is not properly level.
•Level the appliance with the
adjustable feet.
The door will
not close
properly.
•The appliance is not properly level.
•The door was reversed and not
properly installed.
•The gasket is dirty.
•Level the appliance with the
adjustable feet.
•Check the door hinge and
reassemble correctly.
•Clean the door gasket.

19
•The shelves are out of position.
•Check the shelves and refit correctly.
Display “E0”,
“E1”. “E2”,
“E3”, “E4”,
“E5”or “E7”.
•“E0”indicates a communication error for
3-zone models.
•“E1”or “E2”indicates that the air
temperature sensor has failed.
•“E3”or “E4”indicates that the defrost
sensor in the evaporator has failed.
•“E5”indicates a defrost heater failure.
•“E7”indicates a door switch failure.
•Call for service.
The alarm
sounds and
the
temperature
display
flashes.
Has the appliance door been open for
longer than 60 seconds? If not, then the
temperature has risen higher or fallen
lower than the temperature that has been
set. This could be due to:
•The appliance door being opened too
often.
•The ventilation opening being covered
or too dusty.
•A lengthy interruption in the power
supply.
•A large amount of food has been added
to the unit.
If yes, close the door.
•Do not open the door more often than
necessary.
•Clear the obstructions and clean the
dust.
•Leave the appliance to work for a
while until the set temperature has
been reached.
The icon “--” is
lit and flashing
in the
temperature
display.
•The display temperature is out of
range.
•Only temperatures within the range
0~99°F/-9~37°C for refrigerators and
the range -49~99°F/-45~37°C for
freezers can be displayed. If the
temperature is not within this range,
the icon “--”will be displayed instead.
This is normal.
If you've checked the table above and find that you still need help with your appliance, call our Customer
Service facility at 800-932-4267 between 9:00AM and 5:00PM ET. We will do our best to answer your
questions.
CALIFORNIA CARB/SNAP DISCLOSURE
This product uses eco-friendly hydrocarbon refrigerant and fully complies with California
CARB regulations.
However, we are required by California Law to provide the following disclosure statement in every
product sold in California.
"This equipment is prohibited from use in California with any refrigerants on the 'List of Prohibited
Substances' for that specific end-use, in accordance with California Code of Regulations, title 17,
section 95374. This disclosure statement has been reviewed and approved by Felix Storch, Inc. and
Felix Storch, Inc. attests, under penalty of perjury, that these statements are true and accurate."
This product does not use any refrigerants on the 'List of Prohibited Substances'"

20
LIMITED WARRANTY
ONE-YEAR LIMITED WARRANTY
Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is
operated and maintained according to instructions attached to or furnished with the product, warrantor will
pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service
must be provided by a designated service company. Outside the 48 states, all parts are warranted for one
year from manufacturing defects. Plastic parts, shelves and cabinets are warranted to be manufactured to
commercially acceptable standards, and are not covered from damage during handling or breakage.
5-YEAR COMPRESSOR WARRANTY
1. The compressor is covered for 5 years.
2. Replacement does not include labor.
ITEMS WARRANTOR WILL NOT PAY FOR:
1. Service calls to correct the installation of your appliance, to instruct you how to use your appliance, to
replace or repair fuses or to correct wiring or plumbing.
2. Service calls to repair or replace appliance light bulbs or broken shelves. Consumable parts (such as
filters) are excluded from warranty coverage.
3. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper
installation, installation not in accordance with electrical or plumbing codes, or use of products not
approved by warrantor.
4. Replacement parts or repair labor costs for units operated outside the United States.
5. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
6. The removal and reinstallation of your appliance if it is installed in an inaccessible location or is not
installed in accordance with published installation instructions.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE
PRODUCT REPAIR AS PROVIDED HEREIN. IMPLIED WARRANTIES, INCLUDING WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR.
WARRANTOR SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME
STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS, SO THESE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU. THIS
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS,
WHICH VARY FROM STATE TO STATE.
For parts and accessory ordering,
troubleshooting and helpful hints, visit:
www.summitappliance.com/support
FELIX STORCH, INC.
770 Garrison Avenue
Bronx, NY 10474
Phone: [phone]
Fax: [phone]
www.summitappliance.com
WARNING: This product can expose you to chemicals including Nickel
(Metallic) which is known to the State of California to cause cancer.
For more information go to www.P65Warnings.ca.gov
Note: Nickel is a component in all stainless steel and some other metallic compositions.
