Summit CP-35 User manual

CP35 33.5" x 18.75" x 20.25" (H x W x D)
Compact ENERGY STAR listed two-door
refrigerator-freezer with cycle defrost and zero degree
freezer
Highlights:
Extremely narrow 19" width fits into even the tightest spaces
Ice cream stays frozen in zero degree freezer
ENERGY STAR Listed for true efficiency
Cycle defrost system saves energy while protecting food
Thin-line design Limited space is no problem for our thin-line models, designed specifically for those hard-to-fit spots
Reversible doors Keep your options flexible with reversible doors that are easy to switch when your arrangement changes
ENERGY STAR
qualified Rated by the DOE to perform with more efficiency than federal standards require, saving your unit energy and you on higher utility costs
Interior light Automatically illuminates when you open the door
Door storage Store large bottles right on the door for easy access
Two-door design One of the few two-door refrigerator-freezer units of its size in the industry
Adjustable shelves Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple
clean-up
Adjustable
thermostat Control your food's temperature with ease and accuracy
Fruit and vegetable
crisper Get the longest life and best taste out of produce by storing it in a convenient slide drawer
Cycle defrost Combines an automatic defrosting refrigerator with a manual defrosting freezer to save energy

Specifications:
Height 33.5"
Width 18.75"
Depth 20.25"
Capacity 2.9 cu.ft.
Interior Height 1 19.0"
Interior Width 1 16.0"
Interior Depth 1 14.0"
Interior Height 2 6.0"
Interior Width 2 14.0"
Interior Depth 2 10.5"
Comp Step Height 8.0"
Comp Step Width 19.0"
Comp Step Depth 4.0"
Shipping Weight 102.0 lbs.
Canadian Electrical Safety ULC
Energy Usage/Year 290.0 kWh/year
US Electrical Safety UL
Voltage/Frequency 115 V AC/60 Hz
Amps 1.4
Other Energy Info 120 Volts / 60 Hz.
Door Swing RHD
Reversible Yes
Crisper Quantity 1
Shelf Quantity 1
Adjustable Shelf true
Shelf Type Wire
Crisper Cover Type Glass
Crisper Finish Transparent
Full Door Shelf Quantity 2
Defrost Type Cycle
Height to Hinge Cap 33.5"
Depth with door at 90° 37.25"
Thermostat Type Dial
Light true
Condensor Location Rear of Unit
High Side PSI 235.0
Freon Type R134a
Low Side PSI 140.0
Level Legs Quantity 2
Freon Oz 2.6
Compressor Warranty 5 Years
Parts/Labor Warranty 1Year
