Sunartis ME-316 User manual

Model: ME-316
Instruction Manual
Wireless Meat & BBQ Thermometer

GB
TABLE OF CONTENTS
Item drawing
Item description
Introduction
Intended use
Safety instructions
Instructions for handling batteries
Before initial use
Usage
Insert/ replace batteries
Installation/ starting
Insert the measuring probe
Set the food type and cooking setting
Special cake and baking function
Table of preset core (target) temperatures
Set the optional target temperature
Set timer and stopwatch
Cleaning, care and storage
1
2
3
3
4 - 5
6 - 7
7
8 - 14
8
8 - 10
10
11
12
13
13
14
15

TABLE OF CONTENTS
Technical data
Symbols on the packaging
Protecting the environment
Disposal of electrical devices
Disposal of batteries
Disposal of the packaging
After Sales Service
Service adress
Service hotline
16
16
17
17
17
17
18
18
18
GB

51
3
4
2
2g
2b
2e
2f
2a
2c
2d
GH
AI
F
C
E
B
D
J
1GB

ITEM DESCRIPTION:
Receiver:
1 On- / O switch
2 Control keys
3 Belt clip with magnet
4 Battery compartment / compartment lid
5 LC-display (with 2 color back light: green and red)
Control keys on the receiver:
2a GO /STOP-key: Start and stop
2b RESET-key: Reset the time
2c GRADATION-key: Select the required cooking setting
2d MODE-key: switch °C / °F or for an individual target temperature
setting on any food desired
2e FOOD-key: Select the food for cooking
BEEF, LAMB, VEAL, HAMBURGER,
PORK, FISH, TURKEY, CHICKEN, CAKE
2f SEC-key: Set the seconds for the time in timer mode or reduce an
individual target temperature setting
2g MIN-key: Set the minutes for the time in timer mode or reduce an
individual target temperature setting
Base station (transmitter):
A On- / O switch
B LED operating control light
C Measuring probe socket
D Magnet holder of base station
E Eyelets for Velcro tape
F Battery compartment / lid
G Velcro tape for fastening
H Measuring probe / cable / plug
I Frequency selector switch
J Holder for receiver
2
GB

INTRODUCTION:
Congratulations on purchasing your new Wireless Meat and
Barbecue Thermometer. With this item you have purchased a
high quality product.
This operating manual is an integral part of this product and
contains important information on its safety, use and waste
disposal. Familiarise yourself with all operating and safety in-
structions before using the product. Only use the product as
described and only for the purposes specied.
Keep this operating manual in a safe place. If you pass on the
product to third parties, ensure that you give them all the
documentation as well.
INTENDED USE:
This wireless meatand barbecue thermometer with receiver
and base station, hereinafter known as the device, is designed to
measure and monitor the internal temperature of food being
cooked, roasted, baked or barbecued. Any other use or
modication of the device will be deemed to be unintended,
may damage the device and may pose signicant accident risks.
This device is exclusively designed for private use. It is not de-
signed for use in commercial or industrial environments.
The manufacturer cannot accept any liability for any damage
resulting from unintended use, incorrect use or a failure to obey
the instructions in this operating manual.
3GB

SAFETY INSTRUCTIONS:
CAUTION! Making errors in following the instructions below may
result in electric shocks, re and / or serious injuries.
1. Read this operating manual and in particular the safety in-
structions completely before using the device for the rst time.
2. This device complies with the technical standards and the
relevant safety requirements for electrical devices.
3. This device may be used by children aged 8 or over and by
people with reduced physical, sensory or mental abilities or
lacking experience and knowledge if they are supervised and
receive instruction in how to use the device safely and if they
understand the resulting dangers.
4. Children must not be allowed to play with the device. Keep the
device and the cable on the temperature measuring probe
away from children. Cleaning and user maintenance must not
be carried out by children without supervision.
5. Keep the temperature probe away from children.
6. Do not allow people who are not familiar with this device and
who have not read these instructions to use the device.
7. Never open the housing and do not insert any items into
the housing.
8. Do not immerse the device in water. Do not allow any liquids
to get inside the device.
9. This device may only be used in a dry environment and never
in rain or extreme moisture.
4
GB

SAFETY INSTRUCTIONS:
10. Do not use, store or place the device on or near hot surfaces
and naked ames, such as cook plates, ovens, radiators or
candles.
11. Keep the device out of direct sunlight.
12. Check the device at regular intervals for signs of damage.
13. IMPORTANT. Do not use the device if it is damaged.
14. Contact our After-Sales Service team if the device
malfunctions or shows obvious signs of damage.
15. DANGER OF INJURY. To avoid injury, defective components
may only be replaced by the manufacturer, its After-Sales
Service team or similar trained personnel.
16. Do not make any modications to the device.
17. DANGER OF INJURY. Always wear cooking, oven or barbecue
gloves when touching the temperature measuring probe (H)
all the cable during or immediately after use. Never touch the
cable or the temperature measuring probe (H) with your bare
hands.
18. NEVER use the device in a microwave.
19. CAUTION. The temperature measuring probe (H) and the
cable may be used in a maximum temperature of 380°C.
Ensure that the base station is installed away from hot sur-
faces since otherwise it may suer irreparable damage.
5GB

INSTRUCTIONS FOR HANDLING BATTERIES:
Please note the following for handling batteries.
Never throw batteries into a re. Do not attempt to charge non-
rechargeable batteries. Danger of explosion and injury.
• Only replace batteries with the same or an equivalent battery
type.
• Always replace all the batteries at the same time and do not use
new batteries with used ones or batteries with dierent charge
levels.
• Never attempt to open batteries.
• Never carry out soldering or welding work on batteries. Danger
of explosion and injury.
• The connections must not be short-circuited.
• Ensure that you insert the batteries the right way round.
• Refer to the polarity (+) / (-) marks on the battery and on the
battery compartment (7). Incorrectly inserted batteries may
cause them to leak or in extreme cases may cause a re or
explosion.
• Never expose batteries to excessive heat (for example strong
sunlight or re). The batteries may explode.
• Check the batteries at regular intervals. Leaking batteries may
damage the device.
• Remove exhausted batteries. Also remove the batteries if you
know that you won‘t be using the product for a lengthy period
of time. Otherwise the batteries may leak and damage the
device.
• Remove the batteries before disposing of the device.
6
GB

INSTRUCTIONS FOR HANDLING BATTERIES:
• Danger of injury: If batteries have leaked, remove them from the
battery compartment using a cloth and dispose of them
properly. Avoid skin and eye contact with the battery acid. If
your eyes come into contact with battery acid, rinse them with
lots of water and contact a doctor immediately. If your skin
comes into contact with battery acid, rinse the area immediately
with lots of soap and water.
• Keep the batteries out of the reach of children. Children could
put batteries in their mouth and swallow them. If a battery has
been swallowed, seek immediate medical assistance.
BEFORE USING FOR THE FIRST TIME:
Remove all packaging materials and check the device and
accessories for signs of damage.
NOTE:
Clean the temperature measuring probe (H) before using for the
rst time as described in the section entitled
"Cleaning, care and storage".
7GB

USAGE:
INSERT/REPLACE BATTERIES:
1. Open the battery compartment (4) on the receiver and the
battery compartment on the base station (F). Remove the old
batteries if there are any and insert two type AAA/LR03 1.5V
batteries using the polarity indicators in the battery
compartment.
2. Close the battery compartment (4) on the receiver with the
battery compartment cover (4) and the battery compartment
of the base station (F) with its cover (F).
NOTE:
The batteries are NOT supplied with the device.
To operate the device you require four LR03 / AAA 1.5 V batteries,
two for the base station and two for the receiver.
INSTALLATION/STARTING:
NEVER use the device in a MICROWAVE.
Route the cable for the temperature measuring probe (H) away
from the food and the heat source (max. 380°C). Keep the base
station the receiver away from hot surfaces since they could
otherwise be irreparably damaged.
1. Secure the base station using the magnets (D) tted on the
base plate or using the Velcro tape (G).
8
GB

NOTE:
Thread the Velcro tape (G) through the two eyelets (E) on the
underside of the base station so that the hook side of the Velcro
faces the base.
2. You can attach the receiver to your belt or trouser pocket using
the belt clip (3) or the attached magnets.
3. Insert the plug on the temperature measuring probe (H) into
the socket (C) on the base station.
4. Slide the On/O switch (A) on the base station into the "ON"
position to switch on the base station. The LED operating
control lamp (B) will indicate that it is ready for use by ashing
briey.
5. Slide the On/O switch (1) On the receiver into the "ON"
position to switch on the receiver. The LC display (5) will light
up green and the current temperature being measured on the
temperature measuring probe (H) will be shown under
CURRENT TEMP.
6. The device is now ready for use.
NOTE:
The base station will send the current temperature to the re-
ceiver at short regular intervals and this will be shown in the LC
display (5) under (CURRENT TEMP) unless the temperature
changes. As soon as the temperature changes, the updated
actual temperature will be sent automatically by the base station
to the receiver.
9GB

NOTE:
The frequency selector switch (I) on the base station enables you
to select three dierent transmission channels. The receiver will
automatically nd the channel set on the base station each time
the transmitter and base station are switched on. If several
devices are being used simultaneously in the transmission range
of the transmitter (max. 20 m), the transmission channel must be
changed using the frequency selector switch (I) before the
device is switched on. It is not possible to change the frequency
during use.
INSERT THE TEMPERATURE MEASURING PROBE (H):
The temperature measuring probe (H) and the cable may be
used in a maximum temperature of 380°C. Ensure that the base
station is installed away from hot surfaces since otherwise it may
suer irreparable damage.
Insert the tip of the temperature measuring probe (H) into the
side of the thickest point of the food whose temperature you
wish to monitor so that you can turn the food as it cooks.
NOTE:
Ensured that you do not touch any fat, gristle or born with the tip
of the temperature measuring probe (H) since otherwise the
temperature measurement could be falsied.
Always wear cooking, oven or barbecue gloves when touching
the temperature measuring probe (H) all the cable during or
immediately after use.
10
GB

When the temperature measuring probe (H) has been correctly
positioned and the On/O switches (A /1) on the base station
and receiver have been set to "ON", you must select the
measuring unit:
1. Press the MODE key (2d) to select degrees Celsius °C or
degrees Fahrenheit °F.
NOTE:
The thermometer can display temperatures in the following
temperature ranges: 0°C – 250°C (32°F – 482°F). If you attempt to
measure temperatures below 0°C (32°F), LLL will be displayed on
the LC display (5) at (CURRENT TEMP). If you attempt to measure
temperatures over 250°C (482°F), HHH will be displayed on the
LC display (5) at (CURRENT TEMP). In this case remove the tem-
perature measuring probe (H) immediately to prevent it being
damaged.
2. SET THE FOOD TYPE (2e) AND COOKING SETTING (2c):
The device has preset cooking target temperatures for various
food types and, if applicable, the required cooking settings.
The preset target temperature is shown on the LCD display (5) on
the receiver under TARGET TEMP. The target temperature can be
set as required on the receiver using the FOOD (2e) and
GRADATION (2c) keys. Repeatedly press the FOOD key (2e) until
you have selected the required food type. Then press the
GRADATION key (2c) until you have selected the required
cooking setting. The device will now automatically start the
measuring process.
11 GB

SPECIAL CAKE AND BAKING FUNCTION:
If you select the cake function, it makes sense not to use the
temperature measuring probe (H) until the mixture has a slight
crust to ensure that it does not sink into the liquid mixture. For
cakes and other baked goods, you should ideally insert the tem-
perature measuring probe (H) at an angle into the cake mixture
and submerge at least one-third of the total length of the tem-
perature measuring probe (H) into it.
The list of preset food types and the possible settings for them is
set out in the table below:
NOTE:
Refer to the following page of this man-
ual to nd out how to set an own target
temperature.
Doneness
Food
Well done
WELL
Medium well
done
M WELL
Medium
MEDIUM
Medium rare
M RARE
Rare
RARE
BEEF
LAMB
VEAL
HAMBURGER
PORK
FISH
TURKEY
CHICKEN
CAKE
76°C
76°C
76°C
76°C
71°C
71°C
71°C
71°C
71°C73°C
73°C
73°C
58°C
79°C
79°C
96°C
62°C
62°C
62°C
60°C
60°C
12
GB

SET THE OPTIONAL TARGET TEMPERATURE:
• Press the MODE key (2d) until the TARGET TEMP display ashes.
• Press the MIN key (2g) and the SEC key (2f) until you have set
the required target temperature. Pressing and holding these
keys will speed up the setting process for target temperature.
• Press the MODE key (2d) again to conrm target temperature.
3. When the required target temperature has been reached, the
LC display (6) will turn red, the device will start to beep and the
CURRENT TEMP and TARGET TEMP displays will start to ash.
NOTE:
You can stop the beeping temporarily by pressing one of the
2a – 2g keys. The beeping can only be completely switched o by
removing the temperature measuring probe (H) from the
cooking zone or by switching o the receiver or transmitter by
pressing the On/O switch (1/A) on the base station or receiver.
13 GB

SET THE TIMER/STOPWATCH:
This device has a timer and a stopwatch which can be used inde-
pendently of the temperature measuring probe (H). The time can
be counted upwards or downwards when these functions are
being used. The maximum time which can be set on the timer is
99:59 (MIN:SEC).
TIMER:
To count time downwards, press MIN- (2g) or the SEC key (2f)
until the required time is displayed. Pressing and holding these
keys will speed up the time setting process. Then press the
GO / STOP key (2a) to start the timer. When the timer has run
down, 0M:00S will ash in the LC display (5) and the device will
start to beep.
STOPWATCH:
To count the time upwards (stopwatch), press the GO / STOP key
(2a) without rst setting the time.
• For both these functions, press the GO / STOP key (2a) to stop
the selected count.
• You can reset both functions automatically to 00M:00S by
pressing the RESET key (2b).
If you are no longer using the device, slide the two On/O
switches (1 / A) into the "OFF" position and remove the batteries
if you are not planning to use the device for a lengthy period.
14
GB

CLEANING, CARE AND STORAGE:
WARNING Switch the device o and allow the temperature mea-
suring probe (H) and cable to cool before cleaning. The device
and its components are NOT DISHWASHER SAFE.
THIS DEVICE REQUIRES NO MAINTENANCE.
1. Read the safety instructions before cleaning.
2. Use a damp cloth and if necessary a mild detergent to clean
the housing.
3. After use, clean the temperature measuring probe (H) with
warm water and a little detergent and remove all food residue
and dirt particles since otherwise future measurement results
may be falsied.
4. Ensure that no water gets into the housing. Never immerse the
device in water or other liquids during cleaning or use. Never
hold the device under running water.
5. Never use sharp objects, petrol, solvent or cleaning products
which are aggressive to plastic.
6. The device must be clean and dry at all times.
7. Dry all the parts well before reusing the device or placing it in
storage.
8. Store the device and its accessories in a place where they will
be protected from dust, moisture and direct sunlight and
remove the batteries.
15 GB

TECHNICAL DATA:
Model number ME-316
Article number 5-8002
EAN code 4015177580022
Range max. 20 m
Receiver category 3
Measurable temperature range 0°C - 250°C (32°F-482°F)
Voltage supply, base station 2 x 1.5V - 3.0V
Battery type, base station 2 x AAA/ LR03 battery 1.5V
Voltage supply, receiver 2 x 1.5V - 3.0V
Battery type, receiver 2 x AAA/ LR03 battery 1.5V
Measuring probe material Stainless steel (SS304)
SYMBOLS ON THE PACKAGING:
The following contains brief details of the symbols used on the product
packaging.
Measuring range:
0°C to 250°C
Suitable for roasting
lamb
Suitable for roasting
beef and veal
Suitable for roasting
chicken and pork
Suitable for roasting
poultry
The device has a multilingual
instruction manual
Suitable for use in an
oven
Suitable for use in a
frying pan
The device has a timer
and stopwatch
Suitable for use on a
barbecue
IM
0°c
+250°c
DE / GB / FR / NL
16
GB

PROTECTING THE ENVIRONMENT:
Disposal of electrical devices
This product is subject to European Directive 2012/19/EU for
Waste Electrical and Electronic Equipment (WEEE) which states
that waste household devices must not be disposed of with
unsorted domestic waste. These used devices must be collected
separately from normal domestic waste to increase the propor-
tion of recycled devices and their materials with the aim of
reducing their eects on human health and nature. The symbol
of the waste bin crossed out is applied to all devices to remind
users of their duty to collect them separately. Consumers must contact their local
authority (for example licensed waste disposal contractors or local authority
waste disposal facilities) or the seller to nd out how they must dispose of their
device. Please comply with current regulations. If you are in any doubt, please
contact your waste management authority.
Disposal of batteries
Batteries must not be disposed of in domestic waste. All con-
sumers have a duty under law to deposit waste batteries at a
collection point operated by the local authority or local stores.
This duty is designed to ensure that batteries can be disposed
of safely. Only dispose of fully discharged batteries.
Disposal of the packaging
Help us by disposing of waste materials correctly. This packaging
can be recycled. Please dispose of it properly, using the correct
method for each material type.
17 GB
