SUNFEEL FGDD1864FX User manual

ELECTRONIC NO FROST
COMBI REFRIGERATOR
Freezer - Fridge
User manual
FRIGORÍFICO COMBI DOS PUERTAS
CON TECNOLOGÍA NO FROST
Congelador - Frigorífico
Manual de Instrucciones
FRIGORÍFICO COMBINADO
NO FROST
Congelador - Frigorífico
Manual do utilizador
FGDD1864F
FGDD1864FX

EN
2
Index
BEFORE USING THE APPLIANCE................................. 4
General warnings...................................................................... 4
Safety warnings ........................................................................ 7
Installing and operating your fridge........................................... 8
Before Using your Fridge.......................................................... 9
Information about New Generation Cooling Technology .......... 9
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS .......................................................... 10
THE VARIOUS FUNCTION AND POSSIBILITIES ......... 12
Display and control panel ........................................................ 12
Cooler Set Button .................................................................... 12
Sr Alarm................................................................................... 12
Operating your fridge............................................................... 13
Super cool mode ................................................................ 13
Economy mode.................................................................... 13
Cooler temperature settings .................................................... 13
Warnings about temperature adjustments............................... 14
ACCESSORIES ..............................................................15
Freezer box.............................................................................. 15
Chiller Shelf ............................................................................. 15
Humidity Controler................................................................... 16
Adjustable Door Shelf.............................................................. 17
Adjustable Glass Shelf............................................................. 17
CLEANING AND MAINTENANCE.................................. 18
Defrosting ................................................................................ 19
ARRANGING FOOD IN THE APPLIANCE..................... 20
Refrigerator compartment........................................................ 20
Freezer compartment .............................................................. 21
SHIPMENT AND REPOSITIONING................................ 26
Repositioning the door............................................................. 26

EN
3
BEFORE CALLING YOUR AFTER SALES SERVICE... 27
TIPS FOR SAVING ENERGY.......................................... 30

EN
4
General warnings
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear
of obstruction.
WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other
than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance,
unless they are of the type recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: To avoid a hazard due to the instability
of the appliance, it must be xed in accordance with
the instructions.
• If your appliance uses R600a as a refrigerant –
you can learn this information from the label on
the cooler- you should be careful during shipment
and installation to prevent your appliance’s cooler
elements from being damaged. Although R600a
is an environmentally friendly and natural gas.
As it is explosive, in the event of a leak due to
damage to the cooler elements, move your fridge
from open ame or heat sources and ventilate
the room where the appliance is located for a
few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as
aerosol cans with a ammable propellant in this
appliance.
• This appliance is intended to be used in
household and similar applications such as;
BEFORE USING THE APPLIANCE

EN
5
- staff kitchen areas in shops, ofces and other working
environments
- farm houses and by clients in hotels, motels and other
residential type environments
- bed and breakfast type environments;
- catering and similar non-retail applications
• If the socket does not match the refrigerator plug, it must
be replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a hazard.
• A specially grounded plug has been connected to the
power cable of your refrigerator. This plug should be used
with a specially grounded socket of 16 amperes. If there is
no such socket in your house, please have it installed by
an authorized electrician.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazard involved. Children shall not play with the appliance.
Cleaning and user maintenance, shall not be made by
children without supervision.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similar qualied persons
in order to avoid a hazard.
• This appliance is not intended for use at altitudes
exceeding 2000 m.
BEFORE USING THE APPLIANCE

EN
6BEFORE USING THE APPLIANCE
Old and out-of-order fridges
• If your old fridge has a lock, break or remove the lock
before discarding it, because children may get trapped
inside it and may cause an accident.
• Old fridges and freezers contain isolation material and
refrigerant with CFC. Therefore, take care not to harm
environment when you are discarding your old fridge.
Please ask your municipal authority about the disposal of the
WEEE for the reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before
installing and using your appliance. We are not responsible
for the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction
manual, and keep this manual in a safe place to resolve
the problems that may occur in the future.
• This appliance is produced to be used in homes and it
can only be used in domestic environments and for the
specied purposes. It is not suitable for commercial or
common use. Such use will cause the guarantee of the
appliance to be cancelled and our company will not be
responsible for the losses to be occurred.
• This appliance is produced to be used in houses and it is
only suitable for cooling / storing foods. It is not suitable for
commercial or common use and/or for storing substances
except for food. Our company is not responsible for the
losses to be occurred in the contrary case.

EN
7
BEFORE USING THE APPLIANCE
Safety warnings
• Do not use multiple receptacles or extension cord.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow
children to play with the appliance or let them hang off the
door.
• Do not plug-in or out the plug from the receptacle with wet
hands to prevent electrocution!
• Do not place glass bottles or beverage cans in the freezer
department. Bottles or cans may explode.
• Do not place explosive or ammable material in your fridge
for your safety. Place drinks with higher alcohol amount
vertically and by closing their necks tightly in the fridge
department.
• When taking ice made in the freezer department, do not
touch it, ice may cause ice burns and/or cuts.
• Do not touch frozen goods with wet hands! Do not eat ice-
cream and ice cubes immediately after you have taken
them out of the freezer department!
• Do not re-freeze frozen goods after they have melted. This
may cause health issues like food poisoning.
• Do not cover the body or top of fridge with lace. This affects
the performance of your fridge.
• Fix the accessories in the fridge during transportation to
prevent damage to accessories.

EN
8BEFORE USING THE APPLIANCE
Installing and operating your fridge
Before starting to use your fridge, you should pay attention to
the following points:
• Operating voltage for your fridge is 220-240 V at 50Hz.
• Mains cord of your fridge has a grounded plug. This plug
should be used with a grounded receptacle that has a
16 ampere fuse minimum. If you don’t have a receptacle
conrming with this, please have it done by a qualied
electrician.
• We do not take the responsibility of the damages that
occur due to ungrounded usage.
• Place your fridge in a place that it would not be exposed
to direct sunlight.
• Your appliance should be at least 50 cm away from stoves,
Gas ovens and heater cores, and should be at least 5 cm
away from electrical ovens.
• Your fridge should never be used outdoors or left under
the rain.
• When your fridge is placed next to a deep freezer, there
should be at least 2 cm between them to prevent humidity
on the outer surface.
• Do not place anything on your fridge, and install your fridge
in a suitable place so that at least 15 cm is available on the
upper side.
• The adjustable front legs should stabilized in an appropriate
height to allow your fridge operate in a stable and proper
way. You can adjust the legs by turning them clockwise
(or in the opposite direction). This should be done before
placing food in the fridge.
• Before using your fridge, wipe all parts with warm water
added with a tea spoonful of sodium bicarbonate, and
then rinse with clean water and dry. Place all parts after
cleaning.
• Install the distance adjustment plastic (the part with black
vanes at the rear) by turning it 90° as shown in the gure
to prevent the condenser from touching the wall.
• Refrigerator should be placed against a wall with a free
distance not exceeding 75 mm.

EN
9
BEFORE USING THE APPLIANCE
Before Using your Fridge
• When it is operated for the rst time or after transportation,
keep your fridge in the upright position for 3 hours and
plug it on to allow efcient operation. Otherwise, you may
damage the compressor.
• Your fridge may have a smell when it is operated for the
rst time; the smell will fade away when your fridge starts
to cool.
Information about New Generation Cooling
Technology
Fridges with new generation cooling technology have a
different working system than static fridges. In normal fridges,
humid air that enters into fridge and the water vapor that comes
out from the foods, accumulates frost formation in freezer
compartment. In order to melt this frost, in other words defrost,
the fridge has to be stopped. During the stopping period, to
keep the foods cold, user has to extract the food to outside of
fridge and user has to clear the ice during this period.
In the fridges with new generation cooling technology, situation
in the freezer compartment is completely different. With the
aid of fan, cold and dry air is blown out through many points
into the freezer compartment. As a result of the homogenously
blown cold air, even in the spaces between shelves, foods are
frozen equally and correctly. On the other hand there will be
no frost formation.
In the refrigerator compartment, there will be nearly same
conguration with freezer compartment. Air, that is emitted
with the fan, located at the top of refrigerator compartment,
is cooled while passing through the gap behind the air duct.
At the same time, air is blown out through the holes on the air
duct so that cooling process is successfully completed in the
refrigerator compartment. Holes on the air duct are designed
such that the air distribution becomes homogenous in this
compartment.
As there is no air passage between freezer and refrigerator
compartment, there will be no odor mixing.
As a result of these, your fridge with new generation cooling
technology, gives you, ease of use beside the huge volume
and esthetic appearance.

EN
10
This presentation is only for information about the parts of the
appliance. Parts may vary according to the appliance model.
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
1
2
3
4
5
6
7
8
9
A
B
10
11
12
13
14
15

EN
11
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
1) Wine rack *
2) Fridge shelves
3) Chiller *
4) Crisper cover
5) Crisper
6) Freezer top basket
7) Freezer middle basket
8) Freezer bottom basket
9) Leveling feet
10) Ice tray
11) Freezer glass shelves
12) Bottle shelf
13) Door shelf (Adjustable door shelf *)
14) Door shelf
15) Egg holder
* In some models
This presentation is only for information about the parts of the
appliance. Parts may vary according to the appliance model.

EN
12 THE VARIOUS FUNCTION AND POSSIBILITIES
Display and control panel
Cooler Set Button
It is cooler set button. The temperature of cooler compartment can
be changed by this button. Super Cool and Economy mode can be
activated by this button.
Sr Alarm
Sr Alarm will light red and sound alarm will be released if any problem
occurs.
Sr Alarm Indicator
Cooler Set Button

EN
13
THE VARIOUS FUNCTION AND POSSIBILITIES
Super cool mode
How would it be used?
• Push Cooler Set Button until Super Cool Symbol lights.
Buzzer will sound beep beep. Mode will be set.
During this mode:
• Super cool mode can be cancelled by the same operation
of selecting.
Note: Super Cool mode will be automatically cancelled
after 6 hours depending on the environmental temperature
or when the refrigerator sensor reaches a sufciently low
temperature.
Economy mode
How would it be used?
• Push Cooler Set Button until Economy Symbol lights.
• If no pressed any button for 1 sec. When mode is set,
buzzer will sound beep beep.
• To cancel, you will just need to press on Cooler Set
Button.
Cooler temperature settings
• Initial temperature value for Cooler Setting Indicator is
+4°C.
• Press Cooler Set Button once
• When you rst push this button, the last value appears on
the setting indicator of the cooler.
• Whenever you press on this button, lower temperature will
be set. (+8°C, +6°C, Economy, +4°C, +2°C, supercool)
• When you push the cooler set button until supercool
symbol appears on the Cooler Setting Indicator, and if
you do not push any button in 1 seconds Super Cool will
ash.
• If you continue to press, it will restart from +8°C.
Operating your fridge

EN
14 THE VARIOUS FUNCTION AND POSSIBILITIES
Warnings about temperature adjustments
• Your temperature adjustments will not be deleted when
an energy breakdown occurs.
• It is not recommended that you operate your fridge in
environments colder than 10°C in terms of its efciency.
• Temperature adjustments should be made according to
the frequency of door openings and the quantity of food
kept inside the fridge.
• Do not pass to another adjustment before completing an
adjustment.
• Your fridge should be operated up to 24 hours according
to the ambient temperature without interruption after
being plugged in to be completely cooled. Do not open
doors of your fridge frequently and do not place much
food inside it in this period.
• A 5 minute delaying function is applied to prevent damage
to the compressor of your fridge, when you take the plug
off and then plug it on again to operate it or when an
energy breakdown occurs. Your fridge will start to operate
normally after 5 minutes.
• Your fridge is designed to operate in the ambient
temperature intervals stated in the standards, according
to the climate class stated in the information label. We
do not recommend operating your fridge out of stated
temperatures value limits in terms of cooling effectiveness.
Climate
Class Ambient Temperature oC
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)

EN
15
ACCESSORIES
Freezer box
The freezer box allows foods are maintained more regularly.
Removing The freezer box;
• Pull the box out as far as possible
• Pull the front of box up and out.
! Make the inverse of the same operation for the resetting the sliding
compartment.
Note: Always Keep the handle of box while removing the box.
Chiller Shelf
Keeping food in the Chiller compartment instead
of the freezer or refrigerator compartment allows
food retain freshness and avour longer, while
preserving its fresh appearance. When chiller tray
becomes dirty, remove it and wash it with water.
(Water freezes at 0°C, but foods containing salt or
sugar freeze at temperature lower than that)
Normally people use the chiller compartment for
raw sh, lightly pickled, rice, etc...
Do not put foods you want to freeze or ice trays in order to make ice.
Removing the Chiller shelf
• Pull the chiller shelf out toward you by sliding on rails.
• Pull the chiller shelf up from rail to remove.
Freezer boxes
(In some models)

EN
16 ACCESSORIES
Humidity Controler
When the humidity controler in the closed position, it allows fresh fruit and
vegetables to be stored longer.
In case of the crisper is totally full, the fresh dial is located in front of
crisper, should be opened. By means of this the air in the crisper and
humidity rate will be controlled and endurance life will be increased.
If you see any condensation on glass shelf, humidity control should be
taken into the open positions.
(In some models)

EN
17
Adjustable Door Shelf
Six different height adjustments can be made to provide
storage areas that you need by adjustable door shelf.
To change the position of adjustable door shelf ;
Hold the bottom of the shelf and pull the buttons on the side of
the door shelf direction of arrow (Fig.1).
Position door shelf the height you need by moving up and
down. After you get the position that you want the door shelf,
release the buttons on the side of the door shelf (Fig.2) Before
releasing the door shelf, move up down and make sure the
door shelf is xed.
Note: Before moving door shelf is loaded, you must hold the
shelf by supporting the bottom. Otherwise, door shelf could fall
off the rails due to the weight. So damage may occur on the
door shelf or rails.
Adjustable Glass Shelf
Adjustable glass shelf mechanism provides higher storage
spaces with a simple movement. To cover the glass shelf,
push it.
You can load your food as you want in the resulting extra
space. To bring the shelf in its original position, pull it toward
you.
ACCESSORIES
Visual and text descriptions on the accessories section may
vary according to the model of your appliance.
Figure -1
Figure -2
Figure -1
Figure -2
(In some models)
(In some models)

EN
18 CLEANING AND MAINTENANCE
• Make sure to unplug the fridge before starting to clean
it.
• Do not wash your fridge by pouring water.
• You can wipe the inner and outer sides with a soft cloth or
a sponge using warm and soapy water.
• Remove the parts individually and clean with
soapy water. Do not wash in washing machine.
• Never use ammable, explosive or corrosive material like
thinner, gas, acid for cleaning.
• You should clean the condenser with broom at least once
a year in order to provide energy saving and increase the
productivity.
Make sure that your fridge is unplugged while cleaning.

EN
19
CLEANING AND MAINTENANCE
Defrosting
Your refrigerator performs fully automatic defrosting. The
water formed as a result of defrosting passes through the
water collection spout, ows into the vaporization container
behind your refrigerator and evaporates by itself in there.
• Make sure you have disconnected the plug of your
refrigerator before cleaning the vaporization container.
• Remove the vaporization container from its position by
unscrewing the screws as indicated. Clean it with soapy
water at specic time intervals. Thus, the odor formation
will have been prevented.
Replacing LED Lighting
If your refrigerator has LED lighting contact the help desk as
this should be changed by authorized personnel only.
Evaporating
tray

EN
20 ARRANGING FOOD IN THE APPLIANCE
Refrigerator compartment
• For normal operating conditions, adjusting the temperature value of
the cooler partition of the fridge to 4°C will be enough.
• To reduce humidity and consequent increase of frost never place
liquids in unsealed containers in the refrigerator. Frost tends to
concentrate in the coldest parts of the evaporator and in time will
require more frequent defrosting.
• Never place warm food in the refrigerator. Warm food should be
allowed to cool at room temperature and should be arranged to
ensure adequate air circulation in the refrigerator compartment.
• Nothing should touch on the back wall as it will cause frost and the
packages can stick on the back wall. Do not open the refrigerator
door too frequently.
• Arrange the meat and cleaned sh(wrapped in packages or sheets
of plastic) which you will use in 1-2 days,in the bottom section of
the refrigerator compartment(that is above the crisper) as this is the
coldest section and will ensure the best storing conditions.
• You can put the fruits and vegetables into crisper without packing.
Some recommendations have been specied below for the placement
and storage of your food in the cooling compartment.
NOTE: Potatoes, onions and garlic should not be stored in the refrigerator.
Food Maximum Storing
time
Where to place in the
fridge department
Vegetables and
fruits 1 week Vegetable bin
Meat and sh 2 - 3 Days
Wrapped in plastic foil or
bags or in a meat container
(on the glass shelf)
Fresh cheese 3 - 4 Days In special door shelf
Butter and
margarine 1 week In special door shelf
Bottled products
milk and yoghurt
Until the expiry date
recommended by
the producer In special door shelf
Eggs 1 month In the egg shelf
Cooked food All shelves
