Sunfire ICO-E-10-M User manual

Garland Commercial
Industries, LLC
185 East South Street
Freeland, PA 18224
Phone: [phone]
Fax: [phone]
Garland Commercial Ranges Ltd
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
Phone: [phone]
Fax: [phone]
Enodis UK LTD
Swallowfield Way,
Hayes, Middlesex
UB3 1DQ ENGLAND
Telephone: [phone]
Fax: [phone]
Sunre Electric
Convection Ovens
Item: ______________________________
Quantity: __________________________
Project: ____________________________
Approval: __________________________
Date: ______________________________
Sunre Electric Convection Ovens
Models:
ICO-E-10-M ICO-E-20-M
Standard Features:
• Electromechanical thermostat with a tempera-
ture range of 200°F - 500°F (93°C - 260°C), and
60-minute timer
• Total of 11.0 kW loading per oven cavity
• 208 or 240 Volt, 3-Phase, (not convertible to
single phase)
• Two-speed fan with 3/4 HP motor
• 60/40 dependent door design with double
pane thermal window in both doors
• Interior lights
• Porcelain enameled oven interior w/coved cor-
ners
• Five (5) chrome plated oven racks on 11-posi-
tion, removable rack guides
• Stainless steel front, sides, top, and legs
• Double-deck model available, (ICO-E-20-M)
Optional Features:
 Extra oven racks
 Swivel casters, set of four; two locking,
(please specify single or double deck)
Specifications:
Full-size, deep depth, electric convection oven
with electro-mechanical thermostat, 60-minute
timer and 2-speed fan. Designed as a general pur-
pose oven for baking or roasting a variety of food
products faster and at lower temperatures by cir-
culating air throughout the oven cavity.
Model ICO-E-10-M
Note: Ovens supplied with casters must be
installed with an approved restraining device.

Garland Commercial
Industries, LLC
185 East South Street
Freeland, PA 18224
Phone: [phone]
Fax: [phone]
Garland Commercial Ranges Ltd
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
Phone: [phone]
Fax: [phone]
Enodis UK LTD
Swallowfield Way,
Hayes, Middlesex
UB3 1DQ ENGLAND
Telephone: [phone]
Fax: [phone]
40"
(1016mm) 40"
(1016mm)
10-7/8"
(276mm)16-7/8"
(429mm)
36"
(914mm)
C
L
L
L
C
C
10-1/4"
(260mm)
CABLE ENTRANCE
CABLE
ENTRANCE
64"
(1626mm)
8"
(203mm)
11-1/2"
(292mm)
32"
(813mm)
30"
(762mm) 31-1/2"
(800mm)
60"
(1524mm)
6"
(152mm)
44-1/2"
(1130mm)
8-1/2"
(216mm)
28"
(711mm)
SINGLE OVEN DOUBLE OVENS
Sunre Electric Convection Ovens
Form# SXICOE10 (07/07)
Width Depth Height Oven Interior Dimensions Combustible Wall Clearance
ICO-E-10 ICO-E-20 Height Depth Width Sides Rear
40"
(1016mm)
44-1/2"
(1130mm)
60"
(1524mm)
72"
(1829mm)
20-1/2"
(520mm)
28-1/2"
(723mm)
29"
(736mm)
6"
(152mm)
6"
(152mm)
Model Shipping
Lbs./Kg Cube
ICO-E-10 550/250 58.0
ICO-E-20 1100/495 114.0
Model Entry Clearances
Crated Uncrated
ICO-E-10 47"
(1194mm)
32-1/2"
(826mm)
ICO-E-20
NOTE: ICO-E-10 w/Optional Casters - Overall Height = 65-1/2" (1664mm)
ICO-E-20 w/Optional Casters - Overall Height = 71-1/2" (1816mm)
Model Total kW
Load
Nominal Amperes Per Line
208V / 3Ø* 240V / 3Ø*
X Y Z X Y Z
ICO-E-10 11.0 32 32 28 28 28 24
ICO-E-20 22.0 60 65 60 52 56 52
*Not convertible to single-phase
Double Deck Models require individual power supply connections
• These appliances are intended for
commercial use by professionally
trained personnel.
• It is the responsibility of the
installer to ensure that installation
complies with all national and
local codes.
