Diamond PLANET 8 Service manual

Mod: FPG-8N
Production code: PLANET8MGC
07/2012

Electromechanical / Electronic
Convection oven
Installation, use and maintenance manual

INDEX
3
INDEX
1. INTRODUCTION 6
2. HOW TO USE THIS MANUAL 7
3. SPECIFICATIONS 9
3.1 Product identification 9
3.2 Directives 9
3.3 Proper and improper machine use 9
3.4 Technical specifications 10
4. NOTES ON INSTALLATION 12
4.1 Check on delivery 12
4.2 Choice of place of installation 12
4.3 Electrical connection 13
5. INSTALLATION 14
5.1 Checklist 14
5.2 Choice of installation place for the oven 14
5.3 Moving the module 14
5.4 Assembly of the modules 15
5.5 Gas connection 15
5.6 Supply line 15
5.7 Installation of units with exhaust type “A” with power lower than 14 kW 16
5.8 Connection of steam outlet 16
5.9 Water connection for the steam generator 16
5.10 Check before start up electromechanical version 17
5.11 Check before starting the electronic version 17
6. RUNNING ELECTROMECHANICAL VERSION 18
6.1 The controls 18
6.2 General 19
6.2.1 Main luminous switch 0/1 19
6.2.2 Start/stop cooking switch 19
6.2.3 Chamber light switch 19
6.3 Temperature control 19
6.3.1 Chamber temperature display 19
6.3.2 Set button Push-button of ESC (vers. TERM0012)19
6.3.3 Button of SET and of ESC (vers. TERM0060) 20
6.3.4 Buttons and / and 20
6.3.5 Out indicator (vers. TERM0012) 20
6.3.6 "out1" display led green (vers. TERM0060) 21
6.4 Fault signal 21
6.4.1 Thermocouple short-circuit (vers. TERM0012) 21
6.4.2 Disconnected thermocouple (vers. TERM0012) 21
6.4.3 Disconnected thermocouple (vers. TERM0060) 21
6.5 Power control 21

INDEX
4
6.5.1 . Power regulator 21
6.6 Accidental flame-out 22
6.7 Steam generator 22
6.7.1 Programming the steam dosages 22
6.7.2 Delivery of steam dosages 23
6.8 Steam discharge valve control 23
7. RUNNING ELECTRONIC VERSION 24
7.1 The controls 24
7.2 States functional system 25
7.2.1 Member of activity and inactivity on/off general 25
7.3 Settings 25
7.3.1 Setting temperature settings 25
7.3.2 Setting the timer 26
7.3.3 Setting power heating 26
7.3.4 Function setting humidification of a programme of cooking 27
7.3.5 Button Start/Stop 28
7.3.6 Button light room / programming cycle of pre-heating 28
7.4 Programming 28
7.4.1 Setting up a program 28
7.4.2 Programming cycle of pre-heating 30
7.5 Occasional cut-off / absence of flame 30
7.6 Alarm 31
7.6.1 Alarm over-temperature / probe uneven 31
8. USE 32
8.1 Preparation for use 32
8.2 Switching on the control panel 32
8.3 Settings 32
8.4 Start cooking 32
8.5 Loading the oven 33
8.6 Use of the steam generator 33
8.7 General good cooking indications 33
8.8 Switching off 34
8.9 Cleaning 34
9. CLEANING 35
9.1 Cleaning of any parts open to view 35
9.2 Cleaning of the oven cooking chambers 35
9.3 Cleaning outside surfaces 35
10. MAINTENANCE 36
10.1 Ordinary maintenance operations 36
10.1.1 Replacing light 36
10.2 Fault signals 37
10.3 Wiring diagram 37

INDEX
5
10.4 Converting to different types of gas 42
10.4.1 Changing burner jets 42
10.4.2 Minimum flame adjustment 42
10.4.3 Applying a new label 43
10.5 Exploded drawings and spare parts list 43
11. DECOMMISSIONING AND DEMOLITION OF THE EQUIPMENT 50
12. DECLARATION OF CONFORMITY 51

INTRODUCTION
6
1. INTRODUCTION
The convection oven in the PLANET range has been designed to work in areas where the
available space is limited.
The arrangement of the pans above each other in a uniformly ventilated area ensures the
space occupied is small and also the excellent cooking of the pastry and fine foods products.
The control panel has controls to:
1) set the desired temperature;
2) set the cooking time, at the end of which there is a sound warning;
3) to inject steam into the chamber.
Cooking takes place with a heated flow of air, sent through a series of holes in the sides by
each pan into the chamber. The even flow of air provides practically constant heat to ensure
even cooking over the whole of the product.
The ovens can be provided with chambers to take 5 or 8 pans of 60x40 cm.
They have been very carefully built using stainless steel both in the body and in the cooking
chamber to make for easy cleaning and long oven life even when cooking foods with high salt
or humidity content etc.
Dr. Zanolli s.r.l. thanks you for choosing our product. We can assure you that you have made
a good choice in putting your trust in a company that has decades of experience in the
making of high quality products, never cutting corners and always using the best materials.

HOW TO USE THIS MANUAL
7
2. HOW TO USE THIS MANUAL
This installation use and maintenance manual must be kept near the equipment
in a place where it can be readily consulted. This manual must accompany the equipment if it
is transferred to another owner, as the equipment cannot be considered safe and complete
without it.
Note the code and revision number behind the cover. In case of loss you can order another
one quoting those numbers.
This manual consists of a number of chapters. They should all be read by
installers and maintenance staff as well as by the final user, both for its safe use and to
obtain the best results from this product.
Despite this we give here below some useful indications for rapid consultation of the various
chapters.
The paragraphs marked with this symbol contain essential safety
information. They must all be read by installers and the final user, as well as his
employees who use the equipment. Dr. Zanolli s.r.l. assumes no liability for any
damage resulting from failure to observe the rules set forth in these paragraphs.
The paragraphs marked with this symbol contain important information to avoid
any action that could damage the equipment. It is in the user's interest also to read these
paragraphs.
Chapter 3 indicates the intended field of use of the equipment and gives the characteristics
and all the numbers that may be necessary for its choice, installation and use. It should be
used as a reference point to check that the use you intend to make of the equipment does in
fact come within those for which it was intended and any time you need to know any value or
parameter relating to the equipment.
Chapters 4 and 5 provide all the information necessary for the installation of the equipment.
The information is primarily intended for specialised staff but should also be read in advance
by the final user so he can arrange the rooms, or have the rooms and necessary plant
arranged for the proper working of the equipment.
Chapters 6 and 7 serve as a reference for the user in indispensable switching on, use and
switching off operations for the machine in conditions of safety.
Chapter 8 is useful for the user who has to learn to use the oven. It guides the user through
essential operations for switching on, use and switching off of the equipment in safety. To
exploit all of the possibilities of the equipment the user should refer to chapters 6 and 7.
Chapter 9 provides all the information required for the cleaning of the equipment i.e. all those
operations which have to be carried out by the user in order to ensure that the equipment
continues to function safely ( especially from the point of view of hygiene ) and generally
obtains the best result at all times.

HOW TO USE THIS MANUAL
8
Chapter 10 provides the information necessary for proper periodic and extraordinary
maintenance, e.g. repairing or replacing parts of the equipment.
This chapter also has an exploded view of the equipment and list of spare parts to make
ordering and replacing any damaged part easier.
These maintenance operations must be carried out by specialised staff.
Chapter 11 provides the information necessary for the decommissioning and demolition.
Chapter 12 facsimile declaration of conformity.

SPECIFICATIONS
9
3. SPECIFICATIONS
3.1 Product identification
This manual is for the PLANET 5 and PLANET 8 cooking modules.
3.2 Directives
The PLANET 5 and PLANET 8 cooking modules bear the following compulsory markings:
that certify compliance with the following EU directives:
2009/142/CE gas appliances
2004/108/CE electromagnetic compatibility
2006/95/CE low tension
2006/42/CE machines directive
3.3 Proper and improper machine use
The PLANET 5 and PLANET 8 cooking modules have been designed to cook fine pastries
and cakes for professional use in restaurants, patisseries etc. by qualified persons only.
The operations provided for in normal use are the opening and closing of the doors, loading
unloading the products on the pans, switching on, adjustment, switching off and the cleaning
of the equipment.

SPECIFICATIONS
10
3.4 Technical specifications
The following table gives the technical specifications of the cooking modules.
PLANET 5 GAS PLANET 8 GAS
Unit of
measurement
Weight 150 180 Kg
External dimensions 800x1210x775 800x1210x1055 mm
Pans capacity (60x40) 5 8 n°
Production capacity (indicative) Kg/h
Electrical supply mono-phase
Tension 230 Vac
Frequency 50 or 60 Hz
Current at 230V 2.1 4.1 A
Total electrical power 0.47 0.94 kW
Electrical connection cable with 3 wires without plug
Cable length 2 m
Section of wires 2.5 2.5 mm2
Burner type Atmospheric
Category AT II2H3B/P- DK SE FI CH II2H3B/P- CH ES
GB IE IT PT II2H3+- LU I2E- DE II2ELL3B/P-GR
BE I3+ FR BE II2E+3+- NO I3B/P- NL II2L3B/P-
Nozzle diameter according to gas type and pressure
G20 - 20 mbar 2.90 mm
G25 - 20 mbar 2.90 mm
G25 - 25 mbar 2.90 mm
G30 - 28..30 mbar 1.70 mm
G31 - 37 mbar 1.70 mm
G30 - 50 mbar 1.50 mm
G31 - 50 mbar 1.50 mm
Pressure at nozzle according to gas type and supply pressure at rated capacity
G20 – 20 mbar 11 mm
G25 – 20 mbar 16 mm
G25 - 25 mbar 16 mm
G30 - 28..30 mbar - mm
G31 - 37 mbar - mm
G30 - 50 mbar - mm
G30 - 50 mbar - mm
Minimum pressure at nozzle according to gas type and supply pressure
G20 - 20 mbar 3 mm
G25 - 20 mbar 4 mm
G25 - 25 mbar 4 mm
G30 - 28..30 mbar 8 mm
G31 - 37 mbar 8 mm
G30 - 50 mbar 13 mm
G30 - 50 mbar 13 mm
Gas connection ISO 7 - (conical threaded gas)

SPECIFICATIONS
11
Pipe Ø 1/2”
Consumption
Max. burner power 11.5 kW
G20 capacity – 20 mbar 1.8 m3/h
G25 capacity – 25 mbar 2.1 m3/h
G30 capacity - 28..30 mbar 1.33 Kg/h
G30 capacity – 50 mbar 1.33 Kg/h
Minimum burner power 6 kW
G20 capacity – 20 mbar 1.1 m3/h
G25 capacity – 25 mbar 1.2 m3/h
G30 capacity - 28..30 mbar 0.8 Kg/h
G30 capacity – 50 mbar 0.8 Kg/h
Flue
Type A
Diameter 100 mm
Air change 23 m3/h
Flame control Electronic without pilot
Safety time <5 s
Flame ignition Hot surface
Chamber light bulb
Type halogen
Power 35 W
Cooking control
Temperature control
(electromechanical version) electronic thermo regulator
Temperature control
(electronic version) electronic computerized
Maximum settable temperature 300 °C
Temperature activation for
safety thermostat 500 °C
Environmental conditions
Temperature 0-40 °C
Maximum humidity 95% without condensation
Table 3.1. Technical specifications

NOTES ON INSTALLATION
12
4. NOTES ON INSTALLATION
WARNING! These installation instructions are for the exclusive use of
qualified personnel installing and maintaining electrical and/or gas equipment.
Installation by other non qualified staff may cause damage to the equipment, persons,
animals or things.
Where installation of the equipment requires modifications to or additions to the building's
electrical plant, the persons carrying out such changes must have their work certified to show
it has been done in accordance with the norms in force in the country in which the equipment
is installed.
4.1 Check on delivery
Unless it is agreed otherwise, the products shall be carefully packed with a strong wooden
structure and a sheet of bubble pack nylon to protect it from shocks and humidity in transit
and shall be delivered to the hauler in the best of condition.
We therefore recommend you check the packaging on delivery to see if there are any signs
of damage. If there are such signs, have the fact recorded on the receipt, which must be
signed by the driver.
Once the equipment has been unpacked, check for eventual damages.
Also check that all the parts are present, included any non assembled parts. If the equipment
is damaged or any parts are missing, bear in mind that the hauler accepts complaints only
within 15 days of delivery and that Dr. Zanolli s.r.l. shall not be liable for any damages
suffered by its products during transportation. We shall nevertheless be at your disposal to
assist you in presenting your claim.
If damage has occurred do not attempt to use the equipment and contact
professionally qualified persons.
4.2 Choice of place of installation
The good, safe and long-lasting working of the equipment depends also on the place in which it
is installed. It is therefore advisable to carefully assess where it will be installed before it is
delivered.
Install the equipment in a dry and easily accessible place, both for its use and for cleaning and
maintenance. The surrounding area must be kept free of obstacles. In particular make sure the
cooling openings are not obstructed (Fig 5.1).
It must in any case be installed at least 20 cm from the room's walls or other equipment.
You must finally make sure that the temperature and relative humidity of the room
where the equipment is installed must never exceed the maximum and minimum values

NOTES ON INSTALLATION
13
indicated in its characteristics (see 3.). Exceeding the maximum temperature or relative humidity
in particular may easily and unpredictably cause a breakdown or damage the electrical
equipment and create a dangerous situation.
4.3 Electrical connection
Zanolli equipment is supplied with electrical connection cable with an earth wire.
In observance of the safety regulations currently in force it is compulsory to connect the
earth wire (yellow-green) to an equipotential system whose effectiveness must be
properly checked in accordance with the regulations in force.
Before carrying out any connections make sure the mains supply corresponds to
that to which the equipment has to be connected (see 3 and the plate).
See Fig. 5.3 for the exact cable output position for the equipment supply.
The supply cable must end with a plug to connect to an electrical supply board with a
corresponding socket and differential magnetothermal switch.
The plug-socket connection must be such that the earth wire is connected and first and
disconnected last and must be of the right size for the nominal current ( see 3.).Type CEE17
plugs and sockets are suitable, and any others satisfying the European norm EN 60309.
The thermal safety device must be calibrated for the total nominal current, the magnetic safety
device must be calibrated for the maximum instant current ( in the case of ovens it is little more
than the nominal current, while in the case of machines it is the surge current of the most
powerful motor), while the differential device must be set at the 30 mA current (see 3.).
Dr. Zanolli s.r.l. shall not be liable for any damages suffered as a result of failure to observe the
above norms.

INSTALLATION
14
5. INSTALLATION
5.1 Checklist
There are no separately supplied parts.
5.2 Choice of installation place
for the oven
Avoid obstructing the cooling openings on the
module's right side (Fig 5.1).
When choosing the place to install the cooking
modules PLANET 5 and PLANET 8 take
account of the fact that they can be completed
by other modules in the series (hood, proofer,
etc.).
5.3 Moving the module
To unload and transport the module when it is still in its packaging, use a forklift truck or
transpalett of a capacity at least that of the weight of the module, sliding the forks into the
space provided under the bottom of the packaging.
In any case, to avoid sudden movements, take into account the position of the
centre of gravity (Fig. 5.2 and Table 5.2)
To avoid any damage to the module, place protective material between it and the
forks.
Fig. 5.1 Cooling openings
MODEL a mm b mm c mm
PLANET 5 400 605 388
PLANET 8 400 605 528
Tab. 5.2
Fig. 5.2 Centre of gravity

INSTALLATION
15
5.4 Assembly of the modules
Position the modules one above the other in the right order (from the bottom: proofer or base,
cooing module, hood) and fix them by means of the hooks and screws provided.
Fig.5.3. Input position of the electric cable, steam outlet and plate.
5.5 Gas connection
Before making any connection to this appliance, check the identification label and verify
that gas type and pressure of your appliance correspond to the gas supplied (see Tab. 3.1). If
it doesn't match, see chapter 9.4 to perform the necessary adjustments.
5.6 Supply line
Gas appliances are fitted with a ½” conical threaded connector, as indicated in
specifications. Connections to the building’s gas mains must be made in galvanised
steel or copper piping, and must be inspection able.
The oven must be connected to the gas supply through an easily accessible cut-off valve.
The connection between gas piping and the oven must be made with a three piece metal
joint to facilitate dismantling.
Threaded joint sealing must be made of material declared by the manufacturer as
specifically suitable also for LP gases.
See Fig. 5.3 for the exact connection position.
MODEL A mm
PLANET 5 775
PLANET 8 1055
steam outlet
steam outlet

INSTALLATION
16
5.7 Installation of units with exhaust type “A” with power lower
than 14 kW
To install units type “A”, it is necessary to comply with the following requirements for
room ventilation and exhaust of products of combustion.
The room where the appliance is to be installed must have at least two openings, made
directly in the wall and directly connected to the outside (one for suction of combustion air, and
the other for the exhaust of burnt gas). Cross-sectional area of each opening must never be
smaller than 100 sq.cm.
Air inlet must be placed as much as possible near the floor.
Exhaust of burnt gas must be placed in the top side of the wall.
If possible, the two openings must be placed in opposite position, they must never be
obstructed, and have to be protected by a grill with an useful crossing surface of 6 sq.cm. for
each kW used.
Rate between room volume and installed thermal capacity must be higher than 1,5
sq.m./kW.
5.8 Connection of steam outlet
The steam discharge outlet should be connected through the duct on the hood (see the
instructions). A pipe of Ø200 uld be connected to the outside.
Avoid long horizontal sections, where condensation could accumulate with
possible dripping.
Do not connect suction units as they would cause too much of a pressure drop
that would take heat out of the cooking chamber even with the valves closed.
See Fig. 5.3 for the exact connection position.
5.9 Water connection for the steam generator
Connect the water input to the steam generator with a flexible hose to a mains water cock.

INSTALLATION
17
5.10 Check before start up electromechanical version
Switch on the main switch on the electrical panel.
Switch on the switch (6.2.1.), set a temperature over 200°C. (6.3.2), position the
power regulator at 10 (6.5.1.) and switch the switch on (6.2.2.).
Check that the burner is working.
Verify that the current on the phase is the one indicated in chapter 3 for supply tension of 230V.
Switch the switches off and and also the main switch on the electrical panel.
5.11 Check before starting the electronic version
Turn on the main switch on the control panel.
Press the button ignition system. Set a temperature exceeding 200 ° C following the
instructions in paragraph 7.3.1. Set the power of heating value 5 (see section 7.3.3). Set the
timer (see 7.3.2). Press the button start / stop cycle of cooking.
Verify that the current on the phase is the one indicated in chapter 3 for supply tension of 230V.
Press the buttons and and the main switch on the electric cabinet.

RUNNING ELECTROMECHANICAL VERSION
18
6. RUNNING ELECTROMECHANICAL VERSION
6.1 The controls
Fig. 6.1. shows all the controls on the control panel:
Temperature control (vers. TERM0012)
Chamber temperature display
Set button
Push-button of ESC
Up button
Down button
Out indicator
Temperature control (vers. TERM0060)
Baking chamber temperature display
Push-button set and ESC
Up button
Down button
"out1" led green display
Main
Luminous chamber switch
Main luminous switch 0/1
Luminous start/stop cooking switch
Power control
Power regulator
Reset switch
Vaporiser control
Steam delivery timer buttons
Fig. 6.1. The control panel

RUNNING ELECTROMECHANICAL VERSION
19
Timer
Manual timer
For the controls described below refer to Fig. 6.1.
6.2 General
6.2.1 Main luminous switch 0/1
When this switch is at 0, all the panel indicators are off. When it is at 1, the switch itself and
the thermo regulator light up so the temperature can be programmed. Heating in the cooking
chamber stays off until the switch is off.
6.2.2 Start/stop cooking switch
When this switch is at 0, the cooking chamber stays off irrespective of the temperature
and power programmed.
When turned to 1, the switch lights up and heating in the cooking chamber switches on
depending on temperature and power set.
6.2.3 Chamber light switch
When this switch is turned to 1 the switch lights up and chamber light goes on.
6.3 Temperature control
6.3.1 Chamber temperature display
In normal working mode this display indicates the chamber temperature in °C.
In temperature programme mode this display indicates the programmed temperature.
This display is also used as signal for certain faults (6.4).
6.3.2 Set button Push-button of ESC (vers. TERM0012)
Press two times this button to enter the programme temperature mode.

RUNNING ELECTROMECHANICAL VERSION
20
WARNING! Do not keep the button pressed in, as it may change the parameters
inside the thermo regulator and possibly cause unpredictable malfunctions.
In this way of working the display shows the programmed temperature that can
be changed using the buttons and . Unless the buttons are pressed for more than
3 seconds, the thermo regulator automatically returns to normal working mode. For the
settable temperatures field see chapter 3.
To press two times this push-button in order to exit from the way programming
temperature.
6.3.3 Button of SET and of ESC (vers. TERM0060)
To press once this button to select the temperature programming mode.
WARNING ! do not keep this button pressed because this might alter the thermostat
internal parameters and cause possible unpredictable failures.
In this operation mode, the display shows the programmed temperature, which can
be changed using the and buttons. If no buttons are pressed for more than 15
seconds, the thermostat automatically returns to the normal operation mode. See chapter 3 for
the range of temperatures that can be selected.
To press a second time this push-button in order to exit from the way programming
temperature.
6.3.4 Buttons and / and
By pressing and releasing these buttons once, the set temperature increases or is reduced
by one unit. Keeping them pressed in the temperature steadily increases or decreases, first
slowly then more quickly.
6.3.5 Out indicator (vers. TERM0012)
The indicator goes on each time the temperature of the chamber falls below the set
temperature. It switches off when the chamber temperature reaches the set temperature and
goes back on when the temperature in the chamber falls 1°C below the set temperature.
When the indicator is on, heating in the cooking chamber switches on depending on
the respective power settings.
