Sunfire X24 User manual

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)
X Series
Gas Restaurant Ranges
models X24 / X36 / X60
P(US & Canada): 1 800 427 6668
F(US & Canada): 1 800 361 7745
www.Garland-Group.com

Quality Factory Replacement Parts for the World’s Finest
Foodservice Equipment Solutions
This parts list is updated regularly. Please find the most current revision
on our website @
www.Garland-Group.com

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 3
Table of Contents
Rating Plate Location / Serial# & Model Code Interpretation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Oven Section Components — 24” Space Saver Oven / Cabinet Door . . . . . . . . . . . . . . . . . . . . . . . 6
Oven Section Components — 36” Single Standard Oven / Cabinet Door . . . . . . . . . . . . . . . . . . 12
Oven Section Components — 60” Single or Double Standard Oven / Cabinet Door . . . . . . . . . 18
Range Top Section Components - Open Top Burners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Range Top Section Components - Hot Top . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Range Top Section Components - Hi / Low Griddle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Range Top Section Components - Raised Griddle Broiler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
High Shelf & Low Profile Back Guard Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Gas Conversion Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
X Series
Gas Restaurant Ranges
models X24 / X36 / X60

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)Page 4
Blank Page

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 5
The Rating Plate (Product Identification
Plate) is affixed to the front egde of the
chassis bottom, behind the front kick
panel.
For a double-oven model, the plate can
be found behind the kick panel on the
LEFT oven.
INPUT PER BURNER IN BTU/H
PUISSANCE PAR BRULEUR EN BTU/H
GAZ
PRESSION A L'APPAREIL
COMBUSTIBLE
NON-COMBUSTIBLE
FOR INSTALLATION WITH THE FOLLOWING MINIMUM CLEARANCES
POUR INSTALLATION AVEC LES DISTANCES MINIMUM.
FLOOR
FLOOR
PLANCHER
PLANCHER
SIDE
COTES
SIDE
COTES
ARRIERE
ARRIERE
BACK
BACK
MISSISSAUGA, ONT., CANADA
AMPS
HZ
VOLTS
PHASE
MANIFOLD PRESSURE
MODELE
ARTICLE
ITEM
MODEL
CODE FOOD SERVICE EQUIPMENT
ANS Z83.11b - CSA 1.8b-2009
GAS
D
E
C
D
I
F
I
T
R
E
N
S
I
G
E
PL. A. FRIRE
FRITEUSE
DESSUS PLEIN
BROILER
GRILLOIR
FRYER
SOLID TOP
DESSUS OUVERT
FOUR
GRIDDLE
OPEN TOP
OVEN
NSF
R
"C.D.E.
4518397 Rev.6
INTENDED FOR OTHER THAN HOUSEHOLD USE/DESTINE A UN USAGE AUTRE QUE DOMESTIQUE
"
"
"
"
"W.C.
CERTIFIED
GARLAND COMMERCIAL RANGES LTD.,
Kick Panel
Rating
Plate
10 05 1001 00668
Sequential Number
Factory Code
Month
Year
Serial# - Year/Month Information
The serial number is 13 Digits long and is stamped on the rating plate.
See "Rating Plate Location".
Model Code Interpretation
The model configuration code can be found on the unit's rating plate.
See "Rating Plate Location". Example:
S- Storage Base
R- Standard Oven
L- Space Saver Oven
RR - (2) Standard Ovens
RS - (1) Standard Oven (1) Standard Base
2/ 4/ 6/ 10 - Number of Open Top Burners
R24 - Raised Griddle/Broiler, 24" wide
Gxx - Griddle, xx" wide
Unit Width - 24 / 36 / 60 inches
Sunfire X Series Gas Restaurant Ranges
X 36 - 2 G24 R
Rating Plate Location

X series 24inch L Oven Secon 1of2
21
44
43
42
45
15B
17
7
18 20
49 OR 49A
63
64
65 66
67
19A
19B
48
47
46
95
96
8
10
14
12
13
91
69
68A
68
15A
15C
U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)Page 6
X Series Gas Restaurant Ranges
models X24 / X36 / X60
24” Single Space Saver Oven / Cabinet Door (1 of 2)

32A
1
36
30
60
58
59
26
25
3
5
28
27
29
2
70
71
72
75
76
51
78
50
73
79
62
61
62
34
35
37
38
39
40
55
57
56
57
41
92
74
77
3
X series 24inch L Oven Secon 2of2
309
308
310
307
305
300
301
303
306
302
78
304
4
6
32B
31A/31B
32A/32B
33A/33B
33B
32B
31B
33C
(see 33C)
89
90
91
50
58A
203
204
205
202 208
206
208
207
209
208
200
201
U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 7
X Series Gas Restaurant Ranges
models X24 / X36 / X60
24” Single Space Saver Oven / Cabinet Door (2 of 2)

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)Page 8
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
24" SINGLE SPACE SAVER OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
1 4523184 24" Main Channel Front 1
2 4525529 24" Main Channel Rear 1
3 4522764 Body Side L/R 2
4 4523041 Main Back 24" Oven 1
5 4522762 Flue Riser Std Oven 1
6 4524626 24”Veneer Back, S/S
74522787 Oven Pilot Assembly (on L/H Side of Burner) 1 C
8 4522900 Oven Pilot Bracket, Sunre 1
9* F440 #10 - 32 x 1/4" Screw 2
10 2200706 Thermocouple Retaining Nut 1 C
12 2200704 3/16" Compression Nut - Oven Pilot 1 C
13 2200705 3/16" Ferrule - Oven Pilot 1 C
14 4523506 Thermocouple Oven 60" 1 C
15A 4522899 Oven Burner Bracket
Note: Used FROM (serial#) 0903100100769. 1 22MAR/09
15B 4522983 Oven Burner Bracket, Sunre 1 22MAR/09
15C 4512234 Burner Bracket Guide 22MAR/09
17 2200702 Pilot Orice #32 Natural Gas 1 C
2200703 Pilot Orice #23 Propane 1 C
18 M940 Large Orice # 40 Natural Gas 1 C
M952 Large Orice # 52 Propane 1 C
19A 14155XX Oven Orice Fitting (without orice) 1 C
19B 1415540F Oven Orice Fitting with #40 Hood (Natural) 1 C
1415552F Oven Orice Fitting with #52 Hood (Propane) 1 C
20 4522781 Orice Bracket - Oven 1
21 1028100 Steel Oven Burner with Air Shutter 1
25 4525152 Sunre 20W Oven Door Assembly 1
26 4524059 Door Frame Assembly 20W Sunre 1
27 1082500 Oven Door Trunion 2
28 4523336 Oven Door Panel 20W Sunre) 1
29 4522378 Oven Door Liner 20W 1
30 4524061 Insulation Door 20W 2
31A 3010000 Door Handle End Insulator - Type 1
Note: Use Kit 4526108 (item 33C). 2 14AUG/08
31B 4524911
Door Handle End Insulator - Type 2
Note: Used FROM (date) 15-Aug/08 (serial#)
0808100100641 (model) X60-10RR-0001.
2 15AUG/08
32A 3007300 Door Handle End - Type 1
Note: Use Kit 4526108 (item 33C). 2 14AUG/08
32B 4524910
Door Handle End - Type 1
Note: Used FROM (date) 15-Aug/08 (serial#)
0808100100641 (model) X60-10RR-0001.
2 15AUG/08
33A 4524987 Door Handle 20W, Sunre, 1.0”Dia, Type 1
Note: Use Kit 4526108 (item 33C). 14AUG/08
33B 4522647
Door Handle 20W, Sunre, 1.0”Dia, Type 2
Note: Used FROM (date) 15-Aug/08 (serial#)
0808100100641 (model) X60-10RR-0001.
1 15AUG/08
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 9
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
24" SINGLE SPACE SAVER OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
33C 4526108 Oven Door Handle Kit, 20W, Sunre
Note: Kit includes items 31B, 32B, 33B 1 15AUG/08
34 1082802 Hinge Link Rt 1 C
35 4522772 Bell Crank Assembly 1
36 F299 Bolt 1/4-20x1/2" Bell Crank 1
37 4522818 Bell Crank Support Bracket 1
38 1005800 Oven Door Spring - Garland 1 C
39 9004701 Oven Door Spring Hook 1
40 4523654 Spring Support Bracket (20W Door) 1
41 4523039 Kick Panel 20W 1
42 4525442 Knob Assembly - Sunre Oven SIT, deg. F 1 C
4525443 Knob Assembly - Sunre Oven SIT, deg. C 1 C
43 4523081 ES Shield Mount 1
44 4523006 SIT Oven Control 1 C
45 1095499 Straight Connector 7/16 2
46 4523079 ES Shield Rt 1
47 4523080 SIT Lt Shield 1
48 4523499 SIT Top Shield 1
49 4523145 Tube - Sit To Manifold 1
49A 4520720
7/16" Flexible Tubing Sit To Manifold
NOTE: Applicable Only for Models with 12"Griddles
Mounted on the L/H Side of the Range.
1
50 4522411 Rack Guide 26D 2
51 4522410 Oven Rack 20W x 26D 1
55 4522991 Corner Column Rt 24" 1
56 4522990 Corner Column Lt 24" 1
57 F298N Bolt, #10-24 x 3/8" Shoulder Truss HD, Nickel Plated
(was F298) 2
58
4523199
24 Valve Panel
All Burners or 2” Standard Griddle on L/H or R/H
Note: Used from (serial#) 0911100101162.
(4523594 is obsolete, used up to 1-Dec/09)
12DEC/09
4523621
24”Valve Panel - 24" Griddle (Standard)
Note: Used from (serial#) 0911100101162.
(4523635 is obsolete, used up to 1-Dec/09)
12DEC/09
58A 4523746 2.5”Valve Panel Hole Cover (Storage Base Option)
59 4523252 24" Plate Rail, Sunre 1
60 4527427
Valve Panel End Cap - Left (was 4523251)
Note: Used from (serial#) 0911100100549 (model) X60-
6R24RR-0003.
1 17NOV/09
61 4527426
Valve Panel End Cap - Right (was 4523250)
Note: Used from (serial#) 0911100100549 (model) X60-
6R24RR-0003.
1 17NOV/09
62 4526110 Burner Box Filler (was 4523193) 2
63 4522561 Manifold Assembly - 24" (without Fittings) 1 C
64 2127502 Regulator - Natural Gas 4.5" WC 1 C
2127500 Regulator - Propane Gas 10" WC 1 C
65 4529768 90 deg Elbow Fitting,7/16CC to 3/8NPT (was G02352-1) 1
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)Page 10
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
24" SINGLE SPACE SAVER OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
66 G022511 Pressure Test Spigot 1
67 2203400 1/8" NPT Pipe Plug 2
68 4523570 .187 (3/16) Dia Tubing - SIT Valve to Oven Pilot 1
68A 4527220 SIT Pilot Tube Connection 1
69 4530485 .437 (7/16) Dia Tubing - SIT Valve to Oven Orice Fitting 1
70 4523043 Air Shield Pilot 20W 1
71 4523042 Air Shield Solid 20W 1
72 4523052 Capillary Guard 20W Standard Oven 1
73 4523030 Bulb Guard Standard Oven 1
74 4523194 Rail Support Bracket 1
75 1082700 Harness Ring, Nickel Plated 2
76 4522400 Trunion Bracket 2
77 4523087 Grate Support Rail 1
78 4523186 24" Drip Angle 2
79 1005110 Flue Collar - Aluminized 1
89 4525041
Hearth Support, L/H 26D (removable)
Note: Used FROM (serial#) 0804100101527 (model)
X60-10RR.
11MAY/08
90 4525042
Hearth Support, R/H 26D (removable)
Note: Used FROM (serial#) 0804100101527 (model)
X60-10RR.
1
91 4523051 Fireplate, 20W Oven, Sunre
92 4522384 Oven Hearth 20W x 26D - Enamelled 1
95 F16 SIT to Manifold Mounting Bolts (#10-24 x 2-1/2", Round
Head, Slot Drive) 2
96 F312 SIT to Manifold Mounting Lock Nut (#10-24, K-Lock
Nut) 2
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 11
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
24" SINGLE SPACE SAVER OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
LEGS & CASTERS
200 4522416 6" Adjustable Leg, Sunre 4
201 4524104 6" Flanged Leg (Optional) 4
202 4526324
6" Caster Package, non-adjustable (Optional)
Note: Includes items 204, 205, 208, and installation
instructions.
1
203 4526323
6" Caster Package, adjustable (Optional)
Note: Includes items 206, 207, 208, and installation
instructions.
1
204 4522417 6" Caster No Brake, 3/4-10 mount, non-adjustable 2
205 4522916 6" Caster With Brake, 3/4-10 mount, non-adjustable 2
206 4525597 6" Caster No Brake, 3/4-10 mount, adjustable 2
207 4525598 6" Caster With Brake, 3/4-10 mount, adjustable 2
208 4526157
Caster Washer
Note: Used FROM (serial#) 0901100100838 (date) 20-
Jan-09.
4 20JAN/09
209 4526325 Caster Washer Kit 1
DOOR COMPONENTS  24" STORAGE BASE MODEL
300 4524305 Door Panel Outer - 24", Standard Base 1
301 4524306 Door Panel Inner - 24", Standard Base 1
302 F557 5/32" Rivet - S/S (Grip Range .039" - .118") 12
303 0780565 Flange Bearing/Bushing 2
304 2530900 0.375" Hole Plug 2
305 3031900 Storage Door Handle 1
306 4524288 Door Hinge Assembly - Right 1
307 4524287 Door Hinge Assembly - Left 1
308 4524308 Door Stop - 15"/24" Door, Standard Base 1
309 F60 Screw-10AX 5/8INTLock Quad Pan 8
310 0781741 Magnetic Door Catch 1
311* 4523669 Logo, Stick-On, Sunre 1
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS

36inch R Oven Secon 1of2
67
42
96
68A
68
65
43 47
69
48
46
95
44
45
66
63
64
49 OR 49A
21
17
7
18 20
19A
19B
8
10
14
12
13
91
15
U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)Page 12
X Series Gas Restaurant Ranges
models X24 / X36 / X60
36” Single Standard Oven / Cabinet Door (1 of 2)

304
3
3
2
1
307
309
310
302
308
301
303
305
300
306
36inch R Oven Secon 2of2
67
90
57
41
92
27
33C (see 33C)
25
31B
32B
55
33B
32A
28
32B
26
30
70
59
74
75
56
89
73
72
76
60 62
58
6
78
71
91
36
29
34B
35 37
38
77
78
5
4
40
39
50
51
62 61
52
34A
38
32A/32B
31A/31B
33A/33B
58A
203
204
205
202 208
206
208
207
209
208
200
201
U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 13
X Series Gas Restaurant Ranges
models X24 / X36 / X60
36” Single Standard Oven / Cabinet Door (2 of 2)

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)Page 14
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
36" SINGLE STANDARD OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
1 4523068 36" Main Channel Front 1
2 4525530 36" Main Channel Rear 1
3 4522764 Body Side L/R 2
4 4522761 Main Back 36" Oven 1
5 4522762 Flue Riser Std Oven 1
6 4524627 Veneer Back, S/S, 36” Std Oven 1
74522787 Oven Pilot Assembly (on L/H Side of Burner) 1 C
8 4522900 Oven Pilot Bracket, Sunre 1
9* F440 #10 - 32 x 1/4" Screw 2
10 2200706 Thermocouple Retaining Nut 1 C
12 2200704 3/16" Compression Nut - Oven Pilot 1 C
13 2200705 3/16" Ferrule - Oven Pilot 1 C
14 4523506 Thermocouple Oven 60" 1 C
15 4522899 Oven Burner Bracket 1
17 2200702 Pilot Orice #32 Natural Gas 1 C
2200703 Pilot Orice #23 Propane 1 C
18 M932 Large Orice # 32 Natural Gas 1 C
M950 Large Orice # 50 Propane 1 C
19A 14155XX Oven Orice Fitting (without orice) 1 C
19B 1415532F Oven Orice Fitting with #32 Hood (Natural) 1 C
1415550F Oven Orice Fitting with #50 Hood (Propane) 1 C
20 4522781 Orice Bracket - Oven 1
21 1028100 Steel Oven Burner with Air Shutter 1
25 4525051 Sunre 26W Oven Door Assembly 1
26 4524058 Door Frame Assembly 26W Sunre 1
27 1082500 Oven Door Trunion 2
28 4523327 Oven Door Panel 26W Sunre 1
29 4522377 Oven Door Liner 26W 1
30 1472322 Insulation, Door 2
31A 3010000 Door Handle End Insulator (Handle Spacer/Insert)
Note: Use Kit 4525581 (item 33C). 2 14AUG/08
31B 4524911
Door Handle End Insulator - Type 2
Note: Used FROM (date) 15-Aug/08 (serial#)
0808100100641 (model) X60-10RR-0001.
2 15AUG/08
32A 3007300 Door Handle End (L/R)
Note: Use Kit 4525581 (item 33C). 2 14AUG/08
32B 4524910
Door Handle End, Sunre, Alum.
Note: Used FROM (date) 15-Aug/08 (serial#)
0808100100641 (model) X60-10RR-0001.
2 15AUG/08
33A 4524986 Door Handle 25-1/4”, Sunre
Note: Use Kit 4525581 (item 33C). 14AUG/08
33B 4522646
Door Handle 36”, Sunre, 1.0” Dia
Note: Used FROM (date) 15-Aug/08 (serial#)
0808100100641 (model) X60-10RR-0001.
1 15AUG/08
33C 4525581 Oven Door Handle Kit, 26W, Sunre
Note: Kit includes items 31B, 32B, 33B 1 15AUG/08
34A 1082802 Hinge Link R/H 1 C
34B 1082803 Hinge Link L/H 1 C
35 4522772 Bell Crank Assembly 2
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 15
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
36" SINGLE STANDARD OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
36 F299 Bolt 1/4-20x1/2" Bell Crank 2
37 4522818 Bell Crank Support Bracket 2
38 4512250 Oven Door Spring 2 C
39 4523497 Oven Door J-Bolt, 6” (F598) 1
40 4526109 Door Spring Adjustment Bracket (26W Door) 1
41 4522770 Kick Panel 26W 1
42 4525442 Knob Assembly - Sunre Oven SIT, deg. F 1 C
4525443 Knob Assembly - Sunre Oven SIT, deg. C 1 C
43 4523081 ES Shield Mount 1
44 4523006 SIT Oven Control 1 C
45 1095499 Straight Connector 7/16 2
46 4523079 ES Shield Rt 1
47 4523080 SIT Lt Shield 1
48 4523499 SIT Top Shield 1
49 4523145 Tube - Sit To Manifold 1
49A 4520720
7/16" Flexible Tubing Sit To Manifold
Note: Applicable Only to Models with 12" Griddles
Mounted on the L/H Side of the Range.
1
50 4522412 Rack Guide, R/H, Sunre 1
51 4522409 Oven Rack 26W x 22D 1
52 4522754 Rack Guide, L/H, Sunre 1
55 4522766 Corner Column R/H 36" 1
56 4522765 Corner Column L/H 36" 1
57 F298N Bolt, #10-24 x 3/8" Shoulder Truss HD, Nickel Plated
(was F298) 2
58
4523088
36”Valve Panel
All Burners or 12” Griddle on L/H or R/H
Note: Used from (serial#) 0911100101162.
(4523330 is obsolete, used up to 1-Dec/09)
12DEC/09
4523615
36”Valve Panel - 24" Griddle on L/H
Note: Used from (serial#) 0911100101162.
(4523633 is obsolete, used up to 1-Dec/09)
12DEC/09
4523613
36”Valve Panel - 24”Griddle on R/H
Note: Used from (serial#) 0911100101162.
(4523622 is obsolete, used up to 1-Dec/09)
12DEC/09
4524094
36”Valve Panel - 36”Griddle
Note: Used from (serial#) 0911100101162.
(4523622 is obsolete, used up to 1-Dec/09)
12DEC/09
58A 4523746 2.5”Valve Panel Hole Cover (Storage Base Option)
59 4523253 36" Plate Rail, Sunre 1
60 4527427
Valve Panel End Cap - Left (was 4523251)
Note: Used from (serial#) 0911100100549 (model) X60-
6R24RR-0003.
1 17NOV/09
61 4527426
Valve Panel End Cap - Right (was 4523250)
Note: Used from (serial#) 0911100100549 (model) X60-
6R24RR-0003.
1 17NOV/09
62 4526110 Burner Box Filler (was 4523193) 2
63 4522562 Manifold Assembly - 36" (without Fittings) 1 C
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)Page 16
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
36" SINGLE STANDARD OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
64 2127502 Regulator - Natural Gas 4.5" WC 1 C
2127500 Regulator - Propane Gas 10" WC 1 C
65 4529768 90 deg Elbow Fitting,7/16CC to 3/8NPT (was G02352-1) 1
66 G022511 Pressure Test Spigot 1
67 2203400 1/8" NPT Pipe Plug 2
68 4523570 .187 (3/16) Dia Tubing - SIT Valve to Oven Pilot 1
68A 4527220 SIT Pilot Tube Connection 1
69 4523143 .437 (7/16) Dia Tubing - SIT Valve to Oven Orice Fitting 1
70 4522774 Air Shield Pilot 26W 1
71 4522773 Air Shield Solid 26W 1
72 4523031 Capillary Guard 26W Standard Oven 1
73 4523030 Bulb Guard Standard Oven 1
74 4523194 Rail Support Bracket 1
75 1082700 Harness Ring, Nickel Plated 2
76 4522400 Trunion Bracket 2
77 4523087 Grate Support Rail 2
78 4523069 Drip Angle, Large 2
89 4525043
Hearth Support, L/H 36” (removable)
Note: Used FROM (serial#) 0804100101527 (model)
X60-10RR.
11MAY/08
90 4525044
Hearth Support, R/H 36” (removable)
Note: Used FROM (serial#) 0804100101527 (model)
X60-10RR.
11MAY/08
91 4523032 Fireplate, 26W Oven, Sunre 1
92 4522385 Oven Hearth 26W x 22D - Enamelled 1
95 F16 SIT to Manifold Mounting Bolts (#10-24 x 2-1/2", Round
Head, Slot Drive) 2
96 F312 SIT to Manifold Mounting Lock Nut (#10-24, K-Lock
Nut) 2
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 17
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
36" SINGLE STANDARD OVEN / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION QTY FROM UP TO
CRITICAL
LEGS & CASTERS
200 4522416 6" Adjustable Leg, Sunre 4
201 4524104 6" Flanged Leg (Optional) 4
202 4526324
6" Caster Package, non-adjustable (Optional)
Note: Includes items 204, 205, 208, and installation
instructions.
1
203 4526323
6" Caster Package, adjustable (Optional)
Note: Includes items 206, 207, 208, and installation
instructions.
1
204 4522417 6" Caster No Brake, 3/4-10 mount, non-adjustable 2
205 4522916 6" Caster With Brake, 3/4-10 mount, non-adjustable 2
206 4525597 6" Caster No Brake, 3/4-10 mount, adjustable 2
207 4525598 6" Caster With Brake, 3/4-10 mount, adjustable 2
208 4526157
Caster Washer
Note: Used FROM (serial#) 0901100100838 (date) 20-
Jan-09.
4 20JAN/09
209 4526325 Caster Washer Kit 1
DOOR COMPONENTS  36" STORAGE BASE MODEL
300 4524282 Door Panel Outer - 36", Standard Base 1
301 4524283 Door Panel Inner - 36", Standard Base 1
302 F557 5/32" Rivet - S/S (Grip Range .039" - .118") 10
303 0780565 Flange Bearing/Bushing 2
304 2530900 0.375" Hole Plug 2
305 3031900 Storage Door Handle 1
306 4524288 Door Hinge Assembly - Right 1
307 4524287 Door Hinge Assembly - Left 1
308 4524284 Door Stop - 36" Door, Standard Base 1
309 F60 Screw-10AX 5/8 InterLock Quad Pan 8
310 0781741 Magnetic Door Catch 1
311* 4523669 Logo, Stick-On, Sunre 1
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS

Tubings:
OVEN on the LEFT Tubings: OVEN on the RIGHT
60inch R Oven Secon 1of2
67
42
96
65
43
47
48
46
95
44
45
66
63
64
49 OR 49A
81
83
82
82A
80
21
17
7
18 20
19A
19B
8
10
14
12
13
91
15
U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)Page 18
X Series Gas Restaurant Ranges
models X24 / X36 / X60
60” Single or Double Standard Ovens / Cabinet Door (1 of 2)

304
307
309
310
302
308
301
303
305
300
306
60inch R Oven Secon 2of2
67
90
57 41
92
27
33C (see 33C)
25
31B
32B
55B
33B
32A
28
32B
26
30
70
59
74
75
55A
89
73
72
76
60
58
6
55C
78
71
91
36
29
34B
35 37
38
77
78
40
39
50
51
62
61
52
34A
38
32A/32B
31A/31B
33A/33B
2A
2B
85
86
79 5
6A 4
1B
1A
62A
3
3
61
79
203
204
205
202 208
206
208
207
209
208
200
201
U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 19
X Series Gas Restaurant Ranges
models X24 / X36 / X60
60” Single or Double Standard Ovens / Cabinet Door (2 of 2)

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)Page 20
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
60" SINGLE OR DOUBLE STANDARD OVENS / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION
OVEN LEFT OVEN RIGHT DOUBLE OVENS
FROM UP TO
CRITICAL
1A 4523068 36" Main Channel Front   1
1B 4525530 36" Main Channel Rear   1
2A 4523184 24” Main Channel Front   1
2B 4525529 24” Main Channel Rear   1
3 4522764 Body Side L/R   2
4 4522994 Main Back (Double Ovens/Oven on Left or Right)   1
5 4522762 Flue Riser Std Oven 1 1 2
6 4524630 Veneer Back, S/S, 60” Std Oven (Option)   1
6A 4524632 Support, Veneer Back, Standard Oven (Option)   1
74522787
Oven Pilot Assembly
Left Oven - Mounted on L/H Side of Burner;
Right Oven - Mounted on R/H Side of Burner.
1 1 2 C
8 4522900 Oven Pilot Bracket, Sunre 1 1 2
9* F440 #10 - 32 x 1/4" Screw 2 2 4
10 2200706 Thermocouple Retaining Nut 1 1 2 C
12 2200704 3/16" Compression Nut - Oven Pilot 1 1 2 C
13 2200705 3/16" Ferrule - Oven Pilot 1 1 2 C
14 4523506 Thermocouple Oven 60" 1 1 2 C
15 4522899 Oven Burner Bracket 1 1 2
17 2200702 Pilot Orice #32 Natural Gas 1 1 2 C
2200703 Pilot Orice #23 Propane 1 1 2 C
18 M932 Large Orice # 32 Natural Gas 1 1 2 C
M950 Large Orice # 50 Propane 1 1 2 C
19A 14155XX Oven Orice Fitting (without orice) 1 1 2 C
19B 1415532F Oven Orice Fitting with #32 Hood (Natural) 1 1 2 C
1415550F Oven Orice Fitting with #50 Hood (Propane) 1 1 2 C
20 4522781 Orice Bracket - Oven 1 1 2
21 1028100 Steel Oven Burner with Air Shutter 1 1 2
25 4525051 Sunre 26W Oven Door Assembly 1 1 2
26 4524058 Door Frame Assembly 26W Sunre 1 1 2
27 1082500 Oven Door Trunion 224
28 4523327 Oven Door Panel 26W Sunre 1 1 2
29 4522377 Oven Door Liner 26W 1 1 2
30 1472322 Insulation, Door 1 1 2
31A 3010000 Door Handle End Insulator (Handle Spacer/Insert)
Note: Use Kit 4525581 (item 33C). 2 2 4 14AUG/08
31B 4524911
Door Handle End Insulator - Type 2
Note: Used FROM (date) 15-Aug/08 (serial#)
0808100100641 (model) X60-10RR-0001.
2 2 4 15AUG/08
32A 3007300 Door Handle End (L/R)
Note: Use Kit 4525581 (item 33C). 2 2 4 14AUG/08
32B 4524910
Door Handle End, Sunre, Aluminum.
Note: Used FROM (date) 15-Aug/08 (serial#)
0808100100641 (model) X60-10RR-0001.
2 2 4 15AUG/08
33A 4524986 Door Handle, Sunre
Note: Use Kit 4525581 (item 33C). 1 1 2 14AUG/08
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
