SUNFLOWER TRIMMER AUTOMATIC-L Dimensions and installation guide

www.sunower-trimmer.com 1
AUTOMATIC - L
SUNFLOWER TRIMMER®
TRIMMING IS EASY
USER MANUAL
and
WARRANTY FORM

SUNFLOWER TRIMMER ®
1
USER MANUAL AND WARRANTY FORM
SUNFLOWER TRIMMER®
TRIM LIKE A PROFESSIONAL

www.sunower-trimmer.com 2
The trimmers from company Sunower-trimmer Ltd. are designed and
manufactured according to legal standards of EU focusing on maximum
safety of the user during work with the machine. The user is obligated to
read and understand the safety warning and recommended procedures
specied in this manual.
Safety goggles
Use plastic goggles with non-tinted visor and without UV lter.
There is a risk of cut pieces of the ower can y away and cause injury
to your eyes.
1. POTENTIAL RISKS AND SAFETY WARNING
1.1 PROTECTIVE EQUIPMENT
1. Potential risks and safety warning 2
1.1 Protective equipment 2
1.2 Machine unpacking and installation 3
1.3 Protective cover 6
1.4 Other risks and recommendations 6
2. Machine basic description 8
2.1 General information 8
2.2 Range of use 8
2.3 Electrical connection 8
3. Operating and handling
3.1 Connection to power source 9
3.2 Leveling and start up 9
3.3 Rotor / cutting blade adjustment 11
3.4 Flowers infeeding 12
3.5 Cleaning during work 13
3.6 Upper frame exchange 14
4. Cleaning 17
5. Storage 17
6. Warranty 18
Please read this manual carefully before use of the machine.

SUNFLOWER TRIMMER ®
3
1.2 MACHINE UNPACKING AND INSTALLATION
1. Unpacking the table including ventilator
2. Unpacking the machine
3. Installation of the machine on the table
When unpacking the machine out of the box please follow the instruction below:

www.sunower-trimmer.com 4
4. Unpacking the upper frame
6. Unpacking the chute 7. Mounting the chute
to trimmer body
5. Installation of the upper frame
on the machine
more info in section 3.6.

SUNFLOWER TRIMMER ®
5
8. Ventilator connection
9. Bag installation
Connect the ventilator to the machine using a plastic hose.

www.sunower-trimmer.com 6
1.3 PROTECTIVE COVER
Keep in mind your own safety at all time. Do not use the trimmer in dusty
or wet environment.The electromotor is not water resistant.
• Clean the trimmer machine according to specications under chapter 4. Cleaning.
Following these instruction you can prevent the damage of the machine or harm to
your own health.
• The machine can only be used for purposes specied in this manual, chapter 2.
Machine basic description – point 2.2. Range of use!
• Never repair or exchange any part of the trimmer in case of malfunction.
• Keep clean the machine and it’s storage place.
• The trimmer machine can be used in interior only.
The use in exterior is not recommended. The trimmer is not water resistant!
• Pay attention to avoid damage to electrical cables of the machine.
• Never reposition the machine when plugged to power source!
1.4 OTHER RISKS AND RECOMMENDATIONS
Always use protective cover on the upper frame when operating the machine.
Never touch or open the top cover when the motor and rotor is rotating.
Never open the top cover of the machine when the motor and rotor is rotating.
Never leave the trimmer in reach of children or persons under age of 18
which are not familiar with the user manual.

SUNFLOWER TRIMMER ®
7
2. MACHINE BASIC DESCRIPTION
The AUTOMATIC -L trimmer machine is developed and build for you to
speed up the cutting of leaves from the owers.
The main frame is made of eloxed aluminum proles which are connected together with
special connectors. The case of the trimmer is made of stainless steel and fastened to the
main frame from all sides. The electromotor is placed outside of the machine.
The cutting rotor and adjustable blade is positioned next to the electromotor.
The trimmer stands on four adjustable rubber blocks.

www.sunower-trimmer.com 8
• The ON / OFF switch is positioned on the front of the trimmer.
• The button to the left from ON / OFF switch start up the ventilator.
• You can adjust the distance between the blade and cutting rotor using two handling
wheels. You can read more about cutting mechanism adjustment in chapter 3.3
- Rotor / cutting blade adjustment.
• Electrical connection and electrical parts are closer described in this chapter under
point 2.3 Electrical connection.
The machine is designed for cutting of ower petals from most of aromatic owers. The
petals are cut automatically in the upper frame of the machine. The ower petal goes
through the tube grid placed in the upper frame. the petal is then cut in the cutting sys-
tem of the machine. The owers are turning in the tube and moving uently towards right
to the end of the machine. The cut leaves are sucked up by ventilator and ow into the
waste bag.
2.1 GENERAL INFORMATION
• The machine can be used only for purposes specied by
manufacturer.
• We strongly advise you to read all safety warnings before
use of the trimmer!
• The machine is designed to remove the leaves from the
owers of plants.
• The machine can only be used on fresh plants with eshy
leaves and stalks which contains no ligneous and solid
parts. This means you can cut the plants whose composition
and solidity is similar to e.g. freshly harvested nettle.
2.2 RANGE OF USE
The trimmer contains electrical parts and connections. Electrical connection means ca-
bles and other parts connecting the electrical devices. The machine contains following
electrical parts: Electromotor 250 W, start up capacitor 20 µF, 2x power switch and 2x euro
connector. The power cable for power source connection is included in the package. The
ventilator output power is 750 W.
2.3 ELECTRICAL CONNECTION
We particularly advise you to pay close attention to your safety during work and
maintenance of your trimmer. You should not get in contact with electrical connec-
tion when using or cleaning the machine. Do not alter or reconnect the electrical
connection!

SUNFLOWER TRIMMER ®
9
Connecting the machine to power source and connecting the ventilator
into the machine
3. OPERATION AND HANDLING
Before you connect the trimmer to power source make sure you executed all safety pre-
cautions stated above.
3.1 CONNECTING TO POWER SOURCE
Euro connector 1
The connector for power input is on the
side of the trimmer. Connect the proper
end of the power cable into the euro-con-
nector. Connect the other end of the cable
into wall socket.
Euro connector 2
serves for ventilator connection
3.2 LEVELING AND START UP
We recommend to set up the machine to be inclined a bit using the ad-
justable legs.
Tilt of the machine Tilt of the table
Make sure once again the top cover is fastened rmly to the upper frame!

www.sunower-trimmer.com 10
Make sure the fastening levers are in the right position!
Do not power on the machine without levers in "locked" position
The machine starts up by right ON / OFF switch on the front side
of the frame. The ventilator starts up by the ON / OFF switch next
to the machine power on button.
Keep in mind all safety precautions stated above during power on of the trimmer!
locked
unlocked
motor of the machine
motor of the ventilator

SUNFLOWER TRIMMER ®
11
3.3 ROTOR AND CUTTING BLADE ADJUSTMENT
Your new machine is set up and adjusted from the manufacturer. To ensure the proper
functionality and durability please pay attention to the following instructions:
1. The cutting blade is adjusted to the rotor using the two handling wheels positioned on
the back of the machine.
2. Rotating the wheels to the right moves the blade to the rotor making the gap between
the blade and rotor smaller. Always turn the wheels not more than ¼ of the circle. Pay
close attention during the process.
3. You can test the optimal position with piece of paper. Insert the paper between the
rotor and cutting blade. Turn the rotor carefully. If the paper is cut, turn the handling
wheel by ¼ turn to the left and leave it in this position.
4. The cutting blade has to be adjusted from both ends using the two handling wheels –
see picture from the back of the trimmer where the two handling wheels are positioned.
Always remove the top cover in order to adjust the cutting blade!
Always make sure the rotor and cutting blade are not in collision with each other.

www.sunower-trimmer.com 12
3.4 FLOWERS INFEEDING
The owers are inserted into the machine using the black chute.
Never insert dirty owers into the machine. Insert clean owers without stalks
or other parts which could damage the machine.

SUNFLOWER TRIMMER ®
13
3.5 CLEANING DURING WORK
We recommend to clean the cutting blades edge, rotor and upper frame.
Always disconnect the machine from the power source before cleaning
of the machine.
We don‘t recommend to clean the surface with hard materials, especially iron tools!
There is a risk of damage to the surface which may result in corrosion!
Pay close attention to avoid injury from contact with sharp parts of the machine.
Cleaning of the blade
Cleaning of the rotor
Dismount the handling wheels in
order to tilt out the cutting blade.

www.sunower-trimmer.com 14
Ventilator cleaning
3.6 UPPER FRAME EXCHANGE
Use maximum caution when exchanging the upper frame and follow
these instruction:
Make sure the machine is uplugged from electricity
and its parts are not moving.
1. Turn the levers
Before cleaning of the ventilator unscrew the
winged screws and remove the upper ange
from the ventilator.
2. Take the upper frame with both hands and move the front side up.

SUNFLOWER TRIMMER ®
15
1. Take the upper frame with both hands – see picture
Installation of the upper frame:
3. Move the frame towards you and remove it completely.
4. Put the upper frame aside carefully.
During installation make sure the upper frame bar is
inserted correctly into the lock on the machine.

www.sunower-trimmer.com 16
2. Let the upper frame sit on the machine.
3. Lock the levers
4. Install the upper cover, the chute and you are ready

SUNFLOWER TRIMMER ®
17
4. CLEANING
5. STORAGE
After each use of the trimmer we recommend the following:
• 1. Clean all dirty spots of the machine using alcohol-based
cleaner or other solvent.
• 2. Make sure no cut pieces of the plant getting outside of the
cutting area.
• 3. Clean the rotor of ventilator.
• 4. Empty the waste bag.
Store your machine in clean and dry place!

www.sunower-trimmer.com 18
6. WARRANTY FORM
In order to acquire a 5 year warranty according to our warranty
conditions available on www.sunower-trimmer.com
it‘s necessary to complete the following:
• 1. Fill out and keep the warranty form.
• 2. Complete the warranty form with stamp of the seller and date of purchase.
• 3. Send a conrmation of purchase to: info@sunower-trimmer.com
latest within 30 days from the date of purchase. Include name of the retailer,
date of purchase and serial number of the machine.
• You will receive a conrmation by email within one week.
Stamp Sunower-Trimmer, s.r.o.:
Model of the machine
AUTOMATIC - L
Stamp seller:
Serial number:
Sunower-Trimmer, s.r.o.
Kaprova 42/14
110 00 Praha
The Czech Republic
tel.: [phone]
e-mail: info@sunower-trimmer.com
www: info@sunower-trimmer.com
Made in the Czech Republic
