Sunforce MOTION ACTIVATED SECURITY LIGHT & VIDEO... User manual

1
MOTION ACTIVATED SECURITY LIGHT & VIDEO CAMERA
Front View
AFront Surround
BLampshade
CMicrophone
DCamera
EPIR (Motion Sensor)
FWarning Speaker
GLux Control Knob
HTime Control Knob (PIR trigger time)
ILCD control panel and Setting buttons
JBattery Cover
KSD Card Slot
PACKAGE CONTENT
The Motion Activated Security Light & Video Camera is
packed specially to minimize the chance of the
contents been damaged during shipping and handling.
Please check the unit carefully and confirm the
contents listed below are included.
No.
Item
Qty
1
Base Unit (VC603)
1
2
AA Size 1.5V Alkaline Battery
4
3
2GB SD Card
1
4
Screw Pack
1
5
Halogen Bulb
1
6
Operating Instruction Manual
1
INTRODUCTION
Your MOTION ACTIVATED SECURITY LIGHT &
VIDEO CAMERA is a unique surveillance system for
your home or business. At night, the built-in passive
infrared (PIR) motion sensor turns on the light when it
detects motion in its coverage area, so that camera
images can be clearly seen. During the day, the
built-in photocell sensor saves electricity by
deactivating the light. Built-in SD card slot for additional
storage, accept memory storage up to 32GB.
Pre-recorded function allows you to trace event
happening, and customized sound recording is
available at your disposal.
The MOTION ACTIVATED SECURITY LIGHT & VIDEO
CAMERA is compatible with O-Net product and can be
controlled by remote controller. The unit is designed
for indoor/outdoor use.
Note: Read this entire manual before you start to install
the system.
BEFORE START
Please follow the steps as suggested below to get a
better result of installation.
CAUTION: 4 batteries provide for function setting
only, NOT installing the battery until you're ready to set
the function and mount on the wall, the battery power
supports for about 1 hour operation after installed.
POWER UP
The Motion Activated Security Light & Video Camera is
powered by batteries at the initial stage. Press and
release the battery cover, insert 4 AA size 1.5V alkaline
batteries to the battery spring. Please ensure correct
polarity is put. After that, refit the battery cover.
(FIGURE 1)
FIGURE 1
Rear View
6
8
7
9
Side View

K

2
Once Motion Activated Security Light & Video Camera
is powered up, it enters PIR warm up time. The LCD
displays as below (FIGURE 2).
FIGURE 2
After 3 seconds, the unit enters standby mode (as
shown in FIGURE 3). It implies the unit is ready for
function setting.
FIGURE 3
SD CARD INSTALLATION
Once the unit is powered up, if no SD card is found, a
beep sound will be played for 10 seconds once an hour.
Once the unit is powered up, if no SD card is found, a
beep sound will be played for 10 seconds once an hour.
After function setting is completed, the most
appropriate timing to insert the SD card is before
you start AC wiring connection.
For security reason, the 2GB SD card is sealed in the
Cam specially by using a hex design screw. There is
no need to take it out unless an irregular condition has
occurred (e.g. detection of an intruder or breaking
attempts), or to upgrade it with a larger capacity SD
card up to 32GB.
Note: Make sure the unit is powered off before
inserting or removing a SD card. In case the unit is
not powered off, press Set to enter scene mode and
then press Up or Down to choose Scene 4. After the
unit is set in Scene 4, insert or remove a SD card
accordingly. To insert a SD card:
(1) Insert the wrench provided in screw pack. (/- 4
56- 404. '%+)7, +5:- 7;09/9/- ;7- 4+/04#!$
)490!+25+1;08- +07+2- 89/- 4+)4820, - , 5;49/- +5:- 7
9/- 8+7- ;;54=9*- 3 5:- , );)<95):50, 8+7- ;3 08804. "
(FIGURE 4)
FIGURE 4
(2) Insert SD card into the card slot (FIGURE 5).
FIGURE 5
(3) Refit the cover, and fasten the screw clockwise
(FIGURE 6).
FIGURE 6
(4) Once Motion Activated Security Light & Video
Camera is powered up, it will detect
the existence of LIGHT folder. All recorded files will be
saved onto it. If the folder isn’t found, the SD card will
be formatted while a LIGHT folder will be generated.
(5) Once a recording is taken, it will be saved in .asf
format under the path LIGHT\YMD\time+serial
no.asf. Below is an example of a self generated
file name:
17075600
Note: Oldest images are deleted and overwritten as the
card reaches capacity to ensure records of recent
events are always available.
BULB INSTALLATION
CAUTION: Always handle quartz halogen bulb with a
soft cloth. Do not touch the bulb with your bare hand
as it will shorten the bulb life.
(1) Do not touch the light while it is in use or still hot.
Allow it to cool off (about 5 minutes) before
touching it.
(2) Do not use halogen bulb rated higher than 150/300
watts.
(3) Disconnect the power cord or wall switch and then
use a cross head screwdriver, loose the screw at
the bottom edge of the front surround (FIGURE 7).
FIGURE 7
Hour
Minute
Seconds
Serial no.

3
(4) Take off the front surround. Install bulb by inserting
one end first and depressing until enough
clearance is gained to seat the other end of the
socket. Rotate halogen bulb to assure proper
seating. Refit the front surround in place and
fasten the screw (FIGURE 8).
FIGURE 8
FUNCTION SETTING
The Motion Activated Security Light & Video Camera
has a LCD panel with three control knobs: Set, Up and
Down (FIGURE 9).
FIGURE 9
TWO SETTING FUNCTIONS
The Motion Activated Security Light & Video Camera
has two setting functions: general setting and local time
setting. Under standby mode, prompt pressing or long
pressing (about 3 seconds) of Set can lead to different
settings. The following diagram illustrates setting
sequence of general setting and local time setting.
FIGURE 10
LOCAL TIME SETTING
The Motion Activated Security Light & Video Camera
has a pre-record and time record function. The
pre-record time is the length of time before the unit
detects a motion; it can be varied from 4 to 12 seconds.
During this time, video will be taken which allows you to
trace what’s happening. To ensure you get correct
time and day for the recorded images, it is particular
important to set the year, month,
day and time accurately. Please select scene to 1, 2
or 3 before follow the steps below to set up exact local
time.
1. YEAR
Under standby mode (FIGURE 3), press Set for 3
seconds and light flashes once to enter local time
setting. When displays on LCD, it is ready for year
setting.
Year range is between 2010 ~ 2099, press Up or Down
to select correct year, as shows below:
FIGURE 11
2. MONTH & DATE
Once year setting is completed, press Set, the
displays on LCD, it is ready for month and date
setting.
Month ranges from Jan to Dec, press Up or Down to
select correct month. After that, press Set to adjust
date. The digit will not flash so you simply press Up or
Down to select correct date. The date ranges from 1st
to 31st . The LCD shows as below:
FIGURE 12
3. HOUR & MINUTE
Once month and date setting is completed, press Set to
enter hour and minute setting.
Hour ranges from 00 to 23, press Up or Down to select
correct hour. After that, press Set to adjust minute.
The digit will not flash so you simply press Up or Down
to select exact minute. Minute ranges from 00 to 59.
The LCD shows as below:
FIGURE 13
After month and date setting is completed, press Set
and LCD returns back to standby mode (FIGURE 3).
This implies the local time setting is completed. PIR
stops detecting function for one minute.
Standby
Mode
Scene
Mode
Warning
Sound
PIR
Sensitivity
ID Code
Learning
Standby
Mode
(completed)
General Setting
(Prompt Pressing)
Standby
Mode
Year
Setting
Month
Setting
Date
Setting
Hour
Setting
Minute
Setting
Standby
Mode
(completed)
Local Time Setting
(Long Pressing)

4
Note: If no action is taken within 12 seconds, the LCD
returns back to standby mode; the setting is not saved.
To ensure the setting has been saved properly, always
keep pressing Set until LCD returns back to Standby
Mode.
GENERAL SETTING
1. SCENE MODE
Scene selection allows you to choose a most suitable
combination of Motion Activated Security Light & Video
Camera’s functions. Under standby mode (FIGURE
3), press Set to enter scene mode, the LCD shows as
below:
FIGURE 14
Scene one is the preset mode. Press Set, the light
turns on, reminds user the Motion Activated Security
Light & Video Camera starts operating. Four scenes
are available for selecting, press Up or Down to
change scene.
After desired scene is selected, the light flashes once,
and then turns on steadily for 10 seconds implies the
scene changing is in progress. Once the light turns off,
if you wish to save the setting or skip other settings,
keep pressing Set until LCD returns back to standby
mode.
Note: Under scene mode, if no action is taken within 12
seconds, LCD returns back to standby mode and the
light turns off; the setting isn’t saved.
The following are details of four scene modes:
1.1 Scene 1
It’s all armed mode (FIGURE 15). Once the PIR
detects a motion, the camera and light turns on,
microphone starts recording and warning sound plays
for 10 seconds.
FIGURE 15
Ambient Light
Function
Day
Night
Camera & MIC
On
On
Warning Speaker
On
On
Light
On
On
1.2 Scene 2
Once PIR detects a motion, the camera and
microphone starts recording. Depending on the
ambient light is day or night, speaker and light turn on.
FIGURE 16
Ambient Light
Function
Day
Night
Camera & MIC
On
On
Warning Speaker
On
Off
Light
Off
On
1.3 Scene 3
Once PIR detects a motion, the camera and
microphone starts recording. Depending on the
ambient light is day or night, speaker and light turn on.
FIGURE 17
Ambient Light
Function
Day
Night
Camera & MIC
On
On
Warning Speaker
Off
On
Light
Off
On
1.4 Scene 4
The camera and warning speaker are both off, it’s
energy saving mode. Once PIR detects a motion,
depending on the ambient light is day or night, turn
on/off the light. The light can also be turned on/off via
remote controller.
FIGURE 18
Ambient Light
Function
Day
Night
Camera & MIC
Off
Off
Warning Speaker
Off
Off
Light
Off
(Remote Control
ON/OFF)
On
(Remote Control
ON/OFF)
Note: Under Scene 4, local time setting is not available.
2. WARNING SOUND
Under scene mode, press Set to enter warning sound
setting, the LCD shows as below:

5
FIGURE 19
Warning sound 1 is the preset sound. Five warning
sounds are available for selecting, while warning sound
3 and 4 are opened for your voice/sound recording. The
playtime for each warning sound is 10-second, and the
sound volume is 85dB at 30cm distance.
Press Set, the light is still on, reminds user the Motion
Activated Security Light & Video Camera starts
operating. Five warning sounds are available for
selecting, press Up or Down to change warning sound.
After desired sound is selected, if you wish to skip other
settings, keep pressing Set until LCD returns back to
standby mode which implies general setting is
completed.
Note: Under warning sound mode, if no action is taken
within 12 seconds, the LCD returns back to the standby
mode and the light turns off; the setting isn’t saved.
The following are the five warning sounds:
2.1 Warning Sound 1
It is alarm sound; it can’t be changed.
FIGURE 20
2.2 Warning Sound 2
It is dog barking sound; it can’t be changed.
FIGURE 21
2.3 Warning Sound 3
It is opened for user recording; you can record your
own audio warning.
FIGURE 22
2.4 Warning Sound 4
It is opened for user recording; you can record your
own audio warning.
FIGURE 23
Built-in microphone is used for video recording and for
creating your unique warning sound. To create your
unique sound (warning sound 3 & 4):
a. Select warning sound 3 or 4
b. Press Set for 3 seconds, the light flashes once
implies the Motion Activated Security Light & Video
Camera is ready for recording.
c. Wait for 5 seconds, LCD occurs with REC, the
recording starts (FIGURE 24).
FIGURE 24
d. Record time is 10-second.
e. After recording, the LCD returns back to warning
sound 3 or 4 (FIGURE 22 or 23).
f. The unit will replay the record sound for verification.
g. After sound playing, the LCD returns back to
standby mode (FIGURE 3), sound recording and
warning sound selection is completed. PIR stops
detecting function for one minute.
h. If warning sound 1, 2 or 5 is selected, press Set for
3 seconds will not execute recording function. Ten
seconds after LCD returns back to standby mode,
the setting of warning sound is completed.
Note: If you wish to execute sound recording while the
unit is executing video recording, the sound recording
will not be executed until video recording is completed.
2.5 Warning Sound 5 (Mute Mode)
Warning sound 5 is mute mode which can’t be
changed.
FIGURE 25
3. PIR SENSITIVITY
Under warning sound mode, press Set to enter PIR
sensitivity selection.
FIGURE 26

6
Press Set, the light is still on, reminds user the Motion
Activated Security Light & Video Camera starts
operating. Four PIR sensitivities are available for
selecting, press Up or Down to change sensitivity.
PIR sensitivity one is the highest sensitivity and the
preset value.
After desired sensitivity is selected, if you wish to skip
other settings, keep pressing Set until LCD returns
back to standby mode which implies general setting is
completed.
PIR sensor can be swiveled in different direction to
adjust detection coverage.
Note: Under PIR sensitivity setting, if no action is taken
within 12 seconds, the LCD returns back to the standby
mode and the light turns off; setting isn’t saved.
Four PIR sensitivity displays:
FIGURE 27
4. ID CODE LEARNING
Under PIR sensitivity setting, press Set to enter ID
code learning mode, the LCD shows as below:
FIGURE 28
Press Set, the light is still on, reminds user the Motion
Activated Security Light & Video Camera starts
operating. Once the unit enters ID code learning
mode, press Set for 3 seconds. The light flashes, and
the unit starts ID code learning. Thirty seconds
countdown starts and shows as below:
FIGURE 29
If ID code learning can’t finish within 30 seconds, it is
failed and LCD returns back to standby mode. If ID
code learning is successful, LCD returns back to
standby mode and PIR stops detecting function for one
minute.
Once Smart Cam receives RF signals for scene
changing, the light flashes once and then turns on
steadily for 10 seconds implies the scene changing is in
progress. After that, the light turns off. The setting is
completed within one minute after RF signal is
received.
The unit can learn up to 12 ID codes. If you wish to
clear ID codes, please also enter ID code learning
mode. Thirty seconds countdown start, press Set for 6
seconds. Please note once ID code clearing is
executed, all ID codes recorded in the unit will be
cleared.
To ensure learning/clearing is successful, you can use
the remote controller to switch between scenes. Please
refer to the user manual of remote controller for more
operating information.
If unit receives signal of turning on
It works as a working light while the function of
camera and PIR detection is off.
If unit receives signal of turning off
The PIR and LUX detection of Motion Activated
Security Light & Video Camera are still active, but
the light only turns on at night while camera is off.
Note: Under ID code learning mode, if no action is
taken within 12 seconds, the setting isn’t saved. LCD
returns back to the standby mode, and the light turns
off.
SETTING THE LIGHTING SYSTEM
(1) TIME ADJUSTMENT
The TIME adjustment controls how long the light stays
on after the motion has been detected, as well as video
recording time. Three length of time are available for
selection: 20 seconds, 1 minute and 5 minutes. Turn
the TIME control knob to the position of 20s, 1min or
5min (FIGURE30). Please ensure the control knob
has been turned and set to the accurate position.
FIGURE 30
Note: During the set time, if PIR keeps detecting
moving object, the lighting time will be extended, but
not the recording time. Once time is up (i.e. 20
seconds, 1 minute or 5 minutes), the recording stops.
It takes 2 seconds before next recording is on if a
motion has been detected by PIR.
(2) LUX ADJUSTMENT
The LUX adjustment determines at what light level the
PIR Sensitivity 1
(Highest Sensitivity)
Sensitivity 2
Sensitivity 3
PIR Sensitivity 4
(Lowest Sensitivity)

7
light starts operating.
Provisionally turn the LUX control knob to the edge at
the moon (dusk) position (FIGURE 31). In this
provisional setting mode, the Motion Sensor remains
inactive during daylight. At dusk when you find it is the
LUX level desired for operation, simply set the LUX
control knob to the position which will become active as
daylight declines.
Note: The LUX setting range is between 20 LUX to 200
LUX.
FIGURE 31
CHOOSING A MOUNTING LOCATION
For the best results, fix the unit on a solid surface,
2~2.5m above the ground.
Avoid aiming the unit at pools, heating vents, air
conditioners or objects which may change
temperature rapidly.
Do not allow sunlight to fall directly on the front of
unit.
Try to avoid pointing the unit at trees or shrubs or
where the motion of pets may be detected.
The motion sensor is more sensitive to objects
moving across its field of view. It is less sensitive
to an object moving directly towards the sensor
head. (FIGURE 32).
head. (FIGURE
head. (FIGURE
head. (FIGURE
head. (FIGURE
head. (FIGURE
head. (FIGURE
SENSITIVITY TO MOTION
FIGURE 32
SAFETY PRECAUTIONS
Do not install the MOTION ACTIVATED
SECURITY LIGHT & VIDEO CAMERA when it is
raining.
Be sure to switch off power source before
installing.
To avoid fire or burn hazards:
Allow fixture to cool before touching. The bulb
and the fixture operate at high temperatures.
The halogen bulb installed must parallel to the
ground as shown in the below drawing. (FIGURE
33)
FIGURE 33
IMPORTANT
Installation must be performed by skilled
technicians who are informed about the standards
and technical requirements of the appliance and its
proper installation.
Check your local codes as they apply to your
situation. If the house wiring is of aluminum, consult
with an electrician about proper wiring methods.
Before proceeding with the installation, TURN OFF
THE POWER TO THE LIGHTING CIRCUIT AT THE
CIRCUIT BREAKER OR FUSE BOX TO AVOID
ELECTRICAL SHOCK.
INSTALLATION
A drill and a screwdriver are needed for installation.
Select a location for the unit based on the coverage
angles as shown in FIGURE 34. (110º at 8m range)
FIGURE 34
Install a wall switch adjacent to the power source.
(FIGURE 35). This will help you operate MOTION
ACTIVATED SECURITY LIGHT & VIDEO CAMERA
with ease.

8
WIRING INSTRUCTION
American Version
(1) Switch off the power source or wall switch.
(2) Line up the holes on the mounting bracket with the
holes on your junction box. Using fitting screws
(depending on size of the holes in your junction
box), and attach the mounting bracket to your
junction box (FIGURE 36).
FIGURE 36
(3) Place the gasket in position before wiring.
(4) Connect the brown wire from the fixture to the
brown (Live) power supply wire from your power
source using the wire nuts provided. Connect the
blue wire from the fixture to the blue (Neutral)
power supply wire using the wire nuts provided.
Connect the yellow/green wire from the fixture to
the yellow/green (Earth) power supply wire using
the wire nuts provided (FIGURE 37).
FIGURE 37
(5) Place the wiring box and secure it with the two
screws provided. (FIGURE 38)
FIGURE 38
Note: THIS EQUIPMENT MUST NOT BE MOUNTED
ON AN OUTLET BOX WHICH IS SUPPORTED BY A
BAR HANGER or equivalent (NE PAS MONTER CET
ÉQUIPEMENT SUR UNE BOÎTE DE SORTIE FIXÉE À
UNE BARRE DE SUSPENSION or equivalent).
Japanese Version
According to the place where you plan to install, choose
whichever suits you most.
>

(1) Switch off the power source or wall switch.
(2) Undo the screw which is situated adjacent to the
setting buttons so as to detach the mounting
bracket from the unit. (FIGURE 39)
FIGURE 39
(3) Using the mounting bracket as a template, mark
the positions of fixing hole on the wall. Drill the
hole and insert the plastic wall plug supplied.
Secure the mounting bracket using two screws
provided. (FIGURE 40)
FIGURE 40
(4) Place the unit to the mounting bracket by fastening
the screw.
?


(1) Place the clamp to the mounting bracket by
securing with four screws provided. Put the
rubber bumper around the square protrusion of
clamp. (FIGURE 41)

9
FIGURE 41
(2) Insert the L shaped holder through the two holes on
the clamp. (FIGURE 42)
FIGURE 42
(3) Using the thumb nut on the L shaped holder, fasten
the unit on the pillar. (FIGURE 43)
FIGURE 43
@
(1) Place the clamp to the mounting bracket by
securing with four screws provided. Put the
rubber bumper around the square protrusion of
clamp. (FIGURE 44)
FIGURE 44
(2) Insert the pole band through the two holes on the
clamp. (FIGURE 45)
FIGURE 45
(3) Measure the required length of pole band to be
used. Fold up unused pole band. (FIGURE 46)
FIGURE 46
(4) Put the unit on the pillar and connect two ends of
pole band accordingly. (FIGURE 47)
FIGURE 47
European Version
(1) Switch off the power source or wall switch.
(2) Remove the wall box then unscrew one of the
screws on the pressure block. (FIGURE 48)

10
FIGURE 48
Note: There is a “UP” mark shown on the interior
wall box. Be sure to have “UP” mark shown
upwardly when fixing the wall box on the
wall.
(3) Use a screwdriver to break a small hole on the cable
gasket enabling the power cord to enter the wall box.
(FIGURE 49)
FIGURE 49
(4) Route the power cord through the cable gasket.
Note: The power cord must meet H05RN-F,
1.0mm²requirement.
(5) Fix the wall box to the pre-determined mounting
location by making use of the two screws provided.
(FIGURE 50)
FIGURE 50
(6) Strip approximately 6-8mm insulating part of the
wires from the power cord. Before connection,
ensure that the wall box gasket is firmly seated in
its original place.
(7) Connect the BROWN wire (Live wire) to the
terminal block “L” mark.
Connect the BLUE wire (Neutral wire) to the
terminal block “N” mark.
Connect the YELLOW/GREEN (Ground wire) to
the terminal block “ “ mark. (FIGURE 51)
FIGURE 51
(8) The unit should be earthed.
(9) Make sure that the terminal block is put in its
original position after connecting the wires.
Note: Strongly recommend that 4 batteries should be
removed after your Motion Activated Security Light &
Video Camera connected to AC power.
TROUBLESHOOTING
Light does not turn on:
Confirm that you have made a correct “wiring
connection”.
Make sure that the bulb has not burned out
and is installed correctly.
Warning Sound is on after powering up:
SD card is not inserted.
PIR and LUX is not working:
Do not allow sunlight to fall directly on to the
front of the unit.
Warning sound and video recording is not on:
They are on only when the unit is triggered.
Make sure the unit is not on Scene 4.
Please re-power the unit
Filmed videos can’t be saved into SD card:
Damage of the videos might be caused by
inappropriate retrieval/insertion of SD card;
ensure the unit is powered off before the
action is taken.
No action is taken after scene changing:
Under video recording mode, the scene
changing will not happen until PIR triggering
time is finished (e.g. if PIR triggering time is
set to 5 mins, the scene changing will be
taken 5 mins later).
Video and sound recording is not executing:
The function is disabled if the unit is set to
scene 4.
The taken images of people are blurred during the
night:
Avoid taking images with sky as background;
turn the camera lens down if it is the case.
Try not to spot the light on reflective objects;
the reflection of light could cause blurred
images.

11
SPECIFICATIONS
Power Requirement
120V~ 60Hz for USA or
220-240V~ 50Hz for EU or
1.5V AA alkaline battery x 4
(for SD card & camera only)
Lighting Load
Max. 300W Halogen Bulb
(VC603-1-2-3)
Max. 150W Halogen Bulb
(VC603-4-5-6)
PIR Detection Angle
Up to 150°at 3m range
PIR Detection Distance
Up to 12m under 28°C
Protection Class
I
Protection Degree
IP44 for Europe. Suitable for
wet locations for USA
Swiveling Angle
Sensor Part: Horizontal 90°
(45°left, right), Vertical 30°
(downward)
Mounting Height
2 to 2.5m
Time Adjustment
20 secs/1 min /5 mins
Lux Adjustment
Yes
Warm Up Time
About 60 second
Operating Temperature
Range
-10°C ~ 40°C. 20~85%
relative humidity,
non-condensation.
CAMERA
Pixel
640 x 480 Pixel VGA
Lux Sensitivity
1 Lux
White Balance
Auto
AGC
Auto
Backlight
Compensation
Auto
SNR
>48 dB
Gamma Compensation
0.45
Electric Shutter
Auto
Angle
60°
Microphone
Built-in
SD Card
Write-protect Switch
YES
Capacity
Min. 512MB ~ Max. 32GB
(2GB SD card is included)
Format
FAT/FAT32
*Specifications are subject to change without prior
notice.
A501111599R02
Federal Communication Commission Interference
Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions.
1) This device may not cause harmful interference, and
2) This device must accept any interference received,
including interference that may cause undesired
operation.
Per FCC 15.21, you are cautioned that changes or
modifications not expressly approved by the part responsible
for compliance could void the user’s authority to operate the
equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment. End users must
follow the specific operating instructions for satisfying RF
exposure compliance.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Do not dispose of electrical appliances as unsorted municipal
waste, use separate collection facilities.
Contact your local government for information regarding the
collection systems available.
If electrical appliances are disposed of in landfills or dumps,
hazardous substances can leak into the groundwater and get
into the food chain, damaging your health and well-being.
When replacing old appliances with new once, the retailer is
legally obligated to take back your old appliance for disposal
at least for free of charge.
