Samsung SCB-4000 User manual

SCB-4000
• High resolution of 600TV lines (Color)
• Min. illumination of 0.1Lux
• Intelligent video analytics(Moved / Fixed / Fence / Area / Tracking)
• XDR(eXtended Dynamic Range), coaxial control support
• Motion adaptive DNR noise reduction
Equipped with A1 chipset, the SCB-4000 achieves vivid color
images at 600TV lines resolution. With low light levels of 0.1Lux
and XDR technology to increase the level of visible detail in the
dark areas. In addition, there is built-in coaxial control
function, multi-language OSD and intelligent video analytics
for user convenience.
High Resolution Day&Night Camera
Crystal clear images with
600TV Lines
www.samsungsecurity.com05-2010

The Eco mark represents
Samsung Techwin’s will to create
environment-friendly products,and indicates
that the product satisfies the EU RoHS Directive.
0.1
Lux
600TVL
Adaptive
High Resolution Day&Night Camera
SCB-4000
Specifications
Dimensions Unit : mm (inch)
Design and specifications are subject to change without notice.
SCB-4000N SCB-4000P
Dual (12V DC/ 24V AC)
Max. 4.0W
1/2" Ex-view HAD CCD
811(H) x 508(V) 795(H) x 596(V)
768(H) x 494(V) 752(H) x 582(V)
2 : 1 Interlace
Internal / Line lock
H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Color : 600TV lines (Min.) / B/W : 700TV lines (Min.)
Color : 0.1Lux ([email protected]), 0.0002Lux (Sens-up, 512x)
B/W : 0.01Lux ([email protected])
52dB (AGC off, Weight on)
CVBS : 1.0 Vp-p / 75Ω composite
English, Japanese, Spanish, English, French, German, Spanish, Italian, Chinese,
French, Portuguese, Taiwanese, Korean Russian, Polish, Czech, Danish, Turkish
On / Off (Max. 54ea / 2 lines)
Auto (ICR) / Extern / Color / B/W
On / Off
BLC (On / Off)
Low / Medium / High / Off
On / Off
On / Off (12 polygonal programmable zones)
Off / Very low / Low / Medium / High / Very high / User / Fix
On / Off (Selectable limit ~ 512x)
Low / High / Off
ATW1 / ATW2 / AWC (Manual) / 3200°K / 5600°K
1/60 ~ 1/10,000sec 1/50 ~ 1/10,000sec
On / Off (2x ~ 16x)
On / Off (Moved / Fixed / Fence / Area / Tracking)
On / Off
RS-485, Coaxial control (CCVC)
Samsung-T, Samsung-E, Pelco-D, Pelco-P, Bosch, Honeywell, Vicon, Panasonic
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH
64 x 58 x 109.2mm (2.52" x 2.28" x 4.3")
305g (0.67 lb)
C / CS
FCC (Class A), UL (External power supply) CE (Class A)
ELECTRICAL
Input Voltage
Power Consumption
VIDEO
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Synchronization
Frequency
Horizontal Resolution
Min. Illumination
S / N (Y signal)
Video Output
OPERATIONAL
On Screen Display
Camera Title
Day & Night
Digital Noise Reduction
Backlight Compensation
eXtended Dynamic Range
Digital Image Stabilization
Privacy Masking
2D+3D Noise Filter (A1)
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Digital Zoom
Intelligent Video
PIP
Communication
Protocol
ENVIRONMENTAL
Operating Temperature / Humidity
MECHANICAL
Dimension (WxHxD)
Weight
Lens Mount
Certifications
I.E-1005
DISTRIBUTED BY
SAMSUNG TECHWIN CO., LTD.
701, Sampyeong-dong, Bundang-gu, Seongnam-si, Gyeonggi-do Korea 463-400
Tel : [phone]~8749, 8752~8760 Fax : [phone]
www.samsungsecurity.com www.samsungcctv.com
SAMSUNG TECHWIN AMERICA Inc.
1480 Charles Willard St, Carson, CA 90746, UNITED STATES
Tol Free : [phone] Fax : [phone]
www.samsungcctvusa.com
SAMSUNG TECHWIN EUROPE LTD.
Samsung House, 1000 Hillswood Drive, Hillswood Business Park
Chertsey, Surrey, UNITED KINGDOM KT16 OPS
Tel : [phone] Fax : [phone]
TIANJIN SAMSUNG TECHWIN OPTO-ELECTRONICS CO., LTD.
No.11 Wei 6 Street. Micro-Electronic Industrial Park
Jingang Road, Tianjin, P.R. CHINA 300385
Tel : [phone] Fax : [phone]
64 (2.52") 100 (3.94") 9.2 (0.36")
64 (2.28")
