Sunjoy A101012100 User manual

Country of Origin: China Production Number: xxxxxxxxxx
ITEM NO.:A101012100
WE HAVE YOU IN MIND, LET US SERVE YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sunjoyonline.com
1-(866)-578-6569
[email protected]

2/ 8
Country of Origin: China
Safet
y
Information
The limited warranty is extended to the original purchaser and applies to material and manufacturer’s defect provided
the item is maintained with care and used only for personal, residential purposes.
Warranty: 6 months
WHAT IS COVER?
IMPORTANT
CAUTION: Do not climb on top of the
gazebo. Falling off the gazebo can
result in serious injury.
NOTICE: For outdoor use
DANGER: This unit is heavy! Do not assemble
this item alone.
WARNING: Do not leave the gazebo where there
1. Two people are required for this
assembly.
2. Some parts may contain sharp edges. Wear
protective gloves.
3. When assembling and using this product,
basic safety precautions should always be
followed to reduce the risk of personal injury
and damage to equipment. Please read all
instructions before assembly and usage.
WARNING: Keep all flame and heat sources
away from this gazebo fabric. This Gazebo is
made with fabric that meets CPAI-84
specifications for flame resistance. It is not
fire proof. The fabric will burn if left in
continuous contact with any flame source.
The application of any foreign substance to
the gazebo fabric may render the
flame-resistant properties ineffective.
is a risk of high wind, as possible damage will
occur to the structure.

3/ 8
Country of Origin: China
Description Label Part# Qty Image
Screen 1 A P006300073 4
Screen 2 B P006300074 4
Short across
beam C P000400868
2
Long across beam
1 D P000400870
2
Long across beam
2 E P000400869
2
Slanting beam
upper tube F P000601308 4
Middle beam
（Long） G P000601309 2
Middle beam
（Short） H P000601310
2
Big top
connector J P000501141
1
Adjust tube K P005700643 4
Hook L P005800001 1
Connector for
Slanting Beam 1
M P000501142 2
Connector for
Slanting Beam 2
N P000501143 2
Finial P P005600298 4
Big canopy Q P001100524 1
Small canopy R P001100525 1
Parts List

4/ 8
Country of Origin: China
Hardware Pack 1
Label Description Part# Qty Image
AA M6X15 Bolt H010020011 4PCS
BB M6 flat washer H050010023 48PCS
CC M6X30 Bolt H010020023 28PCS
DD M6 nut H040010003 16 PCS
W1 M6 Wrench H090010008 2 PCS

5/ 8
Country of Origin: China
Fig.1：Attach screen1（A）to screen2 （B），then fix by using Bolt（CC）and Flat washer（BB）.
Fig.2：Insert Long across beam 1(D) into Long across beam 2(E) then fix by using Bolt（AA）
and Flat washer（BB）.
Fig.3：Attach the across beam（C/D/E）to screen（A/B）fix by using Bolt（CC）and Flat washer
（BB）nut（DD），form the whole framework.
Hardware Pack 2
Label Description Part# Qty Image
BB M6 flat washer H050010023 4PCS
AA M6X15 Bolt H010020011 4 PCS
Fig.4：Insert Connector for Slanting Beam(M/N) to screen（A/B）.
Fig.5：Insert Slanting beam upper tube(F) to Big top connector(J).
Fig.6：Insert Slanting beam upper tube(F) to Connector for Slanting Beam(M/N).

6/ 8
Country of Origin: China
Fig.7：Insert Middle beam(G/H) to Big top connector(J).
Fig.8：Attach Connector for Slanting Beam（G/H）to across beam fix by using Bolt（AA）and Flat washer
（BB）.then Put big canopy（Q）on big top frame( Do not fasten corner)。。
Fig.9：Insert Adjust tube(K) to Slanting beam upper tube(F)，then Adjust the Adjust tube(K) to the
minimum.
Hardware Pack 3
Label Description Part# Qty Image
FF ￠6*230 H070010005 16 PCS

7/ 8
Country of Origin: China
Fig.10：Put small canopy（R）on small top frame. Fix small canopy four corner to adjustable tube，
then adjust the tube to right position until small canopy tight.
Fig.11: Fix big canopy four corner then Attach Finial(P) to the top.
Fig.12：by using stake“7”(FF) fix assembled
gazebo on ground.

8/ 8
Country of Origin: China

 Oursteelcomponentsforgardenaccessoriesandfurniturearetreatedwithrustinhibitingpaintthatprotectsit
fromrusting.However,duetothenatureofsteel,surfaceoxidation(rusting)willoccuroncetheseprotective
coatingsarescratched.Thisisnotadefectandthusnotcoveredbythewarranty.
 Tominimizethiscondition,werecommendcarewhenassembling&handlingtheproducttopreventscratching
thepaint.Shouldanyscratchingordamageoccur,werecommendimmediatetouch‐upwithrustinhibitingpaint.
 Surfacerustcanalsobeeasilyremovedwithaverylightapplicationofcommoncookingoil.Ifsurfaceoxidation
(rusting)occursandifnomeasureistakentopreventthis,theoxidationmaystartdrippingontodeckorpatioand
causeddamagingstains,whichmaybedifficulttoremove.Thiscanbepreventediftheabove‐mentioned
measuresaretakentokeeptheproductfromoxidizing.
 Usedampclothtowipeoffthestainsasquicklyaspossible.
 Ifnecessary,washwithamildsolutionofsoapandwater;rinsethoroughlyanddrycompletely.
 Periodicallycheckandensurethatallboltsarewell‐tightenduringuse
Sunjoy Group warrants to the original purchaser that this item is free from defects in workmanship and materials for a
period of 6 months from the date of purchase, provided the item was factory-sealed at the time of purchase and is
maintained with care and used only for personal, residential purposes. Should any manufacturing defect arise within this
warranty period, Sunjoy Group will replace (at our option) any defective merchandise or parts upon proof of purchase;
however, transportation and delivery costs, as well as payments to a third party for assembly or disassembly of the item,
remain the responsibility of the purchaser. A purchaser of an "open box," previously-returned, or "clearance" item, as
well as original purchasers outside of the warranty period, may obtain replacement parts from Sunjoy Group for products
in current production, at nominal cost.
Items used for commercial, contract, or other non-residential purposes, or items damaged due to acts of nature,
vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of hardware is not covered. Proof of
purchase (dated register receipt) is required for warranty claims. Warranty is to the original purchaser and is
non-transferable. Any replacement of warranted items will be in the original style and color, or a similar style and
color if the original is unavailable or has been discontinued. As some states do not allow exclusions or limitations on an
implied warranty, the above exclusions and limitations may not apply. This warranty gives you specific rights, and you
may also have other rights, which vary from state to state.
Care and Maintenance
Limited Manufacturer’s Warranty
Exclusions:
