SUNN 300T

p/n 021-3302-000 (120V)

SERVICE MANUAL

CONTENTS:

Notices

Specifications

Circuit description

Parts lists:

PCB assembly

Chassis assembly

Cabinet assembly

End item

Footswitch assembly

Footswitch PCB

Schematics

Service diagrams

sunnis a registered trademark of

Fender Musical Instruments Corp. 7975 North Hayden Road Scottsdale, AZ 85258

SUNN 300T

(This is the model name for warranty claims)

JULY 1998

IMPORTANT NOTICE:

The information contained herein is CONFIDENTIAL and PROPRIETARY to Fender Musical Instruments Co. It is

disclosed solely for use by qualified technicians for purposes of equipment maintenance and service. It is not to be

disclosed to others without the expressed permission of Fender Musical Instruments Co. All specifications subject to

change without notice.

For warranty repair service, only Fender specified part numbers are to be used. It is recommended they also be used

for post-warranty maintenance and repair.

Parts marked with an asterisk (*) indicate the required use of that specific part. This is necessary for RELIABILITY and

SAFETY requirements. DO NOT USE A SUBSTITUTE!

A coded naming convention is used in the description of certain parts. The codes and what they mean are as follows:

CAPACITOR CODES HARDWARE CODES

CAP AE = Aluminum Electrolytic BLX = Black Oxide

CAP CA = Ceramic Axial CR = Chrome Plated

CAP CD = Ceramic Disk HWH = Hex Washer Head

CAP MPF = Metalized Polyester Film M = Machine Screw

CAP MY = Mylar NI = Nickel Plated

CAP PFF = Polyester Film/Foil OHP = Oval Head Phillips

PB = Particle Board

RESISTOR CODES PHP = Pan Head Phillips

PHPS = Pan Head Phillips Sems

RES CC = Carbon Comp SMA = Sheet Metal "A" Point

RES CF = Carbon Film SMB = Sheet Metal "B" Point

RES FP = Flame Proof SS = Stainless Steel

RES MF = Metal Film TF = Thread Forming

RES WW = Wire Wound ZI = Zinc Plated

SPECIFICATIONS

Product Release No.: PR 347 (This is not a model number)

Part Number: 120V Version : 21-3302

240V Aust : 21-3332

230V UK : 21-3342

230V : 21-3362

100V : 21-3372

Power Requirements: All Versions : 900W

Preamp Section

Input impedance: 470 kΩ

Full power sensitivity: 12 mV

Tone controls: Treble: +/- 15 dB @ 6kHz

Bass: +/- 15 dB @ 40Hz

Graphic equalizer: +/- 12 dB @ 31.5Hz, 63Hz, 125Hz, 250Hz, 500Hz, 1kHz, 2kHz,

4kHz, 8kHz, 16kHz

Mid notch: -20 dB @ 700Hz

Low boost: +10 dB @ 40Hz

High boost: +10 dB @ 6kHz

Compressor

Crossover: 400Hz

Ratio: 1:1 min to 4:1 max

Line out level: +6 dB referenced to input (pre), 0 dBV (post)

(Transformer balanced)

Power amplifier section

Input impedance: 20 kΩ

Power output: 300 Watts RMS into 2, 4, 0r 8Ω@ <3% THD

Sensitivity: 1V RMS (0dBV)

Speaker Complement: Designed for use with the Sunn 410H or Sunn 215 Bass

Loudspeaker Enclosures

Dimensions: Height: 10.1" (25.7 cm)

Width: 25.5" (64.8 cm)

Depth: 15.6" (40 cm)

Weight: 75 lbs. (34 kg)

Product specifications are subject to change without notice

CIRCUIT DESCRIPTION

Preamp

The preamp section employs two 12AX7 tubes. Channel one (V1) is fairly conventional, while channel two (V2) uses a

second tube with additional op-amp gain (U2B) to provide a 60's style overdrive sound. The op-amp is used as

straight gain and is never allowed to become non-linear.

In typical operation, the drive channel and the clean channel are presented to the channel 1/2 mix control (R17) so that

a "blend" can be established. The channel select button (S9) on the front panel (or it's foot switch counterpart) selects

between this channel mix or channel one only. This selection employs JFETS Q1-Q4.

Signals are then presented to a second - order Sallen and Key filter set to F0 of 36.6 Hz and a Q of 2.1. This filter

provides about 6.5dB of boost at 41 Hz.

The signal path is routed to U17B where low-boost (S3) , mid-notch (S2), and high-boost (S4) equalization switches

can be used. These circuits are followed by conventional Baxendall low (R58) and high (R62) equalization. The

Baxendall circuit output is then sent to a graphic equalizer which can be selected by the footswitch or graphic EQ

button (S7) on the front panel. The far-right graphic EQ slider (R71) is a +/- 10dB trim for graphic EQ gain

compensation.

Next, the signal is presented to a second-order state-variable filter before being presented to the compressor circuit.

Said filter is set to 420 Hz. At the compressor, low-frequency compression ratio (R100) and high-frequency

compression ratio (R119) are adjustable to suit the user. Audio is presented to the "compressor EQ balance" (R102).

The compressor EQ balance controls the mix ratios of the compressor outputs. A compressor gain trim (R80) is

provided to compensate for the amount of amplification lost due to using the compressor. The compressor-gain trim

control is able to compensate for a compressed signal of up to 10dB.

The FETs Q5 and Q6 select between pre- and post-compressor via the front panel switch (S8) or footswitch. After

passing through op-amp U9B and master-gain control R107, the signal is sent to output jack J2, effects-loop send.

The signal input at J3, effects-loop return, goes to differential receiver U11A.

Heater voltage (24VDC for 2 series-connected 12AX7s in the preamp) is derived from the 32VDC supply (+/-

16VDC).. Excess voltage is dropped across across paralleled ballast resistors, R354-R356, on the preamp PCB.

CIRCUIT DESCRIPTION (CONT)

Output section

On the top side of the chassis, at the rear of each pair (total = 3) of output tubes, is an LED and a fuse. The LED glows green

when the associated pair of tubes is operating properly, and glows red if a tube failure has caused the related fuse to blow. If a

fuse blows, replace it only with one of the same type and rating. NEVER use a fuse with a higher current rating, as this could

damage the equipment and present a serious safety hazard. Next, replace the tubes in their respective locations, check and

adjust the bias and balance.

NOTE: it is normal for the LEDs to glow red when the amp is in standby mode.

Output tube bias adjustment instructions

1. Turn on the 300T and let it warm up for at least two minutes with the STANDBY switch in the ON position. Make sure the

amplifier is connected to a speaker or equivalent load.

2. Remove the bias controls cover box.

3. With a DVM set to it's most sensitive DC voltage scale, measure the voltage between the BIAS 100mV test points, and

adjust the BIAS control for a reading of .1 VDC (100mVDC)..

4. Next, connect the DVM to the BALANCE 0V test points, and adjust the BALANCE control for a reading of 0 VDC.

5. Replace the bias controls cover box.

NOTES:

1. For optimum sonic performance, set bias to 100 mVDC first, then set balance.

2. If the output tubes cannot be biased to at least 80 mVDC, replace the 6550C output tubes.

3. If the output tubes cannot be balanced, check the bias setting and/or replace the 6550C output tubes.

4. If the power tube trouble LEDs are glowing green, it does not indicate that the tubes are not worn or weak.

Tube layout:

PARTS LIST

NOTE: SHADED ITEMS ARE FOR REFERENCE ONLY

PRINTED CIRCUIT BOARD ASSEMBLY

QTY PART # DESCRIPTION REFERENCE DESIGNATION

4 054360 CAP AE AX 22uF 450V 20% 105C C162 C166 C170 C176

2 054361 CAP AE AX 47uF 450V 20% 105C C156 C159

4 033606 CAP AE RDL .47uF 50V 20% C102 C126 C127 C130

2 054355 CAP AE RDL 1000uF 50V 20% 105C C174-175

8 028463 CAP AE RDL 10uF 50V 20% C41 C78 C81 C85 C88 C113 C178-179

1 028458 CAP AE RDL 1uF 50V 20% C82

4 028459 CAP AE RDL 2.2uF 50V 20% C27 C109 C112 C120

36 028467 CAP AE RDL 22uF 50V 20% C16 C19-20 C31 C33-34 C36 C38-39

C45

C48 C51 C54 C57 C61 C64 C67 C70

C73-74 C80 C84 C86 C103 C107-108

C111 C115 C117 C124 C128 C144

C145 C147 C149-150

3 054356 CAP AE RDL 330uF 450V 20% 105C C171-173

4 028460 CAP AE RDL 4.7uF 50V 20% C2 C11 C12 C26

1 038699 CAP CA 100pF 100V 5% C37

2 039265 CAP CA 2200pF 100V 5% C79 C110

7 039259 CAP CA 220pF 100V 5% C8 C40 C104-106 C114 C116

5 038873 CAP CA 22pF 100V 5% C6 C15 C42 C59 C83

1 039261 CAP CA 330pF 100V 5% C142

2 038701 CAP CA 470pF 50V 5% C77 C163

2 039256 CAP CA 68pF 100V 5% C118 C119

25 034788 CAP CD .1uF 50V 20% .15" cut C4-5 C89-100 C121 C140-141 C146

C148

C151-155 C169

3 025995 CAP CD 8200pF 1000V 20% LL C167-168 C177

1 027256 CAP MPF .0015uF 100V 10% C30

3 027260 CAP MPF .0039uF 100V 10% C123 C125 C129

2 027264 CAP MPF .01uF 100V 10% C32 C35

1 024823 CAP MPF .01uF 400V 10% C18

11 027267 CAP MPF .022uF 100V 10% C23-25 C55-56 C58 C60 C62-63 C75-76

2 024835 CAP MPF .022uF 630V 10% C160-161

9 027272 CAP MPF .047uF 63V 10% C9-10 C87 C131-133 C138-139 C143

1 027275 CAP MPF .068uF 100V 10% C22

1 027277 CAP MPF .082uF 100V 10% C14

8 027280 CAP MPF .15uF 63V 10% C28-29 C46-47 C49-50 C52-53

2 024853 CAP MPF .1uF 250V 10% C157-158

4 024854 CAP MPF .1uF 400V 10% C3 C7 C13 C17

6 027278 CAP MPF .1uF 63V 10% C1 C21 C101 C122 C134-135

1 027281 CAP MPF .22uF 63V 10% C137

PARTS LIST

PRINTED CIRCUIT BOARD ASSEMBLY (CONT)

QTY PART # DESCRIPTION REFERENCE DESIGNATION

2 027283 CAP MPF .33uF 63V 10% C43-44

1 027286 CAP MPF .47uF 63V 10% C136

6 030937 CAP PFF RDL .0027uF 50V 5% C65-66 C68-69 C71-72

2 054357 CAP PPF .001uF 2kV 10% C164-165

1 051679 CONTROL 10K5A 10K5C DET R102

11 050514 CONTROL SLIDER 30MM 50KW R71 R127-136

3 037600 CONTROL SNAPIN 100K B R80 R100 R119

1 047540 CONTROL SNAPIN 250K 15A R12

2 037597 CONTROL SNAPIN 250K 30A R31 R42

1 041510 CONTROL SNAPIN 25K B R107

2 051681 CONTROL SNAPIN 25K DET 2B R58 R62

1 051677 CONTROL SNAPIN RND 10KB 250KB R17

2 026133 CONTROL TRIM 25K LIN R335 R361

14 064089 DIODE 1N4003 LL CR75-78 CR80-87 CR101-102

17 026730 DIODE 1N4006 800V 1A CR62-64 CR72 CR88-95 CR97-100

CR103

53 006260 DIODE 1N4448 SIGNAL LL CR1-25 CR27 CR29-39 CR44-50 CR52

CR54-60 CR96

8 048361 DIODE 1N5407 800V 3A CR65-71 CR74

2 029690 DIODE HV 3KV 200mA CR73 CR79

32 025802 FSTN TAB MALE .250x.032 PCB MT CP1-12 CP14-15 CP17-28 CP32-34

CP36-38

2 026000 FSTN TAB MALE PCB MT .187X.032 CP13 CP16

4 031041 FSTN TAB ML RTANG PCB .25x.032 CP29-31 CP35

6 051094 FUSE CLIP PCB 5MM (EXPT) XF1 XF2 XF3

2 013112 FUSE TD 20mmx5mm 250v 1A F1-2

1 013109 FUSE TD 20mmx5mm 250v 250mAT F3

3 033379 CABLE RIBBON 3 CKT 10" P9A P11A P12A

3 049334 CABLE RIBBON 3 CKT 20" P6A P7A P10A

6 027410 HDR .1 CTR 3 CKT SQ PIN P6B P7B P9B P10B P11B P12B

1 051655 CABLE 6 CKT 14" P5A

2 053856 CABLE RIBBON 6 CKT 8" P3A P8A

3 027413 HDR .1 CTR 6 CKT SQ PIN P3B P5B P8B

1 048914 CABLE RIBBON 8 CKT 7" P4A

1 027416 HDR .1 CTR 8 CKT SQ PIN P4B

PARTS LIST

PRINTED CIRCUIT BOARD ASSEMBLY (CONT)

QTY PART # DESCRIPTION REFERENCE DESIGNATION

2 041808 HEADER 8 CKTx.1" LO P1B P2B

2 041825 HEADER 8 PIN VERT. P1A P2A

1 051680 IC AUDIO PROCESSOR SSM2120 U18

18 051198 IC DUAL OP AMP BA4560N SIP U1 U5-8 U11-16 U19-23 U26-27

6 016795 IC DUAL OP AMP TL072 U2-4 U9-10 U17

1 051856 IC QUAD 2-IN NAND GATE 4011 U25

1 013562 IC REGULATOR +15V MC7815CT U28

1 013564 IC REGULATOR -15V MC7915CT U29

1 041261 IC VOLT REF LM4040DIZ-10.0 U24

2 051006 JACK 1/4 PCB DUAL TIP MONO J1 J5

1 051007 JACK 1/4 PCB STEREO W/ SWITCH J7

1 051658 JACK MONO R/A J8

3 053450 JACK STEREO R/A J2-4

3 026481 JACK TIP J9-11

1 049892 JACK XLR MALE J6

3 031871 LED BI-COLOR 5mmx5mm LD6-8

5 028039 LED RED 5x5mm SLB-55VR3 LD2-5 LD9

1 033177 LED RED/GREEN 5x5mm BI-COLOR LD1

1 051411 SPACER LED .4x.1 TURQUOISE AT LD1

5 990470144 SPACER LED.7x.125 BLUE A6192-3 AT LD2-5 LD9

3 041527 SPACER RND NYL .680x.250x.147 AT LD6-8

4 025116 RES CF 1/2W 100K 5% LL R10 R16 R27 R39

5 026368 RES CF 1/2W 100ohm 5% LL R317-318 R354-356

1 048903 RES CF 1/2W 18k 5% LL R331

4 026493 RES CF 1/2W 2.7K 5% LL R234 R237 R241 R287

1 047436 RES CF 1/2W 270ohm 5% LL R357

1 027869 RES CF 1/2W 470ohm 5% LL R221

4 025941 RES CF 1/2W 560ohm 5% LL R258 R337 R342 R347

4 024967 RES CF 1/4W 5% 1.2k LL R6 R14 R79 R150

2 024969 RES CF 1/4W 5% 1.5k LL R38 R50

2 025073 RES CF 1/4W 5% 1.5M LL R124 R189

15 024997 RES CF 1/4W 5% 100k LL R4 R29 R46 R75 R113 R181 R204 R226

R271 R273-275 R289-290 R307

PARTS LIST

PRINTED CIRCUIT BOARD ASSEMBLY (CONT)

QTY PART # DESCRIPTION REFERENCE DESIGNATION

68 024981 RES CF 1/4W 5% 10k LL R1 R5 R8 R15 R18 R20-21 R25 R28

R33 R36 R43-44 R48 R51 R56 R61

R63-64

R66-69 R76 R81-83 R87 R97 R99 R106

R108-109 R112 R114-116 R121 R125

R177 R184 R190 R193 R197 R200-201

R208-209 R212 R217 R228 R231-232

R243-245 R248 R253-254 R261 R266

R276

R285 R291 R298 R305 R308 R351

5 024937 RES CF 1/4W 5% 10ohm LL R178-180 R203 R296

1 024998 RES CF 1/4W 5% 120k LL R13

2 029539 RES CF 1/4W 5% 13k LL R53-54

5 024999 RES CF 1/4W 5% 150k LL R35 R91 R292 R319-320

4 024985 RES CF 1/4W 5% 15k LL R157 R163 R169 R175

4 024986 RES CF 1/4W 5% 18k LL R84 R86 R145 R151

8 024965 RES CF 1/4W 5% 1k LL R90 R94 R162 R174 R294-295 R297

R332

23 025069 RES CF 1/4W 5% 1M LL R2 R19 R26 R32 R37 R45 R49 R92-93

R110 R210 R215 R219 R224 R236

R246-247 R251-252 R264 R279 R282

R286

2 024971 RES CF 1/4W 5% 2.2k LL R170 R218

2 025075 RES CF 1/4W 5% 2.2M LL R225 R267

3 029455 RES CF 1/4W 5% 2.4k LL R98 R120 R146

3 025059 RES CF 1/4W 5% 220k LL R11 R207 R293

7 024956 RES CF 1/4W 5% 220ohm LL R95-96 R122 R182-183 R195 R205

20 024987 RES CF 1/4W 5% 22k LL R23 R40 R72-73 R78 R103 R214 R222

R229 R233 R238 R240 R242 R249

R259

R265 R268-269 R277 R284

4 024988 RES CF 1/4W 5% 27k LL R239 R255-256 R304

1 029005 RES CF 1/4W 5% 2k LL R158

7 024973 RES CF 1/4W 5% 3.3k LL R34 R140 R144 R152 R160 R164 R172

2 026504 RES CF 1/4W 5% 3.6k LL R57 R59

2 024975 RES CF 1/4W 5% 3.9k LL R138 R154

5 028865 RES CF 1/4W 5% 30k LL R153 R159 R165 R171 R270

2 025061 RES CF 1/4W 5% 330k LL R24 R230

15 024989 RES CF 1/4W 5% 33k LL R60 R117 R137 R141 R147 R185 R191-

192 R198-199 R211 R227 R250 R278

R283

2 025063 RES CF 1/4W 5% 390k LL R333 R353

4 024991 RES CF 1/4W 5% 39k LL R88 R118 R186 R188

4 029610 RES CF 1/4W 5% 3k LL R148 R156 R168 R176

1 029472 RES CF 1/4W 5% 4.3k LL R166

8 024977 RES CF 1/4W 5% 4.7k LL R47 R52 R142 R216 R235 R339 R344

R349

1 025828 RES CF 1/4W 5% 430k LL R213

1 028956 RES CF 1/4W 5% 43k LL R223

PARTS LIST

PRINTED CIRCUIT BOARD ASSEMBLY (CONT)

QTY PART # DESCRIPTION REFERENCE DESIGNATION

4 025065 RES CF 1/4W 5% 470k LL R41 R77 R206 R358

7 024961 RES CF 1/4W 5% 470ohm LL R260 R272 R280-281 R338 R343 R348

9 024993 RES CF 1/4W 5% 47k LL R104-105 R202 R373-378

10 024947 RES CF 1/4W 5% 47ohm LL R7 R9 R65 R89 R126 R187 R257 R262-

263

R306

5 024978 RES CF 1/4W 5% 5.6k LL R3 R30 R70 R74 R85

2 024994 RES CF 1/4W 5% 56k LL R155 R167

1 028948 RES CF 1/4W 5% 6.2k LL R55

2 024979 RES CF 1/4W 5% 6.8k LL R194 R196

7 024995 RES CF 1/4W 5% 68k LL R101 R111 R123 R139 R143 R334

R369

2 025942 RES CF 1/4W 5% 7.5k LL R161 R173

1 024980 RES CF 1/4W 5% 8.2k LL R149

8 025068 RES CF 1/4W 5% 820k LL R288 R299-303 R321-322

2 027353 RES FILM 1W 100K LL 5% LL R326-327

1 027349 RES FILM 1W 10K 5% LL R359

2 041706 RES FILM 1W 470k 5% LL R313-314

6 027354 RES FILM 1W 5% 220k LL R336 R340-341 R345-346 R350

3 036470 RES MOX FP 1W 5% 10k LL R328 R379-380

2 054213 RES MOX 2W 100k 5% LL R311-312

1 053945 RES MOX 2W 150k 5% LL R329

2 031629 RES MOX 2W 1ohm 5% LL R365 R368

1 028021 RES MOX 2W 470ohm 5% LL R220

12 027628 RES MOX 2W 47ohm 5% LL R309-310 R324-325 R362-364 R366-

367

R371-372 R381

2 053947 RES MOX BT 18Kohm 5W 5% R316 R323

1 053948 RES MOX BT 39Kohms 5W 5% R360

2 031703 RES WW BT 10W 10% .22 ohm R330 R352

1 026483 RES WW BT 10W 10% 2.7k R370

1 053950 RES WW BT 18k 10W 10% R315

5 050817 SWITCH PB PC VERT MNT DPDT S2-4 S6 S9

1 049557 SWITCH PC MNT 2P3T S10

4 028091 SWITCH PUSH SLFLK SHORT STROKE S1 S5 S7-8

9 048451 BUTTON PUSH OFF WHITE AT S1-9

1 026411 THERMISTOR 2.5 OHM 8A C30-19 TH1

6 029343 TUBE SOCKET 8 PIN PCB MOUNT XV5-10

PARTS LIST

PRINTED CIRCUIT BOARD ASSEMBLY (CONT)

QTY PART # DESCRIPTION REFERENCE DESIGNATION

4 051442 SOCKET TUBE 9 PIN PCB MOUNT XV1-4

1 027325 XFMR LINE OUTPUT T1

10 041465 XSTR N-CH JFET J113 TO-92 Q1-9 Q15

5 016739 XSTR NPN 2N4401 TO-92 Q11-12 Q19-21

6 016742 XSTR PNP 2N4403 TO-92 Q10 Q13-14 Q16-18

3 031729 DIODE ZEN 1N5231B.5W 5.1V 5% CR42 CR51 CR53

1 029898 DIODE ZEN 1N5236B 7.5V 5% LL CR43

3 031635 DIODE ZEN 1N5240B 10V 5% CR40-41 CR61

2 031019 DIODE ZEN 1N5245B.5W 15V 5% LL CR26 CR28

1 054385 WIRE SET PCB SUNN 300T

2 025796 HEATSINK TO-220 AT U28-29

2 017746 WSHR SHLDR NYL 1/8x1/4 AT U28-29

2 017974 INSULATOR MICA TO-220 AT U28-29

2 027638 SCRW TF 4-40x3/8 HWHS ZI .1" HD AT U28-29

12 014171 SCRW M 4-40x3/8 PHP BLX AT XV5-10 TOP

16 039420 SCRW M 4-40x3/8 PHP SS SEMS AT XV5-10 BOTTOM, GEQ REAR PCB

12 040533 STANDOFF 4-40x.937 AT XV5-10

4 016747 STNDOFF RND AL 4-40x3/4x1/4 AT GEQ REAR PCB

PARTS LIST

CHASSIS ASSEMBLY

QTY PART # DESCRIPTION REFERENCE DESIGNATION

1053941 CHASSIS SUNN 300T

1053639 PCB ASSY SUNN 300T

1 050853 XFMR PWR 300W 120V DOMESTIC UNITS

1 053942 XFMR PWR 300W 100/230/240V EXPORT UNITS

1 050854 TRANSFORMER, OUTPUT

1 047213 CONNECTOR AC LINE MALE IEC

3 036703 FUSE HOLDER 5MM FINGER GRIP TUBES, EXPT. PWR (4 IN 230/240V)

1 036702 FUSE HOLDER 3AG FINGER GRIP 100,120V POWER

4 053893 TUBE SHIELD SUNN MODEL T @ PRE TUBES

3 013004 FUSE TD 20mmx5mm 250V 100mA SCREENS

1 028330 FUSE QA 1-1/4x1/4 250v 10A DOMESTIC POWER

1 020798 FUSE QA 20mmx5mm 250v 5A EXPORT POWER

8 025819 NUT KEPS 10-32 ZINC 4/XFMR

4 053479 NUT HEX 7/16 20X1/8 NI @ REAN JACKS

5 016352 NUT HEX 3/8-32x3/32 TK NI 1/4" JACKS

12 039370 RETAINER ANCHOR TUBE SPRING 6550's

12 053956 SPRING, EXTENSION 2.49x.15" 6550's

6 039364 WASHER EPDM TUBE CLAMP DAMPNER 6550's

6 039369 RETAINER TOP TUBE SPRING 6550's

1 053892 COVER BOX BIAS CONTROLS MODEL T RELEASE

11 024604 KNOB BLACK W/WHITE STAMP 1-10 @ CONTROLS

2 051155 SCRW SMB #4x3/8 PHP BLX AT NEUTRIK XLR

2 021568 SCRW M 6-32x3/16 PHP NI AT IMP SEL

23 031184 SCRW M6-32x1/4 PHPS BLX ITLW PCA/CHASSIS

4 014171 SCRW M 4-40x3/8 PHP BLX EQ PCB TO CHASSIS

1 038900 SCRW TF 6-32X1/4 PHP ZI AC GND

4 032806 SCRW TF 6-32x1/4 PHP BLX AT IEC, BIAS COVER

4 016747 STANDOFF 4-40X3/4" RND AL EQ PCB

4 054386 STANDOFF M/F 4-40x9/16 HEX AL EQ PCB

1 036570 SWITCH TOGGLE DPST W/NUTS POWER

1 051855 SWITCH ROCKER DPST W/ BEZEL STANDBY

1 022293 WSHR FLAT .473x.750 NI @ PWR SW

4 053480 WASHER FLAT .442 X.692 NI @ REAN JACKS

3 990430010 WASHER LCK INTL 3/8x.681x.032 IN & SPKR JACKS

PARTS LIST

CHASSIS ASSEMBLY (CONT)

QTY PART # DESCRIPTION REFERENCE DESIGNATION

5 031153 WSHR FLAT 3/8x.614 NI 1/4" JACKS

6 048489 TUBE 6550WA OUTPUT

3 013341 TUBE 7025/12AX7WA RUSSIAN MADE

1 023531 TUBE 12AT7 CHINESE

CAB ASSEMBLY

QTY PART # DESCRIPTION REFERENCE DESIGNATION

8 0029071000 CORNER NOTCHED NICKLE (FD)

4 0051049000 FOOT RUBBER 1.5 DIA

2 0032524000 INSERT HANDLE

4 0019279000 HANDLE CAP 2 HOLE NICKEL

2 0027846000 HANDLE 9.25" NO LOGO

16 0026571000 SCRW SMAB 8X5/8 THP NI @ CORNERS

4 0026625000 SCRW WOOD 8x1 FH

8 0031344000 SCREW SMA 10x3/4 OHP IN

0.03

0027648000 TAPE ALUM 6"x60YDS

1.56 0051343000 VINYL TOLEX 4227A

END ITEM

QTY PART # DESCRIPTION REFERENCE DESIGNATION

10053932000 CHASSIS ASSY SUNN 300T 120V

10053933000 CHASSIS ASSY SUNN 300T 240V AUST

10053934000 CHASSIS ASSY SUNN 300T 230V UK

10053935000 CHASSIS ASSY SUNN 300T 230V

10053936000 CHASSIS ASSY SUNN 300T 100V

10051392000 CAB ASSY SUNN 300T

1 0047248000 CORD PWR W/IEC CONN DOM DOMESTIC - 120V

1 0047250000 CORD PWR W/IEC CONN 240V AUST 240V AUST

1 0047249000 CORD PWR W/IEC CONN 230V UK 230V UK

1 0047251000 CORD PWR W/IEC CONN 230V 230V

1 0053997000 CORD PWR W/IEC CONN 100V 100V

1 0053895000 FOOTSWITCH 3 BUTTON SUNN BASS 1200S RELEASE

2 0051204000 FOAM TAPE 1/4" 1/16 3M4516 @ TOP OF FRONT GRILLE (PER FT.)

PARTS LIST

END ITEM (CONT)

QTY PART # DESCRIPTION REFERENCE DESIGNATION

1 0053564000 GRILLE FRONT SUNN 300T

1 0053598000 GRILLE REAR SUNN 300T

8 0069393000 NUT 6-32 HEX EXT LOCK @ NAMEPLATES

8 0036112000 SCRW SMAB 6x1-1/4 OHP BLX w/WS GRILLE MOUNTING

8 0036199000 SCRW M 8-32x1-3/16 OHP BLX CP CAB/CHASSIS

8 0017433000 SCRW M 6-32x3/8 PHP BLX @ NAMEPLATES

8 0029527000 WSHR FNSH 8-5/8 FLNGD BLX WX @ CAB/CHASSIS SCREWS

1 0051380000 PLATE SUNN LOGO

1 0054382000 PLATE SUNN 300T

PARTS LIST

FOOTSWITCH END ITEM

QTY PART # DESCRIPTION REFERENCE DESIGNATION

1053897 PCB ASSY FTSW 3 BTN SUNN BASS

1053896 PLATE FTSW 3 BTN SUNN BASS

1 028895 CABLE ASSY FTSW RT ANG 12'

1 028109 HSG END CUP LEFT FTSW

1 028143 HSG END CUP RIGHT FTSW

1 028141 HSG FTSW 3 BUTTON

1 031647 NUT HEX 12mmx1mm Nl

8 028684 SCRW SMB 6x3/8 PH PHS BLX

3 031899 WSHR NYL .485x.775x.150 TK

FOOTSWITCH PCB ASSEMBLY

QTY PART # DESCRIPTION REFERENCE DESIGNATION

1053898 PCB FAB FTSW 3 BTN SUNN BASS

2 000626 DIODE 1N4448 SIGNAL LL

1 031017 DIODE ZEN 1N5223B 2.7V 5%

2 027327 DIODE ZEN 1N5234B 6.2V

3 028039 LED RED 5x5MM SLB-55VR3

1 037036 JACK PHONE PCB MONO CA PREMIUM

3 041527 SPACER RND NYL .680x.250x.147

3 028714 SWITCH PUSH SPDT

Other manuals for 300T

Other Sunn Musical Instrument Amplifier manuals

Sunn

Sunn 1200s User manual

Sunn

Sunn 300T User manual

Sunn

Sunn T User manual

Sunn

Sunn T User manual

Sunn

Sunn 1200s User manual

Popular Musical Instrument Amplifier manuals by other brands

AMT

AMT StoneHead-50-4 user manual

Fender

Fender '63 Vibroverb owner's manual

Kuassa

Kuassa Amplifikation Vermilion user manual

Harley Benton

Harley Benton GPA-100 quick start guide

Cerwin-Vega

Cerwin-Vega CUM-3 user manual

acus

acus One Forstreet 10 quick start guide

Marshall Amplification

Marshall Amplification MG10KK owner's manual

Pyle Pro

Pyle Pro PPG860A owner's manual

Crate

Crate Professional BV-120H user guide

Laney

Laney BC30 user manual

Vox

Vox Pathfinder 15SMR instruction manual

Marshall Amplification

Marshall Amplification JVM205C brochure

Peavey

Peavey Wiggy operating manual

Fender

Fender Bassman 1200 operating instructions

ZT Club owner's manual

Ibanez

Ibanez IFS2X owner's manual

Crate

Crate GLX1200H user guide

Laboga

Laboga THE BEAST user guide
