SUNON 10 Series User manual

POWERFUL HVLS FAN
SERIES 10
Installation Manual

POWERFUL HVLS FAN SERIES 10 Installation Manual 1
Caution & Safety
WARNING - TO REDUCE THE RISK OF ELECTRIC SHOCK OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING：
1. Installation work and electrical wiring must be done by qualified person(s) in
accordance with all applicable codes and standards.
2. Do not damage existing wiring and other hidden utilities/devices when cutting or
drilling into a wall or ceiling.
3. Use this unit only in the manner intended by the manufacturer. If you have
questions, contact the manufacturer.
4. Mounting of the suspension system and replacement of parts of the safety
suspension system shall be performed by the manufacturer, its service agent, or
suitably qualified persons.
5. Do not operate any fan with a damaged cord or plug. Please contact manufacturer
and qualified technician for examination and/or repair.
6. Before servicing or cleaning unit, turn off all the power switches to prevent power
from being switched on accidentally. When the circuit breaker cannot be locked,
securely fasten a prominent warning device, such as a tag, to the service panel.
7. SUNON provides installation guide for mounting fans; however, it is the sole
responsibility of the building owner and installer to ensure the safety of the
mounting system, that the building structure is sound and that the installation
complies with all federal, state, and local codes.
8. While turning on power to the fan, please use it with caution. DO NOT connect the
fan to a damaged/dangerous power source. DO NOT attempt to resolve electrical
problems by yourself. Please SEND the fan back to authorized service center for
examination and/or repair. If there is any question with installation, please
contact customer service.
9. When service or replacement of a fan component requires the removal or
disconnection of a safety device, the safety device is to be reinstalled or
remounted as previously installed.
10. Do not bend the airfoils when installing, servicing, or cleaning the fan. Do not
insert foreign objects between rotating airfoils.
11. This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved.
12. SUNON Fans product warranty will not cover equipment damage or failure that is
caused by improper installation or use.
13. If unusual oscillating movement is observed, immediately stop using the ceiling
fan and contact the manufacturer, its service agent, or suitably qualified persons.
14. Powerful HVLS Fan controller is equipped with a memory function. After
disconnecting power, it still remembers the previous operation mode. Once
turning on power to the fan, it also keeps previous operation mode.
15. Please use this unit only the manners specified by the company. Please contact
customer service if you have questions.

POWERFUL HVLS FAN SERIES 10 Installation Manual 2
Thank you for purchasing SUNON products!
Please read this manual carefully before use, use the product accordingly and keep the
manual in safe place.
In order to protect your rights and interests, please make sure that the deals records
the purchase date, dealer’s name, etc. on the guarantee.

POWERFUL HVLS FAN SERIES 10 Installation Manual 3
Table of Contents
Page Introduction
4 Fan Outline
5 Product Specifications
6 Installation Precautions
7
zThe Placement & Clearance between fan and obstructions
7
zThe Placement & Clearance between fan and HVAC diffuser
Page Pre-Installation
8 Inside the box
9 Tools Required for Installation
9 Fan Diagram
10 Pre-Installation Checklist
Page Installation Overview
11 I-beam
Page Installing the Fan
12 Installation Method
16 Fan Connection
zWarning
zPower Requirements
zRecommended Wire Specification
17 J-BOX
zControl Mode
zInstallation Instructions
zJ-BOX Dimensions
18 Wiring Diagram
19 J-Box (Knob)
21 J-Box (MODBUS)/J-Box (RF)
23 RF Remote Control
Page Information
24 Troubleshooting
24 General Troubleshooting
25 Maintenance
26 Powerful HVLS Fan series 10 Model List
27 Warranty
28 Retailer's Stamp

POWERFUL HVLS FAN SERIES 10 Installation Manual 4
Introduction
Thanks for choosing our products, Powerful HVLS Fan is an efficient, economical and
stylish choice. It’s energy-saving, eco-friendly design brings excellent airflow to space.
We assure you this appliance will make your space cozier and occupant comfort in the
near future.
Fan Outline
D A B H1 H2
13 ft/4 m
1.5 ft
/450 mm
0.82 ft
/250 mm
3.3 ft
/1000 mm
0.6 ft
/184 mm
16 ft/5 m
18 ft/5.5 m
20 ft/6.1 m
24 ft/7.3 m

POWERFUL HVLS FAN SERIES 10 Installation Manual 5
Introduction
Product Specifications
Powerful HVLS Fan series 10- 13 ft (4 m)
Input Voltage
(V
AC
)
Input
Frequency
(Hz)
Maximum
Rated Power
(W)
Maximum
Rated Current
(A)
Maximum RPM
(RPM)
Noise
(dB(A))
220-240 50/60 825 6.3 115 50
Powerful HVLS Fan series 10- 16 ft (5 m)
Input Voltage
(V
AC
)
Input
Frequency
(Hz)
Maximum
Rated Power
(W)
Maximum
Rated Current
(A)
Maximum RPM
(RPM)
Noise
(dB(A))
220-240 50/60 1100 8.0 90 50
Powerful HVLS Fan series 10- 18 ft (5.5 m)
Input Voltage
(V
AC
)
Input
Frequency
(Hz)
Maximum
Rated Power
(W)
Maximum
Rated Current
(A)
Maximum RPM
(RPM)
Noise
(dB(A))
220-240 50/60 585 4.4 65 46
Powerful HVLS Fan series 10- 20 ft (6.1 m)
Input Voltage
(V
AC
)
Input
Frequency
(Hz)
Maximum
Rated Power
(W)
Maximum
Rated Current
(A)
Maximum RPM
(RPM)
Noise
(dB(A))
220-240 50/60 765 5.6 60 46
Powerful HVLS Fan series 10- 24 ft (7.3 m)
Input Voltage
(V
AC
)
Input
Frequency
(Hz)
Maximum
Rated Power
(W)
Maximum
Rated Current
(A)
Maximum RPM
(RPM)
Noise
(dB(A))
220-240 50/60 1050 8.3 50 46

POWERFUL HVLS FAN SERIES 10 Installation Manual 6
Introduction
Installation Precautions
1. This HVLS fan need a proper device which can support its weight such as aerial work
platform and at least two installation persons.
2. Please switch off all the power supply before installation to avoid the risk of electric
shock or lighting shock.
3. All wiring construction must comply with the national electrical codes, standards
and the local electrical law, then must be installed by professional technicians or
personnel.
4. An earth leakage circuit breaker (<30 mA) should be installed between the
appliance and the power switch.
5. The power switch must be fitted with a fuse (≥20 A).
6. The hanger must be securely mounted to the ceiling or beam
7. Do not damage electrical wiring and other hidden utilities/devices when
installation.
8. To avoid fire or other hazards, make sure that the wires are completely inside, no
any wire exposed outside the fan appearance or other parts.
9. Do not bend the airfoils when installing the fan.
10. The HVLS fan model covered by the installation instructions must comply with this
installation manual and all national/local electrical codes to avoid personal injury or
property damage.
11. Please ensure that this application is equipped with AC single phase 220-240 V,
50-60 Hz before installation.
12. All fan parts must be ≥2 ft (0.6 m) from all obstructions. The fan installation area
must be free of obstructions such as lights, cables, sprinklers, or other building
structure components.
13. The distance should be at least 3.3 ft (1 m) from the top of the winglet to the ceiling
and no obstructions in this area.
14. The fan must be installed so that it is at least 10ft (3.05m) above the finished floor.
15. Multiple fans must be spaced at a center-to-center distance that is no less than 3x
the fan diameter.
16. The fan should not be located near to air supply outlets or exhausting inlets of other
HVAC equipment. Air supply outlets/inlets can be configured to deliver air away
from the fan and outside the swept area of the fan.
17. If the fan is mounted at the same level or higher than an HVAC diffuser, the distance
between the center of the ceiling fan and HVAC equipment need to at least 1.5x the
measure of the fan's diameter. If the fan is mounted below an HVAC diffuser, the
distance between the center of the ceiling fan and HVAC equipment need to at least
2.5x the measure of the fan's diameter.
18. Pleases see the manufacturer’s requirements for the minimum clearance to
combustibles.
19. The fan inlet or other return air point that produces negative pressure should be
bigger than 1 times the diameter of the ceiling fan. This system will reduce the
airflow of the HVLS fan.
20. Proper systems orientation will provide an enhancement to the Indoor Air Quality
and occupant comfort. Please refer to the illustration below.

POWERFUL HVLS FAN SERIES 10 Installation Manual 7
The Placement & Clearance between fan and obstructions
A. The tip of airfoil need at least 2 ft (0.6 m) away from light or any equipment and
no obstacles.
B. The Ceiling fan need at least 10 ft (3.05 m) away from floor.
C. The tip of the airfoil need at least 3.3ft (1 m) away from beam / ceiling and no
obstacles.
D. Spacing between fans at least 3x diameter of the fans apart.
E. Space from wall at least 1.5x diameter away from the wall.
The Placement & Clearance between fan and HVAC diffuser
zThe HVLS fan position need to above the HVAC outlet
A: The distance between the
center of the ceiling fan
and HVAC equipment
need to at least 1.5x
diameter.
zThe HVLS fan position need to below the HVAC outlet
B: The distance between
the center of the ceiling
fan and HVAC
equipment need to at
least 2.5x diameter.

POWERFUL HVLS FAN SERIES 10 Installation Manual 8
Pre-Installation
Inside the box
Main Box
(with Motor)*1
Extension Tube Shield*2 Airfoil Strut*7 Safety Cable*1
Wire Rope Clamp*20 Turnbuckle*4 Beam Clamp Set*4
Main Fan Unit Winglet*7 Earth Wire*1 Retainer*7
Extension Tube Shield (M6 16L Bolt Kit) Winglet(M6 40L Bolt Kit)
J Box*1 Airfoil Strut (M10 Bolt Kit) Airfoil (M8 45L Bolt Kit)
Airfoil Box
Airfoil*7
Pre-Installation

POWERFUL HVLS FAN SERIES 10 Installation Manual 9
Pre-Installation
Tools Required for Installation
Mechanical Installation Electrical Installation
zStandard wrench/socket set
zStandard Allen wrench set
zHydraulic cutter
zGalvanized wire Ø6 mm (Trim the wire
length according to the situation)
zTorque wrench 50~450 kgf.cm (For
inspection purpose)
zElectronic level
zPhillips screwdriver
zFlat head screwdriver
zMultimeter
zPair if #14 to #24 AWG strippers
Fan Diagram

POWERFUL HVLS FAN SERIES 10 Installation Manual 10
Pre-Installation
Pre-Installation Checklist
Equipped with appropriate mounting kit for roof pitch.
The fan can only be mounted to the I-beam. DO NOT mount the fan
directly to a single stringer, truss shelf or light steel shelf. For installation
methods not included in this manual, please consult a structural engineer.
The mounting structure approved by structural engineers. The mounting
system must be able to withstand the torque generated by the fan.
Having been familiar with the functions of the safety cable.。
For the fan installation, the fan blades should be at least 10 ft (3.05 m)
above the ground. (Please refer to “The Placement & Clearance between
fan and obstructions ” Page 7)
For the fan installation, the distance between the blades and other
objects/building structure should be at least 2 ft (0.6 m). (Please refer to
“The Placement & Clearance between fan and obstructions ” Page 7)
The center-to-center distance between two fans should be at least 3 times
the diameter of the fans. (Please refer to “The Placement & Clearance
between fan and obstructions ” Page 7)
When installing the fan, make sure the fan is not affected by high winds
from HVAC systems or large garage doors. Please refer to “The Placement
& Clearance between fan and HVAC diffuser ” Page 7)
The yoke kit size should match the I-beam. (Please refer to “I-Beam” Page
11)
The power supply unit complies with the specification of the frequency
converter, and the wires pass through the fan installation position.
For power requirements, please refer to voltage sticker on the fan.
The airfoil should not be mix up with other airfoil boxes.

POWERFUL HVLS FAN SERIES 10 Installation Manual 11
Installation Overview
I-beam
The yoke to I-beam for this HVLS fan is attached in our product. The yoke only can be
used within the width of 135-375 mm (B) and thickness of 20 mm I-beam. Within the
thickness of 14 mm (t), the yoke only need to use 1 yoke washer. The thickness of
14-20 mm (t), the yoke need 2 washers. We do NOT suggest to install the HVLS Fan on
the fabricated I-beam, please consult with structural engineer to make sure your
building is approved for fan installation.
Secure the yoke to the I-beam with
attached M12x60L bolt kit.
*Recommended Tightening Torque：
42 N.m (420 Kgf.cm).

POWERFUL HVLS FAN SERIES 10 Installation Manual 12
Installing the Fan
Installation Method
1. Install the 7 sets of airfoil strut on
the motor, this step can be
completed on the ground.
*Recommended Tightening Torque：
24 N.m (240 Kgf.cm)
2-1 Slide the motor, main fan unit to
the side of yoke, hanger on the
yoke and securely fasten.
2-2 Ensure the nuts on the hanger is
tightened.
*Recommended Tightening Torque：
42 N.m (420 Kgf.cm)
3-1 Route safety cable and wrap it
around the I-beam.
3-2 The safety cable must be tighten
as picture shows, make sure the
U-shaped ring inside the wire
rope clamp is tighten to the short
side.
*Recommended Tightening Torque：
12 N.m (120 Kgf.cm)

POWERFUL HVLS FAN SERIES 10 Installation Manual 13
Installing the Fan
4-1 Secure the earth wire with the
shaft of motor.
4-2 Connect three motor wires (u、v、
w) and earth wire to J Box. For
waterproofing purpose, please
use the waterproof joint.
4-3 Secure the extension tube shield
with extension tube.
*Recommended Tightening Torque：
5 N.m (50 Kgf.cm)
5-1 Prepare 4 guy wires with Ø6mm
when installation (The
Technicians need to prepare and
tailor the guy wires according to
the situation).
5-2 Looking up from the bottom of
ceiling fan, the angle between
each wire and I-beam is
recommended to be
45-degrees.
5-3 The angle of the guy wires
should be 45 degrees angle from
horizontal surface.
6-1 Prepare and secure the beam
clamp tightly, you can finish this
process ahead on the ground to
speed up the efficiency.
6-2 The technician needs to prepare
the guy wire and tailor it
according to the situation.
*Recommended Tightening Torque：
12 N.m (120 Kgf.cm)

POWERFUL HVLS FAN SERIES 10 Installation Manual 14
Installing the Fan
7-1 Attach the beam clamps to the
I-beam and securely fasten to
the proper position based on
step 5.
7-2 Pass the guy wire through the
ring and secure with wire rope
clamp.
*Recommended Tightening Torque：
24 N.m (240 Kgf.cm)
8-1 Based on step 7, tighten the guy
wire with turnbuckle and wire
rope clamp as picture shows.
8-2 Adjust the turnbuckle to balance
the ceiling fan.
*Recommended Tightening Torque：
12 N.m (120 Kgf.cm)
9-1 Insert the winglet into the airfoil
then tighten up.
9-2 Please Process this step on the
ground.
*Recommended Tightening Torque：
5 N.m (50 Kgf.cm)

POWERFUL HVLS FAN SERIES 10 Installation Manual 15
Installing the Fan
10-1 Insert airfoil to airfoil strut.
10-2 Place retainer over the airfoil
and spans to the next airfoil.
*
Recommended Tightening Torque：
12 N.m (120 Kgf.cm)

POWERFUL HVLS FAN SERIES 10 Installation Manual 16
Installing the Fan
Fan Connection
Warning
zTo avoid the risk of electric shock, please make sure that the wiring is in good
electrical condition and all electricity supply should be disconnected. Above wiring
should be implemented by a qualified electrician.
zTo avoid the risk of electric shock, please make sure that all wires are insulated
properly before the fan is turn on.
zPowerful HVLS Fan warranty will not cover the equipment damage or failure caused
by improper installation.
zPowerful HVLS Fan installation should follow national electrical code and standard.
Power Requirements
This appliance connecting to AC single phase 220-240 V. Please see the voltage sticker
on this HVLS fan, avoid any voltage transform in case of danger/damage during
installation.
Airfoil Dimension Input Condition Rated Current
13 ft (4.0 m) 220-240 V~ 50/60 Hz 1Ø 6.3 amp
16 ft (5.0 m) 220-240 V~ 50/60 Hz 1Ø 8.0 amp
18 ft (5.5 m) 220-240 V~ 50/60 Hz 1Ø 4.4 amp
20 ft (6.1 m) 220-240 V~ 50/60 Hz 1Ø 5.6 amp
24 ft (7.3 m) 220-240 V~ 50/60 Hz 1Ø 8.3 amp
Recommended Wire Specification
The minimum specification for the motor wire is PVC covered, single PVC insulated wire
2.0mm2/ 4 core.
The minimum specification for the power wire is PVC covered, single PVC insulated wire
3.5mm2/ 3 core.

POWERFUL HVLS FAN SERIES 10 Installation Manual 17
Installing the Fan
J-BOX
Control Mode
J-Box (Knob) J-Box (MODBUS) J-Box (RF)
Installation Instructions
1. Install the j-box in a location where authorized personnel can operate it.
2. J-box should be installed in a safe area to avoid unintentional damage.
3. When installing the j-box, make sure that the opening direction of panel is to the
left, and do not interfere with the operation of the j box.
4. Ensure the body of the j-box is securely mounted at the selected location.
5. Before installing or repairing the j-box (and ceiling fan), ensure the breaker power
distribution is switch off.
6. Do not install the j-box outdoors or in a damp place which may be near water.
J-Box Dimensions

POWERFUL HVLS FAN SERIES 10 Installation Manual 18
Installing the Fan
Wiring Diagram
J-Box (Knob) J-Box (MODBUS) / J-Box (RF)
Notes 1：The length should not exceed 30M, so as to avoid poor performance.
Notes 2：The motor earth wire must be connected to the earth terminal on the J box to
avoid high frequency electrical noise from the building wiring.
Notes 3：Within the rated voltage of the J box, the J box is suitable for direct connection
with the input power supply, but is susceptible to rapid changes in the supply
voltage; abnormal input voltage may cause damage to the J box.
Power wire
must NOT be close to the motor wire (U,V,W), in order avoid electromagnetic
coupling which cause capacitance effect.
Notes 4: Driving HVLS fan, please connect RS-485 communication port with customer
devices for the MODBUS version. In addition, this wiring doesn't apply for
Remote Control version.

POWERFUL HVLS FAN SERIES 10 Installation Manual 19
Installing the Fan
J-Box (Knob)
Panel Description
A.Power Switch
Name Status Function
OFF Input Power OFF status
ON Input Power ON status
B.Rotation Direction
Name Status Function
REV Input Reverse
STOP Input Stop
FWD Input Forward
C.Speed Control
Name Status Function
MIN Input Speed down
MAX Input Speed up
